MIDGET

(GAN

5UC)

STEERING-COLU

LOCK

Note

the key number and

remove the label from the

car

immediately. Refer to

page 6.

MARK

III

HANDBOOK

Publication Part No. AKD 7937

BRITISH

British

Leyland

(Austin-Morris)

Limited

MIDGET

(GAN

5UC)

MARK

III

FOREWORD

This

Handbook

provides an introduction to your car, together with information on the care

and

periodic maintenance required to combine trouble-free motoring with minimal running costs.

Claims for the replacement

parts under warranty

must

be submitted to the supplying Distributor

or Dealer, or when this is

not

possible, to the nearest Distributor or Dealer, informing

them

of the

vendor's

name

and

address.Except in emergency, warranty work should always be carried

out

an appointed Distributor or Dealer.

By keeping the Passport to Service, signed by the Distributor, Dealer, or vendor in the vehicle, you

can quickly establish the date of purchase

and

provide the necessary details if adjustments are

required to be carried

out

under warranty.

Regular use of the Passport to Service Maintenance Scheme is the best safeguard against the

possibility of abnormal repair bills at a later date. Failure'to have your

car

correctly maintained

could invalidate the terms of the

Warranty

and may result in unsatisfactory operation of the emission

control systems.

Safety features embodied in the car may be impaired if

other

than

genuine parts are fitted. In certain

territories, legislation prohibits the fitting of parts

not

to the vehicle manufacturer's specification.

Owners purchasing accessories while travelling

abroad

should ensure

that

the accessory

and

its

fitted location on the car conform to mandatory requirements existing in their country of origin.

Your

Distributor or Dealer is provided with the latest information concerning special service tools

and

workshop techniques. This enables him to undertake

your

service

and

repairs in the most efficient

and

economic manner.

Further

' details on Service Parts will be found under

'SERVICE'

on page 60. Please note

that

references to right- or left-hand in this Handbook are made when viewing the car from the rear.

Specification details set

out

in this

Handbook

apply to a range of vehicles

and

not

to any particular

vehicle.

For

the specification of any particular vehicle owners should consult their Distributor or

Dealer.

The Manufacturers reserve the right to vary their specifications with or without notice,

and

at such

times

and

in such manner as they think fit.

Major

as well as minor changes may be involved in

accordance with the Manufacturer's policy of constant product improvement.

Whilst every effort is made to ensure the accuracy of the particulars contained in this

Handbook,

neither the Manufacturer

nor

the Distributor or Dealer, by whom this

Handbook

is supplied, shall

in any circumstances be held liable for any inaccuracy or the consequences thereof.

Emission Controls

Your

car is fitted with emission controls

and

devices required by the United States Clean Air

Act and regulations issued by the Environmental Protection Agency. 1

Please read carefully the Emission Control Systems section of this

Handbook

which contains

information on the emission systems fitted to your

car

and the recognition of symptoms .of

possible malfunctions which could affect emissions . .

an appointed

Distnbutor

or Dealer.

By keeping the Passport to Service, signed by the Distributor, Dealer, or vendor in the vehicle, you

can quickly establish the date of purchase

and

provide the necessary details if adjustments are

required to be carried

out

under warranty.

Regular use of the Passport to Service Maintenance Scheme is the best safeguard against the

possibility of abnormal repair bills at a later date. Failure'to have your

car

correctly maintained

could invalidate the terms of the

Warranty

and may result in unsatisfactory operation of the emission

control systems.

Safety features embodied in the

car

may be impaired if

other

than

genuine parts are fitted. In certain

territories, legislation prohibits the fitting of parts

not

to the vehicle manufacturer's specification.

Own

.re;:.

nllrr

.h~c;:.ina

~(,"l""p.c;:.<:nrlPc

lhilp

tr~:n

.TpllinO'

'.Jlh'rf"\".:1r1

c'hnnlr1

~nC'ln·o

+kl":t+

+'ho

,.,,...,...'O

l::u:

...........

u,.,,_A :+ro
