MHS Boilers VDY24/18 User manual

INSTALLATION AND OPERATING INSTRUCTIONS
Shown with
Log Set
VDY24/18D2A
This gas log set is to be installed only
in a solid-fuel burning fireplace with a
working flue constructed of noncom-
bustible material.
READ AND SAVE THESE INSTRUCTIONS
Approved to ANSI Z21.60
WARNINGS
If the information in this manual is not followed exactly,
a fire or explosion may result causing property damage,
personal injury or loss of life.
– Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
– WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any
phone in your building.
• Immediately call your gas supplier from a neighbor's
phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the
fire department.
– Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
Shown with
Log Set
VDY30D3R
Shown with
Log Set
VDY24/18D4
Shown with
Log Set
VDY24/18D5
MODELS: VDY24/18 • VDY30
Natural Gas or Propane/LPG Control Type: Manual and Millivolt

2 32D1999
Important Safety Information ........................ 3
Getting Started .............................................. 4
Product Specifications ................................... 5
Product/Features Specifications.................... 6
Placement in a Fireplace with a Restrictive
Barrier ........................................................ 7
Installation ....................................................... 8
Connecting the Gas......................................... 9
Electrical Wiring (Millivolt) ............................ 11
Log Placement .............................................. 12
DUZY II VDY24/18D2, VDY24/18D2A and
24/18VDYD2A Log Installation................... 12
Duzy II VDY30D2, VDY30D2A and 30VDYD2A
Log Installation........................................... 13
VDY24/18D4 Log Installation ..................... 13
VDY24/18D3R Log Installation.................. 14
VDY30D4 Log Installation .......................... 14
VDY30D3, VDY30D3R and 30VDYD3A Log
Installation.................................................. 15
VDY24/18D4 Log Installation ..................... 17
VDY30D4 Log Installation ........................ 18
DUZY 5 Log VDY24/18D5 Log Installation. 19
30VDYD5 and VDY30D5 Log Installation.. 21
TABLE OF CONTENTS
Fireplace Draft Test ....................................... 23
Flame Appearance ........................................ 24
Operating Instructions ................................. 25
For Your Safety Read Before Lighting ....... 25
Manual Control Lighting Instructions ......... 25
Millivolt Control Lighting Instructions ......... 26
Optional Remote Receiver (Millivolt) ........... 27
Cleaning and Servicing ................................ 28
Illustrated Parts List ..................................... 29
Troubleshooting ............................................ 33
Massachusetts Requirements...................... 35
Warranty ..........................................Back Cover

32D1999 3
1. The installation, combustion and ventilation air must
conform with local codes or, in the absence of local codes,
with the National Fuel Gas Code, ANSI Z223.1.
2. This unit complies with ANSI Z21.60 • CSA 2.26 Deco-
rative Gas Appliance for Installation in Solid-Fuel Burn-
ing Fireplace.
3. Installationandrepairshouldbedonebyaqualiedser-
vice person. MHS Vented Gas Logs must be installed only
inasolid-fuel(wood)burningreplacewhichcanonlybe
constructed of non-combustible material, with minimum
venting requirements, see installation section.
4. Topreventmalfunction,gaslogsetandueshouldbe
cleaned at least annually by a professional service person.
More frequent cleaning may be required due to excessive
lint from carpeting, etc. It is imperative that control com-
partments, burners and circulating air passageways be
kept clean.
5. Correctinstallationoftheceramicberlogs,andannual
cleaning are necessary to minimize problems with soot-
ing. See log placement instructions for proper instal-
lation.
6. A damper clamp must be installed to provide the minimum
permanentventopeningtoventueproducts,Seeinstal-
lation instructions.
7. Neverburnsolidfuelsinareplacewhereagaslogset
is installed.
8. This appliance must not be used with glass
doors in the closed position. Provisions for adequate
combustion air must be provided, adequate combustion
airusuallyresultsinallamescurlingintothereplace
awayfromscreenanduptheue.
9. Keep room area clear and free from combustible materials,
gasolineandotherammablevaporsandliquids.
IMPORTANT SAFETY INFORMATION
10. Children and adults should be alerted to the hazard of
high surface temperature and should stay away to avoid
burns or clothing ignition.
11. Young children should be carefully supervised when they
are in the same room with the gas log set in operation.
12. Donotplaceclothingorotherammablematerialnear
thereplacewhenthegaslogsareinuse.
13. Do not use this gas log set if any part has been underwater.
Immediatelycallaqualiedservicetechniciantoinspect
the gas logs and replace any part of the control system
and any gas control which has been under water.
14. The gas log set and its individual shutoff valve must be
disconnected from the gas supply piping system during
any pressure testing of the gas supply piping system at
test pressures in excess of 1/2 psig (3.5kPa).
15. The gas log set must be isolated from the gas supply
piping system by closing its individual manual shutoff
valve during any pressure testing of the gas supply pip-
ing system at test pressures equal to or less than 1/2 psig
(3.5kPa).
16. FOR MASSACHUSETTS RESIDENTS ONLY:
Installation of this vented gas log in the Commonwealth
of Massachusetts requires the damper be permanently
removed or welded in the full open position. In addition, a
naturally vented gas log may not be installed in a bedroom
or bathroom in the commonwealth of Massachusetts.
IMPORTANT
Read these instructions carefully before installing or trying to operate this gas log set.
WARNING
Any modification to this gas log set or its controls can be dangerous. Improper
installation or use of the gas log set can cause serious injury or death from fire, burns,
explosion or carbon monoxide poisoning.
WARNING
This appliance is for installation
only in a solid fuel burning fireplace
(masonry fireplace or manufactured
fireplace)
INSTALLER
Please leave these instructions with the appliance.
OWNER
Please retain these instructions for future reference.

4 32D1999
GETTING STARTED
MAKE SURE YOU HAVE RECEIVED ALL PARTS:
Check your packing list to verify that all listed parts have been received. You should have the following:
BURNER - GRATE ASSEMBLY 24/18, 30
• Burner and Grate Weldment Assembly • Lava Rocks (2)
• Glowing Embers (Rock Wool) • Damper Clamp
• Installation /Operating Instructions • Masonry Screws (2)
• 3/8" Aluminum tube with 3/8" 90° elbow, 1/2" to 3/8"tubetting
CERAMIC FIBER OR REFRACTORY CEMENT LOGS 24/18, 30
• Individual Logs • Installation Instructions
Carefully inspect the contents for shipping damage. If any parts are missing or damaged, immediately inform the dealer
from whom you purchased the appliance. Do not attempt to install any part of the appliance unless you have all parts
in good condition.
ITEMS REQUIRED FOR INSTALLATION
Ensure that the following items are available before proceeding with installation:
• External regulator (for propane/L.P.G. only) • Manual shutoff valve
• Piping which complies with local codes • Pipe wrench
• Tee joint
• Pipe sealant approved for use with propane/L.P.G. (Resistant to sulfur compounds)
 • Drillwithmasonrybit(formountingtotheoor)
CAUTION
• Handle the gas log burner assembly by the grate only. Do not pick the unit up by the
burner.
• Gloves are recommended when handling ceramic fiber logs to prevent skin irritation
from loose fibers. Logs are fragile — handle with care.

32D1999 5
PRODUCT SPECIFICATIONS
NATURAL GAS
Manual Pressure Millivolt Pressure
Regulator Pressure Setting: 4" w.c. Regulator Pressure Setting: 4.0" w.c.
Gas Inlet Pressure: Max. 10 1/2" w.c. Gas Inlet Pressure: Max. 10 1/2" w. c. • Min. 6" w.c.
Min. 6" w.c.
PROPANE/LPG
Note: An external regulator is required to reduce supply pressure to a maximum of 13" w.c.
Manual Pressure Millivolt Pressure
Regulator Pressure Setting: 10" w.c. Regulator Pressure Setting: 10" w.c.
Gas Inlet Pressure: Maximum 13" w.c. Gas Inlet Pressure: Maximum 13" w.c.
Minimum 11" w.c. Minimum 11" w.c.
Model Number Pilot Control Type Gas Rate Min BTU/Hr
VDY24/18NMP Yes Manual (Thermocouple) 50,000
VDY24/18NVP Yes Millivolt (Thermopile) 50,000
VDY30NMP Yes Manual (Thermocouple) 65,000
VDY30NVP Yes Millivolt (Thermopile) 65,000
Model Number Pilot Control Type Gas Rate Min BTU/Hr
VDY24/18PMP Yes Manual (Thermocouple) 50,000
VDY24/18PVP Yes Millivolt (Thermopile) 50,000
VDY30PMP Yes Manual (Thermocouple) 65,000
VDY30PVP Yes Millivolt (Thermopile) 65,000
IGNITION CONTROLS
Piezo ignitor allows ignition of the pilot without the use of matches or batteries.
Manual control with pilot has three (3) positions:
OFF - All gas to the gas logs is shut off at the valve.
IGN - Valve position to light/maintain a standing pilot.
ON - Valve position to light/maintain the gas burner.
Millivolt control with pilot has three (3) positions:
OFF - All gas to the gas logs is shut off at the valve.
IGN - Valve position to light/maintain a standing pilot.
ON - Valve position to light/maintain the gas burner.

6 32D1999
A
C
D
B
BEFORE INSTALLING THE APPLIANCE:
• Turn off gas supply to Masonry fireplace or manufactured wood
burningrebox.
 • Havethereplaceoorandchimneyprofessionallycleanedtoremoveashes,
soot, creosote or other obstructions. Have this cleaning performed annually
after installation.
 • Sealanyfreshairventsorashclean-outdoorslocatedonoororwallofre-
place. If not, drafting may cause pilot outage or sooting. Use a heat-resistant
sealant.
INSTALL AND OPERATE THE APPLIANCE AS DIRECTED IN THIS MANUAL.
DAMPER STOP INSTALLATION:
A damper stop is provided with the unit. The damper stop must be installed as shown in (Figure 2) to prevent full closure of
thereplacedamperbladeandprovideaminimumueopening,pertablebelow.
Shouldtheclampnott,orprovidetherequiredpermanentopeningfromthetablehavethedamperbladecuttoprovide
minimum permanent opening or a permanent stop installed.
Damper Stop
Damper
Figure 2 - Damper Stop
Installation
* MANUAL SERIES * MILLIVOLT SERIES
PRODUCT / FEATURES SPECIFICATIONS
Figure 1 - Minimum Hearth
Dimensions
Minimum Opening Area of Chimney
Damper for Venting
FOR MASSACHUSETTS RESIDENTS ONLY
Installation of this vented gas log set in the Commonwealth
of Massachusetts requires the damper be permanently
removed or welded in the fully open position. In addition, a
naturally vented gas log may not be installed in a bedroom
or bathroom in the Commonwealth of Massachusetts.
Model A B CD
VDY 24/18 17 13 1/226 16
VDY 30 23 13 1/232 16
Model A B C D
VDY 24/18 18 13 1/226 16
VDY 30 24 13 1/232 16
Chimney
Height VDY24/18 VDY30
6' 51 sq in 64 sq in
8' 51 sq in 64 sq in
10' 51 sq in 64 sq in
15' 39 sq in 51 sq in
20' 39 sq in 51 sq in
30' 39 sq in 51 sq in
In compliance with ANS Z21.60 • CSA 2.26 and National Fuel Gas Code, Section 6.6
WARNING
The fireplace and gas logs function
as a system. If the fireplace is spilling
into the room (check with a match or
smoke stick). Reposition the damper
clamp until a positive draft is obtained,
by opening the damper. If negative
pressure in the home prevents having
a positive draft contact your dealer.

32D1999 7
PLACEMENT IN A FIREPLACE WITH A RESTRICTIVE BARRIER
IMPORTANT INFORMATION FOR THE INSTALLATION OF THIS GAS LOG SET
Thefollowingareguidelinesforplacingagaslogsetinareplacethathasarestrictivebarrieralongthebottomfrontopen-
ingofthereplace.Someexamplesofbarriersareglass/screendoorframesandsunken/recessedreplaces.
Glass door frames
with adjustable
louvers should have
the lovers fully open
while the unit is in
operation.
Height of restrictive barrier
caused by glass door frames,
recessed fireplaces, etc. from
the base or bottom surface of the
unit. (See Table).
The log set should be
placed against or as near
as possible to the rear wall
of the fireplace/firebox.
Depth of fireplace/firebox.
(See Table).
Figure 3 - Reference Drawing of a Log Set in an Enclosure
NOTE: Non combustible material such as refractory brick may be used to line the floor of the fireplace
in order to raise the height of the gas log set in relation to a restrictive barrier. If the unit is raised, THE
MINIMUM HEIGHT DIMENSION LISTED IN THE HOMEOWNER’S MANUAL MUST NOT BE EXCEEDED.
NOTE: If the log set is equipped with a remote receiver, a restrictive barrier may reduce the battery life
by increasing the ambient temperature inside the fireplace. Placement of the receiver outside of the
fireplace will extend the battery life.
X
Height of Restriction (X) Minimum Depth of Fireplace/Firebox
No restriction 131/2"
0 to 3" 15"
Greater than 3" ANY BARRIER GREATER THAN THREE INCHES (3") PLACED IN FRONT OF
THE GAS LOG SET IS NOT RECOMMENDED BY THE MANUFACTURER.
WARNING
Barriers such as the bottom of a glass door frame placed in front of a gas log set can
change the air flow characteristics of the fireplace which in turn can cause the unit to
overheat and malfunction. Any deviation from the installation guidelines on this sheet will
potentially void the warranty.

8 32D1999
PLACING AND SECURING APPLIANCE
Figure 4 - Securing Heater to Floor of Fireplace/Firebox
Left Side
Mounting
Hole
INSTALLATION
ASSEMBLY PROCEDURE
1. Centerthegaslogunitinthereplaceorrebox.Makecertainthefrontfeetofthegratesitinsidethefrontedgeofthe
replaceorrebox.
2. See Figure 4 forholelocations.Aftercenteringthegratecorrectly,marktheholepositionsonthereplace/reboxoor.
Drill two (2) 5/32" diameter holes approximately 11/2" deep.
 3. Anchorthegratetothereplace/reboxoorusingthescrewsprovided.See Figure 4.
Proper installation of the grate is essential to prevent any movement of the gas logs and controls
during operation.
Right Side Mounting Hole
WARNING
You must secure the gas log heater to
the fireplace floor. Properly securing
the grate prevents movement of
the entire unit when you adjust the
controls. Grate movement could
cause a gas leak.

32D1999 9
CONNECTING THE GAS
Pipe Coupling
To Gas Log
Regulator Manual Shutoff
Valve
Gas Supply Inlet
Figure 5 - Gas Connection
Pipe
IMPORTANT: Holdapplianceregulatorrmlywithawrenchtopreventmovementwhenconnectingtoinletpiping.
Check gas type: The gas supply must be the same as stated on the gas logs rating plate. If the gas supply is different, DO
NOT INSTALL THE GAS LOGS. Contact your dealer for the correct model.
Always use an external regulator for all propane/LPG gas logs only, to reduce the supply tank pressure to a maximum of
13"W.C.Thisisinadditiontotheregulatorttedtothegaslogset.Highpressurenaturalgassystemsrequirearegulator
to reduce supply pressure to 10" W.C.
Locations that the Pressure Tapping
Point May be Installed
NOTICE
A qualified gas appliance installer
must connect the appliance to the
gas supply. Consult all local codes
before installation.
CAUTION
Use new black iron pipe, steel pipe, copper tubing, or internally tinned copper tubing.
Copper or internally tinned copper tubing can only be used according to the National
Fuel Gas Code, section 2.6.3, providing gas meets sulfide limits, and where permitted by
local codes. Gas piping system must be sized to provide minimum inlet pressure (listed
on Data Plate) at the maximum flow rate (BTU/Hr). Undue pressure loss will occur if the
pipe is too small.
A manual shutoff valve must be installed upstream of the appliance. Union tee and
plugged 1/8" NPT pressure tapping point should be installed upstream of the appliance.
See Figure 5.
WARNING
Connecting directly to an
unregulated propane/LPG tank
can cause an explosion

10 32D1999
Figure 6 - Pressure Test Point Location
Test Plug
MANUAL CONTROL (Figure 6)
The pressure regulator is preset and locked to discourage
tampering.Ifthepressureisnotasspecied,replacewith
the correct part from the parts list in this manual.
Remove 1/8" NPT plug, located on side of regulator body.
Installttingandtubingtopressuregauge.Aftertakingpres-
sure reading, re-install test plug. Check for gas leaks.
MILLIVOLT CONTROL (Figure 7)
The valve regulator controls the burner pressure which should
be checked at the pressure test point. Turn captured screw
counter clockwise 2 or 3 turns and then place tubing to pres-
sure gauge over test point (Use test point labeled “OUT”).
After taking pressure reading, be sure and turn captured screw
clockwisermlytore-seal.Donotovertorque.Checkfor
gas leaks.
Test Port
“Out”
Figure 7 - Pressure Test Point Location
CONNECTING THE GAS
The heater gas inlet connection is 3/8" NPT at the regulator, inlet on the right side facing the gas log. If a left side connection
is required, the connecting pipe may be led under the rear of the gas logs or behind the grate for connection to the inlet.
NOTE: The millivolt valve has an internal regulator, thus the incoming gas line connects directly to
the valve.
Test all gas joints from the gas meter to the appliance regulator for leaks using a gas analyzer or soap and water solution after
completing connection. DO NOT USE AN OPEN FLAME.
Check the gas pressure with the appliance burning.

32D1999 11
THTP
TP
TH
Optional Wall Switch or
Remote Receiver
Switch
Millivolt
Valve
Pilot
ELECTRICAL WIRING (MILLIVOLT)
Figure 8 - Wiring Diagram
The Millivolt (thermopile) is a self powered combination gas control that does not require 110VAC to operate. See Figure 8
and installation instructions provided with optional wall switch or remote control for wiring instructions. A maximum length of
15 feet of 18awg two conductor wire is to be used for wall switch. Note switches must be suitable for millivolt operation.
CHECKING SYSTEM OPERATION
The millivolt system and individual compo-
nents may be checked with a millivolt meter
having a 0-1000MV range. Conduct each check
shown in chart below by connection meter test
leads to terminals as indicated.
A. COMPLETE MILLIVOLT SYSTEM CHECK
("A" READING - CONTACTS CLOSED - CONTROL KNOB "ON" - MAIN BURNER SHOULD BE COME
ON)
a. If the reading is more than 100 millivolts and the automatic valve still does not come on - replace the control.
b. If the closed circuit reading (“A” reading) is less than 100 millivolts, determine cause for low reading - proceed
as follows:
B. THERMOPILE OUTPUT READING CHECK
(“B” READING - CONTACTS OPEN - MAIN BURNER OFF)
a. 325 millivolts minimum. If the minimum millivolt reading is not obtainable, readjust pilot for maximum millivolt
output.Ifmillivoltreadingisstillbelowminimumspecied,replacethermopile.
CHECK
TEST TO TEST
CONNECT
METER LEADS
TO TERMINALS
METER
READING
SHOULD BE
A
COMPLETE
SYSTEM TH & THTP
MINIMUM
100mV
B
THERMOPILE
OUTPUT TP & THTP
MINIMUM
325mV
WARNING
Label all wires prior to disconnection
when servicing controls.Wiring errors
can cause improper and dangerous
operation. Verify proper operation
after servicing.

12 32D1999
LOG PLACEMENT
IMPORTANT: Remove logs, handling carefully by holding gently at each end. Gloves are recommended to prevent
skin irritation from ceramic fibers. If skin becomes irritated, wash gently with soap and water.
LOG PLACEMENT
Figure 12 - Placing Left Log (#3)
Left Log (#3)
1. Install the rear log (#1) on the two locating pins of base.
See Figure 9. Visually check to verify the log is securely
placed on the pins and in contact with the grate. See Figure
10.
2. Install the right log (#2) on top of the control cover. Slide
the log back until touching the rear log (#1). Visually
check to verify the log is resting on the grate and control
cover. See Figure 11.
3. Install the left log (#3) with its bottom groove resting
on the right side of the grate bar. Slide the log back until
touching the rear log (#1). Visually check to verify the
log is resting on the grate. See Figure 12.
4. Install the top log (#4) with the base sitting on the rear
log (#1) and the top sitting on log (#4). Visually check to
verify the log is resting on the rear log (#1) and left log
(#3). See Figure 13.
Figure 13 - Placing Top Log (#4)
Top Log (#4)
Figure 10 - Placing Rear Log (#1)
Rear Log
(#1)
Figure 11 - Placing Right Log (#2)
Right Log
(#2)
Figure 9 - Base
Locator
Pins
Control
Cover
Bottom
Groove
DUZY II VDY24/18D2A LOG INSTALLATION SEQUENCE:

32D1999 13
LOG PLACEMENT
Figure 17 - Placing Left Log (#3)
Left Log (#3)
DUZY II VDY30D2A LOG INSTALLATION
SEQUENCE:
1. Install the rear log (#1) on the two locating pins of base.
See Figure 14. Visually check to verify the log is securely
placed on the pins and in contact with the grate. See Figure
15.
2. Install the right log (#2) on top of the control cover. Slide
the log back until touching the rear log (#1). Visually check
to verify the log is resting on the grate and control cover.
See Figure 16.
3. Install the left log (#3) with its bottom groove resting on the
right side of the grate bar. Slide the log back until touching
the rear log (#1). Visually check to verify the log is resting
on the grate. See Figure 17.
4. Install the top log (#4) with the base sitting on the rear log
(#1) and the top sitting on log (#4). Visually check to verify
the log is resting on the rear log (#1) and left log (#3). See
Figure 18.
Figure 18 - Placing Top Log (#4)
Top Log (#4)
Figure 15 - Placing Rear Log (#1)
Rear Log
(#1)
Figure 16 - Placing Right Log (#2)
Right Log
(#2)
Figure 14 - Base
Locator Pins
Control
Cover
Bottom
Groove

14 32D1999
Top Middle
Log (#4)
LOG PLACEMENT
VDY24/18D3R LOG INSTALLATION
SEQUENCE:
1. Line up pins on bottom of Rear Log #1 with pins on grate
bar and place on grate. See Figures 19 and 20.
2. Place Front Left Log #2 on left front of grate bar lining up
cutout in bottom of log with grate bar. See Figure 21.
3. Place Front Right Log #3 on right front of grate bar lining
up cutout in bottom of log with grate bar. Make sure Log
#3 touches Log #1. See Figure 22.
4. Place back end Top Middle Log #4 on Log #1. Press the
side of Log #4 up against raised area of Log #1. Line up
notch in front end of #4 with grate bar. See Figure 23.
Figure 19 - Base
Pins
Figure 20 - Placing Rear Log on Base (#1)
Rear Log
(#1)
Figure 21 - Placing Front Left Log (#2)
Cutout
Figure 22 - Placing Front Right Log (#3)
Front Left Log (#2)
Front Right Log (#3)
Cutout
Figure 23 - Placing Top Middle Log (#4)
Notch
Control
Cover
Continued

32D1999 15
LOG PLACEMENT
VDY24/18D3R LOG INSTALLATION SEQUENCE (Continued)
5. Rest Top Right Log #5 on Log #3. See Figure 24.
6. Line up Top Left Log #6 with notches on Log #2 and Log #4. See Figure 25.
Figure 24 - Placing Top Right Log (#5)
Top Right Log (#5)
Figure 25 - Placing Top Left Log (#6)
Top Left
Log (#6)
Figure 26 - Base
Locator Pins
Control Cover Figure 27 - Placing Rear Log
Rear Log
(#1)
VDY30D3R LOG INSTALLATION SEQUENCE:
1. Line up pins on bottom of Rear Log #1 with pins on grate bar and place on grate. See Figures 26 and 27.

16 32D1999
LOG PLACEMENT
2. Place Front Left Log #2 on left front of grate bar lining
up cutout in bottom of log with grate bar. See Figure 28.
3. Place Front Right Log #3 on right front of grate bar lining
up cutout in bottom of log with grate bar. Make sure Log
#3 touches Log #1. See Figure 29.
4. Place back end Top Middle Log #4 on Log #1. Press the
side of Log #4 up against raised area of Log #1. Line up
notch in front end of #4 with grate bar. See Figure 30.
5. Rest Top Right Log #5 on Log #3. See Figure 31.
6. Line up Top Left Log #6 with notches on Log #2 and Log
#4. See Figure 32.
Figure 28 - Placing Front Left Log (#2)
Front Left Log (#2)
Figure 29 - Placing Front Right Log (#3)
Front Right Log (#3)
Figure 30 - Placing Top Mid Log (#4)
Top Mid Log (#4)
Top Right Log (#5)
Figure 31 - Placing Top Right Log (#5 ) Figure 32 - Placing Top Left Log (#6 )
Top Left Log (#6)
VDY30D3R LOG INSTALLATION SEQUENCE (Continued)

32D1999 17
LOG PLACEMENT
VDY24/18D4 LOG INSTALLATION SEQUENCE:
1. Place Bottom Front Log (#2) on front of grate. See Figure 33.
2. Place Back Log (#1) on back of grate lining up two (2) pins on
grate with holes in bottom of log. See Figures 34 and 35.
3. Place Left Top Log (#3) on left end of Bottom Front and Back
Logs. See Figure 36.
4. Place Center Crossover Log (#4) across middle of Bottom Front
and Back Logs. See Figure 37.
5. Place Left Top Crossover Log (#5) up against Left Top Log. See
Figure 38.
6. Rest Right Top Log (#6) on Center Crossover Log and front of
grate. See Figure 39.
Figure 33 - Placing Front Log (#2)
Bottom Front Log (#2)
Figure 37 - Placing Center Log (#4)
Center Crossover
Log (#4)
Figure 38 - Placing Left Top Log (#5)
Left Crossover
Top Log (#5)
Right Top
Log (#6)
Figure 39 - Placing Right Top Log (#6)
Figure 35 - Placing Back Log (#1)
Back Log (#1)
Figure 36 - Placing Left Top Log (#3)
Top Left Log (#3)
Figure 34 - Base
Locator Pins

18 32D1999
LOG PLACEMENT
Figure 40 - Placing Front Log (#2)
Bottom Front Log (#2) VDY30D4 LOG INSTALLATION SEQUENCE:
1. Place Bottom Front Log (#2) on front of grate. See Figure 40.
2. Place Back Log (#1) on back of base lining up two (2) pins on base with
holes in bottom of log. See Figures 41 and 42.
3. Place Left Top Log (#3) on left end of Bottom Front and Back Logs. See
Figure 43.
4. Place Center Crossover Log (#4) across middle of Bottom Front and Back
Logs. See Figure 44.
5. Place Left Top Crossover Log (#5) up against Left Top Log. See
Figure 45.
6. Rest Right Top Log (#6) on Center Crossover Log and front of grate. See
Figure 46.
7. Place Small Front Log (#7) between Center Crossover Log and Top Left
Log. See Figure 47.
Figure 44 - Placing Center Log (#4)
Center Crossover Log (#4)
Figure 45 - Placing Left Top Log (#5)
Left Crossover Top
Log (#5)
Figure 46 - Placing Right Top Log (#6) Figure 47 - Placing Small Front Log (#7)
Small Front Log (#7)
Figure 42 - Placing Back Log (#1) Figure 43 - Placing Left Top Log (#3)
Back Log (#1)
Top Left Log (#3)
Right Top Log (#6)
Figure 41 - Base
Locator Pins

32D1999 19
LOG PLACEMENT
DUZY5 LOG VDY24/18D5 INSTALLATION SEQUENCE:
1. Place Back Log (#1) on back of base lining up two (2) pins on base with holes
in bottom of log. See Figures 48 and 49.
2. Placed Bottom Right Log (#2) on right side of grate. See Figure 50.
3. Place Bottom Left Log (#3) on left side of grate. See Figure 51.
4. Place one end of Middle Left Log (#4) on Bottom Left Log. Rest other end
of Middle Left Log (#4) behind Middle Right Log. See Figure 52.
Figure 48 - Base
Locator Pins
Figure 49 - Placing Back Log (#1)
Back Log (#1)
Middle Left Log (#4)
Figure 50 - Placing Bottom Right Log (#2)
Bottom Right
Log (#2)
Bottom Left Log (#3)
Figure 51 - Placing Bottom Left Log (#3) Figure 52 - Placing Middle Left Log (#4)

20 32D1999
Figure 53 - Placing Middle Right Log (#5)
Middle Right Log (#5)
Figure 54 - Placing Top Right Log (#6)
Figure 55 - Placing Top Left Log (#7)
Top Left Log (#7)
Top Right Log (#6)
Figure 56 - Placing Front Middle Log (#8)
First Prong Second
Prong
LOG PLACEMENT
DUZY5 LOG VDY24/18D5 INSTALLATION SEQUENCE (continued):
5. Place Middle Right Log (#5) on top of Bottom Right Log. See Figure 53.
6. Rest Top Right Log (#6) on Back Log and Bottom Right Log. See Figure 54.
7. Place Top Left Log (#7) on Bottom Left Log. See Figure 55.
8. PlaceFrontMiddleLog(#8)betweentherstandsecondprongs.See Figure 56.
