Capture Dry Process Pollutants at the Source
The Port-A-Cart™ helps to eliminate smoke, dust, powders and
other dry process pollutants before they adversly affect indoor
air quality and worker productivity.
Port-A-Cart is adaptable, efficient and easy
to maintain. Its many advantages can help:
• Meet OSHA air quality standards
• Avoid health and safety hazards that cause workers
to experience respiratory ailments
• Reduce make-up air requirements by cleaning and
re-circulating the air
• Cut maintenance costs by eliminating smoke and
dust before particles can settle on equipment and
work surfaces
Port-A-Cart incorporates the latest technological advances in
filtration design and is ideal for applications in which:
• Large pick-up hoods are impractical
• Dust and smoke-producing machinery are used intermittently
• An employee works at multiple stations
The Port-A-Cart’s parabolic (curved) hood and inlet flange make
the device most effective in capturing smoke and fumes at fur-
ther distances, compared to standard designs that allow con-
taminant bypass.
Clean Air
Dirty Air
Dirty Air
How Port-A-Cart Works
The Port-A-Cart functions in three easy steps:
• Contaminants enter the Port-A-Cart through the
unit-mounted hood and are conveyed through the swing
arm into the cartridge filter section
• As the cartridge filter loads with contaminants, the
optional, off-line reverse pulse cleaning system directs
compressed air through the filter, dislodging collected
particles. These particles then fall into the dust drawer
for storage and easy removal
• Clean air is re-circulated into the work area

Clean Airflow 1000 CFM (1700 m3/hr.)
Filter Area 190 ft2(17.7 m2)
Cabinet 48” D x 30” W x 34” H
Dimensions (1222mm x 749mm x 851mm)
Shipping Weight 400 lbs. (180 kg.)
Noise Level 70 dB(A)*at 5’ distance (1.5m)
Horsepower 1.5 HP
Electrical 115/208-230/1/60,
17/9.4-8.5 amps
Construction 14 ga. welded steel,
powder coated cabinet
*dB(A) sound levels are an average of measurements made in a laboratory
environment. Installed sound levels will vary depending on the measure-
ment location, operating conditions and installation.
3
Features and Benefits
• Complete self-contained unit, includes 6.5-foot arm with
parabolic hood, blower and filter cartridge for “plug and
go” operation
• Minihelic®gauge kit to indicate when filter requires cleaning
• Direct-drive backward inclined blower overcomes higher
static pressure to provide longer filter life and greater
reliability; no belts or pulleys to replace
• Removable filter door allows easy access to cartridge filter
• Nanofiber technology provides up to 99.999% filtration
efficiency on 0.5 µm dust particles
• Fire retardant cartridge for increased safety
• Compact design easily fits through a standard doorway
• Impregnated carbon after-filter for odor control
Options
• Off-line, reverse pulse cleaning system, factory or field
installed kit
• Bolt-on, 99.97% HEPA after filter
29.50" [749mm]
33.59" [853mm]
33.59" [853mm]
27.50" [699mm]
48.09" [1221mm]
8.00" [200mm] DIAMETER x 6 1/2' [2m] LG
SELF SUPPORTING SOURCE
CAPTURE SWING ARM
by
P ORT -A-C ART
Portable Cartridge
Air Cleaner
