Sharper Image SI785 User manual

CD/Radio
Alarm Clock
with Sound Soother
®
SI785 Instructions

Features Include:
•AM/FM/TV audio.
•Programmable radio presets.
•Quality CD sound reproduction
in a compact unit.
•Aluminum cone-driver speakers.
•20 Sound Soother®sounds.
•Alarm/Temperature/Month/Date
displays.
•Programmable sleep-timer.
•Ramp-up alarms with Snooze-
BoostTM variable alarm delay.
•Battery or adapter powered.
•Headphone and subwoofer jacks.
•40 second ESP (electronic shock
protection), reduces skipping
during CD playback.
List of Features
PRESS
TO
UNLOCK
SUBWOOFER &
HEADPHONE JACKS
A subwoofer connection
adapter/cable has been
included in this product box.
(Subwoofer sold separately.)

Display and Controls
LCD SCREEN
PANEL CONTROLS
Alarm On/Off
Mode (Settings)
Display
Number Buttons
Memory & Alarm Demo
Hear Time
Sleep Timer
Pre-programmed audio
equalizer (EQ)
Snooze-Boost and Light
AUDIO CONTROLS
Power
Audio Selection
CD Program/Repeat
CD Play/Pause
CD Stop
Tuning
Volume

Power Requirements
Activate the two CR2032
back-up batteries by removing
the paper tab from the battery
compartment. Replacement of
these batteries is required every
2-3 years.
Install 6 AA alkaline batteries.
Use only fresh/new batteries in
this product. Replace all 6 used
batteries when the low battery
icon flashes.
To eliminate the need for AA
batteries, use the AC adapter
designed for this product.
NOTE: Using the AC adapter
will allow the display light
to remain on when LIGHT is
pushed.
ADAPTER
JACK
BATTERY COMPARTMENT
(Bottom of unit)
BACK-UP BATTERIES
(Inside battery compartment)
9K/10K SWITCH
(See radio section of manual.)

BATTERY SAFETY
Batteries may leak or explode if recharged, inserted improperly,
inserted in the wrong direction, disposed of in fire, or mixed with
different battery types.
Only replace with fresh, new batteries. It is important batteries
are inserted in the correct orientation. (See the diagram inside the
battery compartment.) Batteries positioned incorrectly may leak.)
RESET
If this product does not operate
properly, insert the tip of an
unbent paperclip (or similar)
into the opening to reset the
display and memory.
Additional Information

Setting the Clock
Press MODE twice.
(Current time setting
flashes on the display.)
Press 1 to decrease hours,
2 to increase.
Press 3 to decrease
minutes, 4 to increase.
Press and hold buttons
to rapidly change the
setting.
If no additional buttons
are pressed, the setting
is saved and the display
returns to normal.
MODE
Press Twice
BUTTONS
1, 2, 3 & 4
Adjust Clock
Press the “HEAR TIME” button to have the current time
announced.
HEAR
TIME

Year and Temperature Display
Press MODE three times.
(Year and temperature
display flashes.)
Press 3 or 4 to change
temperature display
between Fahrenheit or
Celsius.
Press 1 to decrease year,
2 to increase.
Press and hold buttons
to rapidly change the
setting.
If no additional buttons
are pressed, the setting
is saved and the display
returns to normal.
BUTTONS
3 & 4
Switch °F / °C.
BUTTONS
1 & 2
Adjust Year

Setting the Month and Date
Press MODE four times.
(Current date setting
flashes on the display.)
Press 3 to decrease date,
4 to increase.
Press 1 to decrease month,
2 to increase.
Press and hold buttons
to rapidly change the
setting.
If no additional buttons
are pressed, the setting
is saved and the display
returns to normal.
BUTTONS
3 & 4
Adjust Date
BUTTONS
1 & 2
Adjust Month

Setting the Alarm
Press MODE.
(Alarm time and icon flashes on
the display.)
Press 1 to decrease hours, 2 to
increase.
Press 3 to decrease minutes, 4 to
increase.
Press and hold buttons to rapidly
change the setting.
Press 5 to change and select
alarm volume. (LO/Soft, HI/Loud,
UP/Ramp-up.)
Press ALM ON/OFF to activate
or deactivate the alarm. (Icon is
visible if alarm is activated.)
If no additional buttons are
pressed, the setting is saved and
the display returns to normal.
BUTTONS
1, 2, 3 & 4
Adjust Alarm
Time
ALARM ON/OFF
Activate/Deactivate
Alarm
BUTTON
5
Adjust Alarm
Volume
Options

Press MODE one time, then
press DISPLAY to change the
type of alarm sound.
If CD is the alarm sound, press
TUNING up or down to select
wake-up track.
When alarm sounds, press ALM
ON/OFF to silence alarm and
reset it for the next day. Press
again to cancel the alarm.
SNOOZE-BOOST
To postpone the alarm once it
sounds, press SNOOZE/LIGHT.
Each press of this button adds
10 minutes to the delay time.
(Pressing three times will give
you a 30-minute delay.)
Alarm Features
MODE
Press Once
DISPLAY
Change Alarm
Sound
TUNING
Select CD Track
SNOOZE/LIGHT
Delay Alarm

Audio Controls
Press SLEEP from 1 to 6 times
to turn the audio on for 15 to
120 minutes. Power will shut off
automatically.
Press POWER to turn on for
continuous play.
Press SOOTHER to play Sound
Soother environment sounds.
Press band to play AM/FM and
TV audio.
Press CD
>
|| to play or pause
CD.
Press EQ to rotate through
audio equalizer options.
Press POWER to manually
turn the audio off at any time.
SLEEP
Set Auto Off
POWER
Turns Audio On
SOOTHER
BAND
CD
Selects Audio Choice

Press POWER or Press SLEEP
(1 to 6 times)
Press SOOTHER
LCD screen indicates number
of currently selected sound.
Use SOUND GUIDE located on
the lower portion of the display
to match the desired sound to
its index number.
Change the selected sound by
pressing TUNING up or down.
Stop by pressing POWER or
select a different audio option
(CD or RADIO).
Sound Soother Feature
B
u
o
T
r
a
SLEEP
Set Auto Off
POWER
Turns Audio On
SOOTHER
Activates Sound Soother
TUNING
Changes Sound Selection
SOUND GUIDE
Displays Selection

CD Player - Basic Operation
Press CD OPEN and firmly
press CD onto spindle.
Press POWER or Press SLEEP
(1 to 6 times)
Press CD
>
||
(Play/Pause)
LCD screen indicates number
of track on current CD.
Change the selected track by
pressing TUNING up or down.
Stop by pressing POWER or
select a different audio option
(SOOTHER or RADIO).
Because of the high power requirements of the CD player,
use of the AC adapter is strongly recommended for extended
or frequent CD playing.
This player features electronic shock protection (ESP), which
reduces skipping caused by sudden movement. The ESP is
automatically activated when a CD is being played.
CD OPEN
TUNING
Changes CD Track
CD
Activates Player

CD Player - Play Options
SONG LOOP
Press RPT/PRG one time while a
song is playing to lock the current
song on the continuous play loop.
(Screen displays ONE loop icon.)
CD LOOP
Press RPT/PRG two times while a
song is playing to lock the current
CD on the continuous play loop.
(Screen displays ALL loop.)
RANDOM PLAY
Press RPT/PRG one time while
CD is stopped to play all songs in
random order. The start playing
by pressing CD
>
||
.
(Screen displays RND.)
RPT/PRG
While Playing: Press once
to loop song. Press twice to
loop CD.
While Stopped: Press once
to select random playback,
then press CD
>
||
to play.
SCREEN ICONS
Indicate Selected Options

CD Player Programming
Press RPT/PRG two times while
the CD is stopped to enter the
programming mode.
(Screen displays PGM under CD
icon and program information on
the track display area.)
Press TUNING up or down to
select song track number.
Press RPT/PRG to choose the
selected track and advance the
playlist number.
Program up to 20 songs (tracks) in
any order.
Press CD
>
||
(Play/Pause) to begin
playing.
Press STOP to cancel at any time.
RPT/PRG
While Stopped: Press twice
to enter program mode.
TUNING
Changes Sound Selection
SCREEN ICONS
Indicate Selected Options

24 Hour Clock and International Radio
CHANGE TO 24 HOUR DISPLAY
Press MODE until the time setting flashes.
Advance hours by pressing 2 until it passes 12 midnight,
the display will now be in 24-Hour mode. 3:00 PM will be
displayed as 15:00. (Advancing past 24:00 will return clock
to 12-Hour mode.)
CHANGE RADIO SETTING
Press MODE until the country code setting flashes.
(USA/United States of America, EU/Europe, JP/Japan.)
Press 1 or 2 to sequence through the setting options.
This product is normally shipped with the radio and time
display set to US default. Use the following procedures to
change between worldwide radio options as well to change
the time display between 12-Hour or 24-Hour modes.

Antenna and Reception
The TV audio band (US version)
requires a strong broadcast signal
and will not operate properly in
areas located away from a broadcast
or relay station.
FM radio reception can be optimized
by adjusting the length and position
of the built-it external FM antenna.
Many stations will come in clearer
with the antenna less than fully
extended.
Because of an internal antenna,
AM/MW radio reception can be
improved by adjusting the position
or location of the product itself.
NOTE: TV Audio is featured only in
the US version of this product.
FM
AM/MW

AM/FM/TV Audio and Preset Stations
PROGRAMMING:
(Radio must be on.)
Tune to station.
Press MEM/DEMO
Press any button 1-6.
Repeat using a new station and
preset number.
RECALLING:
Press the desired number 1-6 to
recall previously set stations.
There are 6 presets available for each audio band.
MEM/DEMO
Press to activate.
BUTTONS 1-6
Press to save as preset.

Statement of FCC/DHHS compliance
Model: SI785
WARNING:
Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
NOTE:
This product complies with DHHS Rule 21 subchapter J at date
of manufacture.
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the
FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential instal-
lation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation.
If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for
assistance.

CLASS 1 LASER PRODUCT
CLASS 1 LASER PRODUCT
APPAREILA LASER DE CLASSE1
PRODUCTO LASER DE CLASE 1
PRODUTO LASER CLASSE1
CAUTION
INVISIBLE LASER RADIATION WHEN
OPEN AND INTERLOCKS
DEFEATED.
This product contains a low power laser device.
d
s
e
e
e
e
-
o
e
o
e
r
e
e
