Merry Products MPG-ACE030KIT User manual

- Place Back Rest Cross Beams in order.
- Insert (a) screws partially through Back
Rest Panel C1, C3 and C5. See Figure 1.
- Position screw ends on pre-marked center
points on Back Rest Cross Beams.
- Postition Back Rest Panels C2 and C4 into
place with (a) screws and secure.
Figure 1
Right Arm
Rest (A1 R) Left Arm
Rest (A1 L)
Left Front
Leg (F1 L)
Right Front
Leg (F1 R)
CHAIR COMPONENTS
Back Rest Panels
Right Base
Leg(B1)
Left Base
Leg(B1)
Top Back Rest
Cross Beam (C9)
Back Support (E)x2
Arm Rest
Connection(D)x2
Bass Bottom
Support (B4)
Seat Slats (B5)x5
Front Seat
Slat (B3)
Bottom Back Rest
Cross Beam (C10)
(34 pcs + 2 spare)
(10 pcs + 1 spare)
12
Page 1
v.2.0
Read all instructions before starting.
Do not completely tighten all bolts until the unit is fully assembled.
b
c
d
HARDWARE
(4 pcs + 1 spare)
(8 pcs + 1 spare)
*Powerdrill recommended
for assembly.
CARE INSTRUCTIONS
This is an Unfinished, Solid Fir Wood Adirondack Chair. It is HIGHLY RECOMMENDED that you treat the
chair with a WEATHERPROOF COATING (stain or paint) before use, and continued once a year, to
increase the life expectancy and maintain the look of the chair. Please consult with your local hardware
store on the weatherproof coating options for the chair.
•Cover the Adirondack Chair duing harsh weather to keep it from weathering.
•Rinse any panels with water to clean.
•When assembling MERRY PRODUCTS’™ ADIRONDACK FURNITURE, please handle all
panels and/or hardware with care to avoid any possibilities of damages and/or injuries.
NOTES:
TOOLS RECOMMENDED
# 13mm
C1 C2 C3 C4
C5
Supporting
Block(A2)x4
C9
C10
C5
C3
C1
a
a
C4
C2 a
a
a
MPG-ACE030KIT CHILD’S ADIRONDACK CHAIR KIT
*Powerdrill

Page 2 v.2.0
34
56
8
- Position Back Rest Panel on to the Base Legs(B1)
and on to the Back Support (E).
- Secure the Back Rest Panel on to the Base Legs(B1)
using (a) screws.
- Secure the Back Rest Panel on to the Support(E)
using (b) screws.
- Attach Supporting Blocks (A2)on to
the Back of Arm rests (A1)using
(b) screws.
7
- Position Right and Left Front Legs(F1)to
place on Base Legs(B1)and secure with
(d)bolts, as shown on the drawing.
- Attach Arm Rest Connections (D) to
Right and Left Front Legs (F1)
using (a)screws.
B1
B1
B3
B4
a
a
a
B5
a
a
a
F1R F1L
D
Da
a
A1R
A1L
A2
A2
A2
A2
b
b
b
b
E
E
d
d
d
d
a
a
(a) screws.
- Position Front seat slat (B3) and Base Bottom
Support (B4) into place on Base Legs (B1)
and secure with
- Position all 5 Seat Slats (B5) into place
and secure with (a) screws.
- Position Right and Left Support (E)to
place on Base Legs(B1)and secure with
(d)bolts.
F1R
F1L
b
b
- Do not tighten bolts completely.
MPG-ACE030KIT CHILD’S ADIRONDACK CHAIR KIT
C9
C10

Page 3 v.2.0
- TIGHTEN ALL BOLTS COMPLETELY with chair on level
surface.
9
- Assemble Arm rests (A1) onto Front Legs (F1)
and Back Support (E) using (c) bolts.
MPG-ACE030KIT CHILD’S ADIRONDACK CHAIR KIT
C
C
C
10
- Child’s Adirondack chair is now complete.
F1
E
- NOTE: For easy alignment, do not tight
bolts completely.
A1
A1
