Melitta MEFB2B User manual

USE AND CARE GUIDE FOR
MODELS MEFB2B, MEFB2W
READ AND SAVE THESE INSTRUCTIONS
WARNING: A risk of fire and electrical shock exists in all
electrical appliances and may cause personal injury or death.
Please follow all safety instructions.
12-Cup
Digital Coffeemaker
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 1

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electric shock and injury
to persons, including the following:
•Read all instructions before using appliance.
•Do not touch hot surfaces. Use handle.
•Do not immerse cord, plug or coffeemaker unit in water or other
liquid. See instructions for cleaning.
•This appliance is not for use by children.
•Close supervision is necessary when any appliance is used
near children.
•Unplug from outlet when not in use. Unplug and allow to cool
before attaching or removing parts and before cleaning the
appliance.
•To disconnect, press ON/OFF button to turn unit OFF, then
remove plug from wall outlet.
•Do not let cord hang over edge of table or counter or touch hot
surfaces.
•Do not place on or near a hot gas or electric burner or in a
heated oven.
•Only use appliance as indicated in these instructions.
•Carafe must never be used on a range top. Use only the
designated carafe for your coffeemaker.
•Do not set a hot carafe on a wet or cold surface.
•Do not use a cracked carafe or a carafe having a loose or
weakened handle.
•Do not clean carafe with abrasive cleaners, steel wool pads or
other abrasive material.
•Scalding may occur if the lid is opened during the brewing
cycles.
•Allow filter basket to cool before removing it from coffeemaker.
•Do not pour liquid other than water and the cleaning solution
specified in this manual into the water. See instructions for
cleaning.
•Do not move entire unit when carafe contains hot liquid.
•Do not operate any damaged appliance. Do not operate with a
damaged cord or plug, or after the appliance malfunctions or
has been dropped or damaged in any manner. Return
appliance to the nearest authorized service center for
examination, repair, electrical or mechanical adjustment.
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 2

3
•Use attachments only if recommended by the manufacturer.
•Be certain lids are securely in place before operating appliance.
•Do not use outdoors or while standing in a damp area.
•Coffeemaker must be left to cool down for approximately
10 minutes before adding more water.
•WARNING: Do not remove bottom cover. No user serviceable
parts inside. Repair must be done by authorized service
personnel only.
SAVETHESE INSTRUCTIONS
CAUTION: A short power supply cord is provided to reduce the risk
of personal injury resulting from becoming entangled in or tripping
over a longer cord.Extension cords are available from local hardware
stores and may be used if care is exercised in their use. If an
extension cord is required, special care and caution is necessary.Also
the cord must be:(1) marked with an electrical rating of 125V., and at
least 13 A., 1625 W., and (2) the cord must be arranged so that it will
not drape over the countertop or tabletop where it can be pulled on by
children or tripped over accidentally.
POLARIZED PLUG:This appliance has a polarized plug, (one blade
is wider than the other). As a safety feature to reduce the risk of
electrical shock, this plug is intended to fit in a polarized outlet only
one way.If the plug does not fit fully in the outlet, reverse the plug.If it
still does not fit, contact a qualified electrician.Do not attempt to defeat
this safety feature.
ELECTRIC POWER: If the electric circuit is overloaded with other
appliances, your appliance may not operate properly. It should be
operated on a separate electrical circuit from other appliances.
This product is for household use only.
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 3

4
Your product may vary slightly from illustration.
a.
b.
d.
e.
g.
h.
f.
c.
a. Lid
MEFB2(W) # 30735
MEFB2(B) # 30736
b. Filter Basket
MEFB2(W) # 30731
MEFB2(B) # 30732
c. Water Chamber
d. Control Panel
e. Warming Plate
f. Cord Storage
g. Carafe with Lid
MEFB2(W) # 30733
MEFB2(B) # 30734
h. Water Level Window
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 4

5
Before UsingYour
Coffeemaker
CAUTION: PRESS OFF BUTTON. INDICATOR LIGHT WILL BE
OFF. UNPLUG FROM OUTLET.
Become familiar with parts of the unit.
Clean the carafe, carafe lid and removable filter basket. Fill the
coffeemaker with the maximum amount of water and turn the unit on.
Follow procedures for Brewing – Immediate Start (without coffee).
Unplug coffeemaker and discard the water. Wait 10 minutes to allow
heating elements to cool.Repeat the process once.
CAUTION: DO NOT IMMERSE CORD, PLUG, OR COFFEEMAKER
UNIT INWATER OR OTHER LIQUID.
CoffeeYield
A 5-ounce cup is the American industry standard and is used by
most coffeemaker manufacturers. Your favorite mug will
accommodate about 2 cups (or 10 oz.) of coffee. We do not
recommend preparing less than 4 cups (or 20 oz.) of coffee.
Setting The Clock
1. Plug coffeemaker into a 120V ~ 60 Hz outlet.Display will show
12:00, : will be flashing.
2. Press and hold the AUTO button.
3. Press the HOUR button once to advance the clock one hour
or press and hold the HOUR button for 2 seconds to advance
by hour increments. During the setting, the AM/PM on the
display will change automatically.
4. Press the MIN button following the same procedure to set the
minutes.
5. Release the AUTO button. Flashing of the : indicates the time
is set.
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 5

6
Brewing - Immediate Start
1. Push excess cord into cord storage in base of unit.
2. Make sure the unit is in the OFF position;the indicator light will
be off.
3. Markings on the water level window indicate the level of water
required to brew the desired number of cups. Remove the
snap-on lid by gently pulling up. Fill the carafe with cold tap
water. Snap the lid back into position.
NOTE: Brewing less than 4 cups is not recommended.
4.Lift up the hinged lid on the top of the unit and slowly pour
water into the water chamber opening behind the filter basket.
5. Insert a #4 cone paper filter into removable filter basket and
add coffee grounds. Use approximately 1 measuring spoon of
grounds for every cup of coffee. Close lid.
6. Make sure that the carafe with lid is properly seated on the
warming plate. Press the ON/OFF button twice.The indicator
light will turn on. (You do not have to set the clock before
making coffee, just press ON.)
7. If you wish to serve a cup of coffee before brew cycle is
complete, simply remove carafe from warming plate. Dripping
will automatically cease.Return carafe to position on warming
plate within 30 seconds; dripping will resume. If the carafe is
not returned to the warming plate, the coffee may overflow
from the filter basket.
NOTE: To keep coffee hot, return carafe to the warming plate
after serving. The warming plate will automatically keep ideal
serving temperature as long as the coffeemaker is on. Do not
let empty carafe remain on heated warming plate.
8. Press the ON/OFF button again to turn the unit OFF when not in
use. When the brewing cycle is over, the coffemaker will
automatically shut off after two hours.The indicator light will go off.
9. Unplug and allow to cool for 10 minutes between cycles.
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 6

7
Brewing - Programming
Delay Timer
1. Follow steps 1 – 5 in Brewing – Immediate Start.
2. Be sure clock is set for current time.
3. Make sure that the carafe with lid is properly seated on the
warming plate.
4. Press the AUTO button once and release. The display will
show 12 : 00.
5. Set the desired program start time by using the HOUR and
MIN button as previously described in Setting The Clock.
6. During the setting, the AM/PM on the display will change
automatically.
7. Press the AUTO button again to complete the programmed
start time setting.
8. After setting, press the AUTO button once to display the
programmed start time.Press the AUTO button again to return
to actual time.
9. Press the ON/OFF button once.The display will show PRO in
the top left of the display. The coffeemaker is now in the
programmed delayed mode.
10. If you wish to serve a cup of coffee during the brew cycle,
simply remove carafe from warming plate. Dripping will
automatically cease. Return carafe to position on warming
plate within 30 seconds; dripping will resume. If the carafe is
not returned to the warming plate, the coffee may overflow
from the filter basket.
NOTE: To keep coffee hot, return carafe to the warming plate
after serving. The warming plate will automatically keep ideal
serving temperature as long as the coffeemaker is on. Do not
let empty carafe remain on heated warming plate.
11. Press the power button to turn the unit OFF when not in use.
When the brewing cycle is over, the coffeemaker will
automatically shut off after two hours.The indicator light will go off.
12. Unplug and allow to cool for 10 minutes between cycles.
NOTE: The program must be reset after each programmed
use.
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 7

Helpful Hints for Brewing
•The markings on the water window reflect the quantity of fresh
water to be used.The quantity of brewed coffee is less because the
coffee grounds absorb water.
•Never use hot or carbonated water. This will damage the
appliance.
•Never pour milk, liquid coffee, tea, or other liquid, except water, into
the water chamber.
Care and Cleaning
1. Turn coffeemaker OFF.The indicator light will be off.
2. Unplug and allow to cool completely before cleaning.
3. Open hinged lid on top of unit and remove filter basket.
Discard coffee grounds and paper filter. Wash and dry all
removable parts. Replace basket by fitting notch in groove of
unit.
4. Clean inside of lid and the outside of the coffeemaker with a
damp cloth.
CAUTION: DO NOT IMMERSE CORD, PLUG OR COFFEE-
MAKER UNIT IN WATER OR OTHER LIQUID.
Descaling
We recommend you clean your coffeemaker once a month with a
solution of vinegar and water. Mineral deposits from tap water can
form a coating in the coffeemaker, causing slower brewing time
and possibly an off flavor in the coffee.
1. Pour 1⁄2cup vinegar into the carafe, and add cold water up to
the 4 cup mark. Pour into the water reservoir.
2. Place a clean paper filter in the filter basket and close.
8
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 8

IMPORTANT NOTICE
If any parts are missing or defective,
DO NOTreturn this product.
Please call our Customer Service Department for assistance.
800-233-9054 Monday - Friday 9:00 am - 5:00 pm CST
Thank You
3. Follow brewing instructions (without coffee.)
4.When the unit has finished brewing, turn coffeemaker OFF.
Carefully remove the carafe and place on a heat resistant
surface. Wait 15 minutes and pour the solution back into the
coffee maker.
5. Turn unit ON again. Allow solution to empty into carafe; turn
unit OFF. After dripping stops, discard solution.
6. Allow coffeemaker to cool 10 minutes. Rinse it out by brewing
a carafe full of cold water (without coffee).Repeat process and
discard filter.
7. Wash and dry all removable parts.
8. When coffeemaker has cooled, wipe exterior with a damp
cloth.
Any servicing requiring disassembly other than the above
cleaning must be performed by an authorized service center.
9
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 9

NOTES
10
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 10

11
LIMITED ONE-YEAR WARRANTY
Warranty Coverage: This product is warranted to be free from defects in
materials or workmanship for a period of one (1) year from the original pur-
chase date. This product warranty is extended only to the original con-
sumer purchaser of the product and is not transferable. For a period of
one (1) year from the date of original purchase of the product, our Repair
Center will, at its option, either (1) repair the product or (2) replace the
product with a reconditioned comparable model. These remedies are the
purchaser's exclusive remedies under this warranty.
Warranty Service: To obtain warranty service, you must call our warranty
service number at 1-800-233-9054 for return instructions on how to deliver
the product, in either the original packaging or packaging affording an
equal degree of protection to the Repair Center specified below. You must
enclose a copy of your sales receipt or other proof of purchase to demon-
strate eligibility for warranty coverage.
What Is Not Covered: This warranty does not cover damage resulting
from misuse, accident, commercial use, improper service or any other
damage caused by anything other than defects in material or workmanship
during ordinary consumer use. This warranty is invalid if the serial number
has been altered or removed from the product. This warranty is valid only
in the United States and Canada.
LIMITATION ON DAMAGES: THERE SHALL BE NO LIABILITY FOR ANY
INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR BREACH OF ANY
EXPRESS OR IMPLIED WARRANTY OR CONDITION ON THIS PROD-
UCT.
DURATION OF IMPLIED WARRANTIES: EXCEPT TO THE EXTENT
PROHIBITED BY APPLICABLE LAW, ALL IMPLIED WARRANTIES AND
CONDITIONS, INCLUDING, WITHOUT LIMITATION, IMPLIED WAR-
RANTIES AND CONDITIONS OF MERCHANTABILITY AND FITNESS
FOR A PARTICULAR PURPOSE OR USE ON THIS PRODUCT ARE LIM-
ITED IN DURATION TO THE DURATION OF THIS WARRANTY.
Some jurisdictions do not allow the exclusion or limitation of incidental or
consequential damages, or allow limitations on how long an implied war-
ranty lasts, so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights and you may have other rights
under the laws of your jurisdiction.
For more information on our products, visit our website: www.maxim-toastmaster.com.
To return the appliance, ship to:
ATTN: Repair Center
708 South Missouri Street
Macon, MO 63552 USA
To contact us, please write to, call, or email:
Consumer Relations Department
PO Box 7366
Columbia MO 65205-7366 USA
1-800-233-9054
E-mail:
[e-mail]
MEFB2B&MEFB2W_IB_29-12-04 12/29/04 2:57 PM Page 11
