Menlo Systems’ ber-based femtosecond laser sources integrate the latest
achievements in ber technology into easy-to-use products. Menlo Systems’
unique gure 9® mode locking technology results in reproducible and long-term
stable operation. The ELMO with its all-ber design guarantees excellent stabil-
ity and low-noise operation. As seed source for ber ampliers the oscillator is
maintenance free, user installed and ready to use at the press of a single button.
In short: An OEM laser engineered for 24/7 operation.
Femtosecond Fiber Seed Laser 1560 nm
ELMO
KEy SpEcificatiOnS
■Wavelength 1560 nm
■Output Power >1 mW
■Output Power up to 200 mW
in High Power Conguration
■Repetition Rate 50-100 MHz
appLicatiOnS
■Amplier Seeding
■THz Generation & THz Physics
■Ultrafast Spectroscopy
fEaturES
■High Stability
■Low Amplitude and Phase Noise
■All-PM Solution
■Single Mode-Lock State
■gure 9® Technology
■Laser Output in Less than 60 Seconds
after Pressing On-Button
OptiOnS
■HigH pOwEr
Including matched ber amplier
ELMA to boost average output power
up to 200 mW
■VariO
User-Dened Repetition Rate
Factory-set value selectable in the
50-100 MHz range
■MuLtiBrancH
Additional Seed Ports
Seeding of multiple ampliers with
optional subsequent frequency conver-
sion to cover multiple wavelengths
pErfOrMancE Data
Amplitude noise
< 1.5% rms (over 24h in temperature cycles
from 10-30 °C)
Reproducibility
Identical and consistent laser performance
Output power [a.u.]
0 1 2 9996 9997 9998 9999
On/off turns
1
Amplitude noise
< 1.5% rms (over 24h in temperature cycles from 10-30 °C)
0
10
20
30
40
0
20
40
60
80
100
120
140
0 5 10 15 20 25 30 35
Temperature [°C]
Output Power [mW]
Time [h]
140
120
100
80
60
40
20
0
Output power [mW ]
Time [h]
0 5 10 15 20 25 30 35
Temperature [°C]
40
30
20
10
0

ELMO
Femtosecond Fiber Seed Laser 1560 nm
Menlo Systems GmbH
T+49 89 189 166 0
[email protected]
Menlo Systems, Inc.
T+1 973 300 4490
[email protected]
Thorlabs, Inc.
T+1 973 579 7227
[email protected]
Please call for pricing. Specications are subject to change without notice. Custom modications are available, please inquire.
D-ELMO-En 05/02/16
SpEcificatiOnS ELMO ELMO HigH pOwEr
Center Wavelength 1560 nm ± 30 nm 1560 nm ± 30 nm
Average Power >1 mW >100 mW (up to 200mW)*
Pulse Energy >1.0 pJ >1.0 nJ
Pulse Width chirped <90 fs
Repetition Rate 100 MHz (50-100 MHz with VARIO)* 100 MHz (50-100 MHz with VARIO)*
Output Port ber-coupled, SC/APC ber-coupled, SC/APC
Dispersion Management dispersion can be factory set to achieve
short pulses after 1-10 m of additional ber
dispersion can be factory set to achieve
short pulses after 1-10 m of additional ber
2nd Fiber-Coupled Seed Port yes yes
2nd High Power Output Port n.a. available with MULTIBRANCH
Polarization linear, PM ber linear, PM ber
*Please inquire for your specic combinations of average power, pulse duration, repetition rate and external ber length.
rEquirEMEntS
Operating Voltage 12 VDC/2 A**C/2055 12 VDC/2 A**
Power Consumption 10 VA 20 VA
Operating Temperature 15 °C - 35 °C 15 °C - 35 °C
Laser Head Dimensions/Weight 195 x 95 x 28 mm³ / 0.7 kg 195 x 95 x 75 mm³ /2.9 kg
Warm-Up Time <60 s <60 s
OrDEring infOrMatiOn
Product Code ELMO ELMO HIGH POWER
** Power supply for 100/115/230 VAC can be provided as option.
www.menlosystems.com www.frequencycomb.com
Invisible laser radiation
avoid exposure to beam
Class 3B laser
