Membrane Solutions MSB3 Installation instructions

MSB3 Air Purifier
Please retain owner's manual for future reference
Membrane Solutions®MSB3 Air Purifier
Operators and Maintenance Handbook

Table of Contents
Overview .................................................................................................................. 1
Getting Started........................................................................................................ 2
Introduction........................................................................................................ 2
Health and Safety.............................................................................................. 3
Operating Guidelines....................................................................................... 4
Installation Guide .................................................................................................. 5
System Contents................................................................................................ 5
Commissioning the system............................................................................ 6
Operating Guide..................................................................................................... 7
Power Button ..................................................................................................... 7
Fan Speed ............................................................................................................ 7
Lock ....................................................................................................................... 7
Sleeping Mode ................................................................................................... 8
Timer..................................................................................................................... 8
Light ...................................................................................................................... 8
Turbo Mode ........................................................................................................ 8
Filter Reset.......................................................................................................... 8
Filter Replacement........................................................................................... 9
Replacement Filter Part Number .............................................................10
Troubleshooting Guide ................................................................................11
Warranty...........................................................................................................13
Overview
Getting Started
•Introduction
•System features
•Membrane Solutions®contact details
•Health & Safety
•Warnings & Cautions
•Operating Guidelines
Installation Guide
•System Contents
•Start-up
•Turning on the Purifier
Operation Guide
•Operation Guide
•Mode Selection
•Filter Replacement
•Troubleshooting Guide
•Warranty
1

Getting Started
Introduction
Thank you for purchasing the Membrane Solutions®MSB3 Air Purifier,
that delivers clean and healthy air for you and your home or office. Please
contact us for the latest product information, including operator manuals,
videos, support materials, and where to purchase items.
The MSB3 is a durable piece of equipment,
with proper care it will last for many years.
This owner's handbook outlines the
installation, operation, and maintenance
requirements to sustain perfect product
performance.
The MSB3 features a High-Efficiency
Particulate Air Filter (HEPA) and Activated
Carbon Media, which captures particles with
a diameter greater than or equal to 0.3
microns.
Website: www.mspurelife.com
Customer Service: service@ mspurelife.com
Toll-Free Phone: [phone]
The MSB3 can filter out impurities and particles in the air; such as viruses,
mold, dust, allergens, pollen, bacteria, dust mites, cigarette smoke, pet
dander, off-odors and unhealthy vapors.
Health & Safety
Membrane Solutions®products are designed with safety in mind. However,
personnel using this device must be familiar with any potential dangers. All
safety information detailed in this handbook should be reviewed before
installing and operating this air purifier.
This product is not a toy; children must be supervised when using
the device. Keep packing materials out of children's reach.
The system has been designed for indoor use only. Install the air
purifier out of direct sunlight on a flat, level dry, and secure
surface with average ambient room temperature.
Do not touch the power plug AC adaptor with wet hands. Do not
use power adaptor if the unit is damaged or the product is not
working.
Do not use the device in a place with heavy moisture or smoke.
Please keep the device away from flammable gas appliances such
as heaters of fireplaces.
Clean the device and remove any dust from the power plug
regular. Unplug the unit when cleaning, do not use strong
corrosive detergents of chemicals as they may damage the
surface of the device.
Do not obstruct the air inlets or outlets on the device. Do Not
wash or reuse the composite filters –Replace with new filters.
Warnings! and Cautions! are provided; Failing to observe
these instructions could result in damage to the equipment,
associated parts, surroundings, or personal injury.
2
3

Operating Guidelines
The following table lists the operating parameters for this product.
Operating this product outside these specifications may cause system
performance issues and may even lead to personal injury and void any
warranty. Please contact Membrane Solutions®for further advice and
support.
Operating Parameters
Model
Membrane Solutions® MSB3
Rated Voltage
100~240 Volts AC
Rated Power
3.5 Watts
AC Adaptor Output
12VDC. Please only use the
provided power adaptor.
Dimensions
6.7 inches x 6.7 inches x 8.5 inches
(170 mm x 170 mm x 216 mm)
Operating weight
2.4 lb (1.1 kg)
Filter Element type
A single composite filter element
Temperature & Humidity
Operating: 32-104℉ (0-40℃) 20-90%
Storage: 14-140℉ (-10-60℃) 20-90%
Installation guide
System Contents
Your Membrane Solutions®MSB3 Air Purifier was carefully assembled,
packaged, and shipped complete with all the parts you should require.
Unsure about something? Is there a problem?
Please contact Membrane Solutions® via our service email
or toll-free number.
Website: www.mspurelife.com
Customer Service: service@ mspurelife.com
Toll-Free Phone: [phone]
4
5

Commissioning the system
Step 1
Before using the air purifier for the first
time, open the filter cover and remove the
composite filter. Make sure to remove any
packaging material from the filter element,
or the product will not function correctly.
Step 2
Plug the output of the power adaptor into the
port on the bottom of the air purifier.
Plug the power adaptor into an electrical
outlet, the power button will illuminate red
and beep.
The air purifier should now be in standby
mode.
Step 3
Push the power button once to turn the air
purifier on.
The air purifier should now be in operating
mode at the low fan speed setting.
Operating Guide
Control Panel
Power Button
When the power adaptor is first connected to
the purifier, the indicator light around the
power button will be red, indicating the air
purifier is in standby mode.
Press the power button once to turn on the air
purifier; the indicator light will now be blue;
the unit will operate in the default mode (low)
fan speed.
Operating Mode
Press the power button repeatedly to cycle
through the different speed settings.
1 –High Speed –Lighter blue indicator light
2 –Low speed –Darker blue indicator light
3 –Sleep mode (Low speed) - Blue indicator
light flashes 2 times then lights off
4 –OFF –Red indicator light
The corresponding fan speed indicator light
will display the current fan speed.
6
7

Filter Timer
The filter element lifespan is dependent on
how many hours the air purifier is utilized
and which mode of operation is used.
The system automatically monitors the fan
speed and operational hours, when the filter
lifespan reaches 100% the filter reset button
will flash red.
Filter Reset
Filter Replacement
Step 1
Press the power button until the indicator
light turns red, Unplug the power adaptor
from the powered outlet, and unplug the air
purifier.
Invert the air purifier on a soft surface (to
avoid scratching the case). Twist the filter
cover in the open direction and lift off the
filter cover, then remove the old filter.
Step 2
Clean out any accumulated dust, lint, or hair
inside the air purifier using a vacuum hose of
dry cloth.
DO NOT use water or liquids to clean the air
purifier.
Step 3
Remove any packing material from the new
filter element.
8
9
When the filter lifespan reaches 100%, the
filter reset button will flash red while the
unit is operating; Use a paperclip (straighten
out the end) or something similar (e.g.,
toothpick) to press the filter reset button for
3 seconds while in operation mode. The filter
reset button will flash red and beep 3 times,
indicating the filter life timer has been
successfully reset.
The actual lifespan of the filter may vary depending on the amount
of dust, smoke, humidity, and the concentration of other airborne
particles and vapors in the air.

Step 4
Slot the new filter into the base of the
purifier. Replace the filter cover and twist
in the closed direction to lock it in place.
Turn the purifier upright. Plug in the air
purifier and follow the Filter reset
instructions. (See Page 10)
Please contact our customer service for purchase options:
Website: www.mspurelife.com
Customer Service: servi[email protected]
Toll-Free Phone: [phone]
How to get Replacement Filter
www.mspurelife.com
Search: MSB3 filter
www.amazon.com
Search: MSB3 filter
Or search: B08FCLXMBP
www.ebay.com
Search: MSB3 filter
Troubleshooting Guide
Problem
Possible Solution
1
The air purifier
does not turn on or
respond to on/off
button
Confirm that unit is plugged into a
powered outlet.
Plug the air purifier power adaptor into a
different electrical outlet.
2
Airflow is
significantly
reduced
Make sure the filter is removed from the
packaging. (see page 9)
Press power button to increase fan speed.
Filter may be blocked, replace air filter.
3
Air Purifier makes
unusual noise
while the fan is on
Make sure the air purifier is being
operated on a hard, flat, even surface.
Air filter may be blocked, replace air filter.
The air purifier may be damaged. Contact
Membrane Solutions® customer support.
4
Unpleasant or
musty smell
coming from the
purifier
Do not use in a damp or wet environment,
if the filter becomes damp, replace filter
and move the air purifier to a dry area.
The carbon part of the filter may be
exhausted, replace air filter.
5
Poor air
purification quality
Press power button to increase fan speed.
Close doors and windows while using the
air purifier.
Make sure the air filter is removed from
its packaging. (see page 9)
Replace the filter.
10
11
The actual lifespan of the filter may vary depending on the amount
of dust, smoke, humidity, and the concentration of other airborne
particles and vapors in the air.

Troubleshooting Guide
Problem
Possible Solution
6
The red change filter
indicator light is
flashing
The change filter indicator light will
flash each time the filter needs to be
changed.
7
If your problem is not
listed
Please contact Membrane Solutions®
Customer Service
Warranty
Membrane Solutions®warrants to the customer that its residential air
purifiers will be free from defects in material and workmanship under
normal use and service for a period of 1 year. We will replace or repair
any part of the Membrane Solutions®air purifier that we find to be
defective in operation due to faulty materials or workmanship within one
year since the date of the original purchase. Used replaceable filter
cartridges are excluded.
General Conditions
Membrane Solutions®obligation to the customer under these warranties
shall be limited, at its option, to replacement or repair of items covered by
these warranties. Prior to return or repair of covered items, the customer
must obtain a return goods authorization number from Membrane
Solutions®and, at Membrane Solutions®option, return the item with
freight prepaid by the customer.
Damage to any part of this system because of misuse, misapplication,
negligence, alteration, accident, installation, or operation contrary to our
instructions, this warranty does not cover incompatibility with
accessories not installed by Membrane Solutions®, or damage caused by
freezing, flood, fire, or Acts of God. In all such cases, regular charges will
apply. This limited warranty does not include service to diagnose a
claimed malfunction in this unit. This warranty is void if the claimer is not
the original purchaser of the unit or if the unit is not operated under
normal operating conditions. We assume no warranty liability in
connection with this system other than that specified herein. This
warranty is in lieu of all other warranties, expressed or implied, including
warranties of fitness for a particular purpose. Membrane Solutions®
liability hereunder shall not exceed the cost of the product. Under no
circumstances will Membrane Solutions®be liable for any incidental or
consequential damages or for any other loss, damage or expense of any
kind, including loss of use, arising in connection with the installation or
use or inability to use the covered items. These warranties are governed
by the laws of the state of Washington, USA, and may change at any time
without notice.
12
13

Notes:
Who we are
•Membrane Solutions®is a purification brand from the United States,
specializing in creating a better, healthier you through improved
filtration and purification technologies.
•Back to nature, clean water, and fresh air. Membrane Solutions®
promotes the philosophy of a 'minimalist lifestyle' that is committed
to creating a simple, clean, and comfortable environment.
•Membrane Solutions® design product's to be both smart, easy to
operate, and practical in appearance and functionality.
•Membrane Solutions®products care for you, your family, our planet.
Contact Us
If you require technical assistance, please contact our friendly professional
support engineers, who will be pleased to assist you.
3320 W Valley HWY North Ste D108
Auburn WA 98001
Phone: [phone]
Email: [e-mail]
Website: www.mspurelife.com
14
15
