Promate PX16 User manual

User Guide
PX16
Bluetooth™ Ultra-Mini Headset

The Promate PX16 is an ultra-small, lightweight headset ideal for people on the go.
Performance is insured with excellent sound quality and a single multi- function
button, while mobility is enhanced with a comfortable design weighing only 4
grams! Bluetooth™ 3.0 with EDR allows fast pairing, strong connections and
compatibility with most Bluetooth™ mobile phones. A unique headset for easy,
friendly everyday use.
Before using headset you must charge the battery and pair the headset with a
compatible phone.
The headset contains the following parts:
(1) Multifunction button
(2)Microphone
(3) Charger connector
(4) Earphone
(5) Ear hook
(6) Indicator light
Fully charge the battery for at least 3 hours before the first use. Use only the
supplied AC charger.
This device has an internal non-removable rechargeable battery. Do not attempt to
remove the battery from the device as you may damage the device
1. Connect the charger cable to the headset.
2. Connect the charger to an electrical outlet. The red indicator light will turn on
during charging. If charging does not start, disconnect the charger and plug it in
again. Charging the battery fully may take up to 2 hours in normal use.
Introduction
Getting started
Charging the battery

3. When the battery is fully charged, the red indicator light will
turn off and the blue indicator light will turn on. Disconnect the
charger from the electrical outlet and the headset. The fully
charged battery has power for up to 7-8 of talk-time and up to
100-180 hours of stand-by time. The talk and standby times will
vary with different mobile phones.
To switch on, press and hold the power key. There will be a beep tone, and the
blue LED will be illuminated. When the headset is connected to a paired phone
and is ready for use, the blue indicator light will flash slowly. To switch off, press
and hold the power key. There will be a tone and the blue indicator light will flash
twice before turning off.
Switching the headset On/Off
1. With the headphone off, press and hold the multifunction button for about 5
seconds, until the blue LED flashes quickly.
2. Activate the Bluetooth™ feature on the phone and set the phone to search for
Bluetooth™ devices.
3. Select the headset from the list of found devices (PX16).
4. Enter the pass code "1234" to pair and connect the headset to your phone. If
the pairing is successful, the blue LED will flash twice. For some phones you may
need to make the connection separately after pairing. See the user guide of your
phone for details. You only need to pair the headset with your phone once.
5. If pairing is successful, the headset will beep, and will appear in the phone
menu where you can view the currently paired Bluetooth™ devices.
Pairing the headset with a compatible phone

Disconnecting the headset from the phone
To disconnect the headset from your phone (for example, to connect the
phone to another Bluetooth™ device) see the following:
• Switch off the headset.
• Remove the headset from the list of paired devices in your mobile phone
• Move the headset more than 10 meters (30 feet) away from the phone to
"break" the Bluetooth™ connection. You do not need to delete the Bluetooth™
headset from your phone's Bluetooth™ device list if you only want to
temporarily disable the connection.
Reconnecting the paired headset with your phone
To reconnect the headset with your phone just switch on the headset and it
will automatically reconnect with your phone (depending on the phone
model).
Making / Receiving Calls
Place the headset over your ear. The headset is provided with an ear loop that
you can use for a better fit on your ear. To use the headset without the ear
loop, plug the headset into your ear and point the microphone toward your
mouth. To use the headset with the ear loop, clip the ear loop to the earpiece.
It can be rotated to fit either the left or right side.
Call administration
To make a call, use your phone in the normal way when the headset is
connected with your phone. Once the call is connected, simply press the
multifunction button once to transfer the active call to the headset.
If your phone supports redial, press and hold the multifunction key for 5
seconds when no call is in progress.

Battery Information
Your device is powered by a rechargeable battery. The full performance of a
new battery is achieved only after two or three complete charge and discharge
cycles. The battery can be charged and discharged hundreds of times, but it will
eventually wear out. Recharge your battery only with approved chargers
designated for this device. Unplug the charger from the electrical plug and the
device when not in use. Do not leave a fully charged battery connected to a
charger, since overcharging may shorten its lifetime. If left unused, a fully
Switching the call between phone and headset
To switch the call between the headset and a compatible phone, press and
hold the multifunction key, or use the respective function in your phone.
Using the headset with several phones
You can pair the headset with up to eight phones but connect it with only one
phone at a time.
The phone that was first paired with the headset is the default phone. If the
headset is switched on within 10 meters (30 feet) of several paired phones, the
headset tries to connect with the default phone.
If the headset cannot connect with the default phone. The headset tries to
connect with the last used phone. If the headset cannot connect with this
phone either, one of the other six paired phones can be connected with the
headset. To make the connection, see the user guide of your phone.
If your phone supports voice dialing, press and hold the multifunction key
when no call is in progress and proceed as described in the user guide of your
phone. When no call is in progress and proceed as described in the user guide
of your phone.
When you receive a call, the blue indicator light will flash quickly and you will
hear a ringing tone through the headset.
To answer the call, press the multifunction key briefly, or use the phone keys. If
the automatic answer function is on, the phone will automatically answer the
incoming call after one ring. To reject an incoming call, briefly press the multi-
function key twice, or use the phone keys.
To end a call, press the multifunction key once or use the phone keys.

charged battery will lose its charge over time. Never use any charger that is
damaged. Leaving the device in hot or cold places such as a closed car in
summer or winter conditions will reduce the capacity and lifetime of the
battery. Always try to keep the battery between 15°C and 25°C (59" F and 77"
F). A device with a hot or cold battery may not work temporarily, even when
the battery is fully charged. Battery performance is particularly limited in
temperatures below freezing.
Troubleshooting
If you cannot connect the headset with your phone:
• Ensure that the headset is charged, switched on, and paired with a Bluetooth™
mobile phone.
• Ensure that the Bluetooth™ function is activated on your phone.
• Check that the headset is within 10 meters (30 feet) from your phone and that
there are no obstacles between the headset and the phone such as walls or
other electronic devices.
Care & Maintance
Your device is a product of superior design and craftsmanship and should be
treated with care.
The suggestions below will help you protect your warranty coverage.
• Keep all accessories and enhancements out of reach of small children.
• Keep the device dry. Precipitation, humidity, and all types of liquids or
moisture can contain minerals that will corrode electronic circuits. If your
device does get wet, allow it to dry completely.
• Do not use or store the device in dusty and dirty areas. Its moving parts and
electronic components can be damaged.
Do not dispose of batteries in a fire as they may explode. Batteries may also
explode if damaged.
Dispose of batteries according to local regulations.
Please recycle when possible.
Do not dispose as household waste.

• Do not store the device in hot areas. High temperatures can shorten the life
time of electronic devices, damage batteries, and warp or melt certain plastics.
• Do not store the device in cold areas. When the device returns to its normal
temperature, moisture can form inside the device and damage electronic
circuit boards.
• Do not attempt to open the device.
• Do not drop, knock, or shake the device. Rough handling can break internal
circuit boards and fine mechanics.
• Do not use harsh chemicals, cleaning solvents, or strong detergents to clean
the device.
• Do not paint the device. Paint can clog the moving parts and prevent proper
operation.
All of the above suggestions apply equally to your device, battery, charger, or
any enhancement. If any device is not working properly, take it to the nearest
authorized service facility for maintenance.
