Miboxer DMX512&RDM User manual

Subordinate New Brand
....................................................................................... 2
...................................................................................... 2
......................................................... 2
.................................................................. 2
................................................................................. 3
................................................................................................... 3
Product features
Funcon Sengs
Digital Display status descripon
DMX inial address seng
Connecon Diagram
Aenon
Contents
RGB+CCT LED Lighng ( DMX512&RDM )
Instrucon Manual

Product Features
1. Accord with DMX512 standard protocol.
2. Digital Display, Set DMX inial address through buon.
3. Support RDM funcon.
4. 16 million colors to change, color temperature and brightness
adjustable.
5. IP65 waterproof rate
Funcon Sengs
Color temperature
Brightness control
Support RDM funconRGB colors to choose
Waterproof and
dustproof grade IP65
Beam angle 25°
IP65
RDM
1.Digital Display status descripon
Self-locking: Get into locking state when there is no operaon over
10 seconds, digital display with low light.
Unlock: Each buon press 3 mes separately within 3s to unlock.
Address always ON: DMX signal valid.
Address flickering: DMX signal invalid.
2. DMX inial address seng
Under unlock status, when digital display show 001-512( for example
), Short press ▲ buon or ▼ buon, you can change the
DMX inial address; Long press, you can change it quickly.
For Example: Set Inial address to 100
R G BCW WW
Relave color channel
for DMX address
100 101 102 103 104
⸺ 2 ⸺

Connecon Diagram
L
N
(Yellow-green)
(Brown)
(Blue)
D+
D-
GND
OR
(Yellow-green)
(Brown)
(Blue)
DMX512
Console
L
N
Aenon: If the DMX lighng is over 32pcs, or using the super long signal
cable, you need DMX signal amplifier. Amplify signal cannot be over 5
mes.
Aenon
1. This product should be debugged and installed by professionals.
2. Please check whether the input voltage meets the requirements of the
product voltage range.
3. Before switching on the power, please ensure that all wiring is correct,
so as not to cause damage to the devices.
4. Please do not install the devices on low-lying and easy inundated area.
5. If fault has occurred, non-professionals do not repair it without
permission, otherwise the devices will be damaged.
Made in China
RDM
DMX
IP65
IP Rate
Model No.:X5
DMX512 Master
⸺ 3 ⸺
