MERELLO ME-104 Technical manual

MATTRESSES WRAPPING MACHINE ME 104
INSTALLATION, USER AND MANTENIANCE MANUAL

INSTRUCTION MANUAL ME-104 2
NOTIFICATION OF CE MARKING
The Manufacturer: MERELLO Ingenieros, S.L.
c/Horcajo 20, nave 23
PINTO – 28320 – MADRID - SPAIN
Declare that the product: mattresses wrapper machine ME-104 s/n 1139
Has been developed in accordance with the European Directive 98/37/CE (22nd
June 1.998) and shows compliance with the Normative EN414. EN292,
EN1050, EN945, EN418 and EN1088 when used as directed by the
appropriate documentation
Signed: Miguel Merello Arvilla, industrial engineer
Madrid, August 2.007

INSTRUCTION MANUAL ME-104 3
1. GENERAL MACHINE DESCRIPTION
The machine ME 104 wraps automatically every kind of mattresses (springs, latex, foam,…)
from polyethylene rolls. The machine provides advance of the mattress trough the film and
adjusts itself to the appropriate measures. The finished mattress is ready to be stocked
The machine is compound by the following elements:
EM2
S3
BOX 2
S4
M3
M6
BOX 3
M1
FC1
M7
S2
M4
M5
S7
BOX 1
S1
FC0
M2
S5
S6
MODULE 1MODULE 3 MODULE 2
Module nº1: Mattress In-feed: receive the mattress, put it on position for wrapping and measures
the length for adjust the corresponding sealing bars distance. The machine detects a new mattress
automatically and starts moving the in-feed conveyor. This module contains the upper and lower
rolls of film. For sincronice with in-feed lines, (Y15 output) is ON when the machine is ready
Module nº2: middle sealing: receive the enfold mattress from the previous module, seals all along
and separates the bag from the rolls, cutting it by blade
Module nº3: lateral sealing: receive the wrapped mattress from the previous module, seals both
sides, cut the waste of film by blade and give the mattress away.
Control cabinet: keeps the electrical and electronic components that provide the control of the
machine. A screen allows the man-machine dialogue, input parameters and show error messages.
In order to reduce the electrical peaks, the machine avoids the activation of both welding bars
at the same time. This way, a half-wrap mattress waits for the sealing of the previous.
The machine complies with safety requirements of CE as expressed on last chapter
TECHNICAL DATA
AERIAL NOISE: 70 dB(A)
WEIGHT MODULE 1: 1.400 Kg
WEIGHT MODULE 2: 800 Kg
WEIGHT MODULE 1: 1.600 Kg

INSTRUCTION MANUAL ME-104 4
2. MACHINE INSTALATION
Every element of the machine has its own adjustable legs that allow the installation in any surface
Main job during installation consists on
leveling the machine and couple the
different modules. For this it is
recommendable a burble level
For electrical connections, each module
has cables to connect directly to the control
cabinet and between them. For more
information, see the scheme at the end of
the manual
The machine spends about 4 KW (two
phases electrical energy 220 VAC) while
seals and about 40 l/min. of dry, clean
compressed air at 6 bar.
INSTALLATION PROCEDURE
1.- allocate the module nº1 on its final
position and level
2.- allocate the module nº2 besides the nº1.
Put it to level and align both
3.- bring the module nº3 near the nº2,
leaving 1 m of free space between both
4.- connect cables C23 and C32 to box 3,
following scheme attached
5.- install the waste ramps if they are dismounted (EXTRA-LONG model)
6.- install the sealing bars if they are dismounted (EXTRA-LONG model)
7.- move the module nº3 to its final position besides nº2. Put it to level and align both
8.- install the fix and the movable ascending ramps
9.- install the lateral guards
10.- install and plug the EMERGENCY WIRE
11.- connect cables C2 and C3 to the control cabinet, following the schemes attached
12.- put the machine under voltage (220 VAC). Don’t forget the frame ground to earth
13.- introduce a mattress and effectuate a complete cycle without film. Verify everything works
14.- put the upper and lower reels of film (see section 3) and make a join between them
15.- introduce a mattress. See section 6 for fine adjustment
•SYNCHRONIZING WITH PREVIOUS LINES: the green light (Y15) on the control
cabinet lights when the machine is ready to accept a new mattress. It is possible to activate
an external relay (24Vdc) parallel to it (between Y15 and 0V)
•SYNCHRONIZING WITH FOLLOWING LINES: the mattress will not leave the

INSTRUCTION MANUAL ME-104 5
machine if the input signal X12 remains ON (wired to 24Vdc)
3. LOADING OF THE FILM AND STARTING UP
Place a roll of polyethylene (max. 150 Kg.) on the upper pair of rollers and other one on the
lower pair, keeping the correct side for welding
NOTE: some printed rolls will not join by the printed face due to the chemical
treatment received.
The same could occur with re-enforcement rolls for the top or bottom of the
mattress, because they will be join for the both faces
If this kind of problem appears, please ask your film provider
For the correct guided
of the film, see the
figure attached
The film surface
tension depends on the
adjustment of the
passing trough lever.
This adjustment is the
same for every kind of
mattress and must be
carried out with the
lightest to be wrapped.
In order to give more
tension to the final bag,
you can operate over
the extra advance time
on the keyboard (see
chapter nº 5)
When change a roll, it is necessary to make a seal along the upper and lower rolls. Pull the film
trough the guides (by hand or acting over the plastic lever) and press the key ‘CENTRAL
SEAL’ (see chapter nº 5)
After these adjustments, press the START/STOP button to put the machine ready to work
Please note that the machine will not work while any of the doors stay opened or the
emergency stop is pressed. The screen and lights will indicate this situation

INSTRUCTION MANUAL ME-104 6
ME-104: PLASTIC FILM INSTALLATION

INSTRUCTION MANUAL ME-104 7
4. CYCLE OF THE MACHINE
As a safety measure (CE), the machine won’t be ready to work after turn it ON until the
START/STOP button is pressed. After this, the green light on this button will remain ON and
the machine will work while ON (until a new acting over the button will be executed or an
alarm will occur).
By pressing the START/STOP button twice, the machine will perform a step by step cycle,
which allows analyzing or introducing adjustments
When the machine is turned OFF, it loses any information about the actual cycle. Due to that,
after turn it ON you should verify that there are not half wrapped mattresses on any of the
modules
The machine can vary between different working modes that can be selected on the screen and
act in the following ways:
WITH/OUT PRESS M3: select whether or not the press on the 3
rd
module is going to work.
This press is intended to approach the borders of the mattress and increase the adjustment of the
bag
A special input (X13) is also provided for remote exchange of the press estate, and can be
wired from 24Vdc direct to the PLC. When activated, the second Xtra-advance is applied
instead of the first and the press is annulated for the mattress being in-feed.
WITH/OUT WHEELS M1: select whether or not the wheels on the 1
st
module are going to
work. The wheels are intended to catch the mattress against the conveyor for assure the
advance trough the machine.
WITH/OUT WHEELS M2: idem for second module
BEFORE/LATER ACT. WHEELS M2: select when the wheels on the second module must be
deactivated. BEFORE the welding bar means more adjusted bags and less wrinkles. AFTER
the welding bar can be necessary with very light mattresses
WITH/OUT SEAL SIDES: select whether or not the up and down sides of the mattress are
going to be sealed. Normally they must to be, but in special cases (rolling bags, foam,…) they
must to be opened
The machine controls the sealing temperature by software. The program on the machine has a
temperature simulator that compensate the accumulative heat when is used a high rates. This
value increases proportionally during welding and decreases exponentially the rest of the time.
At any time, the heating time programmed is reduced in function of the value of this
simulation, avoiding the raise of the temperature on bars
By pressing the EMERGENCY STOP or pulling the EMERGENCY WIRE the energy is
removed from the actuators, every movements of the machine are cancelled and the machine
status is moved to STOP. After release it, the energy appears again but the machine remain

INSTRUCTION MANUAL ME-104 8
stopped until START/STOP button is pressed. Then, the cycle will resume to the previous point
(first, it’s necessary to remove the causes of the problem and realize if the mattress need to be
re-introduced. In this case, the best is turn the machine OFF an the ON to start to work from the
beginning)
By open any of the doors, every movements of the machine are cancelled and the machine
status is moved to STOP. After close it, the machine remain stopped until START/STOP button
is pressed. Then, the cycle will resume to the previous point
The meanings of the lights are:
•Green light: the machine will accept a new mattress to wrap
•Yellow light blinking: the machine is working at any point
•Yellow light steady: the machine has been stopped by the green button, in the middle of
a cycle
•Red light blinking: emergency stop is pressed or emergency wire is pulled or a door is
opened or an alarm has occurred. The screen shows the status
•Red light steady: emergency has been eliminated, but the machine is not working until
START/STOP will be press

INSTRUCTION MANUAL ME-104 9
5. MANTENIANCE
EVERY WEEK: remove the waste from the cutting cylinder case in order to avoid damages
EVERY WEEK: check the oil level on the compressed air filter. Refill if necessary
EVERY MONTH: clean the air filter on the control cabinet
EVERY MONTH: test the differential switch, by acting over the TEST button
•CARE OF THE BLADES AND TEFLON COVERS
The blades that cut the film are maintenance free and under normal situations last a lot. When
the blade results damaged it’s necessary to exchange for a new one. For replace the blade,
dismount the cover, untaught and pull carefully the old one and insert the new one
The Teflon covers last between 30.000 and 100.000 processes, depending on the gross of the
film and the heat conditions. When they are half used up, silicone sprayed could help to last
longer.
For covers substitution, please use self-adhesive 0,15 mm thick Teflon fabric
•REPARATION OF RODLESS CYLINDERS:
4
1
2
5
3
REPAIR KIT
1. air connection
2. end caps
3. out seal strip
4. inner seal strip
5. shuttle

INSTRUCTION MANUAL ME-104 10
6. FINE ADJUSMENT
Even though the machine has been tried at factory, the final conditions can differ. These are some
different adjustment that allow to achieve the most perfect bag
TERMICAL ADJUSTMENT OF THE SEALS
By varying the sealing parameters, the machine can join any kind of film. The criterion depends
on the final goal:
-higher speed: ▲power, ▼time heating, ▼time cooling
-less electrical energy, more duration of covers: ▼power, ▲time heating
-more esthetic seals: ▲time cooling
-thicker film: ▼power, ▲time heating, ▲time cooling
-very inelastic film: ▼time cooling, ▲time waiting
ADJUSTMENT OF THE BAG
The final adjustment of the bag to the mattress depends on several points:
-how long the mattress advance over the central seal bar
-how strech is the film during the tie up
The fastest way to change the bag adjustment is by acting on the first point, directly on the
keyboard. In the line EXTRA ADVANCE change the value (cents of second that the mattress will
advance over the seal bar). Note that a too low value can provoke the mattress to be catch by the
bar
The stretch of the film must be between two limits: no too high, because can broke the join at one
or both sides, and no too loose, because can present unwinding problems. Note that the stretch is a
combination of the position of the lever, the relative speed of the film respect to the advance of the
mattress (adjustable by inverter) and the relative speed of the film respect to the bar when moves
down. For initial adjustment, keep the speed of the rolls as similar as posible to the advance of
mattress (watch the lever angle to stabilizate), and adjust the speed of the arm to the desired
stretch
The position of the central seal can be moved by changing one of the film stretch
LONGITUDINAL ADJUSTMENT OF THE BAG
When wrapping mattresses thicker than 10 cm, the press compresses its top and bottom in order to
approach the border before sealing, leaving a better adjusted bag.
On depending on the kind of film and mattress, to achieve this could be easier by keeping some
distance between the mattress and the sealing bar. This adjustment is made by:
-fix side: move the fix end on the module nº1 in order to approach or separate the mattress
-movable side: change the data on the keyboard called LATERAL ADJUSTMENT (bigger
values provoke bigger separation) or move the end-detectors
SPECIAL ADJUSTMENT WHEN USING BOOT SYSTEM
In order to keep the same strenght on every roll, is very recommendable to reduce the rolls speed a
little. This way, the coneyor will help for unwinding the rolls, avoiding different speeds
Also, the parameter ‘Time retro roller’ can be increased with the same purpose

INSTRUCTION MANUAL ME-104 11
7. TOUCH SCREEN
The touch screen is placed on front of the electrical cabinet, and it allows the following
functions:
•shows error and status messages
•introduce different working modes
•introduce control parameter
•activate elements of the machine
PASSWORD: to operate other than the main screen, a password will be requested. In the
beginning, this password is ‘00000000’. The button PWD (in the DATA screen) allows the user
to change the inner password table and introducing different users
This option can be disconnected by acting over the Switch nº8, on the back of the screen
The main screen shows the status message. After an alarm occurs, the message line explains the
alarm that occurs. These messages are:
•Emergency stop (even after it’s been released)
•Door opened (even after it’s been closed)
•Inicializing: while moving the machine to the initial position
•Ready: the machine will accept a new mattress
•Working: there is a mattress in-feed
•Stopped: the START/STOP button was pressed and the machine is waiting
•Error on D3/D4: the length detectors D3 or D4 on M1 (when included) have
been activated with no cycle. They could be broken or to high sensibility. Check
the problem and press START/STOP button to resume
•Error on S3: the movement of the central sealing bar hasn’t reach the final
position. The reason could be: the bar has catch a mattress, the detector has
moved a little down, or the order to move didn’t activate the electro valve
•Error on phase 2: the wrap of the mattress exceeds the time limit. After check
the problem, move the mattress up to pass the sealing bar (F3 key) and press
STAR/STOP button to resume the cycle
•Technical stop: contact technical service

INSTRUCTION MANUAL ME-104 12
The effect of the function keys is the following (the machine should be in STOP mode):
•Seal C: make a seal on the central bar.
•Seal L: make a seal on the side bars
•Belts: advance of conveyor nº 2 y 3
•-Film: retro of the film rollers
•<Char: advance of movable seal bar
•>Char: retro of movable seal bar
The rest of the information on other screens show parameters that can be changed. To change a
value, touch it directly. Then a keyboard appears on the screen and let you write the new value
(press ENTER for finish). If the value is not between the acceptable ranges, the display will
reject it
DATA MENU:
•ALTERNATE BUTTON LAT.SEAL: when activated, the seals on the 3
rd
module
(lateral seals) are made on each bag. When deactivated, the mattress leaves the machine
directly from the first seal
•ALTERNATE BUTTON PRESS M1: when activated, the wheels on the 1
st
module (in-
feed conveyor) descend to increase the pressure of the mattress against the belt, avoiding it to
slip
•ALTERNATE BUTTON PRESS M2: when activated, the wheels on the 2
nd
module
descend to increase the pressure of the bagged mattress against the belt, avoiding it to slip
•ALTERNATE BUTTON bef/aft: when BEFORE and PRESS M1 are activated, the
wheels on the 2nd module release before seal, to avoid wrinkles. When AFTER (and PRESS
M2) are activated, the wheels keep connected to ensure that the mattress is not catch by the
sealing bar.
•ALTERNATE BUTTON RAMPS: when activated, the ramps on the 2
nd
module ascend

INSTRUCTION MANUAL ME-104 13
before sealing to avoid the film to retract on the mattress advance. Is useful for sticky film
•ALTERNATE BUTTON PRESS M3: when activated, the press on the 3
rd
module
descends to approach the edges of the mattress and increase the adjustment of the bag before
sealing. Don’t use it with hard beds (wood)
•ALTERNATE BUTTON DARK/LIGTH: this button works only with the polarity of the
barrier photocell FC1: when DARK, the barrier photocell FC1 need to be OFF while the
mattress is passing. When LIGTH, need to be ON
•BUTTON PWD: give access to the password table, to change or add new users
•BUTTON HEATING: give access to the heating menu (see below)
•BUTTON MEASURES: give access to the measures menu (see below)
•XTRA ADVANCE: time in cents of second while the mattress stays advancing over the
central welding bar. A higher value induces bigger advance before soldering, and the bag will
be looser. The first value will be applied by the machine when X13 is OFF (the second, when
ON). Aprox. values: 10-30
•LENGTH ADJUSTMENT: time in cents of seconds (+/-) that is subtract from the
measure in Module nº1 to adjust the aperture of the bars in Module nº3. This adjustment can
also be achieved by approaching or separating the inductive detectors of this parts. A positive
value will provoke a bigger separation in module nº3 Aprox.: 0
•ADVANCE PRESS M3 (when equipped): advance of the press in Module nº3 over the
mattress to approach their faces and assure the traction. After this advance, the welding bar
down to make the join. Aprox.: 7-12
•MAX. PRESS M3: the first value shows the maximum number of teeth that the press
will count before activate the seal, even if it is not mattress detected. Is only for sizing
purposes, the second number shows the number of teeth already counted, and helps to
calculate the first
•TIME PRESS M1: time in tenth of seconds during which the wheels over conveyor in
Module nº1 push on the mattress to assure the traction. After this time, the wheels up to avoid
a shock against the conveyor. Aprox.: 10-20
•DELAY PRESS M2: time in tenth of seconds during which the wheels over conveyor in
Module nº2 wait to push on the mattress to assure the traction. This permit the mattress to start
advance during wrapping. Aprox.: 10-20

INSTRUCTION MANUAL ME-104 14
MEASURES MENU
•BUTTON DEFAULT: load the default parameters value. Also allows to change the
language of the messages
•SELECTOR AUTO/MANUAL: select between automatic adapt to the measures of the
mattress or not
•BUTTON BARRIER: allows to work with an additional protection barrier at the output
•BUTTON UNSTICK: provokes the machine to make a small movement of the rollers in
order to unstuck the film for the next mattress
•T-RETRO ROLLER: time in tenth of seconds during which the upper and lower rollers
reverse their rotation after wrapping, for stretch and recover the excess of film. Aprox.: 5-10
•EXIT TIME: time in tenth of seconds during which the conveyor in Module nº3 is
running after welding to allow mattress leave the machine. A value higher than necessary will
delay the entrance of the next unit. Aprox.: 30-60
•MINIMUM LENGTH: maximum advance of the measuring bar in module nº1 to avoid it
to shock against the conveyor. The mattress will be wrapped even if is littler than this. Aprox.:
250
•SIZE M2: value relative to the length of the second conveyor, in order to activate the third
conveyor when the mattress exceeds the corresponding size. A bigger makes the third
conveyor to start later. Aprox.: 40-60
•SIZE M3: value relative to the distance between bars in module nº1 and bars in module
nº3, in order to calculate the necessary advance of the mattress. A bigger value provokes the
mattress to advance more. The right value makes the mattress to stop in the beginning of the
module nº3. Aprox.: 200-300

INSTRUCTION MANUAL ME-104 15
•BIGGER-SMALLER: values to distinguish if two consecutives mattresses are the same
length or not. Minor is the negative difference under which the bar in module nº3 will need to
re-locate. Mayor is the positive one. If this value is big enough two different mattresses will
be processed as if were the same length. Aprox: -6, +6
•BLOWER M1: the first number is the delay in tenth of seconds for the blowers in M1 to
be activated to help removing wrinkles. The second time is the duration of the blow,
adjustable to avoid the bag hit the lateral bar
•BLOWER M3: time in tenth of seconds during which the blower in M3 is activated to
help removing waste. Aprox.: 10-20
•SIZE>2M:the first value is the number that, when exceeds, provokes the machine to
make two seals instead of one. The second value show the wide of the present mattress, and
helps to calculate the first
•ADVANCE1 >2M: shows the time in cents of second that the mattress will advance for
make the first seal, if the mattress is >2m (previous point). Then, the mattress will advance up
to the normal position to make the second seal
•TOTAL PRODUCTION: shows the number of units processed by the machine from the
first day to now.
HEATING MENU:
•T HEAT CENTER: time in tenth of second during which power is applied to the central
welding bar. This value will be reduced by the temperature compensation system (see below).
The amount of power can also be regulated in the control cabinet P1. Valor aprox.: 25-50
NOTES:
 The grosser the film is, the lower this value must be
 Too high power values will reduce the Teflon covers life
 Too low values will increase the cycle time

INSTRUCTION MANUAL ME-104 16
•T COLD CENTER: time in tenth of second after heating during which the bar stay down
to allow the film to solidify. Aprox.: 10-40
•T HEAT LATS: time in tenth of second during which power is applied to the lateral
welding bar. This value will be reduced by the temperature compensation system (see below).
The amount of power can also be regulated in the control cabinet P2. Valor aprox.: 30-60
•WAITING CENTER: time in tenth of seconds that the mattress is waiting for the bar of
Module 2 to open. Aprox.: 5-10
•WAITING SIDES: time in tenth of seconds that the mattress is waiting for the bars of
Module 3 to open. Aprox.: 5-10
•TIME CUTTER CENTER: the first value is the time in tenth of seconds that the central
cutter will wait to activate (aprox 5). The second, the time during which the blade travel
trough the film in the central bar to separate the bag. After this time, the blade will back to its
position. Aprox.: 20-30
•TIME CUTTER S: the first value is the time in tenth of seconds that the lateral cutter
will wait to activate (aprox 5). The second, the time during which the blade travel trough the
film in the side bars to separate the rest of film. After this time, the blade will back to its
position. Aprox.: 20-30
•COMPENSATION: graphically shows the quantity to be subtracted from the
programmed time (T.HEAT) to compensate the actual temperature of the bars
•TEMP. SIMULATED: temperature of the welding bars calculated by the program. It
increased proportionally when heating and decrease exponentially the rest of the time. Is used
for introduce a corrective factor when the machine is used continuously, in order to avoid over
heating (see chap. 7)
•GAIN Q: value that increases the simulated temperature each tenth of second while
heating. Aprox.: 10
•GAIN F: value (center and sides) that decreases the simulated temperature while not
heating. It is apply each two seconds subtracting a division of the value (Temp/value) from the
simulated temperature. Aprox.: 8-15
TEST MENU:

INSTRUCTION MANUAL ME-104 17
Give access to every output on the PLC, for monitoring and modify (some of them need to put
the PLC in STOP mode to be accepted). Useful for maintenance actions

INSTRUCTION MANUAL ME-104 18
8. INSTRUCTIONS FOR SAFETY
♦The load of the rolls is dangerous and need two or more people
♦The doors of the machine should remain closed. When a door is opened, the cycle stops and
waits for the START/STOP button
♦The machine detects automatically the arrive of a new mattress, and put the conveyor to move
so, therefore no objects must be put on it to avoid obstructs and accidents
♦The cuts are made by blade which could cause injuries in hands and arms. The operation of
exchange must be realized protected with gloves
♦The seals are achieved by heating. The wrong use of the bars can cause burn on hands or arms
♦ The machine is intended for wrapping mattresses. The use for wrapping other kind of things
can result in injuries or accidents

INSTRUCTION MANUAL ME-104 19
9. PART LIST
FASE Plano ID Cant Descripción
1 1 UCF205 16 Bearing flange type UCFL 205
1 2 UCP204 2 Bearing bridge type UCP 204
1 3 FC1 1 Photocell barrier emitter Telemecanique XUK-2AKSNL2T
1 4 PP1i 2 Polycarbonate door smoked 620x1120x8
1 5 BIS 4 Polypropylene door joint
1 6 FCBIS 2 Safety switch Telemecanique XCSPL591
1 7 FC0 1 Photocell barrier receiver Telemecanique XUK-5APANL2
1 8 PLACA1 2 Steel entrance plate
1 9 BANDA1 1 Conveyor belt PVC NAB-10ELBV 2250X3115
1 10 UCPA206 4 Bearing bridge type UCPA 206
1 11 M2 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
1 12 M1,4,5 3 Motoreducer Bonfiglioli VF44 P1 20 P71 B14, 0,37KW i=20
1 13 EV1,2,3 3 Electrovavle Univer 5/2 1/8 24 VDC G6250
1 14 CIL0 2 Cylinder Univer ISO 32 80 D.M
1 15 PP1d 1 Polycarbonate door smoked 620x1120x8
1 16 MANI 2 Door latch ref 5608
1 17 FC1 1 Photocell barrier receiver Telemecanique XUK-2APANL2R
1 18 GUB1 1 Steel plastic guide Ø50 x 3050
1 19 RU1R 2 Nylon wheel Ø200
1 20 D3,D4 2 Steel detector with inductive
1 21 S2,S7 2 Film tensor Ø20 with inductive
1 22 RUL 8 Roller for film Ø108 x 3050
1 23 FC2 1 Photocell barrier receiver XUM-5APANL2
1 24 CIL1 1 Cylinder Univer ISO 32 160 D.M
2 1 PP2d 2 Polycarbonate door smoked 765x880x8
2 2 CIL4 2 Cylinder Univer ISO 40 320 D.M
2 4 CP21 1 Guards sealing bar blade side
2 7 CP22 1 Guards sealing bar connections side
2 8 CIL3 2 Cylinder Univer ISO 63 400 D.M
2 9 CIL6 2 Cylinder Univer ISO 25 50
2 10 S3 1 Inductive detector Univer ISO63
2 11 PP2t 2 Polycarbonate door smoked 865x880x8
2 12 FCBIS 4 Safety switch Telemecanique XCSPL591
2 13 M7 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
2 14 ESET 4 Baquelite resistance terminal
2 15 NICR408 6 Resistance NiCr 4x0,8 (1m)
2 16 CELO2010 6 Celotex base spline 20x10 (1m)
2 17 NEOP2010 6 Neoprene self-adhesive 20x10 (1m)
2 18 BL 1 Trapezoidal blade (10 units)
2 19 PBL 1 Blade base
2 20 CIL5 1 Rodless cylinder Univer Ø16x3050 S1004163050
2 21 BANDA2 1 Conveyor belt PVC NSL-10ELAV 2250X3115
2 22 RU2L 2 Nylon wheel Ø200
2 23 UCPA206 4 Bearing bridge type UCP 206
2 24 UCFL205 4 Bearing flange type UCFL 205
3 1 PLACA3F 1 Steel fix ramp
3 2 PRT 2 Polyurethane plate for waste
3 3 BANDA3 1 Conveyor belt PVC NSL-10ELAV 2250X4035 (4635 p/EXTRA WIDE)
3 4 PLACA3M 1 Steel movable ramp

INSTRUCTION MANUAL ME-104 20
3 5 M3 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
3 6 S4 1 Inductive detector RESCHNER M12 4mm 30VDC
3 7 LGR15 2 Lineal guide HIWIN LGR15 w/bearing LGH15
3 8,9 PP3 4 Polycarbonate door smoked 910x880x8
3 10 PM3Z14 4 Rotative gear M3 Z=14
3 11 CP3 2 Guards sealing bar lateral side
3 12 CIL11 4 Cylinder Univer ISO 40 400 D.M
3 13 CIL7 4 Cylinder Univer ISO 40 320 D.M
3 14 UCPA206 4 Bearing bridge type UCPA 206
3 15 M6 1 Motoreducer Bonfiglioli VF44 P1 20 P71 B14 B3, 0,37KW i=20
3 16 S5 1 Switch detector with Ø45 wheel
