mensor WE200P3 Guide

M
FTARA
WE 200W
Max 200kg e= 0,1kg
Min 2kg T=-200kg
m [kg]
h [cm]
BMI [kg/m ]
2
stadiometer:
Max 200,0cm
Min 100,0cm
d=0,1cm
indicator for using particular mode:
- mass
- height
- BMI (body mass index)
backlit LCD
display
switching of
the measured
value
BMI range
(only in BMI mode)
- turn on,
turn off.
- tare
- remebering measured
value
- delete of remembering
value
obese III
obese I-II
overweight
normal
weight
underweight
severely
underweight
R
higher
resolution
1
mini USB port
power supply
12V/100mA
V5_05
ApplicaƟon
Medical scales equipped with electronic high meter are designed for weighing paents and meas-
uring their height. Measurements are made in a standing posion.
Fig.1 View of the front panel
Fig. 2 View of the leŌside front panel
Cerficate of approval type WE No. PL 06 003 issued by the Central
Office of Measures(the number of a nofied body: 1440).
Cerficate of Conformity No MD-220/1/2009 issued by the Polish
Research and Cerficaon Centre (Nofied Body number: 1434).
Medical personal scales with
electronic measuring system of height
MANUAL USER
06
1440 1434

m [kg]
h [cm]
BMI [kg/m ]
2
flashing index
TARA
adjustable
legs
spirit
level
wrong
posion
of spirit level
correct posion
2
wait
≈5s
correct
posion
of spirit level
connect to the
wall socket
230V
stabiliser feed 12V/100mA connect to
the scale
wrong posion
PreparaƟon of scale to work
Set the scale on a hard, level surface; put the scale horizontally using a spirit
level and feet regulators;
2. Turn on the power supply to the wall socket 230V, and plug of the cable into
the housing of the scale
3. Push movable strip of high meter in the lowest posion
4. Press the buon TARA and wait for the appearance of a big zero on the display
of the scale ( the plaorm scale should be unloaded at this me). Index flashing
!
Very
importend
unblocking of
adjustable legs
(aer adjustable
it is necessary blocking nuts)
1.

M
F
3
Measuring process
Appearance on the display of “small zeros” means you should wait unl the "big zero” (normal)
appeares` or press the buon " TARA ".
Tare device works in the whole range of scales, it reduces the weighing ranges of the scale.
Over loaded weight of greater mass than Max (given on the scale) is indicated by the following
informaon:
In the case of a zero absence on the display, it is necessary to turn offthe scale and again turn it
on. Pressing the buon M`` causes delete of remembering value of mass and the possibility of
the next weighing (indicator of mass measurement stops blinking or starts connually shining).
Switching mode (F key) without storing the measured value allows you to switch between the
measured weight and height.
The BMI can be read only aer memorizing mass and hight
Go on the plaorm scale and wait a few seconds unl indicaon is stable

lightly
push down
open beam

correct posion
m [kg]
h [cm]
BMI [kg/m ]
2
m [kg]
h [cm]
BMI [kg/m ]
2
wrong posion
6.
5.
Press the buon M for remembering of measuring value of mass
7. Press the buon F to change height meter mode
Put the beam of hight meter on the head of paent
indicator blinking
indicator is stable
or

TARA
F
F
4
M
9. Press the buon F to display BMI value (Body Mass Index)
≈3s
m [kg]
h [cm]
BMI [kg/m ]
2
obese III
obese I-II
overweight
normal
weight
underweight
severely
underweight
In this example BMI range is right mass of body
m [kg]
h [cm]
BMI [kg/m ]
2
Example value of hight in centimeters
8. Press the buon M for remember measuring of hight.
Paent can go down
10. Press the buon F to change meter mode.
11. Turn offthe scale
Press the buon TARA and hold for a few seconds
R
Higher resolution
IIf you need to accurately weigh the small increase in mass, eg determine the mass of food
consumed by a person press the R button and weigh your person before feeding and after
feeding.
Example of measure growth of small mass

5
AddiƟon to the instrucƟon of medical scales
1. The manufacturer is not liable for the consequences of using the scale, in circumstances not
provided for operaon, including the power supply parameters other than those listed below:
a. 60mA 12V DC min
b. Polarity
c. Female plug 2.1 mmx9mm
2. When you turn on the scale and the weight, moving parts (pan of the scale and its structural
components) can not touch any part of the fixed - not related to the pan (wall coverings, other
equipment or apparatus, etc.) This may prevent the inclusion of the scale or the wrong indicaon.
3. When you weighing on the baby scale, the child should be placed to prevent it from slipping from
the pan. A child can not remain on the pan without adult responsible for his safety.
4. When you weighing on the personal medical scale the paent should be in a safe and stable stand
with both feet on the pan.
5. In the scale of the weighng chair scale two feet of the paent should be based on the turnover
brackets.
6. The manufacturer shall not be liable for the consequences of non-checking and verificaon in
requiring period of me for parcular scales referred to the convenient regulaons:
a. Verificaon by the Main Measuring Office should be held before the expiry of three years
from 1 December of the year in which the inial assessment of compliance. Last two digits
of the year in which the inial assessment of compliance are placed on a scker on
hologram (along with the number of units cerfied - the office issuing the check measure
weight) glued next to the plate of the scale.
Legal basis Art 8k paragraph. 3 of the Act of 11 May 2001 Law on Measures (Dz. U of 2004
No. 243, poz.2441, 2005, No. 163, item. 1632, No. 180, 1494, from 2006 r.Nr 170 , pos.
1217, No. 249, item. 1834, 2007, No. 176, item. 1238, in 2008, No. 227, poz.1505, of 2009,
No. 18, item. 97).
b. The next test (re-legalizaon) should be carried out within 25 months from the first day of
the last re-verificaon. Next to the plate are glued (the re-verificaon) 2 with the hologram
scker: monthly (Roman) and annual (two Arabic numerals).
Legal basis: § 27 and 28 and Annex 6 of the Minister of Economy dated 7 January 2008. on
legal metrological control of measuring instruments (Journal of Laws of 2008, No. 5, item
29)..
7. Declaraon and informaon on electromagnec emissions (EMC). Scales are designed to work in
any premises, including dwellings. Scales do not have any radio transmiers, the minimum
electromagnec emissions in the range of 9 kHz to 3 GHz is a result of the scale measurement
system and praccally eliminates any effect on the devices in the immediate vicinity. In accordance
with BS EN 60601-1-2.
8. Declaraon and informaon according to the resistance of the scale on factors - noise. All of the
following distorons do not increase the scale of the errors above the limit values for the parcular
type. However there is not desirable, long-term work under boundary confounders.
a. Changes in the supply voltage:
The lower limit Vmin = V-15%;
The upper limit Vmax = V +10%;
b. Short-term decreases in voltage electricity
Decrease in amplitude = 100% for a half period;
Decrease in amplitude = 50% for 2 half periods;
c. Electrical glitches in electricity with a value of 1 kV.
d. Electrostac Discharge at least 10x at intervals of 10s:
Direct 6kV;
Indirect (by air), 8kV;
e. Electromagnec radiaon: Frequency range 26 MHz to 1 GHz;
Magnec field of 3V / m;
Modulaon 80% AM, 1 kHz sine wave.
In accordance with BS EN 45501

6
The use of weights in excess of the condions in accordance with BS EN 45501 may cause damage to the
weight or the wrong indicaon.
The manufacturer recommends to turn offmobile or other transmiers of electromagnec waves of radio
frequencies that are in close proximity (tens of cenmeters) from the elements of the scale.
1. Elements of scales should be cleaned using publicly available cleaning agents used in the health
sector, with the excepon of measures that may stain the white and light grey structure elements
of scales (e.g. iodine-containing compounds). In the absence of certainty, a try on the invisible
surface scale.
2. In case of doubt as to the accuracy of scale measurements should stop and report the problem to
the manufacturer or distributor.
3. The manufacturer is not liable for acons not agreed with him, such as processing, repairs,
inspecons.
The work with inside baƩery
In the scales there was used a unit of two lithium-ion baery with a charging circuit equipped with light
eming diode which is next to the power supply seat. This diode is signalling a level of charging There are
possible the following condions:
-LED isn’t light - supply is not connected or with connecng supply, baery is fully charged
-LED lights connuously - supply connected, the baery during charging
-LED is blinking (frequency of blinking - tens of seconds) - supply connected, charging is interrupted,
you must turn offthe supply of the scale and once more turn on the supply without turning on the
scale using buon TARE
During charging the power supply should be connected to the scale, and the scale should be turn off
(turning on
the scale may cause an error loading and the need to restart the charging cycle).
-the maximum me (from full discharge to full charge) 15 hours
-the minimum working me from full charge 30 hours
-the baery life is indicated by a sign of LOW BAT in the upper lecorner of the display (it appears
about 10 hours before the final discharge of the baery allowing further weighing).
-to charge the baery use stabilized power supply 12V/100mA 12V/250mA
-in electronic scales equipped with a rechargeable baery for increase baery life should be use as
oen as it is possible
During a long me brake of the work, baery shouldn’t be fully charged or completely discharged

7
Declaration of Conformity
Directive 93/42/EEC, medical equipment and automatic weighing instruments Directive 90/384/EEC
Department of Precision Mechanics
A.J. Lewandowscy
ul. Węglarska 50, 04-689 Warszawa
www.mensor.pl
I conclude that medical scales of our production, the following below mentioned
types meet European standards in the ISO / IEC 45501, and Council of Europe:
93/42/EEC for the first class of medical devices with measuring function and Directive
90/384/EEC for automatic weighing instruments.
Type of scale:
description designation PL designation DE serial number amount
scales for baby weighing WE15P2 PCE-PS-15 MBS
scales for baby weighing WE20P2 PCE-PS-20 MBS
personal medical scale for man WE150P1 PCE-PS-150 MPC
personal medical scale for man WE200P1 PCE-PS-200 MPC
medical chair scale WE150P3 K PCE-PS-150 MCS
personal scale with mechanical measuring syst. WE150P3 M PCE-PS-150 MM
personal scale with mechanical measuring syst WE200P3 M PCE-PS-200 MM
personal scale with electronic measuring system WE150P3 W PCE-PS-150 MA
personal scale with electronic measuring system WE200P3 W PCE-PS-200 MA
personal scale with the display on the pipe arm WE150P3 PCE-PS-150 MPS
personal scale with the display on the pipe arm WE200P3 PCE-PS-200 MPS
medical bad scale WE300P1 L PCE-PS-300MBW
bariatic scale WE200P4 PCE-PS-200 MSH
special scale for weighing patients in wheelchair WM150P1 50x90Z PCE-PS-150 MXL
We hereby declare that the above medical scales meet the requirements of Annex V and Annex I of Council
of the European Economic Community No. 93/42/EEC of 24 June 1993, implemented into Polish law of
Medical Devices Act of 20 April 2004 and the Decree of the Minister of Health of 3 November 2004 on the
basic requirements for medical devices for various purposes and the following harmonized standards: PN EN
45501, EN 61010-1, European Council Directive 73/23/EEC (Low Voltage Directive), PN 1041-2009, PN EN
ISO 14971 - 2009, ISO 13485, BS 60950-2000, PN EN 60065:2001, EN 55022:2000, PN EN 55013 + A: 1997
Conformity assessment according to Annex V of Directive 93/42/EEC was performed with the involvement of a
Notified Body No. 1434, and in / g directive 90/384/EEC Notified Body No. 1440th
Obtained Certificate of EC Type Approval No. PL 06 003 dated 21-04-2006 the Central Office of Measures.
Obtained Certificate of Conformity No. MD - 220/1/2009 date of application of the CE mark – 2009.
M a n a g e r
Warsaw 2009 dr inż. Janusz Lewandowski
06
1440 1434

Digital personal scale with electronical height meter WE200P3 W35X35
Functions and features of the
scale:
Determination of
BMI
Remebering last
result
Mini USB port
Backlit display
Weighing people
Measuring Growth
5 years warranty
on measuring
transmitter of mass
2 years warranty
Overview: Documents and download:
Digital personal scale with electronical height meter
WE200P3 W35X35 is equipped with backlight liquid crystal
display with figures 22mm height, adjustable legs. Scale
features: tare, remember the last result of weighing, and an
additional filter - this feature enables stable reading during of
weighing moving objects or ground vibrations. Pan of the
scale is covered by the grey rubber, which protects the
patient's legs from slipping.
In the case of connecting the scale to a computer via USB
we get 10 times higher resolution.
zmetrological certificate type WE
zmedical EC type-approval
certificate
zdeclaration of conformity CE
compliant
zregistration of medical devices
zWHQL Certified VCP driver for
USB v.2.08.02
Technical specification: Additional options:
Max
capacity 200kg
zLi-ion battery - up to 50h on
battery power to continuously work
zConnect to a computer by USB
(length of 1,8m)
zGenie program allowing
visualizations and registrations
indicated by the scale of USB port
(we execute additional
modifications to the programme) -
standard version for free
Min capacity 2kg
Tare range -200kg
Display resolution 20g / 100g
Time stability indications 1-2s
Mass 9,5kg Figure - Overall dimensions and
weight pan [cm]:
Working temperature +10°C - +40°C
Dimension of pan 35x35cm
Overall dimensions 35x49x117cm
Power supply stabilized adapter
12V/100mA
Resolution of height-meter 1mm
Range measuring system of
high 102 - 198cm
MENSOR Poland, 04-689 Warsaw, WĊglarska 50, tel/fax [phone], tel.[phone]
www.mensor.pl ; [email protected] [2010-07-01]
8
