Mezger AC-1 User manual
Bluetooth TWS Earbuds
AC-1
User Guide
INCLUDED
A) Left ear bud
B) Right ear bud
C) Charging case
D) XS/S/M/L silicone tips
E) S/M/L memory foam tips
F) Charging cable
C
A
D E F
B
CHARGING
To charge the earphones, place them in the
charging case, wait for white LED to turn RED
and close the lid. Open the case to check
if the red LED has turned off. If the LED is
off, earphones are fully charged. Charging
time is approximately 1.5 hours for 6 hours
of playtime. A fully charged case provides 5
extra earphone charges when on-the-go. The
number of lights indicates the charging case
battery status when the earphones are placed
in the case. 3 lights = 67-100% charged,
2 lights = 34-66% charged, 1 light = 1-33%
charged, 0 lights = 0% charged. Charge
the case using the USB-A to USB-C cable
connected to a computer or wall charger. Each
indicator at the back of the charging case
flashes white when charging and turns solid
white when fully charged. Charging time is
approximately 2 hours.
SET-UP / PAIRING
Remove earphones from the charging case
and tap the right earphone to turn it on. Keep
a distance of less than 20 cm between the left
and right earphones. The product indicator will
turn from red white, a sound is heard when the
earbuds are connected to each other. Activate
Bluetooth functionality on the input device,
select Mezger AC-1, once connected the LEDs
will flash white twice. The product is ready
for use. Mezger AC-1 remembers previously
connected devices. When turned on, Mezger
AC-1 attempts to reconnect to previously
connected devices.
FITTING
Mezger AC-1 contains silicone tips and
memory foam tips. Mezger AC-1 is fitted with
medium silicone tips out of the box.
When using the memory foam tips, squeeze
down the foam tip and roll the tip into a thin,
round cylinder. Pull back and up on the ear
into the canal. Gently insert the entire tip into
the ear. Hold the tip in place until it expands.
1
2
3
4
CONTROLS
Double tap the left earphone to skip to
the previous song and double tap the right
earphone to skip to the next song during
music playback. For incoming calls, tap either
one of the earphones to accept or hold for
5 seconds to reject. During a call, double tap
either one of the earphones to terminate the
call or triple tap to transfer audio from Mezger
AC-1 to the connected device.
Single tap:
Play / pause / accept call
Double tap:
Skip to next song / end call
Single tap:
Play / pause / accept call
Double tap:
Skip to previous song / end call
When transporting the headphones use the
case provided lorem ipsum dolor sit amet
consectatur.
Do not drop, throw or lorem ipsum dolor sit
amet consectatur.
Keep away from water lorem ipsum dolor sit
amet consectatur.
Keep away from magnets - as these can
damage the drivers lorem ipsum dolor sit amet
consectatur.
Should you wish to have your headphones
serviced at any point, contact:
CARE AND
MAINTENANCE
WARRANTY AND
SERVICING
This product comes with a 2 year warranty. In
the event that you encounter a fault within 2
years of purchasing contact:
warran[email protected]om
If you experience an issue outwith the
period of warranty, or want to upgrade your
headphones, you can send them to us. We will
review the headphones and repair or upgrade
at a fixed cost of £45 plus shipping, or salvage
the recyclable parts and offer a 35% discount
on a new or refurbished unit. To arrange an
upgrade or repair outwith warranty contact:
SAFETY
Macer Audio Limited hereby declares that this
product is in compliance with the essential
requirements and other relevant provisions of
Directive 2014/53/EU and all other applicable
EU directive requirements. The complete
declaration of conformity can be found at:
www.mezger-audio.com/compliance
This product conforms to all applicable
Electromagnetic Compatibility Regulations
2022 and all other applicable UK regulations.
The complete declaration of conformity can
be found at:
www.mezger-audio.com/compliance
Macer Audio Limited hereby declares that this
product is in compliance with the essential
requirements per Radio Equipment Regulations
2022 and all other applicable UK regulations.
The complete declaration of conformity can
be found at:
www.mezger-audio.com/compliance
PRECAUTIONS
Do NOT use the earphones at a high
volume for any extended period.
To avoid hearing damage, use your
earphones at a comfortable, moderate
volume level.
Turn the volume down on your device
before placing the earphones in your
ears, then turn the volume up
gradually until you reach a
comfortable listening level.
Do NOT use your earphones while
driving or at any time the inability to
hear surrounding sounds may present
a danger to yourself or others.
The charging case and earphones
shall not be exposed to excessive
heat such as sunshine, fire or the like.
Focus on your safety and that of
others if you use the earphones
while engaging in any activity
requiring your attention, e.g., while
riding a bicycle or walking in or near
trac, a construction site or railroad,
etc. Remove the earphones or
adjust your volume to ensure you can
hear surrounding sounds, including
alarms and warning signals.
Do NOT use the headphones as
aviation communication headsets
except in case of emergency. No
incoming audio will be heard with
a discharged or improperly installed
battery. This could result in the
potential of missed communications
while piloting an aircraft. Extremely
loud ambient noise levels common
to many propeller-driven aircraft may
impair your ability to receive incoming
audio communications, particularly
during takeoff and climb out.–
Mezger AC-1 earphones are not
engineered for noise conditions,
altitude, temperature or other
environmental conditions common in
non-commercial aircraft,
resulting in possible interference to
critical communications.
Do NOT place naked flame sources,
such as lighted candles, on or near
the product.
Do NOT make unauthorized alterations
to the product; doing so may
compromise safety, regulatory
compliance, system performance, and
may void the warranty.
In the event of a battery leaking, do
not allow the liquid to come in contact
with the skin or eyes. If contact
has been made, wash the affected
area with copious amounts of water
and seek medical advice.
mezger-audio.com
FCC statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) this device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause u ndesired operation.
Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
-- Reorient or relocate the receiving antenna.
-- Increase the separation between the equipment and receiver.
-- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
-- Consult the dealer or an experienced radio/TV technician for help.
This device and its antenna(s) must not be co-located or operation in conjunction with
any other antenna or transmitter.
Radiation Exposure Statement
The device has been evaluated to meet general RF exposure requirement in portable
exposure condition without restriction.
ISED statement
English:
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference that
may cause undesired operation of the device.
French: Cet appareil contient des émetteurs/récepteurs exempts de licence qui sont
conformes aux RSS exemptés de licence d'Innovation, Sciences et Développement
économique Canada. L'exploitation est soumise aux deux conditions suivantes : (1) Cet
appareil ne doit pas provoquer d'interférences. (2) Cet appareil doit accepter toute
interférence, y compris les interférences susceptibles de provoquer un fonctionnement
indésirable de l'appareil.
This device meets the exemption from the routine evaluation limits in section 2.5 of RSS
102 and compliance with RSS 102 RF exposure, users can obtain Canadian information
on RF exposure and compliance.
cet appareil est conforme à l'exemption des limites d'évaluation courante dans la section
2.5 du cnr - 102 et conformité avec rss 102 de l'exposition aux rf, les utilisateurs peuvent
obtenir des données canadiennes sur l'exposition aux champs rf et la conformité.
This equipment complies with Canada radiation exposure limits set forth for an
uncontrolled environment.
Cet équipement est conforme aux limites d'exposition aux rayonnements du Canada
établies pour un environnement non contrôlé.
The device has been evaluated to meet general RF exposure requirement. This
equipment should be installed and operated with minimum distance 0mm between the
radiator & your body. L'appareil a été évalué pour répondre aux exigences générales
d'exposition aux RF. Cet équipement doit être installé et utilisé avec une distance
minimale de 0 mm entre le radiateur et votre corps.
