Mi Smart Band 5 User manual

Mi Smart Band 5
User Manual

Read this manual carefully before use, and retain it for
future reference.
Product Overview
Wristband Charging Cable
Fitness Tracker
Touchscreen
Touch Button
Heart Rate Sensor
Charging Port

Installation
1.
2.
Insert one end of the fitness tracker into the slot from
the front of the wristband.
Press down on the other end with your thumb to push
the fitness tracker completely into the slot.

Wearing
1.Comfortably tighten the band around your wrist, about 1
finger width away from your wrist bone.

2.To achieve the optimal performance of the heart rate
sensor, make sure its back to contact with your skin.
When wearing your wristband, keep it neither too tight
nor too loose but leaving some space for the skin to
be able to breathe. Tighten the wristband before you
start to exercise and properly loosen it afterward.
Too loose Just right
If the band can easily
move up and down the
wrist, or the heart rate
sensor cannot collect the
data, try tightening the
wristband.
The band can
comfortably fit around the
wrist.

Connecting
1
.
Scan the QR code to download and install the latest
version of the Mi Fit app, or search for it in Google Play,
App Store, or other third-party app stores.
Mi Fit app QR code
（Android 5.0 & iOS 10.0 or above）
Mi Fit

The band did not receive a pairing request
Confirm the pairing on your band
Allowtopair
Allow to pair
2.Log into your Mi account in the Mi Fit app, and follow
the instructions to connect and pair the band with
your phone. Once the band vibrates and a pairing
request is displayed on its screen, tap the touch
button to complete the pairing with your phone.
Note: Make sure the Bluetooth on your phone is
enabled. Hold the phone and the band close to each
other during pairing.

Usage
After successfully pairing with your device, the band
will start tracking and analyzing your daily activities
and sleeping habits.
Touch the button to light up the screen. Swipe up or
down to view various functions such as exercise data,
and heart rate measurements. Swipe right to return to
the previous page.
Swipe up/down to
switch between
functions
Swipe right to return to
the previous page

Disassembly
Remove the band from your wrist, hold on to each
end and pull on the wristband until you see a small
gap between the fitness tracker and the wristband.
Use your finger to pop the fitness tracker out of its
slot from the front side of the wristband.

Charging
Recharge your band immediately when the battery
level is low.

Precautions
When using the band to measure your heart rate,
please keep your wrist still.
The Mi Smart Band 5 has a water resistance rating of
5 ATM. It can be worn in the shower, swimming pool,
or while swimming near the shore. It cannot be used,
however, in a sauna or while scuba diving.
The function of the touch button and touchscreen are
not accessible during underwater. When your band
comes in contact with water, use a soft cloth to wipe
away excess water from its surface before using it.
During daily use, avoid wearing the band too tightly
and try to keep its contact area dry. Please clean the
wristband regularly with water.
Please stop using the product immediately and seek
medical assistance if the contact area on your skin
shows signs of redness or swelling.

Name: Mi Smart Band 5
Model: XMSH10HM
Fitness Tracker Net Weight: 11.9 g
Fitness Tracker Dimensions: 47.2 x18.5 x12.4 mm
Wristband Material: Thermoplastic elastomer (TPE)
Clasp Material: Aluminum alloy
Adjustable Length: 155–219 mm
Compatible with: Android 5.0 & iOS 10.0 or above
Battery Capacity: 125 mAh
Battery Type: Lithium polymer battery
Input voltage: DC 5.0 V
Input Current: 250 mA Max.
Water Resistance: 5 ATM
Bluetooth Frequency: 2402–2480 MHz
Max. Output: ≤13 dBm
Operating Temperature: 0°C to 45°C
Wireless Connectivity: Bluetooth 5.0 BLE
Specifications

Disposal and Recycling Information
All products bearing this symbol are waste
electrical and electronic equipment (WEEE
as in directive 2012/19/EU) which should not
be mixed with unsorted household waste.
Instead, you should protect human health and
the environment by handing over your waste
equipment to a designated collection point for
the recycling of waste electrical and electronic
equipment, appointed by the government or
local authorities. Correct disposal and recycling
will help prevent potential negative consequences to
the environment and human health. Please
contact the installer or local authorities for more
information about the location as well as terms
and conditions of such collection points.

Certifications and Safety Approvals
For regulatory information, product certification, and
compliance logos related to the Mi Smart Band 5,
please go to More > Settings > Regulatory.
Hereby, Anhui Huami Information Technology
Co., Ltd., declares that the radio equipment
type XMSH10HM is in compliance with
Directive 2014/53/EU. The full text of the EU
declaration of conformity is available at the
following internet address:
http://www.mi.com/global/service/support
/

Manufactured for: Xiaomi Communications Co., Ltd.
Manufactured by: Anhui Huami Information
Technology Co., Ltd. (a Mi Ecosystem company)
Address: Room 1201, Building A4, National Animation
Industry Base, No. 800 Wangjiang West Road, Gaoxin
District, Hefei, Anhui, China
For further information, please go to www.mi.com
Importer:
Beryko s.r.o.
Na Roudné 1162/76, 301 00 Plzeň
www.beryko.cz

Warranty Notice
As a Xiaomi consumer, you benefit under certain conditions from
additional warranties. Xiaomi offers specific consumer warranty
benefits which are in addition to, and not instead of, any legal
warranties provided by your national consumer law. The duration and
conditions related to the legal warranties are provided by respective
local laws. For more information about the consumer warranty
benefits, please refer to Xiaomi's official website
https://www.mi.com/en/service/warranty/. Except as prohibited by
laws or otherwise promised by Xiaomi, the after-sales services shall
be limited to the country or region of the original purchase. Under the
consumer warranty, to the fullest extent permitted by law, Xiaomi
will, at its discretion, repair, replace or refund your product. Normal
wear and tear, force majeure, abuse or damage caused by the user's
negligence or fault are not warranted. The contact person for the
after-sale service may be any person in Xiaomi's authorized service
network, Xiaomi's authorized distributors or the final vendor who sold
the products to you. If in doubt please contact the relevant person as
Xiaomi may identify.
The present warranties do not apply in Hong Kong and Taiwan.
Products which were not duly imported and/or were not duly
manufactured by Xiaomi and/or were not duly acquired from Xiaomi
or a Xiaomi’s official seller are not covered by the present warranties.
As per applicable law you may benefit from warranties from the
non-official retailer who sold the product. Therefore, Xiaomi invites
you to contact the retailer from whom you purchased the product.
