MESSER WS5X36 Installation guide

1
Messer Repair & Fabricating
Wood Splitter/Tree Shear
Assembly & Instruction Manual
Model WS5X36
Use this manual for safety instructions and operating instructions.
Make sure that everyone who operates this machine has read this manual completely!
Save for future use.
42739 COUNTY ROAD 184
SAUK CENTRE, MN 56378
320-352-3477 - FAX [phone]
WWW.MESSERREPAIR.COM
3-17 (3.2)

2
Introduction
MRF's Wood Splitter/Tree Shear has been built for ease of operation and long service life. It is
important that you thoroughly understand the operation of this unit before use. Read through
this manual completely, watching especially for safety symbols (see illustration below) which
will alert you to possible safety hazards.
Caution!
This safety alert symbol is used throughout this manual to identify possible safety
hazards. It is the user's responsibility to read the operator's manual and comply with all
the instructions pertaining to operation and maintenance.
It is also the user's responsibility to inspect the machine at regular intervals and repair
or replace worn or damaged parts when continued use would cause damage or
excessive wear to other parts. The word "Important" is used to point out a note which
is of an immediate and urgent nature.
The manufacturer reserves the right to make improvements, discontinue or change
specifications, models or design without notice and without incurring obligation. When
ordering parts for your Wood Splitter/Tree Shear, please specify the part description.
Please give the serial number of the Wood Splitter/Tree Shear in all correspondence
when referring to the Wood Splitter/Tree Shear. Record the serial number and
purchase date here for future use.
Owner's Record:
Date of Purchase _________________Model No. ____________Serial No._________________
Dealers name and address________________________________________________________
______________________________________________________________________________
IMPORTANT: When this unit is traded or sold, make sure this manual accompanies the
unit so future operators will have complete operating instructions and safety warnings
available to them.

3
Safety Instructions
CAUTION: This unit should never be operated by anyone who is not familiar with the product
and has not read the instruction manual. Do not allow children to operate or play on or around
this equipment.
NEVER: Use this Wood Splitter/Tree Shear for any other purposes than splitting/shearing wood.
It is designed for this use only. Any other use can cause serious injury or death.
oAll persons operating this unit should read and understand instruction manual
oRead and understand all safety decals located on the Wood Splitter/Tree Shear
oKeep safety decals clean and legible at all times
oReplace safety decals that are missing or become illegible
oDo not allow anyone to play on or around the Wood Splitter/Tree Shear
oALWAYS establish a safety zone restricting bystanders to a 100 foot radius around the
Wood Splitter/Tree Shear when it is in operation.
oALWAYS operate the Wood Splitter/Tree Shear with a clear mind, free of the influence
of alcohol, drugs or medication.
oALWAYS wear close fitted clothing, free from lanyards, strings or jewelry which could be
an entrapment hazard.
oBefore operating unit inspect for loose or damaged bolts or parts and make necessary
repairs before starting.
oHigh pressure oil leaks can penetrate skin causing serious injury. Do not use your finger
or other skin to check for leaks.
oKeep hands, feet and clothing away from moving parts
oALWAYS keep the work area clean.
Caution!
Important: Do not hand feed material into Wood Splitter/Tree Shear. Should be
operated from the cab of a skid steer only. No bystanders within 100 feet of unit in
operation.

4
Decals
Important: The following decals or similar decals are located on your Wood Splitter/Tree
Shear. Before you operate the Wood Splitter/Tree Shear, read and understand the purpose for
each decal. Replace any damaged decals. Keep all decals clear and readable.
1.
2.
3.
MRF Wood Splitter/Tree Shear Decal List
Item #
Part No.
Description
Qty.
1
96109
Caution Pinch Point
2
2
96028
Stand Clear
1
3
96116
Danger Shearing
1
Operation
Important: Before Operation, the operator should be familiar with these operation instructions
and operation of the skid loader. Do not allow an unqualified person or one under the
influence of medication of intoxicating substances to operate the skid loader.
oRecommended rated loader capacity greater than 1,800 lbs.
oNever shear any trees larger than 8" in diameter.
oConnect the unit to the skid loader using the quick tach system.
oConnect the hydraulic inlet and outlet hoses to the skid loader system.

5
Caution!
Make sure the area around the unit is clear when operating the hydraulics.
Caution!
Make sure the area around the machine is clear when opening and closing the
cylinder.
Maintenance & Safety
oThe hydraulic system of your Wood Splitter/Tree Shear requires careful
inspection along with the mechanical parts. Be sure to replace frayed, kinked,
cracked or otherwise damaged hydraulic hoses or hydraulic components.
oNEVER check for leaks of hydraulic fluid with your hand. Fluid escaping from a
small hole can be almost invisible. Escaping fluid under pressure can have
sufficient force to penetrate skin causing SERIOUS INJURY or even DEATH. Leaks
can be safely detected by passing a piece of cardboard over the suspected leak
and looking for discoloration.
oTo extend the life of the cylinder and hoses, store the machine under cover.
oALWAYS seek professional medical attention immediately if injured by escaping
hydraulic fluid. Serious infection or reaction can develop if proper medical
treatment is not administered immediately.
oALWAYS be sure to relieve all pressure before you loosen or remove any
hydraulic fittings.
oNEVER operate your Wood Splitter/Tree Shear when it is in poor mechanical
condition or in need of repair.
oNEVER alter your Wood Splitter/Tree Shear in any manner. Such alterations may
cause your Wood Splitter/Tree Shear to be unsafe and will void the warranty.
Lubrication
Lubricate all points before operating for the first time and periodically. Keep all lubrication
fittings free of dirt and contaminates.

6

7

8

9

10
MESSER REPAIR & FABRICATING, LLC
Limited Warranty and Terms and Conditions of Sale
The following limited warranty, and terms and conditions of sale (the “Limited Warranty”) apply to all
equipment, products, parts, and goods (any of the foregoing are referred to herein as “Equipment”) sold by
Messer Repair & Fabricating, LLC (“Messer”):
1. Covers All Equipment. Each purchase of Equipment by a purchaser is expressly made conditional on
purchaser’s assent to the terms and conditions in this Limited Warranty.
2. Limited Warranty. Messer warrants that for a period of 24 months from the date of purchase, the Equipment
will remain free from defects in material and workmanship under normal use and proper maintenance.
Messer’s obligation under the warranty shall be limited to the repair or replacement (at Messer’s option) of the
Equipment. Notwithstanding the foregoing, if the Equipment is used for commercial purposes or is rented or
leased out by the purchaser, then, the foregoing warranty shall only be for a period of 180 days and not 24
months.
3. No Warranty For Equipment Components From Third Parties. Notwithstanding the limited warranty terms set
forth above, MESSER OFFERS NO WARRANTY WHATSOEVER WITH RESPECT TO ANY COMPONENTS OF THE
EQUIPMENT MADE OR PROVIDED TO MESSER BY OTHER MANUFACTURERS, PRODUCERS, OR SELLERS (the
“Purchased Components”). The sole and exclusive warranty for each the Purchased Components shall be
limited to the express written warranty with respect to the Purchased Component as provided by the
manufacturer, producer, or seller of such Purchased Component. Messer’s responsibility and liability for the
Purchased Components shall be limited to the assignment of the Purchased Components’ express written
warranties applicable to the Purchased Components. Purchased Components include, without limitation, the
following: axles, tires and rims; trailer hitch components and jacks; hydraulic pumps, motors, cylinders and
components; and bales spears, pallet tines, and bucket teeth.
4. No Other Warranties. THE FOREGOING REPAIR AND REPLACEMENT OBLIGATIONS IN SECTION 2 ARE IN LIEU OF
ALL OTHER WARRANTIES, LIABILITIES AND OBLIGATIONS, INCLUDING ALL WARRANTIES OF MERCHANTABILITY,
OF FITNESS FOR A PARTICULAR PURPOSE OR OTHERWISE, EXPRESSED OR IMPLIED IN FACT OR BY LAW, AND
STATE MESSER’S ENTIRE AND EXCLUSIVE LIABILITY AND PURCHASER’S EXCLUSIVE REMEDY FOR ANY CLAIM IN
CONNECTION WITH THE SALE AND PURCHASE OF EQUIPMENT (AND ALL COMPONENTS THEREOF), THEIR
DESIGN, SUITABILITY FOR USE, INSTALLATION OR OPERATIONS.
5. Location of Warranty Repairs. All warranty repairs pursuant to this Limited Warranty shall be made at Messer’s
corporate manufacturing plant, or other location as determined by Messer, at its discretion. Purchaser shall be
responsible for and pay for any transportation expenses necessary for Limited Warranty repairs.
6. Limited Warranty Voidable. The limited warranty herein is void and deemed waived if the purchaser fails to
give written notice to Messer of any alleged defect under the limited warranty herein within 20 days of its
discovery; or (a) purchaser or parties other than Messer or its authorized representatives attempts to remedy
or fix the alleged Equipment defects; or (b) purchaser has used the Equipment for purposes it was not intended
to be used for; or (c) purchaser has not operated the Equipment in a manner consistent with Messer’s
instructions for the Equipment; or (d) the Equipment has been modified, altered, abused, or misused; or (e) the
Equipment has been damaged pursuant to accident, fire, flood, or other Act of God.
7. No Consequential Damages. IN NO EVENT SHALL MESSER BE LIABLE FOR ANY DIRECT, INDIRECT, SPECIAL OR
CONSEQUENTIAL DAMAGES WHATSOEVER, AND MESSER’S LIABILITY, UNDER NO CIRCUMSTANCES, WILL
EXCEED THE PRICE PAID FOR THE EQUIPMENT FOR WHICH LIABILITY IS CLAIMED.
8. Governing Law. This contract shall be governed by the laws of the State of Minnesota.
9. Arbitration. Any controversy or claim arising out of or relating to the limited warranty provided herein, or any
alleged breach thereof, shall be settled exclusively by arbitration in accordance with the Rules of the American
Arbitration Association, and judgment upon the award rendered by the arbitrator may be entered in any court
having jurisdiction thereof. The arbitration shall be conducted in Minneapolis, MN, by one arbitrator selected
by Messer and Purchaser, or, if they cannot agree, the President of the American Arbitration Association.
