Mercury Ultimate Solutions Hercules Guide

Copyright © 2015 Ultimate Solutions | Mercury Floor Machines
Safety, Operation and Maintenance
Manual with Parts List
Please read before use!
1.5HP, 175 RPM
Important Information and Safety Instructions
Register your Machine Online or Return your Machine Warranty Card!
Serial No:
HERCULES FLOOR MACHINE
Heavy-Duty Floor Machine | 6 Apron Sizes Available
REGISTER
YOUR
MACHINE
ONLINE!
Another Innovative
Product from
Manufactured with
Pride in the U.S.A.
New Equipment Warranty
Limited Warranty
Mercury Floor Machines warrants new equipment against defects in material and
workmanship under normal use and service to the original purchaser. Any statutory
implied warranties, including any warranty of merchantability or tness for a particular
purpose, are expressly limited to the duration of this written warranty. Mercury Floor
Machines will not be liable for any other damages, including but not limited to indirect
or special consequential damages arising out of or in connection with the furnishing,
performance, use or inability to use the machine. This remedy shall be the exclusive
remedy of the purchaser. The warranty period is subject to the conditions stated below.
“Best Warranty on the Planet” – 5-Years on Motor, Transmission
and Chassis
Mercury Floor Machines warrants the roto-molded body to be free from defects in material
and workmanship, under normal use and service for a lifetime. Mercury Floor Machines
warrants the motor and all electrical components to be free from defects in material and
workmanship, under normal use and service for ve (5) years from the original date of
sale. Parts replaced or repaired under this warranty are warranted for the remainder of the
original warranty period. Service labor charges are covered for one (1) year from the date
of purchase, when performed by a manufacturer-authorized service provider.
Labor is only provided by authorized service centers. If an authorized service center is
not near you, it is the purchaser’s responsibility to take their machine to an authorized
service center.
Critical Wear Items such as bearings, capacitors, clutches, pulleys, rectiers, relays,
switches, wheels, tires and casters are warranted for manufacturing defects for one (1)
year from the purchase date. Normal Wear Items such as belts, brushes, bumpers carbon
brushes, cords, nishes, squeegees, actuating cables and gaskets are warranted for
manufacturing defects for ninety (90) days from the purchase date.
All warranties of motors and associated components will be voided: if the machine
is serviced by anyone other than an authorized service provider; if the machine is
mechanically modied; if the machine is operated when not operating properly; or if the
machine is misused or abused.
The warranty starts on the purchase date by the original purchaser from Mercury Floor
Machines subject to proof of purchase.The Machine Registration Card must be completed
and returned immediately at the time of purchase. Registration may also be performed
online at: www.sandiaplastics.com/registration.aspx. If proof of purchase cannot be
identied, the warranty start date is ninety (90) days after the inventory stocking date at
the distributor’s warehouse.
Make a copy of this card for future reference.
Copyright © 2015 Ultimate Solutions | Mercury Floor Machines. All Rights Reserved.
Ultimate Solutions Corporate Oce
15571 Container Lane, Huntington Beach, CA 92649
Phone: [phone] | Fax: [phone]
www.mercury oor machines.com

(1) Hercules Heavy-Duty Floor Machine Versa Pro™ Heavy Duty Floor Machine (12)
Dear Valued Client,
Congratulations on the purchase of your Hercules Super Heavy-Duty Floor Machine!
Our Mercury machines are built to last, are durable and strong to provide optimal oor
bung, cleaning and scrubbing
Please review this manual paying careful attention to the Safety Instructions section.
Keep in mind that any unnecessary damage, neglect or abuse of this machine will void
your warranty. You can be condent that simple maintenance will ensure that your
oor machine provides quality performance for many years to come.
If warranty questions arise, please consult your manual or contact your distributor.
Should you have any questions regarding maintenance, replacing parts or ordering
parts, please call an authorized distributor.
Before you begin using your oor machine, thoroughly review the Owner’s Manual.
Again, congratulations on the purchase of your Hercules Super Heavy-Duty Floor
Machine!
Questions or Comments?
Phone: [phone]
Toll Free: 888-568-4606
Fax: [phone]
Ultimate Solutions Corporate Oces:
15571 Container Lane, Huntington Beach, CA 92649
Visit our website at: www.mercuryoormachines.com
Register your machine online at: www.mercuryoormachines.com/registration.aspx
Mail to:
Mercury Floor Machines, Inc.
110 South Van Brunt Street
Englewood, NJ 07631
See reverse side for Warranty Information.
Make a copy of this card for future reference.
Copyright © 2015 Ultimate Solutions | Mercury Floor Machines. All Rights Reserved.
WARRANTY REGISTRATION
Please take a moment to register your machine. Fill out the
information below and mail back to Mercury immediately.
The warranty starts on the purchase date by the original purchaser subject to proof
of purchase. This Machine Registration Card must be completed and returned
immediately at the time of purchase. If proof of purchase cannot be identied,
the warranty start date is ninety (90) days after the inventory stocking date at the
distributor’s warehouse.
Your machine may also be registered online at:
www.mercuryoormachines.com/registration.aspx
Machine Model Purchase Date
Motor Type Serial No.
Place of Purchase
Shipped To
Your Name Phone
E-mail Fax
Address Line 1
Address Line 2
City State Zip
Comments:

(12) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (2)
Table of Contents
Returned Material Authorization (RMA) Procedure......................................................................2
New Equipment Warranty......................................................................................................................3
1.0 Safety Instructions ............................................................................................................................4
2.0 Grounding Instructions...................................................................................................................5
3.0 Assembly Instructions. ....................................................................................................................6
4.0 Operating Tips.....................................................................................................................................8
5.0 Machine Schematic Drawing........................................................................................................9
6.0 Handle Parts List ............................................................................................................................. 10
7.0 Machine Parts List .......................................................................................................................... 11
8.0 Troubleshooting ............................................................................................................................. 12
9.0 Brush Construction........................................................................................................................ 13
10.0 Pad Driver Construction ............................................................................................................ 13
11.0 Scrubbing Brush Types .............................................................................................................. 14
12.0 Wiring Diagram............................................................................................................................. 15
13.0 Optional Parts and Accessories............................................................................................... 16
Returned Material Authorization (RMA) Procedure
Original purchaser (distributor/service center) must contact the manufacturer to follow correct
RMA/warranty procedures. Must include a copy of RMA Sheet enclosed in the box with returned
item. No returns shall be authorized unless proper RMA procedures are followed. It is the
responsibility of the distributor to repair the client’s equipment as soon as possible. Labor is only
provided by authorized service centers. If an authorized service center is not near you, it is the
purchaser’s responsibility to take their machine to an authorized service center.
Client must contact the distributor prior to working on or changing out any parts, etc. Manufacturer
must issue an RMA Sheet containing approved labor time and replacement parts. Do not send
parts or equipment back to manufacturer without an RMA number and approval. No labor will
be paid for, nor part costs paid for or reimbursed that have not been previously approved by the
manufacturer. All warranty work must be approved and authorized to qualify and appropriate
warranty procedures must be followed.
Please ll out the following information:
Model No:
Serial No:
Distributor Name:
Distributor Phone No:
Date of Purchase:
Hercules Heavy-Duty floor Machine
By Ultimate Solutions | Mercury Floor Machines
The Ultimate Solutions Group
Our Family of Companies
TOGETHER WE’RE BETTER!
Ultimate Carpet Solutions
www.sandiaplastics.com
Ultimate Hard Floor Solutions
www.mercuryoormachines.com
Ultimate Cleaning Solutions
www.ultimatesolutionsinc.net

(3) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (16)
New Equipment Warranty
“Best Warranty on the Planet” – 5-years on motor, transmission and chassis.
Warranty Policy
All equipment is inspected and tested before shipping from the manufacturer. All parts are
warranted to be new and free from defects in workmanship and material, under normal use to the
original retail purchaser. This warranty limits manufacturer’s liability for defects in workmanship
or materials for replacement of defective parts only. The manufacturer accepts no liability for
incidental or consequential damages arisen from the use of any equipment, defective or not. This
warranty is in lieu of all expressed or implied warranties and is extended only to the original retail
purchaser. Manufacturer sales and service representatives are not authorized to waive or alter
the terms of this warranty, or to increase the obligations of the manufacturer under the warranty.
Parts replaced or repaired under this warranty are warranted for the remainder of the original
warranty period.
Labor is only provided by authorized service centers. If an authorized service center is not near
you, it is the purchaser’s responsibility to take their machine to an authorized service center.
The manufacturer covers up to one (1) year (365 days) of service labor at the manufacturer’s
calculated hourly labor rate/repair time when performed by a manufacturer-authorized service
provider. Ultimately, labor reimbursement costs are at the discretion of the manufacturer. At no
time is the manufacturer responsible for travel time to complete on-call repairs. After one (1) year,
the original retail purchaser is responsible for all labor costs with no manufacturer reimbursement.
The original purchaser must contact the manufacturer to follow correct RMA/warranty procedures.
They must include a copy of the RMA Sheet enclosed in the box with the returned item. No returns
shall be authorized unless the proper RMA procedures are followed. It is the responsibility of the
distributor to repair the client’s equipment as soon as possible.
The manufacturer charges a 25% restocking fee for any items that are being returned to stock.
Items must be new, unused, free of damage and are only good for up to 30 days. After 30 days, the
manufacturer does not accept the return of any items for a store credit.
Authorized warranty replacement parts need to come directly from the manufacturer. Any use of
any other parts will void warranty. The manufacturer does not reimburse for parts used by client
that were not supplied directly for the machine under warranty.
The client must contact the manufacturer prior to working on or changing out of any parts, etc.
The manufacturer must issue an RMA Sheet containing approved labor time and replacement
parts. Do not send parts or equipment back to the manufacturer without an RMA Number and
approval. No labor will be paid for, nor parts cost paid for or reimbursed, that have not previously
been approved by the manufacturer. All warranty work must be approved and authorized to
qualify, and appropriate warranty procedures must be followed.
The warranty starts on the purchase date by the original purchaser from an authorized distributor,
subject to proof of purchase. The Machine Registration Form must be completed and sent to
the original manufacturer at the time of purchase. If proof of purchase cannot be identied, the
warranty start date is ninety (90) days after the date of sale to an authorized distributor.
Register your machine online at: www.mercuryoormachines.com/registration.aspx
13.0 Optional Parts and Accessories
Pad Drivers
Includes Riser and 92 Clutch Plate
Optional 1305
12” Short Bristle
Pad Driver
Optional 1505
14” Short Bristle
Pad Driver
Optional 1705
16” Short Bristle
Pad Driver
Optional 1905
18” Short Bristle
Pad Driver
Optional 2105
19” Short Bristle
Pad Driver
Accessories
Optional Unicorn
Weight Kit: add up to 50
extra pounds of pressure
UWK
Optional Solution Tank:
for efficient wet scrubbing
SST-4

(15) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (4)
1.0 Safety Instructions
READ THIS MANUAL BEFORE OPERATING MACHINERY. KNOW THE
PROPER SET-UP, OPERATION, CORRECT APPLICATIONS AND THE
LIMITATIONS OF THIS EQUIPMENT BEFORE USE.
This oor machine will afford you many years of trouble-free operating satisfaction,
provided it is given the proper care. All parts have passed rigid quality control standards
throughout the assembly process. Prior to packaging, your oor machine was again
inspected for assurance of awless operation.
This oor machine is protectively packed to prevent damage in shipment. We recommend
that upon delivery, unpack the unit and inspect it for any possible damage. Only a visual
inspection will reveal damage that may have occurred.
If damage is discovered, immediately notify the transportation company that delivered
your machine. As a shipper, we are unable to report any claim for damage. You must
originate any claim within ve (5) days.
This manual is for your protection and information. Please read it carefully since failure
to follow precautions could result in discomfort or injury.
Reduce the Risk of Fire, Electric Shock or Injury
DO NOT USE ON WET SURFACES OR EXPOSE TO RAIN. STORE INDOORS.
Use only as described in this safety operating manual. Use only the manufacturer’s
recommended attachments, accessories and replacement parts. Replace damaged or
worn parts immediately with genuine, original equipment parts to maintain safety and to
protect your limited warranty.
Always turn OFF the machine before changing brushes, pad drivers or servicing your
machine. This machine must be connected to a properly grounded outlet only (see
grounding instructions). The extension cord provided with this unit is 50-foot, 14/3-gauge
wire and MUST be used with this unit to ensure grounding protection. Turn off all
controls before unplugging. This is not a toy. Close attention is necessary when used
around or near children. Train your staff in proper use of this oor machine to avoid
injury.
• DO NOT use outdoors or expose to rain. This oor machine is
designed for indoor use only.
• DO NOT wash the motor with owing water. If the motor gets wet,
seek authorized service.
• DO NOT handle this electrical equipment with wet hands. DO NOT
operate this machine with bare feet.
• DO NOT operate this equipment near ammable dusts, liquids or vapors. DO NOT
use ammable solvents as a cleaning agent. Engine sparks and operating heat can
cause re.
• DO NOT operate with the motor covered or with vents blocked. Keep the vents on
this air-cooled motor free from debris.
• DO NOT use this machine as a oor sander.
• DO NOT operate over sharp objects that may harm the operator and damage the
oor. Sweep hard oors before scrubbing or bufng. Vacuum clean carpets before
shampooing or bonnet cleaning.
12.0 Machine Wiring Diagram

(5) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (14)
1.0 Safety Instructions Continued
Reduce the Risk of Fire, Electric Shock or Injury.
• DO NOT leave the machine when plugged in. Unplug it
from the outlet when not in use and before servicing.
• DO NOT use this machine with a damaged handle controls,
cord or plug. If it is not performing properly, contact an
authorized service center and seek repair.
• DO NOT unplug the machine by pulling the cord. To
unplug, grasp the plug, not the cord. DO NOT pull by the
cord, close a door on the cord, pull the cord around sharp
edges or corners or drive equipment over it. Keep the cord
away from heated surfaces.
• DO NOT overstretch the safety power cord between the
machine and the electrical outlet in the wall.
2.0 Grounding Instructions
DANGER: IMPROPER GROUNDING METHOD CAN RESULT IN A RISK OF
ELECTRIC SHOCK!
Electrical equipment must be grounded. Improper connection of the equipment grounding
conductor can result in a risk of electric shock. If the equipment should malfunction or
breakdown, grounding provides a path of least resistance for electrical current to reduce
the risk of electric shock.
This machine is equipped with a cord containing a grounding conductor and grounding
plug. The plug must be inserted into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
Check with a qualied electrician or service person if you are in doubt as to whether the
outlet is properly grounded. DO NOT modify the plug provided with the equipment. If it
will not t into the outlet, have a proper outlet installed by a qualied electrician.
If repair or replacement of the cord or plug is necessary, DO NOT connect the grounded
wire to a at bed terminal. The wire with insulation having an outer surface that is green
with or without yellow stripes is the grounding wire.
NOTE: In Canada, the use of a temporary adapter is not permitted by the Canadian
Electrical Code.
This electric equipment is for use on a normal 120 volt circuit. It has a grounded plug that
looks like the plug illustrated in (Fig A). A temporary adapter, such as illustrated in (Fig B
and C), may be used to connect this plug into a two-pole receptacle, as shown in (Fig B),
if a properly grounded outlet is not available.
11.0 Scrubbing Brush Types
Scrubbing brushes are available with a range of bristle types from the softest for high
gloss oors, to the most aggressive for heavy soils. Match your brush to the oor as you
match a detergent with the soils.
Nylon is used for general scrubbing. Because nylon softens
when wet, it is great for gentle scrubbing, mopping and
polishing of decorative oors. Nylon will not scratch tile,
terrazzo or coated surfaces. Nylon brushes are durable and long
lasting.
Polypropylene is a common choice for general purpose
scrubbing and works well on both concrete and on coated
oors. Polypropylene brushes typically cost less than nylon, but
do not last as long.
Non-scuff poly is a ner diameter (0.015-0.018”) lament used
for lighter duty scrubbing conditions and on waxed or nished
oors.
Bassine is a soft, natural ber. The end of the bristle splits or
“ags” to build a polishing surface.
Union mix is a mixture of bassine and tampico (another natural
ber). The mixture is stiffer than bassine alone and is used by
more traditional cleaners for scrubbing. It is often replaced by
poly.
Soft abrasive bristle is a 0.018” nylon lament extruded
with a 500 grade grit. It is used for gentle scrubbing and is as
aggressive as a white scrub pad.
Daily abrasive bristle is a 0.035” nylon lament with 180
grade grit. It is used for daily scrubbing of resilient tile and
nished oors and is as aggressive as a red scrub pad.
Stripper abrasive bristle is a 0.022” nylon lament with 120
grade grit. It is used for aggressive scrubbing and light stripping
of resilient oors, terrazzo and concrete. It is as aggressive as a
blue scrub pad.
Heavy-duty stripper abrasive bristle is a 0.050” nylon
lament with 80 grade grit. It is used for very aggressive
scrubbing and stripping of concrete, brick and quarry le. It is
as aggressive as a black scrub / strip pad.

You will need 7/16” wrenches to complete this assembly:
1. Remove the handle and mounting hardware from the
carton. Bolts, nuts, washers and a locking lever assembly
are in the plastic bag attached to the handle.
2. Position the handle (1) over the mounting yoke (2) with
the power cord (3) facing away from the motor. Push the
tube down until the bolt holes are lined up.
3. Insert the mounting bolts (4) into the bolt holes from the
back of the machine. Secure each bolt with a locking nut
(5). The locking nuts will face the motor.
4. The handle mounting collar (6) is designed to slide
freely up and down the handle tube. This feature allows
the handle to be adjusted for the comfortable operation
of all users. Align the mounting collar (6) and the two
bent handle braces (7).
5. Remove the lever assembly parts from the plastic bag.
• Place the thick spacer with a rectangular hole (9) onto
the locking lever shaft (8). The spacer must t onto
the rectangular neck of the lever.
• Insert the shaft through the mounting hole in the right
handle brace, the mounting collar and the left handle
brace.
• Place the spacer (10) on the shaft.
• Place the split washer (11) on the shaft.
• Adjust the wing nut for tightness. When correctly
installed, the collar slides easily when the cam-
engineered locking lever is “up,” but is rmly xed
when the lever is “down.”
(13) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (6)
2.0 Grounding Instructions Continued
DANGER: IMPROPER GROUNDING METHOD CAN RESULT IN A RISK OF
ELECTRIC SHOCK!
The temporary adapter should be used only until a properly grounded outlet (Fig A) can
be installed by a qualied electrician. The green color rigid ear lug or the like extending
from the adapter must be connected to a permanent ground such as a properly grounded
outlet box cover. Whenever the adapter is used, it must be held in place by a metal screw.
The oor machine is built with a 50 foot (15 M), 14/3-gauge safety power cord
which plugs directly into an approved outlet. Use of any extension cords is NEVER
RECOMMENDED.
3.0 Assembly Instructions
3.1 Install the Handle
This machine handle (1) has been custom t to its mounting yoke (2) at the factory and
then taken apart for shipping. For easy assembly, make sure that the handle number on
the tag (see right) matches the serial number stamped on the chassis.
9.0 Brush Construction
Your new oor machine provides reliable, efcient, safe power to your scrubbing brush.
To get the best results, you need to use a brush of the best design and construction.
Your oor machine is built with a “B” style drive plug (1). The height and width of the
ears on the plug will match a “B” style or “Universal” clutch plate (2) mounted on the
brush block.
The brush block (3) is constructed of molded plastic or plywood. Use a brush with a
block diameter 2” less than your machine apron size.
The bristle material (4) that actually does the scrubbing is typically 1-1/2” to 2” long.
Holes are drilled in the block and bundles of bristles are folded in half, forced into the
hole and stapled in place.
When the bristles wear down to less than 1/2” long, they have little exibility and it’s
time to replace. Bristle materials are described on the next page.
Machine Apron Size 13” 15” 17” 19” 20” 21”
Pad Driver - with 3/4” Riser 12” 14” 16” 18” 20” 20”
Brush - with NO RISER 11” 13” 15” 17” 19” 19”
10.0 Pad Driver Construction
If you scrub or polish with a non-woven pad, use a pad driver to connect the pad to the
machine.
The brush block (3) is constructed of molded plastic, t with shorter, stiffer, pad-holding
bristles (5) or “velcro-like” pad-holding hooks (6) and use a riser (7) to create extra
clearance between the block and the machine apron. With this construction, use a pad
driver with block diameter 1” less than your machine apron size.

(7) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (12)
3.0 Assembly Instructions Continued
3.2 Attach the Power Cord
The triple-wire grounded power cord has been factory-
installed into the handle tube. A exible rubber cable
connector (11) is used to secure the plug-in connections.
The oor machine ships with this connector mounted
on the cord coming out of the handle (10). Stretch the
connector and slip the male connector (9), coming out of
the motor housing, through the connector hole and then
into the female connector.
Now, plug the end of the 50-foot cord into a grounded
power outlet. Squeeze the triggers on the handle and
check for power to the motor.
3.2 Install a Brush or Pad Driver
A brush or pad driver mounts onto your oor machine
with a “B” style Universal clutch plate.
Unplug the oor machine. Lock the machine handle in
the “up” position and tip the oor machine back onto the
handle.
Slide the brush or pad driver clutch plate (12) over the
drive plug (13).
Give the brush a quick counter-clockwise spin to lock
the brush onto the drive plug.
Now, lower the machine back onto the brush. You’re
ready to go to work.
4.0 Operating Tips
4.2 Transporting your Floor Machine
To transport this oor machine from the janitor’s closet
to the work area:
• Lock the handle in the “up” position. Wind the
cord around the handles and the bottom cord hook.
• Tip the machine back onto the transport wheels.
Push or pull the machine by the handle, not by
the cord or any other part of the machine. Travel
carefully
8.0 Troubleshooting
CAUTION: Always disconnect power cord before servicing the oor machine.
WARNING: Never operate the oor machine when it is not performing as expected or
when any part is visibly damaged. Repairs should only be performed by an authorized
service center. Failure to do so will VOID warranty.
8.1 Floor Machine will not Run
• Equipment is unplugged: check plug wall and at machine base. Plug in.
• Circuit breakers are tripped in the building: check and reset.
• Power cord failure: test with a working power cord. Lock the handle up and tip the
motor back. Unplug the cord at the motor and plug the motor into your working
power cord.
IMPORTANT! THIS IS JUST FOR TESTING. When you do this, you have removed
the safety handle controls from the circuit and you are sending power directly to the
motor. If the motor now spins, the problem is in the cord of the handle assembly.
Seek authorized service center. If the motor still does not spin, the problem is either
in the male connection at the motor base or in the motor. Seek authorized service
center.
• Motor sparks or smokes: seek authorized service center.
8.2 Electrical Shock to Operator
• Equipment wiring failure or electrical short in the machine: seek authorized service
center.
• Poor grounding or no grounding: test the outlet with a ground fault interrupter.
Retain certied electrician to inspect and repair grounding. NEVER clip off the
ground plug on your cord.
• Repeated circuit breaking: high amp draw and circuit breaking can be an electrical or
mechanical problem. Seek authorized service center.
8.3 High Vibration
• Pads are not centered on the pad driver: tip machine back and re-center the pad.
• Uneven wear or warp to pad or brushes: replace.
• Machine chassis is damaged by dropping: replace.

(11) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (8)
4.0 Operating Tips
For indoor use only. Sweep abrasive soils before scrubbing
While the brush or pad driver is spinning, keep the oor
machine moving to avoid “donut” burns on the oor.
4.1 Starting your Floor Machine
• Unlock the handle by raising the locking lever.
• Lower the handle to a comfortable position, typically
waist high.
• Re-lock the handle by pushing the lever down. DO NOT
OPERATE THE MACHINE WITH THE HANDLE
UNLOCKED.
• This oor machine has a high torque motor. Hold the
machine rmly with both hands when starting up.
• Use your index nger to lift the safety interlock lever up.
• Squeeze the dual triggers to release power to the motor.
Once power is on, either trigger will keep power to the
motor.
• To stop the oor machine release both triggers.
• The spinning brush helps move the oor machine. Lift
the handle slightly to work to the right. Push the handle
down slightly to work to the left.
4.2 Storing your Floor Machine
• Lock the handle in the “up” position. Tilt the machine
back and remove the pad driver or brush.
• Wind the cord around the handles and the bottom cord
hook.
• Wash brushes or pads and hang to dry. Never store
machine standing on the brush.
• Check and clean pads after each operation. Remove soil
and chemical buildup. Replace worn or damaged pads.
• Check the triggers and switches for proper operation.
• Repair or replace damaged skirts and dumpers.
• Use air pressure or vacuum to remove dust and debris
from the motor vents.
• Inspect and maintain equipment on a regular schedule for
best results.
• See an authorized service center for repairs.
CONTINUED on Page 12
7.0 Machine Parts List
Drawing No. Item No. Description Quantity
37 B-8 Acorn Nut for Yoke Pin 2.00
38 B-5 Rubber Spacer 2.00
39 B-7 Yoke Pin 1.00
40 A-1001 Yoke 1.00
41 B-30 Spring 2.00
42 B-29 1/2” Flat Washer 2.00
43 M-245 6” Wheel 2.00
44 B-51 Spring Washer 4.00
45 V0038 Hub Cap 2.00
46 A-166 Main Machine Frame 1.00
47 B-95 Base Casting Screw 3.00
48A M-232-13/Y Bumper 13” - Yellow 1.00
48B M-232-15/Y Bumper 15” - Yellow 1.00
48C M-232-17/Y Bumper 17” - Yellow 1.00
48D M-232-19/Y Bumper 19” - Yellow 1.00
48E M-232-21/Y Bumper 21” - Yellow 1.00
49A A-163 Apron 13” 1.00
49B A-167 Apron 15” 1.00
49C A-169 Apron 17” 1.00
49D A-171 Apron 19” 1.00
49E A-172 Apron 21” 1.00
50 B-50 Apron Plug 1.00
51 B-31 Cap Screw 4.00
52 MOTOR 1.5 HP/GB 66 Frame Motor, 1.5 HP with Gearbox,
115V
1.00
53 M-240 Axel 1.00
54 M-248 Cork Drip Cap Cover 1.00
55 M-239-Y 66 Frame Drip Cap Bumper Cover - Yellow 1.00
56 M-242-1A-Y 66 Frame Drip Cap Cover - Yellow 1.00
57 B-151 Drip Cap Mounting Screw 3.00
58 G-14-50-Y 50-Foot, 14/3-Gauge Power Cable - Yellow 1.00

(9) Hercules Heavy-Duty Floor Machine Hercules Heavy-Duty Floor Machine (10)
5.0 Machine Schematic Drawing 6.0 Handle Parts List
Drawing No. Item No. Description Quantity
1 A-104 Switch Box Back 1.00
2 B-23 Handle Tube Screw 2.00
3 B-21 Switch Box Closing Screw 4.00
4 M-213 Strain Relief Clip 1.00
5 M-218-Y Hand Grip with Rubber Spacer - Yellow 2.00
6 M-247 Handle Tube Insert 1.00
7 M-206 Handle Tube Assembly 1.00
8 B-2 Cable Hook Screw 2.00
9 A-164 Cable Hook 1.00
10 A-111 Sliding Collar 1.00
11 B-37 Cam Washer 1.00
12 B-39 Cam Split Washer 1.00
13 B-25 Cam Lock Wing Nut 1.00
14 M-216 Bent Brace 2.00
15 B-18A Yoke Bolt 2.00
16 B-19 Yoke Nut 2.00
17 M-249 Black Rubber Cable Connector 1.00
18 B-63 Cable Grommet 1.00
19 G-16 Handle Tube Cable 1.00
20 B-67 Rectangular Hole Came Washer 1.00
21 C-100-1 Cam Handle Assembly 1.00
CCA (See Exploded
View)
Complete Cam Assembly Kit (Includes 1 of
each drawing: 21, 20, 11,12, 13)
1.00
22 G-48 Insulated Flag Wire Connector 2.00
23 G-30-A On/Off Switch Plate Assembly 1.00
24 B-68 Ground Wire Screw 2.00
25 G-30-B Switch Mounting Plate 1.00
26 B-1 Switch Plate Screw 2.00
27 B-35 Int. Tooth Lock Washer for Switch 1.00
28 B-33 Lock Washer 1.00
29 G-30-CT057 Trigger Return Spring 1.00
30 A-103 Switch Box Front 1.00
31 G-47 Wire Connector 1.00
32 A-105 Trigger 2.00
33 M-211-A 16” Crossbar 1.00
34 SIA-1 Safety Interlock Assembly 1.00
35 B-70 Trigger Pin 2.00
36 B-22 Crossbar Screw 2.00
