Merry Products CUBBY SHELF MPG-EF01L User manual

Page 1
v. 4.0
CUBBY SHELF MPG-EF01L
PRODUCT
R R YE
S
M
Step 1: Secure Side Panels (A and B), Dividers
(C and D) and Bottom Panel (G) to Back
Panel (E) using b screws. Step 3: Secure Feet (H) to Bottom
Panel using a screws.
Step 4: Insert all d Pins into Side
Panels and Dividers.
Step 5: Insert Shelves (I) into place.
Step 6: Insert Shelf Lips (J) into place
and secure with b screws.
Step 2: Secure Top Panel (F).
Step 7: Secure Cubby to wall with e
L-Brackets using c screws.
* This step is optional, but recommended.
x 4
x 4
x 4
x 4
D
A
B
C
G
F
x 4
c
b
b
b
b
b
b
b
b
b
b
b
b
cc
c
1 Left Side
Panel (A)
1 Right Side
Panel (B)
1 Right
Divider (D)
1 Left
Divider (C) 1 Back Panel
(E)
1 Top Panel
(F)
1 Bottom Panel(G)
4 Feet (H)
5 Shelves (I)
6 Shelf Lips
(J)
d
NOTE: • Read all instructions before starting.
• Phillips Screwdriver recommended for assembly.
a
b
c
Screws 33 pcs + 1 extra
Screws 8 pcs + 1 extra
Screws 6 pcs + 1 extra
Flat Brackets (1 pc) *
*Needed Only for Stacking
f
e
d
L-Brackets (2 pcs)
Pins (20 pcs)
d
dd
b
b
b
b
bbb
bb
b
b
b
b
b
bbbbbb
b
a
a
aa
a
a
aa

STACKING INSTRUCTIONS
Step 1: Do NOT attach feet
to second unit
* Skip step 3 of assembly on
page 1.
Step 4: L-brackets
* This step is optional, but recommended
for both sides.
Step 2: Place second unit on top.
Step 3: Secure both f Flat Brackets
to the back of both units.
* This step connects the two units
together at the back.
Page 2
CUBBY SHELF MPG-EF01L
PRODUCT
R R YE
S
M
Do NOT attempt to lift a unit by yourself. If you would like to have two
units stacked, two people are recommended to assemble and move this unit.
v. 4.0
c
c
c
c
c
c
c
c
c
c

Page 3
CUBBY SHELF MPG-EF01L
PRODUCT
R R YE
S
M
v. 4.0
CARE INSTRUCTIONS
Thank you for choosing MERRY PRODUCTS’™ FURNITURE.With little care and maintenance,
MERRY PRODUCTS’™ FURNITURE will provide you with comfort and enjoyment for many years to come!
• MERRY PRODUCTS’™ FURNITURE may be used both indoor and outdoor.
• The Cubby Storage Unit has been treated with an oil-based stain. If used outdoors, staining or
repainting with an oil-based weatherproof coating of your choice before use, and continued
once a year, may increase the life expectancy and maintain the look of MERRY PRODUCTS’™
FURNITURE.
• Cover the Cubby Storage Unit duing harsh weather to keep it from weathering.
• Rinse any panels with water to clean.
• When assembling MERRY PRODUCTS’™ FURNITURE, please handle all panels and/or hardware
with care to avoid any possibilities of damages and/or injuries.
