1. Precautions on disassembly and reassembly
[Bold] numbers in the description below correspond to the item numbers in the parts list and exploded
assembly diagram for the Model C 1810DFA.
1. Removing the TCT saw blade and link
(1) Remove the Left Hex. Socket Bolt M7 [71] using the Hex. Bar Wrench 5 mm [503] (standard accessory).
(2) Remove Washer (E) [72], TCT Saw Blade [73], and Washer (D) [74] in this order.
(3) Remove Special Screw (C) M5 [94] and Special Screw M6 [87] to remove the Link [89].
(4) Remove the three Machine Screws (W/Washer) M4 x 8 (Black) [98] and remove the Lower Guard [90]
from the Gear Case [2].
(5) Remove the two Machine Screws (W/Sp. Washer) M5 x 16 [91]. Slightly tap the Gear Case [2] with a
plastic hammer to remove the Spindle Ass'y [75].
REPAIR GUIDE
Disassembly
[75] [81]
[80]
[79]
[78]
[77]
[76]
[74]
[73]
[72]
[71]
[97]
[88]
[94]
[89]
[90]
[91] [93]
[92]
[87]
[95]
[96]
[1]
[2]
[3] [5]
[4]
[15]
[14]
[13]
[9]
[8]
[7]
[6]
[10]
[11] [12]
[98]
[88]
[16]

-2-
Fig. 2
2. Removing the head portion
(1) Remove the Hex. Socket Hd. Bolt M5 x 10 [1].
NOTE: The Hex. Socket Hd. Bolt M5 x 10 [1] acts as the upper limit stopper of the head portion.
Be careful that the head portion is raised by the force of the Spring [5] when the Hex.
Socket Hd. Bolt M5 x 10 [1] is removed.
(2) Raise the head portion carefully and then remove the Seal Lock Hex. Socket Set Screw M6 x 10 [3].
Bring a flat-blade screwdriver into contact with the end surface of Shaft (C) [12] and lightly tap the flat-
blade screwdriver with a plastic hammer to remove Shaft (C) [12]. Then remove the Spring [5] and
Sleeve [4].
NOTE: Be sure to hold the head portion with hand during disassembly to prevent the head portion
from dropping when Shaft (C) [12] is removed from the hole of the head portion.
[1]
[2]
[3]
[4]
[5]
[12]
[11]
[10]
[6]
[7]
[8]
[9]
[13]
[14]
[15]

-3-
Fig. 3
3. Removing the turn table and base
(1) Remove the three Bolts M8 x 35 [41], Spring Washers M8 [30], and Bolt Washers M8 [42] to remove
the Fence [47].
(2) Loosen the Clamp Lever [7] and remove the Machine Screw (W/Washers) M6 x 20 (Black) [6]. Turn the
Bolt (Left Hand) M10 [8] and remove it from the Hinge [13].
(3) Remove Shaft (D) [10] and remove the Hinge [13] from the Turn Table [25].
(4) Remove the Table Insert [23] from the Turn Table [25] by removing each fixing screw. Remove the Side
Handle [26] to remove the Spring Plate [29] from the Turn Table [25].
(5) Remove the Nylon Nut M8 [20] and Turn Table [25] from the Base Ass’y [54].
[6]
[7]
[8]
[9]
[13]
[10]
[11] [12]
[16]
[17]
[22]
[23]
[19]
[24]
[25]
[26]
[27]
[28]
[29]
[30]
[31]
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[41]
[30]
[42]
[54]
[52]
[51]
[46]
[47]
[48]
[49]
[50]
[32]
[33]
[21]
[20]
[18]
[19]
[55]

-4-
Fig. 4
4. Removing the rotor ass'y
(1) Remove the Tapping Screws (W/Flange) D4 x 20 (Black) [108] to remove the Switch Handles Set [106].
(2) Remove the four Machine Screws (W/Washers) M5 x 40 (Black) [115]. Then the Housing Set [116] can
be removed from the Gear Case [2] together with the Switch Handles Set [106]. The Lock Lever [102]
and Rotor Ass'y [100] can also be removed.
(3) Remove the Stator Sensor PCB [104].
[108]
[113]
[114]
[115]
[115]
[116]
[117]
[112]
[111]
[110]
[104]
[103]
[99]
[100]
[101]
[102]
[106]
[109]
[108]
[105]
[108]
[2]
[83]
[82]
[84]
[85]
[86]

-5-
Fig. 5
5. Disassembly of the vise ass'y
(1) Remove the Wing Bolt M6 x 15 [34] to remove the Vise Shaft [40].
(2) Remove the Machine Screw M4 x 10 [39] to remove the Vise Plate [38].
(3) Remove the Knob Bolt M10 x 66 [35] from the Screw Holder [36].
[34]
[35]
[36]
[37]
[38]
[39]
[40]
[33]
[47]

-6-
Fig. 6 • Internal wiring (1)
Fig. 7 • Internal wiring (2)
Reassembly can be accomplished by reversing the disassembly procedure. However, special attention
should be given to the following item.
1. Internal wiring
Perform wiring according to the wiring diagram shown on page 14.
NOTE: Be careful not to get the internal wires caught between housings (A) and (B) and switch
handles (A) and (B).
Reassembly
Mount the LED [84] to the LED Cover [85] as
shown in the figure, and then mount it to the
Gear Case [2].
Fit the internal wires in the ribs properly.
Pull the signal internal wires around the
ball bearing portion taut to prevent contact
with the Rotor Ass’y [100].
Position the internal wires behind the
cylindrical poles of the ball bearing portion.
NG
Stamped side
Put the internal wires to be connected to the
Switch Handle Set [106] through the hole.

-7-
Fig. 8 • Internal wiring (2)
Internal wires coming out from the hole of Housing Set [116]
Pay attention to the mounting direction.
Connect to the LED [84].
Put the internal wires through the hole of the Housing Set [116]. Secure the Switch Handle Set [106] to the
Housing Set [116] with two screws, and mount it to the Gear Case [2]. Then, perform wiring as shown below.
Fit the internal wires in the ribs properly.

-8-
Apply specified amount of grease to the following portions.
Grease (SEP-3A)
• Surface of the Base Ass’y [54] where Liner (A) [52] slides ··································5 g
• Surface of Shaft (B) [55] where the Turn Table [25] slides···································0.5 g
• Surface of the Turn Table [25] where Liner (A) [52] slides ···································3 g
• Pinion of the Rotor Ass'y [100] and tooth surface
and gear chamber of the Spindle Ass'y [75] ···················································15 g
• Surface of Shaft (D) [10]··············································································1 g
• Surface of the O-ring (P-6) [15] of the Stopper Pin Ass'y [14] ······························0.2 g
• Surface of the Hinge [13] where the Turn Table [25] slides··································2 g
• Surface of the Gear Case [2] where the Hinge [13] slides (grease chambers) ·········5 g x 2 places
• Inside of the Spring [5] ················································································5 g
• Surface of the Hinge [13] where Shaft (C) [12] slides·········································1 g
• Sliding surface of the Link [89] ······································································0.2 g
Please purchase the following grease as necessary.
Item Registered part name Net weight Code No.
Grease (SEP-3A)
Grease (SEP-3A) (100 g) 100 g 930035
Grease (SEP-3A) (2.5 kg) 2.5 kg 930038
Advise the customer to lubricate the machine as indicated below at least once a month. Prior to lubrication,
any sawdust, dirt or other foreign matter should be thoroughly wiped away with a soft cloth.
(1) Swiveling section of the Gear Case [2] and Hinge [13]
Coat the swiveling and sliding portions of the Gear Case [2] and the Hinge [13] with machine oil.
(2) Vise ass’y section
Coat the screw thread portion of the Knob Bolt M10 x 66 [35] of the Vise Ass’y [33] with machine oil.
(3) Swiveling section of the Turn Table [25] and Hinge [13]
Coat the swiveling and sliding portions of the Turn Table [25] and Hinge [13] with machine oil.
1. Checking after reassembly
• Check that the motor section can be moved up and down smoothly by holding the handle portion of the
Switch Handle Set [106] with operating force 58.8 N {6.0 kgf} max.
• Check that the Turn Table [25] can be rotated to the left and right smoothly by holding the Side Handle
[26] with operating force 34.3 N {3.5 kgf} max. while the index stopper is released by pushing down the
Spring Plate [29].
• Check that the Lower Guard [90] moves smoothly and properly.
• Check that the Off Lock Lever [113] and Trigger [110] operate smoothly and properly.
• Check that the motor does not start by pulling the Trigger [110] without moving the Off Lock Lever [113] of
the Switch [114] (switch operating force:100 N {10 kgf}).
• Check that LED [84] turns on and off by pushing the LED button.
• Check for braking (blade stopping time: 5 seconds max.)
• Check that the rotating direction of the spindle is the same as the arrow mark on the Gear Case [2].
Lubrication points and type of lubricant
Checking and adjustment after reassembly

-9-
Fig. 9
Left fence Right fence
Square rule
r
Saw blade
(dummy disc)
2. Adjustment after reassembly
(1) Check for squareness between the saw blade (dummy disc) and both fences (right and left)
Be sure to check squareness between the saw blade
(dummy disc) and both fences (right and left) after
mounting the Base Ass’y [54], Turn Table [25], Fence [47],
and Hinge [13]. The squareness tolerance is 0.4/100 mm.
Make the right and left fences square to the saw blade
(dummy disc) by moving the fences. First, make the left
fence square to the saw blade (dummy disc) by using a
square ruler as shown in Fig. 6. Then align the right fence
with the left fence by using a straight edge ruler. Finally,
check that the right fence is square to the saw blade
(dummy disc) by using a square ruler.
(2) Check for turning of the turn table
When mounting the Turn Table [25] and the Base Ass’y
[54], tighten the Nylon Nut M8 [20] so that the Turn Table
[25] turns smoothly without excessive clearance or
vibration. During reassembly,
fully apply grease (SEP-3A)
at the point marked ”A” in Fig. 7.
3. Product precision
On completion of reassembly, check the precision tolerances.
Item Tolerance
Deflection of the dummy disc 0.38/220 mm (0.016”/8-5/8”)
Squareness between the base and fence 0.4/height of fence (mm)
(0.016”/height of fence)
Flatness of the right and left fences 0.2 mm (0.008")
Squareness between the dummy disc and both fences (right and left) 0.4/100 mm (0.016”/4”)
Squareness between the dummy disc and turn table 0.4/100 mm (0.016”/4”)
Surface alignment of the base and turn table
(Use the upper surface of the base as a reference.)
0.2 mm ( 0.008”)
0.2 mm ( 0.008”)
Fig. 10
A
[20]
[25]
[49]
[50]
Turn table
Base
+
Turn table
Base
–
+ +
–
–
Fig. 11

-10-
4. Troubleshooting
Item Phenomenon Cause Factory standard Inspection, repair or
adjustment
1Inaccurate cutting
• Inaccurate
squareness of the cut
surface.
• Cut surfaces do not fit
together properly.
a. Inaccurate squareness
between the fence and
the turn table and/or the
base causes the
workpiece to tilt at an
angle and prevent
accurate cutting.
0.4/height of
fence (Fig. 9)
• Replace the Fence [47].
b. Loose fitting of swiveling
portion of the hinge and
gear case, or sluggish
movement. As a result,
components may be
deformed because of
unstable gear case or
because the operator
applies excessive
pressure during
operation.
— • Check the fitting
surfaces of the Hinge
[13], Gear Case [2] and
Shaft (C) [12] for foreign
substances (such as
cutting dust), and
remove them if any.
c. Excessively fast cutting
speed causes deflection
of the saw blade and
inaccurate cutting.
— • Reduce the cutting
speed (for example,
appropriate length of
time is 10 seconds for
cutting a square wood
workpiece of 60 mm).
d. Excessive cutting force
(pressure) is required
because of dull saw
blade.
— • Sharpen the saw blade.
e. The workpiece moves
during cutting because it
is bent or deformed.
— • Correct bend, flex or
other deformation by
planing and try cutting
again.
Squareness
0.4/height of
fence
Fence
Fig. 12

-11-
Item Phenomenon Cause Factory standard Inspection, repair or
adjustment
2 Rough cut surface
Parallelism =0.02/43
a. Large deflection of the
saw blade (It causes
rough cut surface.)
0.38/220
(Dummy disc)
• Replace the TCT Saw
Blade [73].
• Check for surface
defects on Washer (D)
[74], and repair with a
file as necessary.
• Replace Washer (D)
[74].
b. Surface parallelism of
washer (D) and washer
(E) is inaccurate due to
surface defects such as
impact marks and
scratches.
0.02/43
(Fig. 8)
• Repair impact marks or
scratches on Washer (D)
[74] and Washer (E)
[72] or replace them as
necessary.
c. Inaccurate squareness
between the turn table
and saw blade causes
the saw blade to cut at
an improper angle and
make cutting marks.
0.4/100
(Fig. 10)
• Readjust them to be
square using the Bolt
M6 x 10 [50].
• Replace the Hinge [13],
Gear Case [2] or Turn
Table [25] with new one
if deformed.
d. Excessively fast cutting
speed
— • Reduce cutting speed.
e. Improper clamping of
workpiece
— • Properly clamp the
workpiece with the Vise
Ass'y [33].
f. Turn table is not fixed
with the side handle.
— • Before cutting, fix the
Turn Table [25] in
position with the Side
Handle [26] without fail.
g. Loose fitting of swiveling
portion of the hinge and
gear case, or sluggish
movement.
— • Check the fitting
surfaces of the Hinge
[13], Gear Case [2], and
Shaft (C) [12] for any
foreign substances
(such as cutting dust)
and remove it as
necessary.
h. Cutting operation
becomes sluggish
because workpiece is
warped or bent.
— • Correct warp or bend
with a planer.
i. Excessive vibration — • Recheck the items a, b,
and f.
Saw blade
Squareness
0.4/100
Fence
Turn table
A
A
Washer (E) Washer (D)
A
Fig. 13
Fig. 14

-12-
Item Phenomenon Cause Factory standard Inspection, repair or
adjustment
3 Saw blade is locked. a. Excessively fast cutting
speed
— • Reduce cutting speed.
b. Excessive cutting force
is applied due to dull
saw blade.
— • Sharpen the saw blade.
c. Incorrect saw blade is
used.
— • Use a suitable HiKOKI
supplied saw blade.
• An increased number of
teeth on the saw blade
increases the cutting
resistance. When using
a saw blade with a large
number of teeth, reduce
the cutting speed.
d. Saw blade binds in
workpiece during cutting
because workpiece is
warped or bent.
— • Correct warp or bend
with a planer.
4 Saw blade does not
rotate when switch is
triggered.
a. No remaining battery
power.
— • Charge the battery.
b. The battery is not fully
installed.
— • Insert the battey into the
tool until you hear a
click.
c. Contact failure of the
switch
— • Check the Switch [114]
for conductivity.
• Replace the Switch
[114].
d. Stator sensor PCB
failure
— • Replace the Stator
Sensor PCB [104].
e. Controller (A) failure — • Replace Controller (A)
[117].
5 Saw blade runs too
slow, too fast, or
unstably (no-load
speed of the saw
blade: 3,420 to 4,180
min-1)
a. Power supply voltage is
lower than the rated
voltage.
— • Check the power supply
voltage.
• Check if the battery is
appropriate.
b. Stator sensor PCB
failure
— • Replace the Stator
Sensor PCB [104].
c. Controller (A) failure — • Replace Controller (A)
[117].
6 LED does not light. a. Contact failure of the
connectors
— • Check the connectors
for connection.
b. LED switch failure — • Replace Controller (A)
[117].
c. LED failure — • Replace the LED [84].

-13-
Location Item
No. Part name Tightening torque
N•m ft-lb
Head portion
Gear Case [2] [1] Hex. Socket Hd. Bolt M5 x 10 5.9±1.5 4.3±1.1
Shaft (C) [12] [3] Seal Lock Hex. Socket Set Screw M6 x 10 9.8±2.0 7.2±1.5
Handle [82] [83] Machine Screw (W/Washers) M6 x 20 (Black) 4.9±1.0 3.6±0.7
TCT Saw Blade [73] [71] Left Hex. Socket Bolt M7 8.3±0.5 6.2±0.4
Bearing Cover [77] [76] Seal Lock Flat Hd. Screw M4 x 10 1.8±0.4 1.3±0.3
Bearing Holder [79] [91] Machine Screw (W/Sp. Washer) M5 x 16 3.4±0.7 2.5±0.5
Link [89] [87] Special Screw M6 4.9±1.5 3.6±1.1
[94] Special Screw (C) M5 3.4±0.7 2.5±0.5
Lower Guard [90] [98] Machine Screw (W/Washer) M4 x 8 (Black) 2.0±0.5 1.5±0.4
Switch Handles Set [106] [108] Tapping Screw (W/Flange) D4 x 20 (Black) 2.0±0.5 1.5±0.4
Housing Set [116] [115] Machine Screw (W/Washers) M5 x 40 (Black) 3.4±0.7 2.5±0.5
[108] Tapping Screw (W/Flange) D4 x 20 (Black) 2.0±0.5 1.5±0.4
LED Cover [85] [86] Machine Screw (W/Washers) M4 x 12 (Black) 1.8±0.4 1.3±0.3
Base portion
Clamp Lever [7] [6] Machine Screw (W/Washers) M6 x 20 (Black) 4.9±1.0 3.6±0.7
Indicator [18] [19] Machine Screw (W/Washers) M4 x 10 (Black) 1.8±0.4 1.3±0.3
Indicator (A) [24] [19] Machine Screw (W/Washers) M4 x 10 (Black) 1.8±0.4 1.3±0.3
Table Insert [23] [22] Machine Screw (W/Washer) M4 x 12 (Black) 2.0±0.5 1.5±0.4
Spacer (A) [27] [28] Machine Screw (W/Washers) M4 x 8 (Black) 1.8±0.4 1.3±0.3
Spring Plate [29] [31] Hex. Socket Hd. Bolt M8 x 16 22.1±4.9 16.3±3.6
Vise Ass'y [33] [39] Machine Screw M4 x 10 1.8±0.4 1.3±0.3
Fence [47] [41] Bolt M8 x 35 14.7±3.0 10.8±2.2
Holder [49] [55] Shaft (B) 7.8 to 11.8 5.8 to 8.7
The no-load current value should be 7.0 ± 3.0 A (19.8 VDC ―equivalent to the voltage of a fully charged
battery) after no-load operation for 5 minutes.
Tightening torque
No-load current value

-14-
Fig. 15
Carefully ensure that wiring is accomplished as illustrated below. As incorrect wiring will result in lack of
rotation, reverse rotation or other malfunctions, close attention is absolutely necessary.
Wiring diagram
White
Red
Battery terminal
Yellow
Red
Black
Black
Gray
Switch
LED ass’y
Controller ass’y (A)
Stator sensor PCB ass’y
Panel ass’y

M O D E L
Rev.1
C1810DFA(1/2)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
19
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
54
51
52
53
55
601
602
603
604
605
606
607
608
609
610
611
612
613
614
615 616
617
618
619
620
621
622
623
624
625
30
613 610
626
617 619
627
601 609
613

M O D E L
Rev.1
C1810DFA(2/2)
71
72
73 74
75
76
77
78
79
80
81
82
83
87
88
88
89
90
92
93
84
85
86
94
95
96
97
98
108
108
108
106
107
99
100
101
102
103
104
105
109
110
111
112
113
114
115
115
116
117
501
502
503
504
505
91

ITEM CODE NO.
NO. NO. USED
1 949819 HEX. SOCKET HD. BOLT M5 X 10 (10 PCS.) 1
2 378668 GEAR CASE 1
3 307956 SEAL LOCK HEX. SOCKET SET SCREW M6 X 10 1
4 322889 SLEEVE 1
5 322890 SPRING 1
6 323208 MACHINE SCREW (W/WASHERS) M6 X 20 (BLACK) 1
7 371742 CLAMP LEVER 1
8 371743 BOLT (LEFT HAND) M10 1
9 318934 SPECIAL WASHER 1
10 371740 SHAFT (D) 1
11 322934 WASHER M16 1
12 322888 SHAFT (C) 1
13 371732 HINGE 1
14 302518 STOPPER PIN ASS'Y 1 INCLUD. 15
15 984528 O-RING (P-6) 1
16 371733 SCALE (B) 1
17 303409 NYLOCK BOLT M8 X 25 2
18 321329 INDICATOR 1
19 304043 MACHINE SCREW (W/WASHERS) M4 X 10 (BLACK) 2
20 371739 NYLON NUT M8 1
21 318929 WASHER (F) 1
22 333781 MACHINE SCREW (W/WASHER) M4 X 12 (BLACK) 4
23 371729 TABLE INSERT 1
24 322904 INDICATOR (A) 1
25 371719 TURN TABLE 1
26 376050 SIDE HANDLE 1
27 326696 SPACER (A) 1
28 317200 MACHINE SCREW (W/WASHERS) M4 X 8 (BLACK) 1
29 322903 SPRING PLATE 1
30 949457 SPRING WASHER M8 (10 PCS.) 5
31 949655 HEX. SOCKET HD. BOLT M8 X 16 (10 PCS.) 2
32 371741 NYLON NUT M12 1
33 322952 VISE ASS'Y 1 INCLUD. 34-40
34 375132 WING BOLT M6 X 15 1
35 302522 KNOB BOLT M10 X 66 1
36 SCREW HOLDER 1
37 949432 BOLT WASHER M6 (10 PCS.) 1
38 302532 VISE PLATE 1
39 949216 MACHINE SCREW M4 X 10 (10 PCS.) 1
40 322954 VISE SHAFT 1
41 949678 BOLT M8 X 35 (10 PCS.) 3
42 949433 BOLT WASHER M8 (10 PCS.) 3
43 326704 SUB FENCE (B) 1
44 963837 NYLON NUT M6 1
45 326711 PLATE (A) 1
46 301806 WING BOLT M6 X 15 1
47 375117 FENCE 1
48 949342 FLAT HD. SCREW M6 X 25 (10 PCS.) 1
49 326705 HOLDER 1
50 949610 BOLT M6 X 10 (10 PCS.) 1
51 931701 BEARING LOCK 1
52 371720 LINER (A) 2
53 372290 SCALE (A) 1
54 372289 BASE ASS'Y 1 INCLUD. 53
55 371738 SHAFT (B) 1
71 371730 LEFT HEX. SOCKET BOLT M7 1
72 371731 WASHER (E) 1
73 318963 TCT SAW BLADE 255 MM-D15.88 HOLE-NT24 1
74 308789 WASHER (D) 1
75 371725 SPINDLE ASS'Y 1 INCLUD. 76-81
76 990430 SEAL LOCK FLAT HD. SCREW M4 X 10 2
77 322919 BEARING COVER 1
78 6003VV BALL BEARING 6003VVCMPS2L 1
79 322918 BEARING HOLDER 1
80 371726 SPINDLE AND GEAR SET 1
81 608VVM BALL BEARING 608VVC2PS2L 1
82 326708 HANDLE 1
83 323208 MACHINE SCREW (W/WASHERS) M6 X 20 (BLACK) 2
84 378670 LED 1
85 378671 LED COVER 1
86 935196 MACHINE SCREW (W/WASHERS) M4 X 12 (BLACK) 3
87 322950 SPECIAL SCREW M6 1
88 322948 WASHER M7 2
DESCRIPTION REMARKS

ITEM CODE NO.
NO. NO. USED
DESCRIPTION REMARKS
89 371735 LINK 1
90 378669M LOWER GUARD 1
91 987512 MACHINE SCREW (W/SP. WASHER) M5 X 16 2
92 949340 FLAT HD. SCREW M6 X 16 (10 PCS.) 1
93 961729 CUSHION 1
94 322947 SPECIAL SCREW (C) M5 1
95 322938 WASHER M10 1
96 371745 SPACER (B) 1
97 949454 SPRING WASHER M5 (10 PCS.) 1
98 315500 MACHINE SCREW (W/WASHER) M4 X 8 (BLACK) 3
99 371723 RUBBER RING 1
100 361175 ROTOR ASS'Y 1 INCLUD. 101, 103
101 6002VV BALL BEARING 6002VVCMPS2L 1
102 322916 LOCK LEVER 1
103 606ZZM BALL BEARING 606VV 1
104 341119 STATOR SENSOR PCB 1
105 959141 CONNECTOR 50092 (10 PCS.) 3
106 378672 SWITCH HANDLE SET 1
107 371751M BATTERY BSL 36A18 (USA, CAN) 1 INCLUD. 502
108 301653 TAPPING SCREW (W/FLANGE) D4 X 20 (BLACK) 16
109 NAME PLATE 1
110 378673 TRIGGER 1
111 336667 LOCK SPRING 1
112 376830 SPRING (A) 1
113 378674 OFF LOCK LEVER 1
114 371907 SWITCH 1
115 303796 MACHINE SCREW (W/WASHERS) M5 X 40 (BLACK) 4
116 378676 HOUSING SET 1
117 378675 CONTROLLER (A) 1
501 CHARGER (MODEL UC 18YSL3) 1
502 329897 BATTERY COVER 1
503 944459 HEX. BAR WRENCH 5 MM 1
504 949695 BOLT M10 X 35 (10 PCS.) 1
505 322955M DUST BAG (BLACK) 1
601 322957 VISE (B) ASS'Y 1 INCLUD. 602-608
602 321551 KNOB BOLT M10 X 54 1
603 998836 KNOB BOLT M6 X 11 1
604 SCREW HOLDER (B) 1
605 306985 WASHER (H) 1
606 964851 BASE RUBBER 1
607 304043 MACHINE SCREW (W/WASHERS) M4 X 10 (BLACK) 1
608 318967 VISE SHAFT 1
609 323546 CROWN MOLDING STOPPER (L) ASS'Y 1 INCLUD. 610-613
610 301806 WING BOLT M6 X 15 2
611 CROWN MOLDING STOPPER (L) 1
612 321390 CROWN MOLDING STOPPER HOLDER 1
613 323682 WING BOLT M6 X 85 2
614 323547 CROWN MOLDING STOPPER (R) ASS'Y 1 INCLUD. 610, 613, 615, 616
615 321390 CROWN MOLDING STOPPER HOLDER 1
616 CROWN MOLDING STOPPER (R) 1
617 974561 STOPPER 1
618 949404 WING BOLT M6 X 20 (10 PCS.) 1
619 322956 HOLDER ASS'Y 1 INCLUD. 620-625
620 321549 HOLDER 1
621 949313 WING NUT M6 (10 PCS.) 1
622 949556 NUT M6 (10 PCS.) 1
623 322047 VISE PLATE 1
624 949425 WASHER M6 (10 PCS.) 1
625 323134 HIGH TENSION BOLT M6 X 80 1
626 322710 GUIDE ASS'Y 1 INCLUD. 613, 617-619
627 322712 CROWN MOLDING VISE ASS'Y 1 INCLUD. 601, 609
628 976472 TCT SAW BLADE CROSS-CUT 255 MM-D15.9 HOLE 1
629 319658 TCT SAW BLADE 255 MM-D15.88 HOLE-NT100 1
STANDARD ACCESSORIES
OPTIONAL ACCESSORIES
