Merrithew Tower Trainer User manual

Please review this important assembly, safety and warranty information about your new
Merrithew™equipment and keep it handy for future reference.
OWNER’S MANUAL
Tower Trainer

17.
PART IDENTIFICATION
Tower Trainer™Owner’s Manual2
26.
24.
.
29.
28.
30.
32.
31.
21.
22.
23.
19.
16.
18.
20.
1Eyehook
2Upper Tube Assembly
3Safety Chain
4Spring Clip
5Large Securing Knob
6Light Arm Springs (Yellow)
7Left Sliding Stability Bar Holder
8Roll-Down Bar
9Foam Grip Handles
10 Left Upright
11 Wheel Cap
12 Outer Cover
13 Base Frame
14 Main Frame
15 Handle Strap
16 Round Feet
17 Serial Number Sticker (see pg. 5 for detail)
18 Extension Frame
19 Raised Extension Mat
20 Raised Main Mat
21 Locking Knob
22 Raised Base Mat
23 Inner Cover
24 Right Upright
25 Push-Thru Bar
26 Push-Pin
27 Fuzzy Hanging Straps [fig. A]
28 Right Sliding Stability Bar Holder
29 Spring-loaded Pin
30 Sliding Stability Bar
31 Padded Sliding Stability Bar Sleeve
32 Rolldown Spring (Black)
33 Single D-ring Strap [fig. B]
34 Leg Springs (White) [fig. C]
35 Padded Long Spine Straps [fig. C]
36 Push-Thru Spring (Blue)
37 Vinyl Spring Cover [fig. D]
38 Locking Spring Clip [fig. D]
39 Bolt-on Wheels [fig. E]
Tower Trainer™
Hardware Identification QTY
40 Screw, Round Head (M4 x 20mm) 4
41 Bolt, Button Head (M8 x 1.25 x 50mm) 2
42 Bolt, Button Head (M8 x 1.25 x 55mm) 2
43 Bolt, Button Head (M8 x 1.25 x 60mm) 4
44 Bolt, Button Head (M8 x 1.25 x 76mm) 8
45 Acorn Nut (M8 x 1.25) 4
46 Nylock Nut (M8 x 1.25) 12
47 Washer (M8) 8
48 Arc Washer (M8) 16
49 Lock Washer (M8) 4
Covered by one or more of the following patents and/or patent applications:
US 8,057,371 B2, 7,878,954 B2, US Application No. 11/329,252, US Application No. 12/233,968,
US Application No. 60/642,985, PCT International Application No. 2006000814.
Required Tools
1/4" (6mm) Hex Key
Adjustable Wrench

C
A
34
33
27
35
B
3
11
6.
5.
7.
10
1.2.3.
13
8.
4.
9.
12
15
14
D
E
36
37
39
38
38

SAFETY & USAGE
Tower Trainer™Owner’s Manual4
IMPORTANT!
This manual contains important assembly, safety and
warranty information. Read the manual carefully
before using your new equipment and keep the
manual on hand for future reference.
UNSAFE OR IMPROPER USE OF THIS EQUIPMENT
BY FAILING TO READ AND COMPLYWITH ALL
REQUIREMENTS ANDWARNINGS COULD RESULT
INSERIOUSINJURY.
It is impossible to predict every situation and
condition that can occur while using this equipment.
Merrithew™makes no representation about the
safe use of any exercise equipment that cannot be
predicted or avoided.
PLEASE DO NOT ATTEMPT TO ASSEMBLE ON YOUR
OWN. SOME OF THESE STEPS REQUIRE TWO PEOPLE.
PLEASEREAD THESE INSTRUCTIONS COMPLETELY
BEFOREBEGINNING ASSEMBLY.
Merrithew recommends cautious assembly and
usage andwishesyou many hours of safe and
effectiveexercise.
User Guidelines
Pilates equipment when used effectively can faciliate many
Pilates exercises safely and effectively. However, care and caution
must be taken as there are some inherent dangers when using
any exercise equipment — especially when spring resistance
isinvolved.
The Trainer comes equipped with a full compliment of
springs,straps and a safety chain. The springs can be attached
tovarious locations on the frame, or on the straps hooked
aroundthe sliding bar. Besure your spring clips are completely
closed and secure.
For inexperienced or first-time users, this equipment
should only be used under the supervision of a
trainedprofessional.
Please ensure that you and your clients/patients have
receivedproper instruction regarding the correct and safe
useofthis equipment.
This manual includes general guidelines for setup and usage.
To get the most out of this equipment, Merrithew offers
instructional DVDs and manuals. Personalized training is offered
through our Host, Licensed and Corporate Training Centers.
Visit merrithew.com for more information.
CAUTION IMPROPER USE OF EXERCISE EQUIPMENT MAY CAUSE SERIOUS BODILY INJURY. TO REDUCE RISK, PLEASE READ THE FOLLOWING:
wThe Tower Trainer™must be used under the supervision
of a trained professional.
wBefore starting any exercise program, consult a physician.
Stopexercising immediately if you experience chest pain,
feel faint, have difficulty breathing or experience discomfort.
wBefore using equipment, read and follow the safety
instructions in this manual and obtain thorough instruction
from a qualified trainer. Use equipment for intended
exercises only.
wDo not use if equipment appears worn, broken or damaged.
Donot attempt to repair equipment yourself without
contacting Merrithew.
wDo not wear loose clothing while using the Tower Trainer.
wSet up and operate the Tower Trainer on a solid level
surface. Do not position the Tower Trainer on loose rugs or
uneven surfaces.
wMake sure that adequate space is available for access to
and around the Tower Trainer.
wEnsure the equipment is properly adjusted for your size
and ability level.
wWhen springs are used, ensure spring clips are fully closed
at both ends of springs. A spring clip that is only half closed
risks coming undone and detaching with high force.
wWhen using the push-thru bar with spring from below,
locking spring clips must be used to attach to the frame or
uprights, and the safety chain must be attached.
wWhen using the push-thru bar, a trained professional must
keep a hand on the bar at all times.
wEnsure that the Main Frame is secured properly on the
Base Frame with the locking knobs before using the
TowerTrainer.
wAlways make sure that the Dowel Holder is adjusted to the
same height with Spring Pins in parallel holes in Uprights.
wAlways choose the workout which best fits your physical
strength and flexibility level. Know your limits and train
within them. Always use common sense when exercising.
wBe careful to maintain your balance while using, mounting,
dismounting or assembling the Tower Trainer, loss of balance
may result in a fall and serious injury.
wThe Tower Trainer should not be used by persons weighing
over 250 lbs (113 kgs).
wThe Tower Trainer should be used by only one person at a
time. Do not allow children to use or be around equipment
withoutadult supervision.
WARNING: As with any athletic activity, the use of
exercise equipment involves risk of injury, damage
and/or death.
By choosing to use Merrithew equipment, you and/or
your clients/patients assume responsibility for that risk,
not the people who sell, distribute and/or manufacture
this equipment.

48
28
29
46
5
1. Attach the bolt-on wheels [39] to the base frame [13] by
inserting the button head bolts [44] and arc washer [48],
secure with arc washer [48] and nylock nut [46].
2. Attach the left [10] and the right uprights [24] to the base
frame [13] by inserting the button head bolts [44] and arc washers
[48] from top and secure with arc washers [48] and nylock nut
[46] from bottom. Do not tighten the bolts until step 6.
NOTE: The correct positions of the holes and eyehooks on
the left upright and right upright in the illustration. The holes
face away from the raised base mat [22] and the eyehooks
face to the outside.
3. Pull the spring-loaded pin [29] then slide the right sliding
stability bar holder [28] onto the right upright [24]. Release the
spring-loaded pin so it catches in one of the adjustment holes and
locks the holder in place. Repeat with the left sliding stability bar
holder [7] and left upright [10]. Position the left and right sliding
stability bar holders so they are the same distance from the top of
the left and right uprights.
NOTE: The correct position of the eyehooks on the sliding stability
bar holders in the illustration. The eyehooks face to the outside.
7
10
24
48
44
39
44
13
22
SERIAL NUMBER
PLACEMENT
48
step 1
step 3
step 2
17
ASSEMBLY INSTRUCTIONS
Assembling the Tower Trainer
STOP! Please do not attempt to assemble on your own. This is, at minimum, a job for two people.
Read these instructions completely before beginning.
wPlace all parts from the box in a cleared area and position on thefloor in front of you.
wRemove all packing materials and place back into the box. Do not dispose of the packing materials untilassembly iscompleted.

28.
24.
44.
30.
49.
45.
40.
23
step 6
ASSEMBLY INSTRUCTIONS
Assembling the Tower Trainer cont’d
Tower Trainer™Owner’s Manual6
4. Attach the sliding stability bar [30] to the left and right
sliding stability bar holders [7, 28] with button head bolts [43],
lock washers [49] and acorn nuts [45]. Do not tighten
the bolts until Step 6.
NOTE: The padded stability sleeve can easily be removed
by undoing the zipper.
5. Insert the upper tube assembly [2] into the left and right
uprights [10, 24] and secure with the large securing knobs [5].
NOTE: The correct position of the holes and eyehooks [1]
on the upper tube assembly [2] in the illustration below.
6. Tighten the button head bolts [43] to secure the sliding stability
bar [30]. Tighten the button head bolts [44] to secure the left and
right upright [10, 24].
7. Attach the outer cover [12] and inner cover [23] to the right
upright [24] with round head screws [40]. Repeat on other side.
2.
1.
43.
5.
7.
10
12
step 5
step 4
step 7

7
step 9
step 8 18
42
47
46
21
14
13
47
46
41
8. Place the main frame [14] with the mat side face down.
Attach the extension frame [18] by placing it (mat side up)
on top of the mat frame, aligning hinge brackets.
Use button head bolts [42], washers [47] and nylock
nuts [46] to secure together.
9. Unfold the extension frame [18] from the main frame [14]
and turn the mat side face up. Attach the Main frame [14] to the
base frame [13] with button head bolts [41], washers [47], and
nylock nuts [46]. Lock the main frame [14] and the base frame
[13] together with the locking knobs [21].
Care and Cleaning
Wipe vinyl surfaces using warm water with mild soap and
clear water rinses for day-to-day cleaning. Ensure soap does
not leave an oily residue, or make surfaces slippery.
Clean all metal surface areas as required, using a soft cloth
and gentle cleaner. CAUTION: We do not recommend using
chemical-basedproducts.
WARNING
Replace all springs every 24 months and spring clips
every 12 months, or as needed within that period.
FAILURE TO PERFORM RECOMMENDED SAFETY
CHECKS, OR USING EQUIPMENT WITH IMPROPERLY
ADJUSTED, BROKEN OR WORN PARTS, COULD RESULT
IN SERIOUS BODILYINJURY.

10
26
EQUIPMENT SET-UP
Tower Trainer™Owner’s Manual8
Safety & Usage
Sliding Stability Bar Adjustment
To adjust the height of the Sliding Stability Bar [30], pull out
on the spring-loaded pins [29] and carefully slide the bar to the
desired location. Release the pins and ensure they are fully locked
in one of the holes. The bar also comes with a soft padded
covering to increase comfort and usability.
NOTE: Always make sure that the sliding stability bar holders
[7, 28] are adjusted so the bar is parallel with the mat.
Set-Up For The Push-Thru Bar
Attach the push-thru bar [25] to the top adjustment hole
in the uprights [10, 24] with two upper push-pins [26].
Attach the safety chain [3] to the eyehook [1] on the top of the
upper tube assembly [2]. For some exercises, the push-thru bar
[25] should be up and secured in position with the safety chain
[3]. The push-thru bar [25] can be used as a foot bar for some
exercises. Attach the push-thru bar (25) to the lowest adjustment
hole in the upright [10, 24] with two upper push-pins [26].
Lock the push-thru bar [25] to the uprights [10, 24] with
two lower push-pins [26].
NOTE:
wThere are three adjustment holes in the uprights that allow you
to attach the push-thru bar [25] at one of the different heights.
wRefer to the inset illustration. Push down the button on the “T”
end of the push-pins [26] to release. Then you can insert
the push-pin [26] into the adjustment hole.
wAlways make sure the safety chain [3] is connected when the
push-thru bar [25] is in use in the rotating positions.
1.
2.
3.
29.
28.
25.
24.
30.7.

2.
3.
25.
24.
4.
37.
36.
1.
4.
36.
38.
25.
9
Using the Push-Thru Bar
Springs from Above
When doing exercises that require the spring resistance to come
from above the bar, attach the push-thru spring [36] to the
eyehook on the upper side of the push-thru bar [25] with the
locking spring clip [38]. Attach the other end of the push-thru
spring [36] to one of the eyehooks [1] on the upper tube
assembly [2] with the spring clip [4].
CAUTION: To prevent accidental injury, never put your face
(or another body part) above the push-thru or roll-down bars
while spotting an exercise.
Springs from Below
CAUTION! If using the push-thru bar with springs from
below, attach safety chain first.
1. When using the push-thru bar [25] with the push-thru spring
[36] attached from below for bottom load exercises, connect
one end of the safety chain [3] to one of the eyehooks [1] on
the upper tube assembly [2] with the spring clip [4]. Connect the
other end of the chain to the eyehook on the push-thru bar [25]
with the spring clip [4] as per illustration below.
2. Hook the spring to the eyehooks located at the base on the
other side of the upright [10 or 24] with the spring clip [4];
see illustration below. Ensure that the vinyl spring cover [37]
which covers the push-thru spring [36] is moved over the lower
part of the spring to avoid catching the user’s hair or clothing,
and to keep the spring from coming into contact with the
upholstered raised mat.
3. Attach the push-thru spring [36] to the loop on the underside
of the push-thru bar [25] with the locking spring clip [38],
as per illustration below.
Be sure that the safety chain is always connected to the push-thru
bar when in use with springs from below.
38.
10.
4.

9.
6.
35.34.
38
EQUIPMENT SET-UP
Tower Trainer™Owner’s Manual10
Roll-Down Bar
The roll-down bar [8] attaches via the rolldown springs [6]
to the eyehooks [1] on the upper tube assembly [2] between the
twouprights [10, 24] with the spring clip [4]. Attach the arm
springs [6] to the roll-down bar [8] with the spring clip [4].
Ensure the spring clips are completely closed and secure.
Springs
Light Arm Springs – yellow
Attach light arm springs [6] to eyehooks at desired height
with the locking spring clip [38]. Attach the other ends of the
springs to the foam grip handles [9] with the spring clips [4].
Ensure the spring clips are completely closed and secured.
Leg Springs – white
Attach leg springs [34] to eyehooks at desired height with the
locking spring clips [38]. Attach the other ends of the springsto
the padded long-spine straps [35]. Ensure the clips are completely
closed and secured.
1.
4.
6.
10.
4
8.
2.
24.
Safety & Usage cont’d

To order, visit merrithew.com/replacementparts or email [e-mail]
11
Storage & Mobility
WARNING: When folding or unfolding the Tower Trainer™, keep all children away from the Tower Trainer and make sure hands and feet are
clear of any folding or pinch point.
Folding
a. Move any attached accessories to the back side of the tower so
the mats can fold up against the sliding stability bar [30].
b. Ensure upper and lower push-pins (26) are inserted with the
push thru bar (25) locked down.
c. Remove the locking knobs [21] to unlock the main frame [14].
d. With one hand on one of the handle straps [15] on the raised
main mat [20], and one hand on the extension frame [18], slowly
lift the main frame [14] and extension frame [18].
The extension frame [18] will fold down against the
main frame [14] as you lift.
e. When both frames are in the most vertical position possible,
parallel to the left and right uprights [10, 24], secure the
main frame [14] to the left and right uprights [10, 24] with the
locking knobs [21].
Unfolding
a. Unscrew the locking knobs [21] from the uprights completely.
b. With one hand on the handle strap [15] of the raised main mat
[20], and one hand on the extension frame [18], carefully extend
it completely to rest on the floor.
c. Replace the locking knobs [21] securing the main frame [14]
tothe base frame [13] and fully tighten for security.
Moving
To move the Tower Trainer, it must be folded. The push-thru bar
must be locked down. While on the wheeled side of the folded
Tower Trainer, grasp the upper tube assembly [2] with one hand,
place your foot against the base frame [13], and hold the upright
with your other hand. Pull the Tower Trainer toward you while
holding the base steady with your foot until the wheels come in
contact with the floor. Then roll the Tower Trainer while holding
the upper tube assembly [2] and right upright [24] to steady and
guide the Tower Trainer.
Storing
Store the Tower Trainer in a clean, dry place.
25.
14/20.
24.
26.
13.
2.
16/18
15.
21

Replacement Parts
For more information and to place an order, visit merrithew.com/replacementparts or email [e-mail]
MAINTENANCE & REPLACEMENT PARTS
Fuzzy Hanging Straps
Soft and woolly, these add extra comfort
and securit. Sold in pairs.
Large Securing Knob
Use to secure upper tube assembly
to uprights.
Locking Knob
Use to lock in folded or unfolded position.
Replacement Spring Package
Replace springs every 24 months, or as
needed within that period. A complete
replacement spring package is available
and includes:
wleg springs (2) wroll-down springs (2)
warm springs (2) wpush-thru springs (2)
wspring clips (10) wlocking spring clips (6)
Light Arm Springs, Yellow
Sold as a pair with four spring clips.
Leg Springs, Green
Sold as a pair with four spring clips.
Push-Thru Springs, Blue
For use with push-thru bar. Sold as a pair
with four spring clips (2 locking/2 regular).
Roll-Down Bar
Shown with springs attached.
Sold separately.
Roll-Down Springs, Black
Supports the roll-down bar. Can also
function as regular arm springs. Sold as
apair with four spring clips.
Foam Grip Handles
Cushioned and rounded, these provide
extracomfort.
Single D-Ring Straps
Connecter for attaching springs
to stability bar.
Padded Long Spine Straps
Also available without padding.
Tower Trainer™Owner’s Manual12

Optional Items
Gripper Mat
Non-slip rubber mats are handy to
increase traction and prevent slipping.
A Gripper Mat can be wrapped around
push-thru bar [64], roll-down bar [62],
uprights or placed on upholstered beds.
Foam Cushions
Available in three sizes. Used for comfort
and additional support when performing
a wide variety ofexercises.
A: 9"x 6"x 1" / 23 x 15 x 2.5 cm
B: 9"x 6"x 3" / 23 x 15 x 7.6 cm
C: 13"x 10"x 2.5" / 33 x 25.4 x 6.4 cm
Eco-Friendly Pilates Pad
Non-slip eco-friendly pads can help
establish correctalignment and positioning
or to provide cushionedsupport.
Reformer Box
Used to facilitate or vary exercises.
Safety Chain
For use with push-thru bar.
CAUTION: Safety chain must be in place
when using push-thru springs from above.
Push-Pin
Used to secure push-thru bar.
Spring Clips
Replace spring clips every 12 months or
earlier as needed.
CAUTION: Locking spring clips are
required when using pu sh-thru bar with
springs from below. Do not use non-
locking spring clips.
Metal & Maple Roll-Up Poles
This solid maple roll-up pole is used
to increase scapular awareness while
performing exercises. Sold separately.
Extension Straps
Assists alignment of the knee
jointAvailable in 24" or 26" lengths.
Arc Barrels
Ideal to increase or decrease challenge
and to assist rehab clients. The Arc Barrel
Deluxe addscomfort withBalticBirch hand
grips on the sides.
Padded Platform Extender
Provides a raised padded surface on
theupholstered bed for seated or
standingexercises.
Padded Sliding StabilityBar Sleeve
Removable covering adds cushioning to
sliding stability bar.
13

Tower Trainer™Owner’s Manual14
THE FINE PRINT
Warranty
Merrithew™warrants that all new equipment is free of manufacturing defects in workmanship and materials, subject to the terms below.
Thiswarranty becomes effective at the invoice date of the original purchase. Parts repaired or replaced under the terms of this warranty
willbe warranted for the remainder of the original warranty period.
It is the purchaser’s responsibility to notify the Company of any change of contact information. This ensures, that in the unlikely event
ofareplacement or safety notice, we are able to contact you immediately.
This warranty applies to equipment only:
w While it remains in the possession of the original purchaser and proof
of purchase is demonstrated
wIf claims are made within the part-specific warranty period
w If upgrades are made as required by Merrithew
This warranty shall be null and void if:
w Equipment failure is a result of improper assembly,
installationormaintenance
w The equipment is used for any other purpose other than as
intended, or is stored or used outdoors, or in environments
without adequate climate/humidity controls
wEquipment has been subjected to accident, misuse, abuse,
improperservice, or any modification not authorizedbyMerrithew
This warranty does not cover damage to the finish of any equipment
nor shipping charges, customs clearance fees (if applicable), or any costs
incurred in installing repaired or replacement parts shipped under the
provisions of this warranty.
Failure to change springs every two (2) years may void warranty.
Five (5) Year Limited Warranty
Merrithew will, at its option, repair or replace any of the parts listedbelow,
provided that the part(s) fail due to a defectin workmanship or materials:
wvertical bars and overhead frame
wcomponents of the frame and related welding
Two (2) Year Limited Warranty
Merrithew will replace springs that fail for any reason, provided suchfailure
is reported to MERRITHEW within a period of two years fromthe invoice
date of the original purchase. We recommend that springs be changed
every two (2) years
One (1) Year Limited Warranty
On other parts and components. We recommend that spring clips
be changed annually.
90-Day Upholstery Fabric Warranty
The vinyl fabric upholstery and spring sleeves will be replaced if they
fail to give normal wear for 90 days after delivery. Proof of damage
may be required. This warranty does not cover cuts, burns, stains,
soiling, petdamage or damage caused by other unreasonable use.
Thiswarranty does not apply to fabrics cleaned with abrasive, corrosive
orchemical cleansers. If the identical fabric is not available, Merrithew
willprovideanequivalent.
Disclaimer of Implied Warranties and LimitationofRemedies
Repair or replacement of defective parts is your exclusive remedy under
the terms of this limited warranty. In the event of parts availability issues,
Merrithew will not be responsible for any consequential or incidental
damages arising from the breach of either this limited warranty or any
applicable implied warranty, or for failure or damage resulting from acts
ofnature, improper care and maintenance, accident, alteration, replacement
of parts by anyone other than Merrithew, misuse, transportation, abuse,
hostile environments (inclement weather, acts of nature), improper
installation or installation not in accordance with local codes or
printedinstructions.
This limited warranty is the sole express warranty given by
Merrithew. No product performance, specification or description
wherever appearing is warranted by Merrithewexcept to the extent
set forth in this limited warranty. Any implied warranty protection
arising under the laws of any state, provinceor territory including
implied warranty of merchantability or fitness for a particular
purpose, oruse, is hereby limited in duration to the duration of this
limited warranty.
Neither distributors, dealers, web resellers, nor the retailers selling this
product have any authority to make any additional warranties or to
promise remedies in addition to, or inconsistent with those stated above.
Merrithew’s maximum liability, in any event, shall not exceed the purchase
price of the product paid by the originalpurchaser.
IMPORTANT
Please keep this manual in a safe place.
If you have questions, issues or are missing parts:
Do NOT return this unit to your local retailer,
please contact the manufacturer directly.
[e-mail]
416.482.4050 |1.800.910.0001 |0800.328.5676 UK |ext. 0907
Mechanical Safety Check
Proper maintenance and timely replacement of your equipment or component parts is your responsibility.
Conduct a regular inspection of the following:
Daily
wClean all surface areas after each use,
using a soft cloth and gentle cleanser.
Weekly
wCheck all springs and spring clips for wear
and damage and replace as needed.
Monthly
wEnsure all nuts, bolts and screws are securely fastened.
wEnsure eyehooks are securely fastened.
Yearly
wReplace all spring clips.
Every Two Years
wReplace all springs.
REPLACE ALL SPRINGS EVERY 24 MONTHS AND SPRING CLIPS
EVERY 12 MONTHS OR AS NEEDED WITHIN THAT PERIOD.
FAILURE TO PERFORM RECOMMENDED SAFETY CHECKS, OR
USING THE MACHINE WITH IMPROPERLY ADJUSTED, BROKEN OR
WORN PARTS, COULD RESULT IN SERIOUS BODILY INJURY.

Tower Trainer™Wall Chart: This full-size poster, measuring 27"x 39", depicts exercises featured
in the STOTTPILATES®Programming on the Tower Trainer™and CORE Athletic Conditioning
& Performance Training on the Tower Trainer™programs. Each exercise is described with
name,equipment accessories, one photo, as well as suggested repetitions.
Our Wall Charts are printed with vegetable-based inks on FSC paper.
A step-by-step exercise guide for the Tower Trainer repertoire can
be downloaded by visiting merrithew.com/guide
Make the Most of Merrithew™Equipment
As Leaders in Mindful Movement™, Merrithew is committed to developing unique, top-quality fitness programs
based on the latest in exercise science and research. Our signature STOTT PILATES®education is unparalleled,
and we bring the same expertise and passion to our full range of branded programs, including CORE™Athletic
Conditioning and Performance Training™, ZEN·GA®, Total Barre™and Halo®Training. Join our global community
of elite fitness professionals. Merrithew courses and workshops are offered worldwide.
Find courses and workshops near you at merrithew.com/education/training
Contact Us 416.482.4050 | 1.800.910.0001 | 0800.328.5676 UK | ext. 300
Take Advantage of our Training Tools
Instructional DVD: Focusing on the biomechanical principles of STOTT PILATES®while using
the variouscomponents of the Tower Trainer™to develop core stability and improve flexibility.
Enjoythis hybrid workout of Pilates and traditional fitness moves that increase overall
strengthandconditioning.
We offer almost limitless exercise challenges in our clear and detailed repertoire of cutting
edgetitles. For a full listing visit merrithew.com/shop/dvds

Please keep this manual in a safe place.
IMPORTANT
This is your Tower Trainer Serial Number:
Go to merrithew.com/warranty
to activate your warranty!
Get the benefits:
wEnsure that you’ll be able to repair it under warranty should you encounter a problem.
wMake warranty service fast and efficient by having your information in our records.
wIn the unlikely event of a replacement or safety notice, we’ll be able to contact you immediately.
wProof of purchase for insurance purposes in the event of a loss due to fire, flood or theft.
wStay informed of any product updates.
Can’t get online?
Please fill out the warranty card enclosed with this product, and return to us.
2200 Yonge Street, Suite 500, Toronto, Ontario, Canada M4S 2C6
416.482.4050 | 1.800.910.0001 | 0800.328.5676 UK | ext. 0907
[email protected]om | merrithew.com
P00215 PM-ST02093A-2 SEPT17 ™/® Trademark or registered trademark of Merrithew Corporation, used under license. Printed in Canada. All rights reserved.
