Mercury 2005 User manual

2005 Mercury
|
Montego
Get ready to redefine your
driving expectations. Your new Mercury
Montego is going to take your
automotive experience to a whole new
level. And, you get to go along for the
ride in style, comfort and confidence.
You know your new Montego has
attitude...and you’re about to find out
it also has intelligence. Your new
Montego was one very smart choice.
This Quick Reference Guide was
designed to help you get to know your
new Montego. The perfect combination
of attitude, intelligence and style.
That’s your new Montego.
Feels good doesn’t it?

2005 Mercury Montego
|
Instrument Cluster
1
7
3
45
6
2

one |Windshield Wiper Washer The multifunction lever controls the windshield
wiper modes, speeds and the windshield washer. For intermittent operation, move the
control up one position. You can then adjust the rotary control to the desired interval
speed. For normal or low wiper speed, move the control up two positions from OFF. For
high speed operation, move the control up three positions from OFF. For windshield
washer control, pull the end of the lever toward you. A brief pull causes a single swipe
of the wipers without washer fluid. With a quick pull and hold, the wipers will swipe three times with washer
fluid. With a long pull and hold, the wipers will activate washer fluid for up to ten seconds.
two
|
Speed Control For your speed control to work, you must press and release
the ON button. Pressing and releasing the OFF button disengages the system and
turns it off. To set a speed, accelerate to the desired speed and press the SET+ button,
then take your foot off the accelerator pedal. You can Increase speed using speed
control by pressing and releasing the SET+ button until you reach the desired speed;
increasing speed by 1 mph (1..6 km/h) with each tap. You can decrease speed in the
same way using the SET- button. Pressing the RSM (resume) button will automatically return the vehicle to
the previously set speed. The RSM control will not work if the vehicle speed is below 30 mph (48 km/h) or
if the OFF or CNCL button was pressed. To disengage the speed control, press the OFF or CNCL button or
press the brake pedal.
three
|
Headlamp Control Turning the headlamp control clockwise to the first
position turns on the parking lamps, instrument panel lamps, license plate lamps and
the tail lamps. Continuing to turn the headlamp control to the second position turns on
the headlamps. To use the autolamp light-sensitive, automatic on-off control for the
headlamps, turn the headlamp control counterclockwise. To turn autolamps off, turn
the control clockwise to the OFF position. To activate the high beams, simply pull the
turn signal lever towards you to the second detent. Pull the lever towards you again to deactivate high
beams. Use the same lever to activate the “Flash to Pass” feature. Pull the lever towards you to the first
detent to activate and release it to deactivate.
four
|
Foglamp Control With the ignition on, the foglamps can be turned on when
the headlamp control is in the parking lamp, headlamp, or autolamp position and the high
beams are not on. Simply pull the headlamp control toward you to turn on the foglamps.
The foglamp indicator light will illuminate. The foglamps will not operate when the high
beams are activated.
Instrument Panel

five
|
Panel Dimmer Use to adjust the brightness of the instrument panel and all
applicable switches in the vehicle during headlamp and parking lamp operation. Move
the control to the full upright position, past the detent, to turn on the interior lamps.
six
|
Steering Wheel Audio Controls These controls allow you to adjust the
radio and CD features from the steering wheel. Press MEDIA to select AM, FM1, FM2
or CD. Press SEEK +/- to access the next/previous strong station or to select the
next/previous track on a CD. Press VOL +/- to adjust volume and MUTE to mute
the volume.
seven
|
Tilt Steering Column To adjust the steering wheel, push the
adjustment lever down to unlock the steering column. While the lever is down, tilt the
steering column to your desired position. Then, while holding the steering column in
place, pull the lever up to its original position to lock the steering column. Do not adjust
while driving.
Continuously Variable Transaxle (CVT)
The Continuously Variable Transaxle is a fully automatic transmission
that electronically monitors vehicle system inputs/outputs and driver
demands to select the desired drive ratio. Unlike traditional automatic
transmissions, the CVT continually adjusts the optimum overall drive
ratio between engine and drive wheels for all operating conditions.
As traditional automatic transmissions shift up or down in gears, the
shifting in gear ratios are noticeable by increasing and decreasing
engine RPM which causes a slight energy loss as the gears change.
These gear changes can be felt by the driver.
With the CVT, there is no energy transfer loss from shifting because there is no gear shifting up or down.
Acceleration up to vehicle operating speed is smooth and continuous, uninterrupted by gear shifting.
The same holds true for coasting down to idle, smooth and continuous.
Unlike traditional automatic transmissions, the CVT offers more responsive performance and increased
fuel economy.
The use of fluids other than the recommended fluid could seriously damage internal
transmission components. For more information, please consult your Owner’s Guide.
Understanding the CVT (if equipped)

2005 Mercury Montego
|
Instrument Cluster
A
E
D
B
C

Warning Lamps and Message Center
a|ABS Warning Lamp In an emergency, apply continuous force to the brake pedal. Do not pump
the brakes. Any pulsation or mechanical noise you may feel or hear is normal. If the light doesn’t illuminate
or stays on, have your vehicle serviced. Normal braking is still functional unless the brake warning light
is also illuminated.
b| Speed Control Lamp The speed control lamp will Illuminate when the speed control is
engaged. It will turn off when the speed control system is disengaged. The controls for the speed
control are located on the steering wheel. Press and release the ON and OFF buttons to engage and
disengage the system. Speed control does not work at speeds below 30 mph (48 km/h). For more
information, please consult your Owner’s Guide.
c|Check Engine Lamp The Check Engine indicator lamp illuminates when the ignition is first
turned to the ON position to check the bulb. If the light turns solid or blinks, the On Board Diagnostics
System has detected a malfunction. Drive in a moderate fashion (avoid heavy acceleration or
deceleration) and have your vehicle serviced immediately.
d| Brake System Warning Lamp To confirm the brake system warning light is functional, it
will momentarily illuminate when the ignition is turned to the ON position when the engine is not
running, or in a position between ON and START, or by applying the parking brake when the ignition is
turned to the ON position. If the brake system warning light does not illuminate at this time, seek
service immediately from your dealership. Illumination after releasing the parking brake indicates low
brake fluid level and the brake system should be inspected immediately by your servicing dealership.
e| Message Center With the ignition in the ON position, the message center displays important
vehicle information by constantly monitoring vehicle systems. You may select display features on the
message center for a display of status. The system will also notify you of potential vehicle problems
with a display of system warnings. For more information, please consult your Owner’s Guide.
Throttle Control/Transmission Lamp The Throttle Control/Transmission lamp illuminates
when a powertrain fault has been detected. Contact your dealer as soon as possible.
Engine Coolant Lamp The Engine Coolant lamp illuminates when the engine coolant is low.
Stop the vehicle as soon as safely possible and let the engine cool.

Ford Motor Company
Customer Relationship Center
P.O. Box 6248
Dearborn, MI 48121
1-800-392-3673 (FORD)
(TDD for the hearing impaired: 1-800-232-5952)
This Quick Reference Guide is not intended to replace your Owner’s Guide which contains more
detailed information concerning the features of your vehicle, as well as important safety warnings
designed to help reduce the risk of injury to you and your occupants. Please read your entire Owner’s
Guide carefully as you begin learning about your new vehicle and refer to the appropriate sections
when questions arise.
All information contained in this Quick Reference Guide was accurate at the time of duplication.
We reserve the right to change features, operation and/or functionality of any vehicle specification at
any time. Your Mercury dealer is the best source for the most current information.
For detailed operating and safety information, please consult your Owner’s Guide.
May 2004 | First Printing | Quick Reference Guide
Mercury Montego | Litho in U.S.A.
*F5T5J19G217AA*
5T5J-19G217-AA
2005 Mercury Montego
|
Quick Reference Guide

Essential Information
Location of Spare Tire and Tools Your vehicle is equipped with a temporary spare tire which
is smaller than a regular tire and designed for emergency use only. The jack, spare tire, jack handle and
lug nut wrench are under the cargo cover in the trunk of the vehicle.
Fuses If your electrical components aren’t working properly, a fuse may have blown. For more
information, please consult your Owner’s Guide.
Fuel Pump Shut-off Switch This device stops the electric fuel pump from sending fuel to the
engine when your vehicle has had a substantial jolt. After an accident, if the engine cranks but does
not start, this switch may have been activated. The fuel pump shut-off switch is located in the front
passenger footwell area in the right upper corner.
Unleaded Fuel Recommendations For optimum performance use “Regular” unleaded fuel
with a pump (R+M)/2 octane rating of at least 87. We do not recommend the use of gasolines labeled
as “Regular” with octane ratings of 86 or lower that are sold in high altitude areas.
Tire Pressure Safe operation of your Montego requires that your tires be properly inflated. The
Mercury recommended inflation pressure is found on the Tire Label or the Certification Label located
near the front door latch on the driver’s side. At least once a month and before long trips, inspect each
tire and check the air pressure with a tire gauge. Don’t forget the spare. Air pressure should be checked
when the tires are cold. Inflate all tires to the inflation pressure recommended by Ford Motor Company.
Roadside Assistance In addition to your New Vehicle Limited Warranty, Mercury provides new
vehicle owners with a complimentary roadside assistance program. This service is available 24 hours
a day, seven days a week, for three years or 36,000 miles (60,000 km). It covers changing a flat tire,
jump starts, limited fuel delivery, lock-out assistance and towing of your vehicle.
United States (800) 241–3673
Canada (800) 665–2006

Additional Features
Memory Feature (If equipped) This feature will allow you to set two positions for
the driver's seat, power mirrors, and adjustable pedals (if equipped). Set the position
by pressing the SET button (indicator will illuminate) then press the 1 or 2 button to
set the position to either Driver 1 or Driver 2. This memory setting can then be
recalled when you press the 1 or 2 button, enter Customer Code 1 or 2 on the keypad,
or when you press unlock on the remote entry system (one of your remote
transmitters is associated with Driver 1 and the other transmitter is associated with Driver 2)
.
HomeLink¨ (if equipped) The HomeLink¨ Wireless Control System on the driver’s visor provides a
convenient way to replace up to three handheld transmitters with a single device. This feature will
operate most garage doors, entry gate operators, security systems, and home or office lighting.
For programming, please consult your Owner’s Guide.
Power Mirrors To adjust your mirrors, rotate the control clockwise to adjust the
right mirror and counterclockwise to adjust the left mirror. Move the control in the
direction you wish to tilt the mirror. Then rotate the control to the center position to
lock the mirrors in place.
Keyless Entry Pad The keyless entry keypad can be used to lock or unlock the
doors without using a key. It can also control the memory seat, power mirrors, and
adjustable pedals features (if equipped). For more information, please consult your
Owner’s Guide.
Autolock Your vehicle is equipped with an autolock feature. The autolock feature will automatically
lock all doors when your vehicle is in motion and meets a set of conditions, as described in your
Owner’s Guide. Your vehicle comes with this feature enabled. You can enable or disable this feature
by following the activation or deactivation procedure outlined in your Owner’s Guide.
Adjustable Pedals (if equipped): The accelerator and brake pedal should only be adjusted when
the vehicle is stopped and the gearshift is in the P (Park) position. Press the top of the control to adjust
the pedals away from you or press the bottom of the control to adjust the pedals toward you.
Reverse Sensing System (if equipped) The Reverse Sensing System (RSS) sounds a tone to warn
the driver of obstacles near the rear bumper when R (Reverse) is selected and the vehicle is moving at
speeds less than 3 mph (5 km/h). The system is not effective at speeds above 3 mph (5 km/h) and
may not detect certain angular or moving objects.

one
|
Tune/Disc Selector Press to go up or down
the radio frequency or to select a desired disc.
Also use in menu mode to select various settings.
two
|
Load Press to begin the CD load
sequence. Press and hold to autoload up to
6 CDs.
three
|
CD Press to enter CD mode. If a CD is
already loaded into the system, the CD will
begin playing where it last ended.
four
|
On/Off/Volume Control Push to turn
the system ON or OFF. Turn to increase or
decrease volume. If the volume is set above a
certain level and the ignition is turned off, the
volume will come back on at a “nominal” level
when the ignition switch is turned back on.
five
|
AM / FM Press to select AM or FM
frequency bands.
six
|
Seek Function Press to access the
next/previous strong station or track.
seven
|
Scan Function Press for a brief
sampling of radio stations or CD tracks. Press
again to stop.
eight
|
CD Rewind Press to manually reverse in
a CD track.
nine
|
CD Fast Forward Press to manually
advance in a CD track.
ten
|
Setting Memory Preset To set a station:
Press AM/FM to select frequency band; tune to
a station, then press and hold a preset button
until the sound returns.
Bass / Treble Press MENU until bass or treble
settings are displayed, adjust using the
SEEK control.
Balance / Fade Press MENU until Balance is
displayed, press to adjust the audio between
the left and right speakers using the SEEK
control. Press MENU again to display Fade,
press SEEK to adjust audio between the front
and rear speakers.
Setting The Clock Press MENU until SELECT
HOUR or SELECT MINS is displayed. Press the
up/down arrows or SEEK control to adjust the
hours/minutes. Press MENU again to
disengage clock mode.
MP3 Track/Folder Mode In Track mode, pressing
SEEK will scroll through all tracks on the disc.
In Folder mode, pressing SEEK will scroll only
through tracks within a selected folder.
4
3
5
6
6
8
10
2
1
7
9
Premium / Audiophile In-Dash 6-CD Sound System (if equipped)

Driver and Passenger Side Temperature
Set desired cabin temperature with the
1or 4red and blue buttons. Press 1 for driver’s
side, 4for passenger’s side. Recommended
setting is 72°F (22°C) to 75°F (24°C).
Dual Control (if equipped)
Press 10 DUAL to engage/disengage separate
passenger side temperature control. For controls
without a 10 DUAL button, press and hold 2
AUTO to engage/disengage separate
passenger
side temperature control.
Automatic Operation
Set desired 1cabin temperature. Press 2AUTO
button for full automatic operation. The system
will automatically adjust airflow temperature,
fan speed, airflow direction, A/C, and
recirculated air based on the selected
temperature to heat or cool the vehicle to the
desired temperature as soon as possible.
Max A/C Operation
Automatic operation: Press 2AUTO button for
full automatic operation. Do not override A/C or
recirculated air. Set the desired temperature.
Override Operation: Select 7air distribution.
Select 8A/C and 9 recirculated air. Use
recirculated air with A/C to provide colder
airflow. Set temperature setting to 60°F
(15.5°C). Initially set to highest fan speed 5,
then adjust to maintain comfort.
Manual Override Operation: Press 1to set
desired cabin temperature. Adjust any of the
following for personal comfort preferences: 5
fan speed, 7 airflow direction, 8 A/C, and
9 recirculated air. Fan speed, A/C, and
recirculated air overrides will not turn off the
AUTO indicator light. Airflow direction overrides
will turn off the AUTO indicator light.
One Button Airflow Direction Control (if equipped)
Press 7repeatedly to select airflow direction.
Defogging / Demisting
Press 3to distribute outside air through the
windshield defroster vents and demister vents.
To reduce humidity buildup in the vehicle,
do not drive with the Climate Control turned off.
Also, do not drive with recirculated air selected
unless A/C is operating.
Heated Seats (if equipped)
Press 6to cycle through available settings of
high heat (2 lights), low heat (1 light), and off
(no lights).
1
2
4
5
7
9
10
3
6
8
6
Climate Control

2005 Mercury
|
Montego
Quick Reference Guide
