Mercedes-Benz 2016 Sprinter User manual

Special Equipment Handbook
SPRINTER 2016
Descriptions of all Packages, Codes & Accessories
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
Publication Date 07/2015

Equipment Handbook
NOTE:
This handbook provides all principal
equipment codes available from the
factory. It is intended to serve as an active
aid during sales consultations.
It should assist in formulating key sales
arguments to customers.
The index pages list the equipment code
numbers and the code names in
alphabetical order
The description pages explain technical
features and their benefits in detail.
Pictures are included where possible.
The model overview pages outline all
available Sprinter variants with the
corresponding model designations.
Complete 2D-drawings are available at:
www.UpfitterPortal.com
UpfitterManagement Contact:
www.UpfitterPortal.com
DISCLAIMER:
Mercedes-Benz USA, LLC and Daimler
Vans USA, LLC reserve the right to make
changes to the form, features and
technology of its product. As a
consequence no rights may be derived
from statements, illustrations and
descriptions in this guide.
Illustrations may include accessories or
equipment which is not part of the
specification of the code to which they
relate.
Mercedes-Benz USA, LLC and Daimler
Vans USA, LLC reserve the right to modify
or append this document without prior
notification.
The specifications, descriptions,
information, and recommendations
contained in this publication are believed
to be accurate at time of publication.
Always consult with your authorized
Sprinter dealer!
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
2

Equipment Handbook
PACKAGE CODE DESCRIPTION:
Engine Packages:
4CE 4 Cylinder Engine/7-Speed Trans.
6CE 6 Cylinder Engine/5-Speed Trans.
Customer Packages:
C01 Driver Comfort Package
C02 Driver Efficience Package
C03 Active Safety Plus Package
C04 Active Safety Plus Package
w/Parktronic
C05 Premium Appearance Package
C06 Workspace Access Package
C07 Cargo Protection Package
C08 Cold Weather Package
C09 Rear Passenger Comfort Package
Fleet Pacakges:
F01 Swivel Seat Package (Fleet Only)
F02 Window Fleet Package (Fleet Only)
F03 Window Prep Package (Fleet Only)
F04 Wide Step Bumper Package
(Fleet Only)
F05 Rear Wall Deletion Cutaway
(Fleet Only)
F06 Interior Trim Package (Fleet Only)
F07 Window Prep Package II
(Fleet Only)
F08 Lowered Roof Cutaway Package
(Fleet Only)
F09 Shuttle Door Prep Package
(Fleet Only)
F10 Ambulance Prep Package –Cab
Chassis (Fleet Only)
F10 Ambulance Prep Package –Cargo
Van (Fleet Only)
Specialized Pacakges:
X01 Suspension Seating Package
X02 Partition with Sliding Door w/
Jump Seat
X03 Partition with Sliding Door No Jump
Seat
X04 Multi-function Wheel/Display
Package
X05 Front Bench Seat Package
X06 High Idle Fixed Package
X07 High Idle Variable Package
X08 Front Heating Package I
X09 Front Heating Package II
X11 High Performance Air Conditioning
Package
X12 Crew Van Heating Package
X13 Lighting Package
X14 Upfitter Prep Package
X15 Window and Mirror Package
X16 Parktronic Package
X17 Suspension Package I
X18 Suspension Package II
X19 Suspension Package III
X20 Suspension Package IV
X21 Heavy Duty Front Axle Package
X22 Trailer Hitch Package
X23 Floor Package
X24 Crew Cab Package
X25 Rear Window Package
X26 Spare Tire Deletion Package
X27 Additional Battery Package
X29 High Range 4x4 (V6 Model only)
X30 Low & High Range 4x4
(V6 Model only)
X31* Super Single Tires
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
3

Equipment Handbook
CODE DESCRIPTION:
A50 Front axle reinforced
AR2 Axle Ratio 1 : 3.923
AR3 Axle Ratio 1 : 4.182
AR4 Axle Ratio 1 : 4.364
BB9 Electronic Stability Program
(ESP9i)
BE2 Handbrake lever, folding
C33 Firmer rear springs
C36 Rear springs adapted for GVWR
110,140lbs*
C38 Rear Springs (Single)
C39 Rear Springs (Dual)
C40 Stabilizer Front Axle
C42 Stabilizer, rear axle, under frame
C43 Stabilizer, rear axle, reinforced
C45 Stabilizer, reinforced at front axle
C47 Shock Absorbers Reinforced
C72 Bumpers Front/Rear Primed
CE8 Raised Rear Body Mounts
CF2 Chassis for application A
CF3 Chassis for application B
CF4 Chassis for application C
CF5 Chassis for application D
CF6 Springs and dampers, front,
reinforced
CL1 Adjustable Steering Wheel
CL4 Multifunction Steering Wheel
w/trip computer
CL9 ECO power steering pump
CM9 Primed Sidewall Moldings
CT1 Rear Spring Vibration Absorbers
D03 High Roof
D05 Super High Roof
D06 Super High roof painted*
D13 Roof Rails
D22 Fixed sun roof (rear roof section)*
D50 Cargo Partition
D51 Cargo Partition w/ Fixed Window
D53 Cargo Partition w/ Sliding Window
D62 Cargo Partition Provisions
D64 Bulkhead with sliding door
D93 Omission Bulkhead
E07 Start Off Assist
E1N Becker Map Pilot Navigation
System
E28 Additional battery for retrofit
E30 Starter Battery Disconnect
E33 Battery Managment
E36 Cutoff relay for additional battery
E40 Trailer Hitch Prep Package
E46 12V Power outlet at driver seat
base
ED4 AGM battery, 12V 95A
ED5 Parametric special module (PSM)
ED8 PreinstallationParametric Special
Module (PSM)
EE8 Battery 12V 100 Amp
EK1 Body Builder Connector under
Driver Seat
EL8 Audio System Speakers, 5 Front
EL9 Audio System Speakers, 5 Front &
8 Rear
EN6 Audio 10
EN7 Audio 15
ER0 Radio Prep
ES0 Jump Start Terminal
ES2 12V Power outlet in load
compartment
EV6 Pre-Installation Becker Map Pilot
Navigation
EZ8 Parktronic System (PTS)
F28 Roof and rear wall deletion
F35 Window in cab rear wall
F46 Headlamp cleaning system
F49 Electronically Heated Windshield
F61 Interior rear view mirror
F66 Lockable glove compartment
F68 Heated and electrically adjustable
mirrors
FA1 Lowered cab roof
FF0 Coat hooks*
FF3 Cup holders in passenger
compartment
FF4 Storage compartment - Super High
Roof
FF5 Shelf above Windscreen
FF8 Storage Slot at Front u/Roof Liner
FI1 Remote Key Fob –315MHZ
FJ1 Hinged lid for storage
compartment
FK3 Chrome Trimmed Radiator Grille
FR7 Pre-wiring, rear view camera
FR8 Rear view camera
FS2 Exterior Mirror Extended (96")
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
4

Equipment Handbook
CODE DESCRIPTION:
FW1 Rear wall deletion –Chassis
cabFY1Security Alarm
FZ9 Two additional master keys
G40 5-Speed Automatic Transmission
G42 7G Tronic Automatic Transmission
H00 Warm/Cool air duct to rear
passenger compartment
H01 Heat Insulation rear compartment
H04 Heat Insulation front compartment
H08 Air conditioning rear, roof mounted
H12 Fuel-fireed pre-heater/booster
(17,000 BTU)
H13 Rear cabin heater and vents
H15 Heated front passenger seat
H16 Heated driver seat
H20 Windshield - Tinted
H21 Windshield with filter band
H22 Defroster –rear window
H72 Roof Fan - electric
H88 Rear heater - prep
HH0 Air conditioning system pre-
installation
HH2 Heater - Auxiliary Elect Hot Air
HH5 Part kit, A/C system
HH9 Air Conditioning - Front
HY1 Remote Control Aux Heater
HZ5 Heavy Duty Fuel-fired pre-heater /
booster (34,000 BTU)
HZ9 Fuel-fired heater booster(17,000
BTU)
J11 Speedometer km/miles
J51 Fuel Gauge,optimized for Aux. Fuel
Tap*
J58 Sealt belt reminder for driver
J65 Outside Temperature Gauge
J78 Sealing of Speedometer Drive
JA5 Light and Rain Sensor
JA6 Collision Prevention Assist
JA7 Blind Spot Monitoring
JA8 Crosswind Assist
JK3 Pixel matrix display
JP2 Driving Assistance Package
JW0 Alarm - Rear Backup
JW2 Deactivate Lamp Monitoring
Failure
JW5 Lane Keeping Assist
K60 Exhaust Straight to Rear
KB0 Fuel Tank - 26.4 gallon*
KB7 Fuel Tank - 24.5 gallon*
KL1 Aux Fuel Sending Unit w/ Fuel tap
KL5 Fuel Filter w/Water separator
KP1 Fuel Pump, electric
L16 Fog lamps
L49 LED Identification Lamps, Roof
Mounted
L63 Ceiling Lights in Rear
Compartment, LED
L65 Interior Light, Cargo/passenger
compartment
L71 Light/motion sensor in load
compartment
L72 Electrical Pre-installation for Load
Compartment Lighting
L76 Wire Harness Tail Lamp w/ext
Wiring
L77 Wiring for additional Turn Signals
L90 Tail Lamp Deletion
L94 Parking Lights Deletion
LA1 High Beam Assist
LB5 Third Brake Light
LB9 Illuminated Exit
LD0 Overhead control panel with 2
reading lights
LD4 Convenience lighting in passenger
compartment
LG0 Bi-xenon headlamps
LG6 Daytime Driving Lights
LV6 Third Brake Light Prep
LV7 Clearance Light Prep
M20 Speed Limitation 65mph*
M40 Alternator 14V/200A
M46 Alternator 14V/220A
M47 Alternator for fuel economy
M53 High idle preset
M60 Generator 14V/250A
MD3 Top-Speed Limitation to 74 mph
MG3 Engine 2.1L 4-Cylinder BlueTEC
Turbo Diesel
MG5 Engine - 3.0L Turbo Diesel BlueTec
MH5 SCR Emissions with 4.75 gal DEF
Tank as well as EPA14/CARB
MH7 Emission EPA 16/CARB*
MH8 SULEV Emissions
MS1 Cruise Control
MT4 High idle –driver adjustable
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
5

Equipment Handbook
CODE DESCRIPTION:
MV6 “V6” Badge on right rear cargo
door
MZ0 Blueefficiency Badge
N62 PTO at front w/ bracket for
additional Alternator
N63 Bracket for aux A/C Compressor
N81 Refrigerant Compressor (KMV)
P08 Cover for transport
P47 Front Mud Flaps
P48 Rear Mud Flaps
Q18 End Cross Member Bolted
Q24 Trailer Cross Member with capacity
of 5000 lbs
Q67 Tow Hook Rear
Q72 End Cross Member deleted
QA2 Trailer Cross Member with capacity
of 7500 lbs
R60 Spare Wheel Carrier Provision to
Frame
R65 Spare Tire Carrier –Under Frame
R87 Spare Tire - Steel
R91 Spare wheel deletion
R92 Spare tire carrier deletion
R98 Rims - Painted Jet Black
RF1 Tire Brand –CONTINENTAL
RF4 Tire Brand Firestone*
RH0 Tire Brand - KUMHO
RH7 Tires LT215/85 R16
RH8 Tires LT245/75 R16
RH9 Super Single tires rear285/65 R16
C*
RL5 Light alloy wheels
RM0 Tires, All Season
RM1 Tires, M&S Winter Tire
RM2 Wheels - Painted Artic White
RM9 Make of Tires as an Option
RS3 Wheel Steel 6.5 X 16
RS5 Stell wheels:8.5Jx16Rear;6.5Jx16
Front*
RS6 Wheel Steel 5.5 X 16
RY2 Tire Pressure Monitor Lamp
S04 Adjustable Front Passenger Seat
S20 Passenger seat foldable
S22 Seat Armrest - Driver Seat
S23 Twin front passenger seat*
S25 Seat Armrest - Passenger Seat
S62 Orange Seat Belt
S78 Assist handle for inner seat
S87 Driver seat frame, low
S88 Passenger seat frame, low
S99 Passenger Seat Pedestal & Airbag
deletion
SA5 Front Air Bag - Driver
SA6 Front Air Bag - Passenger
SB1 Comfort seat, driver
SB2 Comfort seat, passenger
SB3 Driver Suspension seat, comfort
version
SB4 Passenger Suspension seat,
comfort version
SB9 Driver Seats plus*
SC1 Backrest, folding w/table*
SD0 ISO Fix Child Seat
SD2 Seat belt mount deletion
SH6 Air Bag - Thorax Driver (Backrest)
SH7 Air Bag - Thorax Drv /Co-Drv
SH9 Air Bag - Window Drv /Co-Drv
SR8 Swivel base for driver seat
SR9 Swivel base for front passenger
seat
SW1 seat belt deletion, passenger*
SZ7 Storage Net, driver seat backrest
SZ8 Storage Net, passenger seat
backrest
T09 Sliding Door Ext Track
T12 Sliding door, two stage opening
T16 Sliding Door - Right Side
T19 Sliding Door - Left Side
T57 Electric Step, Right Sliding Door
T74 Assist handle, sliding door
T75 Door–mounted assist handles,
driver & passenger
T77 Assist handle w/ partition
T85 Assist handle, left rear door
T86 Assist handle, right rear door
T93 Sliding Door - Right Side delete
U62 Three Seater Bench in passenger
first row narrow
U74 Seat armrest, rear seats left
U75 Seat armrest, rear seats right
UC3 Rear Seats Second Row, three
seats, narrow
UD6 Rear Seats Third Row, four seats
V07 Rear wall liner –partition cab back
V21 Luxury interior trim
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
6

Equipment Handbook
CODE DESCRIPTION:
V25 Half Height Load Compartment
Trim
V31 Window Pillar trim
V35 Rear roof trim
V36 Rear trim
V39 Weight Optimized Plastic Floor
V40 Passenger seat anchors and floor
V42 Cargo lashing rails, waist line
V43 Cargo Van wood floor
V46 Rear floor covering, rubber
V64 Ashtrays - Rear
V85 Ashtrays - Front
V93 Wood Floor, delete
VA1 Side wall paneling waist height PVC
VA3 Side wall paneling, full hardboard
VA7 Storage compartment with net in
rear doors
VC4 Cargo lashing rails, upper
VC5 Door Sill Protective Edge
VU9 Leatherette Black
VV2 Load securing rail system
VY2 Black Tunja Upholstery
W02 Panel van w/windows all round
W16 Fixed window at front left sidewall
in left side sliding load
compartment door
W17 Fixed window at front right sidewall
in right side sliding load
compartment door
W22 Fixed window, center left
W23 Fixed window, center right
W27 Fixed window, rear left
W28 Fixed window, rear right
W33 Window - Left Side Front
Emergency Exit
W54 Rear Doors 270 Degree Opening
W61 Windows in tailgate/rear doors
W70 Black Tinted Windows in Rear
W73 Rear door step
W75 Step, wide, at rear end
W76 Rear Bumper –Steel, Spring
Loaded
W78 Window Rear Door w/Wash-Wipe
W93 Rear Side Window Openings w/o
Glass
W94 Window openings w/o Glass
X90 Badging - Rear Door Deletion
X93 Badging - Side Door Deletion
XA4 GVWR 10,140lbs*
XB3 GVWR 9,990 LBS
XB5 GVWR 11,030 LBS
XL8 GVWR 8,550 LBS
XW6 Front License Plate Delete
Y10 First aid kit
Y26 Wheel Chocks
Y43 JACK - Hydraulic
Y45 Emergency Flash Light
YK3 Cargo straps, D-rings
YK4 Cargo Straps - Lashing Rails
ZE6 Shelving Prep
ZG1 4x4 High Range
ZG3 4x4 High Range w/ low range
transfer case
ZH4 Downhill Speed Regulation for
4x4*
* denotes addition and/or modification
over MY 2015
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
7

Equipment Handbook
DEALER INSTALLED ACCESSORIES:
B66570012 All-Season Floor Mats, (Rubber) Black, Driver & Passenger Mat
B66570009 All-Season Floor Mats, (Rubber) Black, Driver & Passenger Mat,
(w/ Code H00)
B66359841 Ripped Carpeted floor mats, Set of 3 (Black) Driver, Pass & Center
B66359843 Ripped Carpeted floor mats, Set of 3 (Black) Driver, Pass & Center
( w/ Code H00)
B66359842 Ripped Carpeted floor mats, Set of 3 (Black) Driver, Pass. Bench
( w/ Code S23)
B66560963 Carpeted Velour floor mats, anthracite, Driver's, Passenger and Center
B66560965 Carpeted Velour floor mats, anthracite, Driver's, Passenger and Center
(w/Code H00)
B66560964 Carpeted Velour floor mats, anthracite, Driver's, Pass. Bench (w/Code S23)
B66560966 Carpeted Velour floor mats, anthracite, Driver's, Pass. Bench
(w/Code S23 & H00)
B66560752 C-rail for 144” WB
B66560753 C-rail for 170” WB
B66560754 C-rail for 170” EXT WB
B66560800 Basic Carrier Bar, One Crossbar, with Two Supports
B66560801 Basic Carrier Bars, Three Crossbars, with Six Supports
B66561014 Cargo Rack, for high roof , Front and Rear Module, w/out supports
B66561013 Cargo Rack, for standard roof, front and rear Module, w/out supports
B66560811 Cargo Rack, for Standard Roof (LH1), center section, w/out supports
B66560814 Supports, 1 pair (Cargo Rack Required)
B66560807 Ladder Rack, Black, for Standard Basic Carrier Bars
B66560816 Loading Roller, for Basic Carrier Bars or Cargo Rack
B66560806 High-Standing Bracket Set, Black, for Basic Carrier Bars
B66560104 Side Windows Wind Deflector, Acrylic Glass
B66560921 Stowage Box, in Twin Passenger Seat
A0008900294 Tie-down strap, Black
A0008140132 Coat Hanger, Chrome / Black
A9069000402 Becker ® MAP PILOT - Navigation module
A9063102495 Trailer Hitch Kit Q24 (5,000lbs), 2500 Vans, all wheel bases
A9063102595 Trailer Hitch Kit Q24 (5,000lbs), 3500 Van, 170”WBExt
A9063102695 Trailer Hitch Kit QA2 (7,500lbs), 3500 Van, 144”WB
A9063102795 Trailer Hitch Kit QA2 (7,500lbs), 3500 Cab Chassis, all wheel basis
A9063102895 Trailer Hitch Kit QA2 (7,500lbs), 3500 Van, 170” WB
A9068200500 Becker MAP ® PILOT- Retrofit of Code EV6 (Pre Installation)
B66470995 Collapsible shopping crate, black
B66560920 Sun visor, front –acrylic glass
BQ6880139 Sprinter License Nameplate with laser etching
VKA001906 Sprinter Chrome Grille Kit
BQ6880140 Sprinter Slim-line Frame with laser etching
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
8

Equipment Handbook
VEHICLE AND MODEL DESIGNATIONS
Mercedes Model
Freightliner Model
Description
M2CA144
F2CA144
SPRINTER 2500 Cargo Van 144" WB
M2CA170
F2CA170
SPRINTER 2500 Cargo Van 170" WB
M2CA170E
F2CA170E
SPRINTER 2500 Cargo Van 170" WB Ext
M3CL144
F3CL144
SPRINTER 3500 Cargo Van 144" WB (Low Roof, Fleet Only)
M3CA144
F3CA144
SPRINTER 3500 Cargo Van 144" WB (High Roof)
M3CA170
F3CA170
SPRINTER 3500 Cargo Van 170" WB
M3CA170E
F3CA170E
SPRINTER 3500 Cargo Van 170" WB Ext
M2CV144
F2CV144
SPRINTER 2500 Crew Van 144" WB
M2CV170
F2CV170
SPRINTER 2500 Crew Van 144" WB
M2PV144
F2PV144
SPRINTER 2500 Passenger Van 144" WB
M2PV170
F2PV170
SPRINTER 2500 Passenger Van 170" WB
M3CC144
F3CC144
SPRINTER 3500 Chassis Cab 144" WB
M3CC170
F3CC170
SPRINTER 3500 Chassis Cab 170" WB
M3DB170
F3DB170
SPRINTER MiniBus
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
9

Equipment Handbook
SPRINTER SUSPENSION MATRIX –PASSENGER VAN
Passenger Van
Low Roof 144”
High Roof 144”
High Roof 170"
High Roof 170”
Ext
X17 (Standard
suspension)
X17 (Standard
suspension)
X17 (Standard
suspension)
Typical Total
Load(Cargo+Pass)
Heavy Load
(with 12
occupants)
Heavy Load
(with 12
occupants)
Heavy Load
(with 12
occupants)
Center of Gravity
Normal
Normal
Normal
Weight
Distribution
Even
Even
Even
Notes
PV has CF4, b/c
8,550 GVWR is
near the max
when all 12
Passengers +
Cargo in a typical
application.
PV has CF4, b/c
8,550 GVWR is
near the max
when all 12
Passengers +
Cargo in a typical
application.
PV has CF4, b/c
8,550 GVWR is
near the max
when all 12
Passengers +
Cargo in a typical
application.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
10

Equipment Handbook
SPRINTER SUSPENSION MATRIX –2500 CARGO VAN
2500 Cargo Van
Low Roof 144”
High Roof 144”
High Roof 170"
High Roof 170”
Ext
N/A
N/A
Standard
Suspension
Standard
Suspension
Typical Total Load
(Upfit+Cargo+Pass)
Small to medium
Small to medium
Center of Gravity
(Load/Upfit)
Low to normal
Low to normal
Weight Distribution
(Load/Upfit)
Any
Any
X19
(Standard for
144")
X19
(Standard for
144")
X19 Package
X19 Package
Typical Total Load
(Upfit+Cargo+Pass)
Medium to max
Medium to max
Medium to max
Medium to max
Center of Gravity
(Load/Upfit)
Normal
Normal
Normal
Normal
Weight Distribution
(Load/Upfit)
Any
Any
Even
Even
X17 Package
X17 Package
X17 Package
X17 Package
Typical Total Load
(Upfit+Cargo+Pass)
Max
Max
Max
Max
Center of Gravity
(Load/Upfit)
High (roof
mounts or high
cabinets)
High (roof
mounts or high
cabinets)
High (roof
mounts or high
cabinets)
High (roof
mounts or high
cabinets)
Weight Distribution
(Load/Upfit)
Any
Any
Any
Any
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
11

Equipment Handbook
SPRINTER SUSPENSION MATRIX –3500 CARGO VAN
3500 Cargo Van
Low Roof 144”
High Roof 144”
High Roof 170"
High Roof 170”
Ext
N/A
Standard
Suspension
Standard
Suspension
Standard
Suspension
Typical Total Load
(Upfit+Cargo+Pass)
Small to medium
Small to medium
Small to medium
Center of Gravity
(Load/Upfit)
Low to normal
Low to normal
Low to normal
Weight Distribution
(Load/Upfit)
Any
Any
Any
X19 Package
X19 Package
X19 Package
Typical Total Load
(Upfit+Cargo+Pass)
Medium to max
Medium to max
Medium to max
Center of Gravity
(Load/Upfit)
Normal
Normal
Normal
Weight Distribution
(Load/Upfit)
Even
Even
Even
X20 Package
X20 Package
X20 Package
Typical Total Load
(Upfit+Cargo+Pass)
Max
Max
Max
Center of Gravity
(Load/Upfit)
High
High
High
Weight Distribution
(Load/Upfit)
Near or beyond
rear axle
Near or beyond
rear axle
Near or beyond
rear axle
Notes
Upfits and loads
past the rear
axle can benefit
here
Upfits and loads
past the rear axle
can benefit here
Upfits and loads
past the rear axle
can benefit here
X17 Package
X17 Package
X17 Package
Typical Total Load
(Upfit+Cargo+Pass)
High-max
High-max
High-max
Center of Gravity
(Load/Upfit)
Very high (roof
mounts or high
abinets)
Very high (roof
mounts or high
abinets)
Very high (roof
mounts or high
abinets)
Weight Distribution
(Load/Upfit)
Even or towards
front axle
Even or towards
front axle
Even or towards
front axle
Notes
Optional A50, to
have increased
weight
distribution
towards front
Optional A50, to
have increased
weightdistribution
towards front
Optional A50, to
have increased
weightdistribution
towards front
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
12

Equipment Handbook
SPRINTER SUSPENSION MATRIX –CAB CHASSIS
Cab Chassis
(by upfit type)
Long & Low
(e.g. flatbed)
Tall & Wide
(e.g. box body)
Tall, Wide & Long
(e.g. body w/
long overhang)
X20 Package
X17 Package
X18 Package
Typical Total Load
(Upfit+Cargo+Pass)
Any
Any
Max
Center of Gravity
(Load/Upfit)
Low to normal
High
High
Weight Distribution
(Load/Upfit)
Any
Even or towards
the front axle
Any, but
especially past
the rear axle
Notes
Optional A50, to
have increased
weight
distribution
towards front
Optional A50, to
have increased
weight
distribution
towards front
X18 Package
Typical Total Load
(Upfit+Cargo+Pass)
Max
Center of Gravity
(Load/Upfit)
High
Weight Distribution
(Load/Upfit)
Any, but
especially past
the rear axle
Notes
Optional A50, to
have increased
weight
distribution
towards front
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
13

Package Codes
4CE –X31
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
14

Sprinter 906
4CE
4 Cylinder Engine / 7-Speed Transmission
Package Contents
CL9 ECO Power steering pump
G42 7G Tronic Automatic Transmission
KP1 Fuel Pump, electric
MG3 Engine 2.1L 4-Cylinder BlueTEC turbo diesel
MH5 Emissions EPA 14 / CARB
M47 Alternator for fuel economy
N81 Refrigerant Compressor (KMV)
Remarks
Depending on model variant some options may not be available or included. Please always
consult your Sprinter dealer.
For a full description please refer to the individual code page.
Package content may change without notice.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
15

Sprinter 906
6CE
6 Cylinder Engine / 5-Speed Transmission
Package Contents
G40 5-Speed Automatic Transmission
MH7 Emissions EPA 16 / CARB
MG5 Engine 3.0L BlueTEC turbo diesel
MV6 “V6” badge on the right rear cargo door
M46 Alternator 14V/220V
Remarks
Depending on model variant some options may not be available or included. Please always
consult your Sprinter dealer.
For a full description please refer to the individual code page.
Package content may change without notice.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
16

Sprinter 906
C01
Driver Comfort Package
Package Contents
E46 12V Power outlet at driver seat base
FJ1 Hinged lid for storage compartment
FZ9 Two additional master keys
SB1 Comfort seat, driver
SB2 Comfort seat, passenger
Remarks
Depending on model variant some options may not be available or included. Please always
consult your Sprinter dealer.
For a full description please refer to the individual code page.
Package content may change without notice.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
17

Sprinter 906
C02
Driver Efficiency Package
Package Contents
E1N Becker Map Pilot Navigation System
FR8 Rear view camera
L16 Fog lamps
MS1 Cruise Control
Remarks
Depending on model variant some options may not be available or included. Please always
consult your Sprinter dealer.
For a full description please refer to the individual code page.
Package content may change without notice.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
18

Sprinter 906
C03
Active Safety Plus Package
Package Contents
CL4 Multifunction Steering Wheel w/trip computer
JA5 Light and Rain Sensor
JP2 Driving Assistance Package
Elements include:
 JA7 Blind Spot Monitoring
 JA6 Collision Prevention Assist
 JW5 Lane Keeping Assist
 LA1 High Beam Assist
JK3 Pixel matrix display
F68 Heated and electrically adjustable mirrors
H21 Windshield with filter band
LD0 Overhead control panel with 2 reading lights
Y10 First aid kit
Y45 Emergency Flash Light
Remarks
Depending on model variant some options may not be available or included. Please always
consult your Sprinter dealer.
For a full description please refer to the individual code page.
Package content may change without notice.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
19

Sprinter 906
C04
Active Safety Plus Package w/ Parktronic
Package Contents
CL4 Multifunction Steering Wheel w/trip computer
EZ8 Parktronic System (PTS)
JA5 Light and Rain Sensor
JP2 Driving Assistance Package
Elements include:
 JA7 Blind Spot Monitoring
 JA6 Collision Prevention Assist
 JW5 Lane Keeping Assist
 LA1 High Beam Assist
JK3 Pixel matrix display
F68 Heated and electrically adjustable mirrors
H21 Windshield with filter band
LD0 Overhead control panel with 2 reading lights
Y10 First aid kit
Y45 Emergency Flash Light
Remarks
Depending on model variant some options may not be available or included. Please always
consult your Sprinter dealer.
For a full description please refer to the individual code page.
Package content may change without notice.
©2015 Mercedes-Benz USA, LLC / Daimler Vans USA, LLC
