Mesqool CR1001F User manual

- 01 - - 02 -
Chapter 2 POWERING ON
1. Install 2pcs 1.5V “AAA” size batteries to the proper terminals in
the battery compartment to memorize the time/alarm setting in
case of power outage.
Note: Without AC power in, batteries don't support time display ,but alarm
will still goes off.
2. Connect the adapter line to DC jack , then plug into a 100~240V
AC wall power outlet.
Chapter 1 LOCATION OF CONTROLS
CR1001F Alarm Clock with Time Projection
CREATE YOUR PERFECT SLEEP ENVIRONMENT
SNOOZE
SLEEP
Mad e in China Version 3.0
1.SET TIME BUTTON
2.HOUR BUTTON
3.MINUTE BUTTON
4.DIMMER/DST BUTTON
5.SNOOZE/OK BUTTON
6.ALARM 1
7.ALARM 2
8.ALARM ON/PAUSE
9.PROJECTION ON/FLIP/OFF
10.VOLUME+ BUTTON
11.VOLUME- BUTTON
12.AM INDICATOR
13.PM INDICATOR
14.ALARM 1 INDICATOR
15. ALARM 2 INDICATOR
16. DST INDICATOR
17. FOCUS RING
18. BATTERY COMPARTMENT
19. USB PORT
20. DC JACK
21.SPEAKER
22.HOLDER ( x 2pcs)
23. PROJECTION DIMMER
10
11
123456789
12
13
14 17
SNOOZE
SLEEP
15
16
18 20 19
21
22
17
23
Contact our experts
[email protected]
Http://www.mesqool.com
ALARM OF F
HOL D PRESS FO R
ALA RM OF F
HOL D PRESS FO R

- 05 -
- 04 -- 03 -
Chapter 5 PROJECTION MODE
1. Press projection mode button to turn on projection.
2. Press button once again to flip the projection
reversely when the time projected backwards.
3. Press once again to turn off projection.
PROJECTION
ON/FLIP/OFF
PROJECTION
ON/FLIP/OFF
PROJECTION
ON/FLIP/OFF
Turn OFF
Note: 1. Best projection distance is 1.5 to 3.0 meters (4.92 to 9.84 feet).
2. Projector is a common LED light. So the projector is not visible in bright
environment.
4. Rotate focus ring to adjust clarity of projection image.
Note: if projection is fuzzy,please rotate the focus ring (17) to adjust
angle for clear image.
1. Press button, the alarm indicator will light up,
the display starts flickering.
2. Press button to set the hour, press button to set
the minute.
3. Press button or button to save alarm time or
just wait for another 10 seconds to confirm automatically.
4. Press or button to adjust alarm volume.
5.Press button to save volume setting.
Turn off Alarm
When alarm goes off:
1. Press button to temporarily turn off alarm for 9
minutes. Alarm will ring every next 9 minutes.
2. Press button or button to turn off alarm for 24
hours. The alarm indicator is still on, which means alarm is
still activated and will ring after 24 hours.
3. When alarm is off, press button to active the alarm,
setting will be the same as last time.
4. Cancel Alarm
Hold press button until the alarm indicator will
disappear from the display, the alarm will never goes off.
Setting ALARM 2 is the same as ALARM 1.
Chapter 4 ALARM SETTING
ALARM
1
1
VOL+ VOL-
1
ALARM
1
HOUR MIN
1
ALARM
1
SNOOZE
SNOOZE
Chapter 3 TIME SETTING
1. Press button once, display starts flashing.
2. Press button to set the hour. press button to set
the minute.
3. Press button to save time or wait for another 10
seconds to confirm automatically.
4.To change 12H/24H time format
Hold press to change 12H/24H time format.
SET
TIME
HOUR MIN
SET
TIME
SNOOZE
ALARM
1
Chapter 6 PROJECTION DIMMER
Chapter 8 USB CHARGING
Our projection clock has a USB Charger Port, which can charge
both your phone or tablet at the same time.
The maximum charge current is 1 Ampere.
22:23
2
89%
E
E
1
Repeat press button to adjust the brightness of display for
your preference.
Hold press button to switch DST function.
Chapter 7 DIMMER & DST
DIMMER
DST
DIMMER
DST
SNOOZE
- 06 -
press button to adjust the brightness of projection for
your preference.
ALARM
ON/PAUSE
PROJECTION
DIMMER
ALARM
ON/PAUSE
