METREL A 1582 User manual

High temperature Flex current clamps
A 1582
User Manual
Version 1.2; Code No. 20 752 751

2
Distributor:
Producer:
METREL d.d.
Ljubljanska 77
SI-1354 Horjul
Tel.: [phone]
Fax: [phone]
E-mail: [e-mail]
http://www.metrel.si
Mark on your equipment certifies that this equipment meets the requirements of
the EC (European Community) regulations concerning safety and
electromagnetic compatibility.
© 2017 Metrel
No part of this publication may be reproduced or utilized in any form or by any means
without permission in writing from METREL.

Flex current clamps A 1582
3
Table of contents
1Introducing the A1582.............................................................................................. 4
2Features.................................................................................................................. 5
3Safety...................................................................................................................... 6
4Symbols................................................................................................................... 7
5Measuring current with A1582 ................................................................................. 8
6Cleaning.................................................................................................................. 9
7Service.................................................................................................................. 10
8Technical specifications......................................................................................... 11

Flex current clamps A 1582
4
1 Introducing the A1582
The A1582 Flexible Current Clamps consist of the flexible sensor and an
electronic module on the connected wire. It has three current ranges 30A, 300A and
3000A. The current range of the A1582 is selected directly by the connected instrument.
The electronic module is powered from the connected instrument to. The flexible sensor
permits measurements on conductors where standard clamp-on current transformers
can not be used. It is particularly useful for installation in tight spaces, or around breaker
panels, cable bundles, wide or large bus bars and irregular shapes. Unlike standard
current transformers, this flexible CP does not use magnetic cores. The transformation
principle is based on an air core. It presents virtually no load to the system under test,
has a low phase shift and excellent frequency response.
A1582 Flexible Current Clamps have silicone cover, and therefore are particularly
suitable for measuring on substations busbars where temperature can reach more than
105 °C temporary. Additionally, A1582 cannot be damaged by overloads. The A1582
Flexible Current Clamps are insensitive to DC current and measure only the AC
component of the measured signal.

Flex current clamps A 1582
5
2 Features
Range setup from the instrument, no additional range setup needed
Power supply for electronic module is assured from the instrument
mV output
Waterproof sensor
Minimum angle shift to accomplish accurate power measurements
High accuracy
Total rejection of d.c. component
Friendly-use of the closing-opening system of the current sensor (even if wearing
gloves) due to its highly ergonomic design
It is possible to set the seal on the closing system of the current clamp.
Very light, flexible and fully adaptable to busbar trunking system and insulated
cables
Strengthened security, regardless the working environment industrial or services
