Meelectronics Atlas User manual

THENEXTHEADPHONE

Please read this manual in its entirety and
visit meelec.com/manual for additional
information and troubleshooting
If you have any questions or issues
after reading the manual, please contact
MEElectronics customer service at
[email protected]
or [phone]
Congratulations, and thank you for choosing the
MEElectronics ATLAS Headphones
THENEXTHEADPHONE

Package Contents
How to Use
Listening to Music/Audio
Headset Use
Headset Use: Controlling Volume
Headset Use: Taking Phone Calls
Microphone and Remote Use
Care and Maintenance
Warranty
Troubleshooting
Specifications
1
2
3
4
5
6
7
8
9
11

Headset
Cable
User
Manual
Headphones
Protective
Case
Note: An online version of this manual is available at meelec.com
L

How to Use
Use the headset cable with smartphones.
left ear cup audio device
headphone
jack
headset
cable
Plug the 4-pin plug
into compatible
device
Plug the 3-pin plug
into the Atlas’s
headphone jack

Listening to Music/Audio
Connect the headset cable to the jack on the left ear cup, making
sure the plug is firmly seated. Orient the cable so that the
microphone is closer to the headphones.
Connect the other end of the cable to the headphone jack of your
audio device.
Adjust the volume on your device and on the headphone cable to a
comfortable level
1.
2.
3.
left ear cup audio device
headset
cable
headphone
jack

www.meelec.com 04
Microphone The opening for the microphone is located as shown.
For best results ensure microphone/remote unit is close
to your mouth with the opening facing you
Remote
button
Please see pages 5 and 6 for information on using the
remote button
Universal
volume
control
The + symbol indicates the maximum volume position.
If you don’t hear sound, please check the volume control
slider.
Headset Use
The included headset cable features an inline microphone, remote,
and universal volume control. The headset cable is compatible with
most smartphones and tablets.
For full compatibility and functionality, including controlling media playback,
please visit meelec.com/phone.
Maximum volume is located when the switch
is closest to the + on the remote.
maximum volume setting
universal volume control
microphone
remote button
+

05 brings musical enjoyment to everyone
Headset Use: Taking Phone Calls
Headset Use: Volume Control
Phone Mode
Incoming phone call
Phone call in progress
Button Press
Single press
Single press
Action
Answer phone call
End call
Functionality for iPhone
®
and most Android
™
phones:
Note: If you experience issues please make sure no other applications
are interfering with remote functionality
The MEElectronics volume control is a universal volume control that
will work with any device, and volume setting on your remote will
supersede device volume. If you are not hearing any sound, please
check the volume control position.
Volume is maximum when the switch is closest to the + on the
remote.
The microphone is directional and needs to be near your mouth to
operate properly. If your voice is not transmitted loudly and clearly,
adjust the location of the microphone so it is in front of your mouth. At
times, poor voice clarity can be a result of poor call connection quality,
in which case you should hang up and retry your call.

www.meelec.com 06
Microphone and Remote Use:
Controlling Media
Note: Different applications will behave differently, and this is not a
guarantee of functionality
Note: Modern iPhones (2011 and newer), as well as Android devices,
support multi-tasking and allow one program to have priority over others,
which can affect button functionality. If your remote button is not working,
try bringing the program you want the button to work with into focus
(active window).
Android device functionality:
Apple device functionality (iPhone, iPad
®
, iPod touch
®
):
Phone Mode
iPod, iPad, or
iPhone with
no incoming
call / active
call
Button Press
Single press
Quick double press
Quick triple press
Press and hold
Action
Play/pause music
Next track
Start track over or previous track
Activate voice control (iPod Touch 3G, 4G,
iPhone 3GS, 4); Activate Siri (iPod Touch
5G and newer, iPhone 4S and newer)
Phone Mode
No incoming
call/active call –
functionality depends on
the program
Button Press
Single press
Quick double press
Quick triple press
Action
Play/Pause
Next track
Varies with the application

07 brings musical enjoyment to everyone
Care and Maintenance
When not in use, store the Atlas in the included protective carrying
pouch.
If the device comes in contact with liquids, quickly wipe away. Do not
use the device until completely dried.
Note: Liquid submersion voids the warranty
To clean the headphones, wipe with a clean, soft cloth. Do not use
harsh cleaners on the headphones.

Warranty
The Atlas Headphones are covered by a 1 year manufacturer warranty
against manufacturing defects.
For issues with your product, contact [email protected].
Contact [email protected] for warranty claims from:
For international retailers or distributors and unauthorized resellers
(see authorized resellers at www.meelec.com/wheretobuy)
contact your retailer for warranty service.
Limitations:
Within the US or Canada from an authorized reseller
(see www.meelec.com/wheretobuy)
From www.meelec.com
From the MEElectronics store at Amazon.co.uk
•
•
•
This limited warranty does not cover failure of the product
resulting from misuse, abuse, accident, neglect, mishandling,
or wear from ordinary use or environmental deterioration.
Environmental deterioration includes exposure to moisture,
extreme heat or cold, and sun damage.
This limited warranty does not cover accessories.
This limited warranty does not cover consequential damage to
other components.
This limited warranty is null and void for altered products.
This limited warranty terminates if you sell or otherwise
transfer this product to another party.
•
•
•
•
•
•
•
www.meelec.com 08

Troubleshooting
Check that the cable is plugged into the headphones
completely and the other end is plugged completely
into an audio source, audio is playing, and the volume
is loud enough to hear
Make sure the volume control is not at the minimum
position; adjust both the volume on the device and
headset cable to a comfortable level
Check that the cable is plugged into the headphones
completely and the other end is plugged completely
into an audio source
If you are using the headset cable with a computer,
laptop, media player, or airplane and the sound
improves when you hold the mic button, the 4-pin
headset plug may not be compatible; see
meelec.com/phone for more details
Check the audio jack of your device for lint and debris
and wipe the plug of the headphone cable firmly with
a cloth or paper towel to remove any dirt or oil
Problem Solution
No sound
Poor audio
quality
09 brings musical enjoyment to everyone

Troubleshooting Continued
Make sure the microphone/remote unit on the cable
is closest to the headphones and the microphone is
close to your mouth
Check the compatibility of your phone at
meelec.com/phone
Try unplugging the headset cable and plugging it back
in to your phone
If you are using a computer, you may need an
adapter (Skype adapter on meelec.com) to separate
the microphone and audio signals
Make sure the microphone/remote unit on the cable
is closest to the headphones and L-shaped end is
plugged into the phone
Check the audio jack of your device for lint and debris
and wipe the plug of the headphone cable firmly with
a cloth or paper towel to remove any dirt or oil
Check the compatibility of your device at
meelec.com/phone; if the sound improves when you
press the remote button, the device requires an
adapter
Multitasking can prevent the button presses from
being recognized; make sure the application you want
to work with the remote is the active window
Problem Solution
During
phone calls
the person
on the other
end can’t
hear me
The
remote
button
doesn’t
work
www.meelec.com 10

Specifications
40 mm cobalt magnet dynamic driver
20 Hz to 20 KHz
32 ohms
113 dB @ 1KHz
3.5 mm gold plated, right angle
color matched 130 cm (51 in) cord
Driver:
Frequency response:
Impedance:
Sensitivity:
Connector:
Cable:
11
MEElectronics and its logo are registered trademarks of S2E, Inc.
All rights reserved.
iPod®, iPhone®, and iPad®are registered trademarks of Apple Inc.
Android™is a trademark of Google Inc.

THENEXTHEADPHONE
