MS9500 SERIES VOYAGER®
PRODUCT GUIDE
Single Line, Hand-Held,
1D, High-Density 1D,
PDF-417 2D and Wireless
Laser Bar Code Scanners
TPV Center

MS9520 Voyager®
MS9540 VoyagerCG®
with CodeGate
MS9521 VoyagerHDTM
MS9541 VoyagerHDTM
with CodeGate
MS9524 VoyagerPDFTM
MS9544 VoyagerPDFTM
with CodeGate
MS9535 VoyagerBTTM
with CodeGate
Sunrise 2005 Compliant
Complete Kits Standard
User-replaceable Detachable Cables
Decoding of all standard 1D, RSS-14, RSS Limited and RSS Expanded bar code
Flash ROM Upgrades
Custom Edit Bar Codes
Support for Common Interfaces
Auto Activation Mode (hands-free)
Metrologic’s Voyager®family is a diverse group of single-line, hand-
held, laser bar code scanners with features for virtually every requirement from
decoding standard 1D bar codes to wireless applications. Specific Voyager models
incorporate Metrologic’s proprietary CodeGate technology, scan 2D (PDF) or high
density bar codes. Whatever your needs, Voyager is the right scanner for you.
Voyager®Selection Chart
ALL VOYAGER MODELS FEA-
STANDARD
WIRELESS
2D
BAR CODES
HIGH DENSITY
BAR CODES
Page 6
Page 5
Page 4
Page 3
CCoonntteennttss
About Voyager®Scanners
Voyager Selection Chart
MS9520 Voyager
MS9540 VoyagerCG®
MS9535 VoyagerBTTM
MS9524 VoyagerPDFTM
MS9544 VoyagerPDFTM
MS9521 VoyagerHDTM
MS9541 VoyagerHDTM
Options and Accessories
MetroSet®2Software Utility
Specifications
1
2
3
3
4
5
5
6
6
7
8
9-10
1

Modes of Operation
In Stand, Auto Trigger - CodeGate and Non-CodeGate Models
11
The auto-
trigger will
activate the
laser line in
the stand.
22
Present bar
code to the
scanner and
it will be
decoded and
the data
transmitted
automatically.
Out-of-Stand - CodeGate Models
11
The auto-
trigger will
activate the
laser line.
22
Place the
laser line on
the bar code.
33
Press the
button to
decode and
transmit bar
code data.
Out-of-Stand, Manual Activation - CodeGate Models
11
Press and
hold the
button to
activate the
laser line.
22
Place the
laser line on
the bar code.
33
Continue
holding down
the button to
decode and
transmit bar
code data.
Out-of-Stand, Auto Trigger - Non-CodeGate Models and CodeGate Models with CodeGate Feature Deactivated
11
The auto-
trigger will
activate the
laser line.
22
Place the
laser line on
the bar code
and it will
decode and
transmit the
data
automatically.
BEEP
BEEP
BEEP
PRESS
AND HOLD
PRESS
BEEP

qquuiicckkssppeeccss
Depth of Field 0 mm - 203 mm (0” - 8”) for 0.33 mm (13 mil) bar codes
Width of Field 64 mm (2.5”) @ face; 249 mm (9.8”) @ 203 mm (8.0”)
Scan Speed 72 + 2 scan lines per second
Scan Pattern Single scan line
Minimum Bar Width 0.127 mm (5.0 mil)
Dimensions 198 mm (7.8”) H x 40 mm (1.6”) D x Handle Width: 45 mm (1.8”) Head Width: 78 mm (3.1”)
Interfaces PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, IBM 468X/469X,
Stand Alone Keyboard, USB
Light Source Visible Laser Diode 650 nm + 10 nm
Weight 149 g (5.25 oz)
Shock Normal operation after 30 drops to concrete of 1.5 m (5’)
Bar Code Minimum Element
0.132 mm (5.2 mil)
0.190 mm (7.5 mil)
0.264 mm (10.4 mil)
0.330 mm (13 mil)
0.533 mm (21 mil)
0 mm 50 mm 100 mm 150 mm 200 mm 250 mm
(0”) (2”) (4”) (6”) (8”) (10”)
Scan Area
249 mm
(9.8”)
Voyager and VoyagerCG are auto-trigger,
single-line laser bar code scanners designed for decoding
all standard 1D bar codes, including RSS codes. Their sleek,
futuristic designs certainly catch your attention. But looks get you
only so far, it’s performance and value that really count. It is here
that Voyager excels and sets new industry standards.
SCANS 1D BAR CODES
with or without CodeGate
Features
•Automatic trigger
•Decodes all standard 1D, RSS-14, RSS Limited, and
RSS expanded bar codes
•User-replaceable, single cable interface to host
•Adjustable stand
MMooddeellMMSS99554400OOnnllyy
•CodeGate data transmission technology
SSuunnrriissee22000055CCoommpplliiaanntt
MS9520
MS9540
MS9520 Voyager®& MS9540 VoyagerCG ®
3
64 mm
(2.5”)
158 mm
(6.2”)
Long Range IR
Short Range IR
320 mm
(12.6”)
Width of Scan Field
Distance
From Face
0 mm
(0.0”)
102 mm ± 25 mm
(4.0” ± 1.0”)
279 mm ± 51 mm
(11.0” ± 2.0”)
IR Activation
and Scan Width

qquuiicckkssppeeccss
Depth of Field 0 mm - 203 mm (0” - 8”) for 0.33 mm (13 mil) bar codes
Width of Field 64 mm (2.5”) @ face; 249 mm (9.8”) @ 203 mm (8.0”)
Scan Speed 72 + 2 scan lines per second
Scan Pattern Single scan line
Minimum Bar Width 0.127 mm (5.0 mil)
Dimensions Scanner: 198 mm (7.8”) H x 40 mm (1.6”) D x Handle Width: 45 mm (1.8”) Head Width: 78 mm (3.1”)
Base: 61 mm (2.4”) H x 204 mm (8.0”) D x 107 mm (4.2”) W
Interfaces PC Keyboard Wedge, RS232, Light Pen Emulation, IBM 468X/469X, Stand Alone Keyboard, USB
Light Source Visible Laser Diode 650 nm + 10 nm
Weight Scanner (with battery):199 g (7.0 oz); Base: 225 g (7.9 oz)
Shock Normal operation after 30 drops to concrete of 1.5 m (5’)
Bar Code Minimum Element
0.132 mm (5.2 mil)
0.190 mm (7.5 mil)
0.264 mm (10.4 mil)
0.330 mm (13 mil)
0.533 mm (21 mil)
0 mm 50 mm 100 mm 150 mm 200 mm 250 mm
(0”) (2”) (4”) (6”) (8”) (10”)
249 mm
(9.8”)
MS9535 VoyagerBTTM
Metrologic's VoyagerBT offers convenience and the freedom of
mobility by incorporating Bluetooth wireless technology into a Voyager
Series scanner. VoyagerBT provides a lightweight, comfortable, and
easy to use scanning solution with unmatched standard features.
Features
•Cable-free scanning using Bluetooth®technology
•CodeGate®data transmission ideal for menu scanning
•Up to 12,000 scans per charge
•Adjustable volume and beeper tone
•Recharging base station with in base scanning
•Wall or countertop mounting
•10 meter (33') working range
•Two way communication - user receives audible
and visual confirmation of each scan
•Scanner locating button on cradle
SSuunnrriissee22000055CCoommpplliiaanntt
64 mm
(2.5”)
158 mm
(6.2”)
Long Range IR
Short Range IR
320 mm
(12.6”)
Width of Scan Field
Distance
From Face
0 mm
(0.0”)
102 mm ± 25 mm
(4.0” ± 1.0”)
279 mm ± 51 mm
(11.0” ± 2.0”)
IR Activation
and Scan Width
SCANS 1D BAR CODES USING WIRELESS
BLUETOOTH TECHNOLOGY
with CodeGate Scan Area

MS9524 VoyagerPDF TM & MS9544 VoyagerPDF TM
Features
•Decodes 1D & 2D (including RSS, PDF417, PDF417
truncated, micro PDF and macro PDF) bar codes
•Automatic trigger operation
•180 scans per second
•Auto stand detect
MMooddeellMMSS99554444OOnnllyy
•CodeGate®data transmission technology
SSuunnrriissee22000055CCoommpplliiaanntt
Depth of Field 0 mm - 203 mm (0” - 8”) for 0.33 mm (13 mil) bar codes
Width of Field 64 mm (2.5”) @ face; 249 mm (9.8”) @ 203 mm (8.0”)
Scan Speed 180 + 10 scan lines per second
Scan Pattern Single scan line
Minimum Bar Width 0.127 mm (5.0 mil)
Dimensions 198 mm (7.8”) H x 40 mm (1.6”) D x Handle Width: 45 mm (1.8”) Head Width: 78 mm (3.1”)
Interfaces PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, IBM 468X/469X, Stand Alone Keyboard, USB
Light Source Visible Laser Diode 650 nm + 10 nm
Weight 149 g (5.25 oz)
Shock Normal operation after 30 drops to concrete of 1.5 m (5’)
Metrologic’s MS9524 and
MS9544 VoyagerPDF scanners offer the same outstanding
performance found in all Voyager Series scanners. What differentiates
the VoyagerPDF scanners is the ability to decode 2D codes such as
PDF417, PDF417 truncated, micro PDF, macro PDF and RSS-14
composite bar code symbologies.
5
qquuiicckkssppeeccss
Bar Code Minimum Element
0.132 mm (5.2 mil)
0.190 mm (7.5 mil)
0.264 mm (10.4 mil)
0.330 mm (13 mil)
0.533 mm (21 mil)
0 mm 50 mm 100 mm 150 mm 200 mm 250 mm
(0”) (2”) (4”) (6”) (8”) (10”)
249 mm
(9.8”)
PDF417 Bar Code Minimum Element
0.254 mm (10 mil)
0.381 mm (15 mil)
64 mm
(2.5”)
158 mm
(6.2”)
Long Range IR
Short Range IR
320 mm
(12.6”)
Width of Scan Field
Distance
From Face
0 mm
(0.0”)
102 mm ± 25 mm
(4.0” ± 1.0”)
279 mm ± 51 mm
(11.0” ± 2.0”)
IR Activation
and Scan Width
Scan Area
SCANS 1D AND
PDF-417 (2D)
BAR CODES
with or without
CodeGate
MS9524
MS9544

Features
•Decodes high density bar codes
with a minimum width of 0.076 mm
(3.0 mil), as well as all standard 1D,
RSS-14, RSS Limited and
RSS expanded bar codes
•Automatic trigger operation
•Custom edit the bar code data
•User-replaceable, single cable interface to host
MMooddeellMMSS99554411OOnnllyy
•CodeGate®data transmission technology
SSuunnrriissee22000055CCoommpplliiaanntt
qquuiicckkssppeeccss
Depth of Field 0 mm - 102 mm (0” - 4”) for 0.33 mm (13 mil) bar codes
15 mm - 35 mm (0.6” - 1.4”) for 0.076 mm (3.0 mil) bar codes
Width of Field 64 mm (2.5”) @ face; 157 mm (6.2”) @ 102 mm (4.0”)
Scan Speed 72 + 2 scan lines per second
Scan Pattern Single scan line
Minimum Bar Width 0.076 mm (3.0 mil)
Dimensions 198 mm (7.8”) H x 40 mm (1.6”) D x Handle Width: 45 mm (1.8”) Head Width: 78 mm (3.1”)
Interfaces PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, IBM 468X/469X,
Stand Alone Keyboard, USB
Light Source Visible Laser Diode 650 nm + 10 nm
Weight 149 g (5.25 oz)
Shock Normal operation after 30 drops to concrete of 1.5 m (5’)
Metrologic’s MS9521 and MS9541 VoyagerHD
are high performance single line laser bar code scanner capable of
scanning high density (3 mil) bar codes.
Bar Code Minimum Element
0.076 mm (3.0 mil)
0.122 mm (4.8 mil)
0.173 mm (6.8 mil)
0.264 mm (10.4 mil)
0.330 mm (13.0 mil)
0 mm 50 mm 100 mm
(0”) (2”) (4”)
Scan Area
156 mm
(6.2”)
MS9521 VoyagerHDTM & MS9541 VoyagerHDTM
64 mm
(2.5”)
158 mm
(6.2”)
Long Range IR
Short Range IR
320 mm
(12.6”)
Width of Scan Field
Distance
From Face
0 mm
(0.0”)
102 mm ± 25 mm
(4.0” ± 1.0”)
279 mm ± 51 mm
(11.0” ± 2.0”)
IR Activation
and Scan Width
SCANS HIGH-DENSITY 1D BAR CODES
with or without CodeGate
MS9521
MS9541

Optional
Wall Mount
shown with
MS9540 VoyagerCG
(scanner sold
seperately)
Voyagers
are available in two standard
colors: Light Grey and Black.
They are also available in a
variety of other colors with
minimum quantity purchase.
Standard
Stand Mounting
Hardware
Included in all
MS9500 Series Kits
- except MS9535
shown with
MS9541 VoyagerHD
Optional
Charger Only
Cradle
for applications
where the scanner
communicates directly
with another
Bluetooth device
Optional
VoyagerBT
Presentation
Stand
shown with
MS9535 VoyagerBT
(scanner sold
seperately)
MS9500 Series Voyager ®Options and Accessories
7

MetroSet®2 Software Utility
The Voyager®Family of Scanners
SSttaannddaarrddVVooyyaaggeerrCCoolloorrss
Light Grey Black
Voyagers are available in a
variety of other colors with min-
imum quantity purchase
MetroSet®2 is a graphical programming utility that provides users with a Windows based tool for programming,
formatting data parsing and flashing Metrologic Voyager Series Scanners.
Simply select the scanner type from the list provided and begin programming. Users can upload their current
settings and easily make changes to create a custom configuration. This file can then be saved and used to
program multiple scanners, assuring they all have the same configuration.
Also included in MetroSet 2 is a Flash Utility that allows users to upgrade firmware by simply selecting the
file and clicking the "Flash Scanner" button. Customers can receive new firmware from Metrologic's
Technical Support Department by contacting their local Metrologic representative.

MS9520 Voyager®& MS9540 VoyagerCG®
SCANS 1D BAR CODES - with or without CodeGate
MS9521 & MS9541 Voyager
SCANS HIGH DENSITY 1D BAR
- with or without CodeGate
Height
Depth
Width
Weight
Termination
Cable
Input Voltage
Power - Operating
Power - Standby
Current - Operating
Current - Standby
DC Transformers
Laser Class
EMC
Current Charging
Recharge Time
Battery Capacity
Radio Range
Frequency
Operating Temperature
Storage Temperature
Humidity
Light Levels
Shock
Contaminants
Light Source
Laser Power
Depth of Scan Field (program)
Width of Scan Field
Scan Speed
Scan Pattern
Minimum Bar Width
Decode Capability
System Interfaces
Print Contrast
Number Characters
Roll, Pitch, Yaw
Beeper Operation
Indicators (LED)
Profile Support
Bluetooth Version
Visible Laser Diode 650 nm + 10 nm
0.96 mW (peak)
0 mm - 203 mm (0” - 8”) for 0.33 mm (13 mil) bar codes
64 mm (2.5”) @ face; 249 mm (9.8”) @ 203 mm (8.0”)
72 + 2 scan lines per second
Single scan line
0.127 mm (5.0 mil)
Autodiscriminates all standard 1D bar codes, including RSS,
for other symbologies call Metrologic
PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, Non-decode
Emulation, IBM 468X/469X, Stand Alone Keyboard, USB (low speed and full speed)
35% minimum reflectance difference
Up to 80 data characters
42°, 68°, 52°
7 tones or no beep
Green=laser on, ready to scan; yellow=auto trigger mode active; red=good read
N/a
N/a
Visible Laser Diode 650 nm + 10 nm
0.96 mW (peak)
15 mm - 35 mm (0.6” - 1.4”) for 0.076 mm (3 mil) bar code
64 mm (2.5”) @ face; 157 mm (6.2”) @ 102 mm (4.0”)
72 + 2 scan lines per second
Single scan line
0.076 mm (3.0 mil)
Autodiscriminates all standard 1D bar codes, including RSS,
for other symbologies call Metrologic
PC Keyboard Wedge, RS232, OCIA, Light Pen Emulation, Non
Emulation, IBM 468X/469X, Stand Alone Keyboard, USB (low
35% minimum reflectance difference
Up to 80 data characters
42°, 68°, 52°
7 tones or no beep
Green=laser on, ready to scan; yellow=auto trigger mode
N/a
N/a
198 mm (7.8”)
40 mm (1.6”)
Handle - 45 mm (1.8”); Head - 78 mm (3.1”)
149 g (5.25 oz)
10 pin modular RJ45
Standard 2.7 m (9’) coiled; optional 2.1 m (7’) straight
198 mm (7.8”)
40 mm (1.6”)
Handle - 45 mm (1.8”); Head - 78 mm (3.1”)
149 g (5.25 oz)
10 pin modular RJ45
Standard 2.7 m (9’) coiled; optional 2.1 m (7’) straight
5 VDC + 0.25 V
500 mW
110 mW
100 mA typical @ 5 VDC
22 mA typical @ 5 VDC
Class 2; 5.2 VDC @ 650 mA
Laser Class 1 In accordance with IEC 60825-1:1993+A1:1997+A2:2001
and EN 60825-1:1994+A11:1996+A2:2001
FCC, ICES-003 & EN55022 Class B
N/a
N/a
N/a
N/a
N/a
5 VDC + 0.25 V
500 mW
110 mW
100 mA typical @ 5 VDC
22 mA typical @ 5 VDC
Class 2; 5.2 VDC @ 650 mA
Laser Class 1 In accordance with IEC 60825-1:1993+A1:199
and EN 60825-1:1994+A11:1996+A2:2001
FCC, ICES-003 & EN55022 Class B
N/a
N/a
N/a
N/a
N/a
0°C to 40°C (32°F to 104°F)
-40°C to 60°C (-40°F to 140°F)
5% to 95% relative humidity, non-condensing
Up to 4842 Lux (450 footcandles)
Normal operation after 30 drops to concrete of 1.5 m (5’)
Sealed to resist airborne particulate contaminants
0°C to 40°C (32°F to 104°F)
-40°C to 60°C (-40°F to 140°F)
5% to 95% relative humidity, non-condensing
Up to 4842 Lux (450 footcandles)
Normal operation after 30 drops to concrete of 1.5 m (5’)
Sealed to resist airborne particulate contaminants
OPERATIONAL
MECHANICAL
ELECTRICAL
ENVIRONMENTAL
9
