Medion PORTABLE DVD PLAYER User manual

PORTABLE DVD
PLAYER
PORTABLE DVD
PLAYER
Operating Instructions

IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3 Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the manufacturer's
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by the
manufacturer, or sold with the apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when unused for long periods
of time.
14. Refer all servicing to qualified service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has
been dropped.
15. To Reduce the Risk of Fire or Electric Shock, Do not Expose This Appliance To
Rain or Moisture.
16. The Shock Hazard Marking and Associated Graphical Symbol is provided on the
bottom panel of unit.
17. Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids, shall not be placed on the apparatus.
NOTE:
This battery pack (Sb11, SB11-X,) is just for SDV17, SDVX7, SDVX7-XXX series
use only.

Thank you for purchasing Portable DVD player. Please read this manual
carefully before operating and reserve it for future reference. It will be helpful
to you if you encounter any operational problem.
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE, DRIPPING OR SPLASHING AND THAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
DANGEROUS HIGH VOLTAGES ARE PRESENT
INSIDE THE ENCLOSURE. DO NOT OPEN THE CABINET.
REFER SERVICING TO QUALIFIED PERSONNEL ONLY.
ATTENTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
LASER:
Use of controls, adjustments or the performance of procedures
other than those specified may result in hazardous radiation
exposure.
To prevent direct exposure to laser beam, do not try to open the
enclosure.
Visible and invisible laser radiation when open and interlocks
defeated.
DO NOT STARE INTO BEAM
LASER
Type
Wave length
Output Power
Beam divergence
Semiconductor laser GaAIAs
650 nm/780nm
5mW
60degree
WARNING:
CLASS 1
LASER PRODUCT
This Digital Video Disc employs a Laser System.
To ensure proper use of this product, please read this owner s
manual carefully and retain for future reference. Should the
unit require maintenance, contact an authorized service
location - see service procedure.
player
Precautions
-1-

WARNING:
To reduce the risk of fire or electric shock, do not expose this
appliance to rain or moisture.
CAUTION:
Use of controls or adjustments or performance of procedures
those specified may result in hazardous radiation exposure.
CAUTION
RISK OF ELECTRIC SHOCK. DO NOT OPEN
To reduce the risk of electric shock, do not remove cover (or back).
No user serviceable parts inside. Refer servicing to qualified service personnel.
!
The lightning flash with arrowhead symbol, with in an equilateral
triangle, is intended to alert user to the presence of uninsulated
dangerous voltage within the product enclosure that may be
of sufficient magnitude to constitute a risk of electric shock to
persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating and
maintenance (servicing) instruction in the literature accompanying
the appliance.
CAUTION:
INVISIBLE LASER RADIATION WHEN OPEN AND
INTERLOCK FAILED OR DEFEATED.
AVOID DIRECT EXPOSURE TO LASER BEAM.
Precautions
-2-

MACROVISION: This product incorporates copyright protection technology
that is protected by U.S. patents and other intellectual
property rights. Use of this copyright protection technology
must be authorized by Macrovision, and is intended for
home and other limited viewing uses only unless otherwise
authorized by Macrovision. Reverse engineering or
disassembly is prohibited.
FCC NOTICE: This device complies with part 15 of the FCC Rules.
Operation is subject of the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause und sired operation.e
Manufactured under license from Dolby Laboratories.
"Dolby" and the double-D symbol are trademarks of Dolby
Laboratories.
DOLBY:
Precautions
-3-

Table Of Contents
INTRODUCTION
-4-
PRECAUTIONS FOR
BATTERY PACK
OPERATION ....................8
TYPES OF DISCS
PLAYABLE ON THIS
PLAYER........................... 9
USING THESE
OPERATING
INSTRUCTIONS.............
11
CHECKING THE
ACCESSORIES...............
12
PARTS AND
FUNCTIONS...................
15
CONNECTING THE
PLAYER TO OTHER
DEVICES........................
USING THE BATTERY... 27
Operation of the battery pack...............8
Storage...................................................
Service life and disposal ......................
Marks indicated on DVDs................9
Disc structure ................................. 22
Notes on using the remote control
unit...............................................
Replacing the battery....................
Remote control unit operating
range...........................................
Liquid crystal display....................
Main unit control section..............
Main unit left side..........................
Main unit right panel.....................
Main unit rear side........................18
How to stand.................................
Main unit bottom side...................
Remote control unit (frequently
used buttons)..............................
Remote control unit (other
buttons).......................................
Names of battery parts and
their functions............................
Connecting to a TV.......................
Connecting to a Dolby Digital/ DTS/
MPEG decoder or an amplifier
with built-in decoder................23
Connecting to a digital amplifier
that is not Dolby Digital/ DTS/
MPEG compatible......................
Connecting to active speaker
systems.......................................
Connecting earphone..................
Recharging the battery pack.......
Notes for recharging....................
Attaching the battery pack to
the player...........................................
AC power operation......................
Removing the battery pack
from the player..............................
8
8
10
13
14
15
15
16
17
18
18
19
20
21
22
24
25
26
27
28
28
PRECAUTIONS................. 1
TABLE OF CONTENTS.....4
CAUTIONS ON USING
THIS PLAYER.................. 6
BEFORE USING
REMOTE CONTROL
UNIT AND MAIN UNIT
PREPARATIONS............ 13
29
29
13

Table Of Contents
-5-
TURNING ON THE
POWER......................... 30
PLAYBACK
FUNCTIONS..................31
Loading ..... .....................................
Playing.............................................
If a menu screen appears...............
Stopping playback..........................
Pausing playback............................
Returning to the previous chapter
or track(DVDs, video CDs and
CDs)...............................................34
Moving to the next chapter or
track(DVDs, video CDs and
CDs)...............................................34
Removing the disc..........................
TURNING OFF THE
POWER......................... 35
ADVANCED
FUNCTIONS..................
CAUTIONS ON USING.. 48
TROUBLE SHOOTING.. 49
31
32
32
33
33
34
BASIC OPERATIONS
ADVANCED OPERATCONS
Viewing in slow motion DVDs and
video CDs....................................
Repeating DVDs, video CDs and
CDs...............................................
Selecting angle
(multi-angle)................................
Changing from AV OUT
to AV IN..........................................
Searching for a specific scene...
SYSTEM SETUP
TV SYSTEM..........................................
SCREEN SAVER..................................
TV TYPE...............................................
PASSWORD.........................................
RATING................................................
DEFAULT..............................................
LANGUAGE SETUP
OSD LANGUAGE................................
AUDIO LANGUAGE............................
SUBTITLE LANGUAGE.......................
MENU LANGUAGE..............................
AUDIO SETUP
AUDIO OUT..........................................
VIDEO SETUP
BRIGHTNESS......................................
CONTRAST..........................................
HUE......................................................
SATURATION.......................................
SETUP THE PLAYER
GENERAL STEPS OF SETUP..............
DIGITAL SETUP
DIGITAL SETUP...................................
36
36
36
36
36
37
38
39
39
40
41
41
41
42
42
43
43
44
45
46
45
46
47

-6-
Cautions on Using this Player
Do not move the player during playback
During playback, the disc spins at high speed, so do not lift or move the player.
Doing so may damage the disc.
Transporting the player
When transporting the player be sure to remove the disc and turn off the power,
then unplug the power cord .
Place of installation
Select a stable place near the TV or stereo system to which you are going to connect
the player.
Do not place the player on top of a TV or color monitor. Install the player away from
cassette decks or other devices which are easily affected by magnetic forces.
Do not place objects on top of the player
Do not place any objects on top of the player.
Turn off the power when not using the player
Special note regarding use of player in vehicles
We strongly advise against using the player while driving.
Most countries and states have laws which prohibit or severely restrict the
use of the player in vehicles while driving.
Do not leave the player or the battery pack in places where the temperature
is extremely low (about-10 or lower) or extremely high (about 60 or
higher), such as inside the passenger cabin or trunk in midsummer. Doing
so may warp the outer case or reduce the performance or quality of the
battery pack.
When carrying on planes
Heed the airline company's rules.
When carrying in hospitals
Heed the hospital's rules.
If the player is connected to your TV but not in use then switch the power off this will
prevent interference with your normal TV picture.
Noise problems may also be experienced if used near a radio.

Cautions on Using this Player
-7-
When using with car power cable in cars
Please turn on the engine and then connect with the car power cable for using.
Cleaning the player
Normally clean the player using a soft, dry cloth. For tough dirt, apply some neutral
detergent diluted in 5 to 6 parts water to a soft cloth, wring out thoroughly, wipe
off the dirt, then wipe the player with a dry cloth. Note that alcohol, thinner, benzene,
insecticides, etc., may cause the print or coating to peel off. Also avoid leaving
rubber or plastic products in contact with the player for long periods of time, as this
may damage the cabinet. When using chemically treated cloths, read the cloth's
instructions carefully. Always unplug the power cord from the power outlet before
cleaning the player.
To clean dirt off the liquid crystal display, wipe the display gently with a soft, dry
cloth(such as an eyeglass cleaning cloth). Note that leaving water droplets on the
display for long periods of time may result in discoloration or stains. For tough dirt,
use a commercially available liquid crystal display cleaner.
Copyrights
Unauthorized duplication, broadcast, public performance or rental of discs is
prohibited by law.

Precautions for Battery Pack Operation
Operation of the battery pack
Charge the battery pack fully before
using it for the first time.
When the surrounding temperature
is high, the battery pack may
sometimes be unusable due to
activation of protection circuitry.
When the portable DVD player is
powered from the battery pack and
if the player has not been operated
for about 10 minutes with the power
switched on, the player will turn off
automatically. (Auto power off)
The battery pack becomes hot after
use and the portable DVD player
also becomes hot during use. This
is not malfunction.
When the battery pack is not to be
used for a long period, be sure to
remove it from the portable DVD
player. If the battery pack is left
attached, continual flow of weak
current renders it overdischarged
and eventually unusable even when
you try to charge it later.
If the portable DVD player is switched
on while the battery pack is not fully
charged, the operation may
sometimes be unstable. Be sure to
charge the battery pack fully before
use.
The battery pack should be stored
under an surrounding temperature
between 15 and 25 . Avoid storing
it under extremely low temperatures,
in a place with high temperature and
high humidity or in a place subject to
Storage
soot, etc.
When the battery pack is stored for
a long period, at least once an year
it is recommended to discharge it
fully on the portable DVD player,
recharge it fully and store it again.
Service life and disposal
When the charging time or available
operation time becomes extremely
short, the battery may be reaching
the end of its life. The battery pack
can be used for about 300 cycles of
recharging and operations.
To dispose of a used battery pack,
wrap a piece of tape around the
terminal section and treat it in
compliance with your local
regulations.
-8-
Caution:
Danger of explosion if battery is
incorrectly replaced.
Replace only with the same or
equivalent type.
