Mesutronic METRON 07 C Installation and operating instructions

Translation of the original-
USER MANUAL
METRON 07 C, CI, SlimLine
Version: GB-MN07-M0-004 Mode: 0
Date: 05.01.2013 Acknowledgement:
Please read user manual before you start working on the machine!
GB


-1-
Dear customer,
to begin with, we would like to thank you for your confidence in our metal detection
system.
Prior to switching the system on, please read the user manual completely as this
provides you with the expertise necessary for optimum operation and adjustment of the
system according to your requirements.
If, contrary to expectations, you have any problems in operating your system, the
MESUTRONIC-Team and our contractors will be able to assist you at any time.
The MESUTRONIC-Team is at your disposal from Monday until Friday between 8
a.m. and 6 p.m., tel. +49 9927 / 94 10-0 or fax +49 9927 / 17 32. Outside our office
hours, you can contact us, at any time, via MESUTRONIC-Helpline. The respective
phone number can be retrieved from our answer machine. Please do not hesitate to
contact us.
If a demonstration on site is required, we will respond as soon as possible offering
national and international services.
Enjoy your MESUTRONIC-System and a metal-free time, yours
Gerätebau GmbH
Hackenfeld 13
94259 Kirchberg, Wald
Germany
Phone +49 (0) 9927 – 9410-0
Fax +49 (0) 9927 – 1732
Internet www.mesutronic.de

-2- Index

-3- Index
INDEX
GENERAL INFORMATION .............................................................................................................................. 5
INFORMATION ABOUT THE OPERATING MANUAL................................................................................................... 5
COPYRIGHT........................................................................................................................................................... 5
EXPLANATION OF SYMBOLS.................................................................................................................................. 6
WARRANTY AND LIABILITY .................................................................................................................................. 6
TRANSPORT .......................................................................................................................................................... 7
INSTALLATION ...................................................................................................................................................... 7
STORAGE .............................................................................................................................................................. 7
DISPOSAL ............................................................................................................................................................. 8
OPERATING PRINCIPLE .......................................................................................................................................... 8
GENERAL NOTES ON METAL DETECTION ............................................................................................................... 9
SAFETY............................................................................................................................................................... 11
OPERATION OF THE DEVICE AS PROVIDED........................................................................................................... 11
CONTENTS OF THE OPERATING MANUAL............................................................................................................. 12
MODIFICATIONS AND CONVERSIONS OF THE MACHINE ....................................................................................... 12
DUTIES OF THE OPERATING COMPANY ................................................................................................................ 12
DUTIES OF THE PERSONNEL ................................................................................................................................ 13
HAZARDS RELATED TO THIS METAL DETECTION EQUIPMENT: ............................................................................. 14
ACTUATION ...................................................................................................................................................... 17
GENERAL............................................................................................................................................................ 17
SAFETY PROCEDURES BEFORE TAKING THE DEVICE INTO OPERATION ................................................................. 17
ACTUATION MANUAL ......................................................................................................................................... 18
ASSEMBLY......................................................................................................................................................... 21
INSTALLATION GUIDELINDES .............................................................................................................................. 21
TIPS FOR SET-UP ................................................................................................................................................. 25
General........................................................................................................................................................... 25
Electronic housing AMD 07 ........................................................................................................................... 26
Detector C-Coil .............................................................................................................................................. 27
Detector CI-Coil............................................................................................................................................. 28
Detector SlimLine-Coil................................................................................................................................... 29
CONNECTION ...................................................................................................................................................... 30
Relay............................................................................................................................................................... 30
Supply voltage................................................................................................................................................. 31
OPERATION ...................................................................................................................................................... 33
GENERAL............................................................................................................................................................ 33
TOUCH SCREEN DISPLAY OPERATION................................................................................................................. 34
ADJUSTMENT ................................................................................................................................................... 37
GENERAL............................................................................................................................................................ 37
OVERVIEW OPERATING LEVELS .......................................................................................................................... 38
OPERATING LEVEL 1 ........................................................................................................................................... 40
Detection level................................................................................................................................................ 40
Choose product............................................................................................................................................... 40
Batch number.................................................................................................................................................. 40
Reject counter................................................................................................................................................. 40
Test reject unit 1 (optional) ............................................................................................................................ 41
Start detector test............................................................................................................................................ 41

-4- Index
Change password ........................................................................................................................................... 41
OPERATING LEVEL 2 ........................................................................................................................................... 42
Learn Product................................................................................................................................................. 42
Product memory (Create product).................................................................................................................. 44
Reject counter................................................................................................................................................. 44
Reject parameters relais 1/active 1 ................................................................................................................ 44
Conveying speed............................................................................................................................................. 45
Detection......................................................................................................................................................... 45
Frequency....................................................................................................................................................... 46
USB................................................................................................................................................................. 46
Systeminfo....................................................................................................................................................... 47
Clock setup ..................................................................................................................................................... 48
Language........................................................................................................................................................ 48
Display............................................................................................................................................................ 48
Restore factory setting.................................................................................................................................... 49
OPERATING LEVEL QM....................................................................................................................................... 50
User Manager................................................................................................................................................. 50
Password expires............................................................................................................................................ 50
Password expires in (days) (optional)............................................................................................................ 50
Protocol.......................................................................................................................................................... 50
Reports............................................................................................................................................................ 51
Detector test.................................................................................................................................................... 51
Contamination level........................................................................................................................................ 53
MAINTENANCE AND CLEANING................................................................................................................ 55
MAINTENANCE ................................................................................................................................................... 55
CLEANING .......................................................................................................................................................... 56
ERRORS AND PROBLEMS ............................................................................................................................. 57
GENERAL............................................................................................................................................................ 57
CONTROL UNIT MESSAGES (1-XXX)................................................................................................................... 58
SENSOR UNIT MESSAGES (2-XXX) ..................................................................................................................... 62
DISPLAY UNIT MESSAGES (3-XXX) .................................................................................................................... 64
MAINS SUPPLY.................................................................................................................................................... 66
SERVICE.............................................................................................................................................................. 67
TECHNOLOGY ................................................................................................................................................. 69
TECHNICAL DATA ............................................................................................................................................... 69
PLUG CONFIGURATION........................................................................................................................................ 70
Ethernet interface for networking................................................................................................................... 70
Connection to customer network (e.g. mesuNET)............................................................................................... 70
Connection Sensor Unit.................................................................................................................................. 70
Connection Display-Unit................................................................................................................................ 70
Relay 1 (switches when metal is detected)...................................................................................................... 71
Relay 2 (switches when an error is detected) ................................................................................................. 71
Switching inputs / switching outputs............................................................................................................... 71
KEY PLAN ........................................................................................................................................................... 72
SPARE PARTS ................................................................................................................................................... 75
DANGER DUE TO NON-ORIGINAL SPARE PARTS! .................................................................................................. 75
ELECTRONICS HOUSING AMD07 ........................................................................................................................ 76
CI-COIL BA 24 WITH AMD07............................................................................................................................ 78
DISPLAY COVER FOR DISPLAY UNIT ................................................................................................................... 79
SLIMLINE /C- COIL AMD07 .............................................................................................................................. 80
APPENDIX.......................................................................................................................................................... 81
ACCESS CODES ................................................................................................................................................... 81
EXAMPLE OF AN EU DECLARATION OF CONFORMITY ........................................................................................ 82

-5- General information
Information about the operating manual
This operating manual provides you with important information about handling the machine. The
prerequisite for safe working is adherence to all instructions given for safety and action.
Beyond that, the local rules for the prevention of accidents and general safety regulations applicable to the
place of use of the machine must be adhered to.
The operating manual is part of the product; it must be kept near to the machine and must be accessible to
personnel at all times.
Copyright
The operating manual must be treated confidentially. It is intended exclusive for those persons who deal with
the machine. It is forbidden to give the operating manual to third parties without the written permission of
the manufacturer.
NOTE!
The specifications, texts, drawings, pictures and other representations contained in the manual
are protected by commercial property rights. Any misuse is punishable by law.
General information 1

-6- General information
Explanation of symbols
The following symbols are used in this operating manual
(all symbols conform to DIN 4844 and/or BGV A 8 standards):
Warning symbols: Directive symbols:
Hazardous voltage
This warning symbol designates
potential hazards. Non-observance of
this symbol can lead to injuries, even to
death.
Prohibited for persons fitted
with a cardiac pacemaker
Danger of injury
to hands
Warning of harmful or irritant
substances
Mandatory signs:
Take particular care
Switch off before carrying out work
Warranty and liability
We are liable for defects in the unit manufactured by us in accordance with our terms and conditions of
business. All claims are voided if damage occurs due to improper operation, repairs or interventions by
persons not authorised by the manufacturer or the user, or the use of accessories and spare parts which not
suitable for our unit.

-7- General information
Transport
When transporting the machines, you must observe the following points:
When exceeding the country’s legally prescribed maximum weight limits for
people moving goods, lifting devices must be used!
Mount the lifting devices in accordance with the following drawing! (check your
coil type!)
When mounting the eye bolts, please take care that they fit snugly onto the
bearing face. Loads that run diagonal to the ring face are not allowed.
Mounting the lifting devices and transport may only be carried out by trained and
authorised staff!
During transport, the safety regulations in force must be observed!
Mounting the C, CI-Coil, SlimLine
1. horizontal
2. vertical
Installation
Requirements for the place of installation:
Sufficient stability and load-bearing capacity of the substrate
Please consult the manufacturer if the position is not horizontal
Storage
The place of storage must be free from direct influences of the weather (frost, wetness,
direct exposure to the sun).
Place of storage in dust-free, closed rooms.
Place of storage free from condensed water, acids, alkalis and other corrosive materials
(vapours of these materials)
Storage in the packed condition
The adherence to the storage conditions is to be checked at regular intervals.
In the event of non-adherence to the above conditions, no warranty claims can be accepted
for any technical defects caused by improper storage.

-8- General information
Disposal
If no agreement has been reached with regard to the taking back or disposal of the machine,
dismantled components should be recycled following proper dismounting.
Dispose of components according to the applicable laws/regulations of the user’s
country.
Used substances and materials (greases, oils, cleaning agents or solvents, etc.) are to be
disposed of according to the legal regulations.
Operating principle
The following shows the simplified principle of a metal search detector, with an example of a conveyor belt
application. The shape and look of your application may differ, but the principle is the same.
a) Metal detector
b) Electromagnetic field
c) Product line
Metal detection
1. The seeker head creates and evaluates an electromagnetic field with the help of transmitter and receiver
coils.
2. If a metal body enters the field, the signal indication display deflects in one direction.
see too chapter Operation
3. If the metal body leaves the field, the display deflects in the opposite direction.
If both switching thresholds are reached, metal is detected.
If metal is detected, several outputs, depending on your configuration, can be used to query the events: At
least one Relay and a 24V (output A1) are available for your queries.

-9- General information
General notes on metal detection
Electro-magnetic short circuits
Certain metal frame constructions in conveyor belt frames (see drawing) and suspensions (e.g. castors, cross-
bars, adaptor plates) can act as an electro-magnetic loop in the vicinity of the metal detector, affecting the
magnetic field of the metal detector. Closed conductive loops must either be welded tight, or interrupted, e.g.
with unilateral isolation.
Example:
a) Conveyor belt frame
b) Conveyor belt motor
c) Isolation
1. If the crossbar is permanently welded, the electromagnetic effect on the metal detector remains
constant and does not negatively affect the field of the metal detector.
If the crossbar is only bolted, a constantly conducting connection cannot be guaranteed. The metal
detector is negatively affected by the changing conductor loop.
2. Rollers and moving parts that form a conductor loop must be insulated at one end (see fig. 3.), in
order to interrupt the conductor loop.
Electrostatic discharges
Prevent at all cost electrostatic discharges to the metal detector and surrounding construction components
using the appropriate earthing. Electrostatic discharges can cause false signals and at worst, destroy the
analysis electronics.

-10- General information
Differences in sensitivity within the outlet opening
Please note, that the detector coil does not create a homogeneous electromagnetic field. As a consequence,
differences in sensitivity occur in the outlet opening. The least sensitive part of the detector is in the middle
of the outlet opening.
Sensitivity distribution taking the example of a
C-coil (1) and a CR-coil (2):
a) Area of highest sensitivity
b) Area of lowest sensitivity
Sensitivity differences of different metal types
Please note, that different metal types influence the electromagnetic field to a different degree. Please read
the metal-type dependent maximum sensitivity degrees in the data sheet.
Position-dependency of the metal parts
Metal detection can be dependent on the position and orientation of the metal part, depending on the shape
of the metal part. The maximum sensitivity values of the data sheet are tested with ball-shaped test parts.
Generally speaking, all metal parts that have at least the same diameter as the balls used for the data-sheet
values can be detected with certainty, irrespective of position and orientation.
Testing at regular intervals
Normally, errors of the detector itself are recognized by the self-monitoring system. However it cannot be
excluded that errors may occur which are not detected. Changes in the environment of the detector (e.g. new
machines) can influence the function of the detector.
For this reason, settings and function of the metal detector must be checked at regular intervals with suitable
test equipment.
Environmental and weather influences
The metal detector has to be protected against environmental and weather influences (direct sun, wind,
frost). The detector has to be especially protected from direct or indirect insulation when heating up is
above the allowed temperature. High surface temperatures can lead to false detections and destruction
of the metal detector in the worst case. A suitable protection device must therefore be provided (do not
use metal walls or roofing covers made from metal!)
.

-11- Safety
Operation of the device as provided
The device only serves for detecting metal in flight conveyors. The following products
are excluded:
those contained in metallic or partially metallic casings,
electrically conductive products
products containing desired metal constituents.
Since these products could possibly disturb the sensitivity of the metal detector, they may only be examined
after consulting the manufacturer beforehand.
This device may not be operated
in areas with explosive hazards (customized version available),
outside the stated protective system,
outside the permitted temperature range
Operating the device in an improper way can lead to damages at the device and also
to injuries or the death of persons.
Any structural change of the device may only be effected after consent and prior inspection of the
manufacturer.
The data provided in the manual regarding operation, maintenance have to be observed. Works at the metal
detector may only be carried out by trained and authorized personnel.
Safety 2

-12- Safety
Contents of the operating manual
Each person who is assigned to work on or with the machine must have read and understand the operating
manual before commencing any work on the machine. This also applies if the person concerned has already
worked with such a machine or a similar machine or has been trained by manufacturers.
Modifications and conversions of the machine
To avoid hazards and to ensure optimum performance, the machine may neither be modified nor converted
nor may attachments be made to it unless expressly permitted by the manufacturer. Only original spare parts
and accessories from the manufacturer may be used.
Duties of the operating company
The machine is used in an industrial area. The company that operates the machine is therefore subject at least
to the legal health and safety requirements in the country of use.
Apart from the notes in this operating manual concerning health and safety at work, the regulations for
safety, accident prevention and environmental protection applicable to the place of use of the machine must
be adhered to. The following applies in particular here:
The product fulfils the CE marking requirements within the machine limits. The
company that operates the machine is solely responsible for implementing the
interfaces to the surroundings and the fixings in a safe manner, taking into
account relevant regulations and directives. The machine may be put into
operation only if it meets the safety requirements!
Assign only trained or instructed personnel.
Clearly define the responsibilities of the personnel for the installation, operation, setup,
maintenance and repair of the machine.
The manual must always be kept at the place of use of the machine where it is
accessible to all persons who operate the machine.
Trainees may only work under the supervision of already trained personnel. New
personnel must receive the same training as those personnel who have already been
trained
The operating company is responsible for defining the protective equipment that is
necessary in order to make safe working possible.
Provide the personnel with all necessary protective equipment.
Check regularly that personnel are working in a safety-conscious manner.
Keep all safety and danger notices on the machine complete and in a good, legible
condition. Danger of injury due to illegible or missing symbols!

-13- Safety
Duties of the personnel
Danger of injury if personnel are not sufficiently qualified to work on the machine!
Inappropriate handling can lead to serious injuries and material damages.
Therefore:
Allow only the persons named in the respective chapter to perform special tasks.
Personnel assigned to work on the machine must have read and understood the
operating manual before commencing work.
Observe all legal and basic regulations for health and safety and accident prevention
when working.
Observe all safety and danger notices on the machine
In case of malfunction, stop the machine immediately and secure it.
Have faults rectified immediately.
Observe the safety regulations applicable to the product when handling oils, greases
and other chemical substances. Use the necessary personal protective equipment.
All persons concerned with the assembly, commissioning, operation, maintenance and repair of the metal
detector unit must be correspondingly qualified and trained.
Persons
Activity
Specially
trained
personnel
Personnel under
instuction
Personnel with job-
Specific training
(mechanical/electronic)
Transport * -- --
Commissioning * -- --
Fault-finding and repair -- -- *
Adjustment, equipping * -- *
Operation -- * --
Maintenance -- -- *
Disposal * -- --
Key: *= allowed -- = not allowed

-14- Safety
Hazards related to this metal detection equipment:
A risk / hazard analysis has been carried out on the metal separator with subsequent safety check and safety
acceptance. In the case of misoperation or misuse, there is a danger of injury to, or death of operators,
maintenance personnel and others, damage to the metal detection equipment and the user’s other property,
and reduced efficiency of the equipment.
Safety and usage notices:
The following symbols have been applied to the equipment to indicate hazards which cannot be eliminated
via structural measures:
WARNING!
Danger of injury due to illegible or missing symbols!
Keep all safety and danger notices on the plant complete and in a good, legible
condition.
Symbol Description Location
Hazardous voltage Control and evaluation unit
Please take particular notice of the following residual hazards:
Hazard Activity Dangerous part Solution
Equipment weight
Transport / Removal Complete
equipment
Transport of the plant with
suitable and approved lifting
appliances by trained personnel.
Observe applicable safety
regulations.
Danger of plant tipping
Set-up/installation,
cleaning,
decommissioning/dis
assembly
Complete
equipment
Mount plant securely on
mounting holes.
Danger of injury to
hands
Assembly Complete
equipment
Mounting only by trained and
authorised personnel

-15- Safety
Hazardous voltage
All operating modes Electronic cabinet,
pneumatic cabinet
Keep the covers of the electronic
and pneumatic cabinets closed
Danger due to
pressurised hot water
Cleaning with steam
jet
Complete
equipment
Wear suitable protective
clothing when cleaning with a
steam jet. Observe the
manufacturer’s safety
instructions. Observe
protection class of the plant.
Danger of substances
hazardous to health or
irritants
Cleaning with
cleaning agents
Complete
equipment
Wear personal protective
equipment and observe the
cleaning agent manufacturer’s
instructions.
Warning of visual or
acoustic signal
All operating modes Warning device
(alarm)
Instruction of personnel on
existing warning devices
Prohibited for persons
fitted with a cardiac
pacemaker
Normal operation Complete
equipment
Persons fitted with a cardiac
pacemaker (or other implanted
medical aid) must not work on
this machine.
Generally, before cleaning or repairing the equipment, it must be switched off,
made safe against accidental switch-on, the air pressure released and the
conveyor belt stopped. The switch outputs should be checked for external
voltages.

-16- Safety

-17- Actuation
General
It is our company’s goal to ship the metal detector to the customer with as many pre-configured settings as
possible. If the machine is shipped with factory default settings, it should be noted, that the factory defaults
are the best possible compromise between maximally attainable detection precision and lowest possible
sensitivity to interference. The data sheet sensitivities are achieved with detection threshold settings between
20 and 10.
In order to adapt the settings to your own needs, a schematic sequence is provided below in which the start
up should ideally take place. Only the sequence is described. The individual explanations of the menu items
must be read in the operating instructions.
Safety procedures before taking the device into operation
Before actuating the metal detector at least the following parts of the device must be
checked:
Is the device damaged anywhere?
Are the electric ports and mains undamaged?
Are all protective covers fitted and free of damage?
Are all pneumatic supplies and mains undamaged (if installed)?
The device can start if everything is perfect.
Danger due to incorrect assembly and commissioning!
Assembly and commissioning require trained technical personnel with sufficient
experience. Errors made during assembly can lead to life-threatening situations or
result in considerable material damages.
Actuation 3

-18- Actuation
Actuation manual
1. Clean the metal detector
If the product is not allowed to have contact with foreign matter, all surfaces having contact with the product
must be cleaned before start-up operation.
Please follow the safety instructions!
see chapter Maintenance and cleaning Cleaning
2. Assemble metal detector
Assemble the metal detector according to the information provided in the chapter „Assembly“.
see chapter Assembly
3. Connecting the 24V switching exits and relays
Connect the 24V switching exits and relays as needed. Please follow the indications in the chapter Set-up.
see chapter Assembly Connection
4. Connect power supply
see chapter Assembly Connection Supply voltage
5. Switch metal detector on
Having assembled the detector mechanically, as a first step it is taken into operation. Under this condition
the detector is only subject to external influences (peripheral disturbances). If at this point faulty responses
are triggered, you have to try and find the source of the disturbance and to correct the error. For this switch
off all machines (motors, actuation, etc.) in the direct surroundings of the metal detector so that the metal
signal of the metal detecting device stays within the triggering range. As a next step the device is taken again
into operation step by step.
After each step control the measure signal in order to locate the disturbance, that causes an increased noise
level. If a noise suppression is not possible, remains only an increase of the detection threshold, until there
are no more false alarms.
see chapter Adjustment Operating level 1 Detection level
The metal detector is now fully assembled and connected.
All further points are concerned with the most important adjustments
that should be made to your machine in order to ensure trouble-free
operation with the maximum possible sensitivity.
This manual suits for next models
2
Table of contents
Popular Metal Detector manuals by other brands

Whites
Whites Goldmaster 66TR-4B operating instructions

Centech
Centech 94138 Assembly and operating instructions

Whites
Whites Coinmaster 1/DB Series 2 Operator instructions

C-SCOPE
C-SCOPE CS6MX operating instructions

Whites
Whites Goldmaster 64TR operating instructions

Whites
Whites Conquistador 100 operating instructions
