METRON PC05T User manual

www.eauto.si [email protected] [phone]
PC05T PORTABLE CHARGER
GET STARTED
Blue LED starts blinking slowly which means the
vehicle is charging. When your electric vehicle is fully
charged the blue LED glows constantly. To unplug
PC05T press and hold the “3-function” button for a
second. The TESLA car will unlock the plug (only if car
is unlocked/owner nearby!) and you can unplug
PC05T without touching the smart phone or central
screen.
1
USER MANUAL
INTEGRATED REMOTE
CHARGE PORT OPENER &
PLUG UNLOCKER
3-phase 11 kW »BOXLESS« portable
charger design
PC05T PORTABLE CHARGER
for TESLA electric vehicles
11 kW 3-phase METRON EV portable charger PC05T is
designed to charge TESLA electric vehicles equipped
with Type 2 charging sockets (European standard)
from 3-phase 16A CEE sockets (or any other 1 or 3
phase outlets by using appropriate adapter). PC05T
features integrated REMOTE CHARGE PORT OPENER
& PLUG UNLOCKER that works with all TESLA brand
cars.
It also offers possibility to set desired charging
current/power with a simple button press. Where’s
the heavy in-line “bulky box”? It doesn’t exist,
miniaturized portable charger electronics is placed
inside METRON Type 2 charging plug itself! This
makes METRON portable charger PC05T lighter, easier
to install/connect and easier to store in a carrier case.
First plug the PC05T portable charger in the wall
outlet. Immediately blue signal LED starts blinking:
number of blinks indicates saved power setting (see
the next page). Afterwards, LED glows constantly till
AC power is present indicating standby/ready status.
Next, press the “3-function” button to remotely open
TESLA charge port and insert PC05T Type 2 plug into
the vehicle’s Type 2 charging socket.

2
REMOTE CHARGE PORT OPEN & PLUG UNLOCK
SETTING THE DESIRED CHARGING CURRENT/POWER
PC05T portable charger allows user to set desired charging current/power before it’s plugged in the TESLA
electric vehicle Type 2 socket or even while the vehicle is charging! Procedure is simple:
• press and hold the “3 function” push button: LED turns off immediately,
• after 5 seconds LED starts blinking slowly,
• releasing the push button after a certain number of blinks determines charging
current/power as follows:
1 3 x 6 A / 4,1 kW
2 3 x 8 A / 5,5 kW
3 3 x 10 A / 6,9 kW
4 3 x 13A / 9,0 kW
5 3 x 16A / 11,0 kW
Charging current/power
LED light
“3-function”
Push Button
New charging current/power setting is stored in the memory and it stays the same
(even after the power supply is not present anymore) until the next setting change is
performed.
All Tesla vehicles also allow users to set charging current manually on the Tesla central
screen or smart phone application. But if you set PC05T charging current to e.g. 10A
that would immediately LIMIT the max. charging current setting to 10A also on Tesla
central screen or smart phone application.
(6 A / 1,4 kW – single phase mode)
(8 A / 1,8 kW – single phase mode)
(10 A / 2,3 kW – single phase mode)
(13A / 3,0 kW – single phase mode)
(16A / 3,7 kW – single phase mode)
Number of
LED blinks
When PC05T is plugged into the wall outlet/socket (power applied) pressing a “3-function” button sends a
remote-control signal to your TESLA vehicle charge port which then opens remotely. Signal range is usually
between 3 and 15 meters. This feature eliminates user “touching” the smart phone or Tesla central screen in
order to open the charge port.
To unplug PC05T while still charging or when charging completed press and hold the “3 function” button for
a second. The car will unlock the plug (only if car is unlocked/owner nearby!) and then you can unplug PC05T.
This feature once again eliminates the need for user “touching” the smart phone or Tesla central screen in
order to unlock PC05T plug from Tesla charge port.
These are two functions of the “3-function” push button. Third one is described in the next chapter below.

3
RCD is an acronym for Residual Current Device - sometimes it can be called also Earth Leakage Circuit Breaker or
Safety Switch. Its purpose is to prevent you from getting a fatal electric shock if you touch live part, such as a bare
copper wire under high voltage. RCDs offer a level of personal protection that ordinary fuses/circuit-breakers
cannot provide. RCD constantly monitors the electric current flowing through one or more circuits which it
protects. If it detects electricity flowing down an unintended path, such as through a person who has touched a
live part, the RCD will switch the circuit off very quickly, significantly reducing the risk of death or serious injury.
PC05T is equipped with Metron RCD Type B device called RCDB1-316CEE which represents maximum possible
level of personal protection as it protects users from AC, pulsating DC, pure DC and also high frequency AC
leakage currents. In order to ensure “BOXLESS” design of PC05T portable charger RCD is packed inside 3-phase
16A CEE plug itself what eliminates even the smallest unsafe section found on other portable chargers where
there is at least 30cm of unprotected cable between wall plug and “bulky” in cable control box.
Red LED indicates RCD cut-off the power because of leakage current detection.
To reset just unplug, wait a second, and plug it in again.
WHAT IS RCD AND HOW DOES IT WORK?
STATUS NOTIFICATION BY LED BLINKS
LED STATUS NOTIFICATION
Slow blinking when power supply is applied
Constantly on when not plugged in
Slow blinking when plugged in
Constantly on when plugged in
Indicating previous saved current setting
Stand-by / Ready to charge
Charging
Electric vehicle fully charged
Electric vehicle requests room ventilation
(no charging)
Portable charger overheated (no charging); restarts
charging automatically when it cools down
Fault
Slow blinking 3 times (plugged in or not plugged in)
Rapid blinking (plugged in or not plugged in(
Slow blinking 2 times when plugged in
RED LED light
On request PC05T can be also supplied without RCDB1-316CEE. The use of PC05T
portable charger version without RCD protection is allowed exclusively on the
installations protected by RCD.
In the event the cable has been damaged the product should be removed from
use immediately!
3-phase portable charger PC05T can also charge from any domestic wall socket
(e.g. Schuko) or 1-phase 16A CEE “camper” socket if proper adapter is used. In such
case PC05T behaves like a regular 1-phase portable charger (same charging
current/power).

Rev.0 9/2019
4
LIMITED WARRANTY
METRON warrants its product to the original consumer purchaser that it will repair, or replace, any product that is
determined to be defective for the following terms: One (1) year from date of purchase on all components.
To be eligible for repair or replacement under this warranty, the product in question must be sent back to
METRON within the warranty period and the original consumer purchaser must comply with the following
conditions:
• The product thereof must not have been modified or altered in any way by an unauthorized source.
• The product thereof must have been used in accordance with the user manual.
This limited warranty does not cover:
• Damage due to improper use;
• Accidental or intentional damage;
• Misuse, abuse, corrosion, or neglect;
• Product impaired by severe natural conditions, such as excessive hail storms, lightning strikes,
tornados, flooding, ice or other natural occurrences;
• Damage due to improper packaging on return shipment.
Any and all labor charges for troubleshooting, removal or replacement of the product are not covered by this
warranty and will not be honored by METRON.
All shipping costs regarding repair or replacement of the product is to be pre-paid by the original consumer
purchaser.
yes (all parts)
UV resistance
Type 2 (IEC 62196) Female Plug
CEE 16A (3-phase/3P+N+E)
6/8/10/13/16 A
11 kW (3-phase)
3,7 kW (1-phase)
400 Vac (3-phase)
230 Vac (1-phase)
155 V to 470 V (3-phase) (50/60 Hz)
90 V to 270 V (1- phase) (50/60 Hz)
3x16A (3-phase) or
1x16A (1-phase)
5m to 12m (or on request)
yes
Yes, 30mA, integrated inside 3-phase CEE 16A plug
(optionally PC05T can be supplied without RCD)
IP54 (rain water resistant)
from -30°C to +50°C
With RCD: 2,3 kg (5m cable) + 0,22 kg per each additional meter of cable
Without RCD: 1,9 kg (5m cable) + 0,22 kg per each additional meter of cable
TECHNICAL SPECIFICATIONS
EV Side Plug Type
Wall socket/grid side Standard Plug Types
Max. Charging Current
Possible charging current settings
Max. Charging Power
Rated Voltage
Operating voltage/frequency range
PREMIUM quality polyurethane
compound cable (Made in Germany)
Cable length
IP Rating
Operating Ambient Air Temperature Range
Type B ground fault protection device (RCD)
Weight
Note: Tesla Model 3 vehicle on-board charger is phase sequence sensitive, what means that the phases have to
be in a proper sequence 1-2-3 at wall socket. If they are not, the car will not charge.
