DATA SHEET
Keysight N1913A and N1914A
EPM Series Power Meters
E-Series and 8480 Series Power Sensors

Page 2
Find us at www.keysight.com
Table of Contents
Do More With New-Generation EPM Series Power Meters�������������������������������������������������������������������������3
Using EPM Series with BenchVue Software�������������������������������������������������������������������������������������������������3
Take a Closer Look ����������������������������������������������������������������������������������������������������������������������������������������4
N1913A/14A EPM Series Power Meter: Applications and Compatible Sensors
for Average Power Measurements �����������������������������������������������������������������������������������������������������5
N1913A/14A EPM Series Power Meters Performance Characteristics �������������������������������������������������������6
N1913A/14A EPM Series Power Meters Ordering Information������������������������������������������������������������������ 12
E-Series Power Sensor Specifications�������������������������������������������������������������������������������������������������������� 13
E-Series CW Power Sensor Specifications������������������������������������������������������������������������������������������������� 13
E-Series E9300 Average Power Sensor Specifications������������������������������������������������������������������������������ 16
848xD Series Diode and 8483A Thermocouple Power Sensor Specifications �����������������������������������������22

Page 3
Find us at www.keysight.com
– Get up to four channels 1to speed and simplify RF average power measurements
– Measure faster with improved measurement speed of 400 readings/sec with the
Keysight Technologies, Inc� E-Series sensors
– View test results more easily with the industry’s first color LCD readout in an average
power meter
– Go beyond GPIB with USB and LAN/LXI-C interfaces
– Automate frequency/power sweep measurements with the optional external trigger
in/out feature
– Easily replace existing 436A, 437B and 438A meters with optional 43x code
compatibility 2
– Enhance manufacturing test by connecting a large external monitor with the unique
VGA output option
1� Additional two optional USB channels available (see Ordering Information, page 10)�
2� N1913A is backward compatible with the 436A and 437B, while N1914A is compatible with 438A�
As signals become more complex, it becomes more difficult to make fast, accurate power
measurements� For years, you’ve depended on Keysight’s EPM Series power meters�
Today, the Keysight N1913A and N1914A EPM Series power meters are versatile, user-
friendly replacements for the discontinued E4418B/19B EPM Series� Best of all, you get
these extras for about the same price� Get consistent results and greater capability—with
the new EPM Series power meters�
Using EPM Series with BenchVue Software
The EPM Series is supported by the Keysight BenchVue software’s BV0007B Power
Meter/Sensor Control and Analysis app� Keysight BenchVue software for the PC
accelerates testing by providing intuitive, multiple instrument measurement visibility
and data capture with no programming necessary� You can derive answers faster than
ever by easily viewing, capturing and exporting measurement data and screen shots�
BenchVue software license (BV0007B) is now included with your instrument�
For more information, www.keysight.com/find/BenchVue
Essential specifications
– Supports all average power
sensors and their frequency
range� The power range
depends on the connected
power sensor�
– Measurement speed: Up to
400 readings/sec with
E-Series sensors
– Absolute accuracy:
± 0�02 dB logarithmic,
± 0�5% linear
– Relative accuracy: ± 0�04 dB
logarithmic, ± 1% linear
Do More With New-Generation EPM Series Power Meters

Page 4
Find us at www.keysight.com
Take a Closer Look
N1914A front panel
Industry’s first high-resolution
color LCD in an average power
meter
Display keys select
the display format
for the active window
(single/split screen)
Hard keys provide quick access to
the most frequently used functions,
such as Trigger and Acquisition Channel
A&B sensor
connectors
Arrow keys and Select allow positioning of the cursor
for character selection and editing
Soft keys provide
menu selection
Numeric keypad
Power reference
(0 dBm, 50 MHz)
USB port for
additional sensor
connection (Optional)
Run/Stop enables single-shot
measurements
Cal enables fully automatic
digital zeroing (corrected for
residual offsets) and fully
automatic sensor calibration
N1914A back panel
DC recorder outputs (0-1 V)
Trigger in and out
connectors (for
automated power
or frequency sweep
function) (Optional)
Line power accepts
voltage with automatic
range selection
LAN port
Rear-panel sensor and Power Ref
connectors provide an option to
replace front-panel connectors
GPIB connector
VGA output
(Optional) USB port
USB port for additional sensor
connection (Optional)

Page 5
Find us at www.keysight.com
N1913A/14A EPM Series Power Meter: Applications and Compatible Sensors for
Average Power Measurements
Signal characteristics > CW Modulated
CW Pulse/
averaged
AM/FM
profiled
Wireless standards
Mobile phone WLAN WPAN WMAN
Typical application
examples >
Metrology
lab
Radar/
navigation
Mobile
radio
GSM cdma®2000 3G 802.11a Bluetooth®WiMax™
EDGE cdmaONE HSPA 802.11b RFID Wibro
GPRS IDEN LTE 802.11g ZigBee
802.11n
Thermocouple sensors:
8480A/B/H, N8480A/B/H,
R/Q8486A, N8486AR/AQ 1
Average
only
Average
only
Average
only
Average
only
Average
only
Average
only
Diode sensors: 8480D,
V8486A, W8486A 1,
E8486A
Average
only
Average
only
Average
only
Average
only
Average
only
Average
only
Diode sensors compensated
for extended range:
E4412A/3A
FM only
Two-path diode-stack
sensors: E9300 Series Average
only
Average
only
Average
only
Average
only
Average
only
Average
only
USB sensors: U2000A,
U8480A & U2040x Series
(except U2049X Series & in
Average Mode only)
Average
only
Average
only
Average
only
Average
only
Average
only
Average
only
1� The N1913A/4A power meters are compatible with all 8480 Series power sensors, including discontinued models�

Page 6
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Performance Characteristics
Specifications describe the instrument’s warranted performance and apply after a 30 minute warm-up� These specifications are valid
over its operating/environmental range unless otherwise stated and after performing a zero and calibration procedure�
Supplemental characteristics (shown in italics) are intended to provide additional information, useful in applying the instrument by
giving typical (expected), but not warranted performance parameters� These characteristics are shown in italics or labeled as “typical,”
“nominal” or “approximate�”
Compatible power sensors Keysight 8480 Series
Keysight E9300 E-Series
Keysight E4410 E-Series
Keysight N8480 Series
Keysight E8486A, V8486A, W8486A
Keysight U2000 Series
Keysight U8480A Series
Keysight U2040x Series (except U2049X Series & in Average Mode only)
Frequency range 9 kHz to 110 GHz, sensor dependent
Power range –70 to +44 dBm (100 pW to 25 W), sensor dependent
Single sensor dynamic range 90 dB maximum (Keysight E-Series power sensors)
50 dB maximum (Keysight 8480 Series power sensors)
55 dB maximum (Keysight N8480 Series power sensors)
80 dB maximum (Keysight U2000 Series USB power sensors)
55 dB maximum (Keysight U8480A Series USB power sensors)
96 dB maximum (Keysight U2040x Series, except U2049X Series & in Average Mode only)
Display units Absolute: Watts or dBm
Relative: Percent or dB
Display resolution Selectable resolution of: 1.0, 0.1, 0.01 and 0.001 dB in logarithmic mode, or 1, 2, 3 and 4 significant digits in linear mode
Default resolution 0.01 dB in logarithmic mode or three digits in linear mode
Accuracy
Absolute accuracy ± 0.02 dB (Logarithmic) or ± 0.5% (Linear). Please add the corresponding power sensor linearity percentage from Tables
6, 9 and 10 (for the E-Series sensors), Table 14 (for the 8480 series sensors) and Table 16 (for N8480 sensors) to assess
the overall system accuracy.
Relative accuracy ± 0.04 dB (Logarithmic) or ± 1.0% (Linear). Please add the corresponding power sensor linearity percentage from the
mentioned tables above to assess the overall system accuracy.
Zero set (digital settability of
zero)
0.0000175% (meter only)
Power sensor dependent (refer Table 1), this specification applies when zeroing is performed with sensor input
disconnected from the POWER REF.
Zero drift of sensors This parameter is also called long term stability and is the change in the power meter indication over a long time (within
one hour) at a constant temperature after a 24-hour warm-up of the power meter. Sensor dependent, refer to Table 1.
For E9300 sensors, refer to Table 11 for complete data.
Measurement noise
Sensor dependent, refer to Tables 1 and 2. For E9300 sensors, refer to Table 11 for complete data
Effects of averaging on noise Averaging over 1 to 1024 readings is available for reducing noise. Table 1 provides the measurement noise for a
particular power sensor with the number of averages set to 16 for normal mode and 32 for x2 mode. Use the “Noise
Multiplier” for the appropriate mode (normal or x2) and number of averages to determine the total measurement noise
value.
For example: For a Keysight 8481D power sensor in normal mode with the number of averages set to 4, the
measurement noise is equal to: (< 45 pW x 2.75) = < 124 pW

Page 7
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Performance Characteristics (Continued)
1 mW power reference
Power output 1.00 mW (0.0 dBm). Factory set to ± 0.4 % traceable to the National Physical Laboratories (NPL), UK
Accuracy (for two years) ± 0.4% (25 ± 10 ºC)
± 1.2% (0 to 55 ºC)
Frequency 50 MHz nominal
SWR 1.05 (typical), 1.08 (0 to 55 ºC)
Connector type Type-N (f), 50 Ω
Measurement speed
Using remote interface (over the GPIB, USB or LAN), three measurement speed modes are available as shown, along with the typical maximum
measurement speed for each mode.
With N1913A power meter Normal: 20 readings/second
x2: 40 readings/second
Fast: 400 readings/second, for Keysight E- Series power sensors only
With N1914A power meter The measurement speed is reduced, for example, with both channels in FAST mode, the typical maximum measurement
speed is 200 readings/second.
Fast mode is for Keysight E-Series power sensors only.
Maximum measurement speed is obtained using binary output in free run trigger mode.
Table 1. Power sensors zero set, zero drift and measurement noise.
Model Zero set Zero drift 1Measurement noise 2
E9300A, E9301A, E9304A 3± 500 pW < ± 150 pW < 700 pW
E9300B, E9301B 3± 500 nW < ± 150 nW < 700 nW
E9300H, E9301H 3± 5 nW < ± 1.5 nW < 7 nW
E4412A, E4413A ± 50 pW < ± 15 pW < 70 pW
N8481A, N8482A, N8485A, N8487A, N8486AR, N8486AQ ± 25 nW < ± 3 nW < 80 nW
8483A ± 50 nW < ± 10 nW < 110 nW
N8481B, N8482B ± 50 μW < ± 10 μW < 110 μW
8481D, 8485D, 8487D ± 20 pW < ± 4 pW < 45 pW
N8481H, N8482H ± 5 μW < ± 1 μW < 10 μW
R8486D, Q8486D ± 30 pW < ± 6 pW < 65 pW
V8486A, W8486A ± 200 nW < ± 40 nW < 450 nW
1� Within 1 hour after zero set, at a constant temperature, after a 24-hour warm-up of the power meter�
2� The number of averages at 16 for normal mode and 32 for x2 mode, at a constant temperature, measured over a one minute interval and two standard
deviations� For E-Series sensors, the measurement noise is measured within the low range� Refer to the relevant sensor manual for further information�
3� Specification applies to the low power path, 15 to 75% relative humidity�
The 8480 Series sensors in the table do not include discontinued models�
Table 2. Noise multiplier.
Number of averages 124816 32 64 128 256 512 1024
Noise multiplier
–Normal mode 5.5 3.89 2.75 1.94 10.85 0.61 0.49 0.34 0.24 0.17
–x2 mode 6.5 4.6 3.25 2.3 1.63 10.72 0.57 0.41 0.29 0.2

Page 8
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Performance Characteristics (Continued)
Table 3. Settling time
Number of averages 1 2 4 8 16 32 64 128 256 512 1024
Settling time with E-Series sensors (s)
Normal mode 0.08 0.13 0.24 0.45 1.1 1.9 3.5 6.7 14 27 57
x2 mode 0.07 0.09 0.15 0.24 0.45 1.1 1.9 3.6 6.7 14 27
Settling time with N8480 Series sensors (s)
Normal mode 0.15 0.2 0.3 0.5 1.1 1.9 3.4 6.6 13 27 57
x2 mode 0.15 0.18 0.22 0.35 0.55 1.1 1.9 3.5 6.9 14.5 33
Settling time with 8480 Series sensors (s)
Normal mode 0.15 0.2 0.3 0.5 1.1 1.9 3.4 6.6 13 27 57
x2 mode 0.15 0.18 0.22 0.35 0.55 1.1 1.9 3.5 6.9 14.5 33
E-Series sensors In FAST mode (using free run trigger), within the range –50 dBm to +17 dBm, for a 10 dB decreasing power step, the
settling time is:
– N1913A: 10 ms 2
– N1914A: 20 ms 2
1� Settling time: 0 to 99% settled readings over the GPIB�
2� When a power step crosses through the sensor’s auto-range switch point, add 25 ms� Refer to the relevant sensor manual for switch point information�
Settling time 1
Manual filter, 10-dB decreasing power step for normal and x2 modes (not across range switch points for E-Series and N8480 Series
sensors)�

Page 9
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Performance Characteristics (Continued)
Settling time (Continued)
Auto filter, 10 dB decreasing power step for normal and X2 modes (not across the range switch points for E-Series and N8480 Series
sensors)�
x2
speed
120 ms
400 s
6.5 s
70 ms
210 ms
3.4 s
–40 dBm
–50 dBm
–60 dBm
Normal
speed
T
ypical
settling
times
Sensor
dynamic
range
Maximum
dBm
Minimum
dBm
With E-Series E4412/13A sensors
With N8480 Series sensors
40 ms 70 ms
x2
speed
150 ms
200 ms
1 s
6.6 s
13.5 s
150 ms
180 ms
400 ms
3.6 s
6.6 s
20 dBm
10 dBm
10 dBm
10 dBm
5 dB
Normal
speed
Typical
settling
times
Sensor
dynamic
range
Maximum
dBm
Minimum
dBm
x2
speed
150 ms
200 ms
500 ms
6.6 s
150 ms
180 ms
350 ms
3.5 s
20 dBm
10 dBm
10 dBm
10 dBm
Normal
speed
Typical
settling
times
Sensor
dynamic
range
Maximum
dBm
Minimum
dBm
x2
speed
70 ms
210 ms
400 ms
1 s
70 ms
120 ms
1 s
6.5 s
13 s
40 ms
120 ms
210 ms
400 ms
40 ms
70 ms
400 ms
3.4 s
6.8 s
+10 dBm
+2 dBm
–4 dBm
-10 dBm
-20 dBm
-30 dBm
-40 dBm
-50 dBm
Normal
speed
T
ypical
settling
times
Sensor
dynamic
range
High power
path
Low power
path
Maximum
dBm
Minimum
dBm
x2
speed
70 ms
210 ms
400 ms
1 s
70 ms
120 ms
1 s
6.5 s
13 s
40 ms
120 ms
210 ms
400 ms
40 ms
70 ms
400 ms
3.4 s
6.8 s
+40 dBm
+3 2 dBm
–26 dBm
-20 dBm
-10 dBm
0 dBm
-10 dBm
-20 dBm
+20 dBm
+12 dBm
–6 dBm
0 dBm
-10 dBm
–20 dBm
-30 dBm
-40 dBm
Normal
speed
T
ypical
settling
times
Sensor
dynamic
range
High power
path
Low power
path
Maximum
dBm
Minimum
dBm
With E-Series E9300A/01A/04A sensors
With E-Series E9300B/01B/00H/01H sensor
With 8480 Series sensors

Page 10
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Performance Characteristics (Continued)
Power meter functions
Accessed by key entry Either hard keys, or soft key menu, and programmable
Zero Zeros the meter. (Power reference calibrator is switched off during zeroing.)
Cal Calibrates the meter using internal (power reference calibrator) or external source. Reference cal factor settable from 1%
to 150%, in 0.1% increments.
Frequency Entered frequency range is used to interpolate the calibration factors table. Frequency range from 1 kHz to 999.9 GHz.
Also settable in 1 kHz steps.
Cal factor Sets the calibration factor for the meter. Range: 1% to 150%, in 0.1% increments.
Relative Displays all successive measurements relative to the last displayed value
Offset Allows power measurements to be offset by –100 dB to +100 dB, settable in 0.001 dB increments, to compensate for
external loss or gain
Save/recall Store up to 10 instrument states via the save/recall menu
dBm/W Selectable units of either Watts or dBm in absolute power; or percent or dB for relative measurements
Filter (averaging) Selectable from 1 to 1024. Auto-averaging provides automatic noise compensation.
Duty cycle Duty cycle values between 0.001% to 99.999%, in 0.001% increments, can be entered to display a peak power
representation of measured power. The following equation is used to calculate the displayed peak power value: peak power
= measured power/duty cycle.
Sensor cal tables Selects cal factor versus frequency tables corresponding to specified sensors
Limits High and low limits can be set in the range –150.000 to +230.000 dBm, in 0.001 dBm increments
Preset default values dBm mode, rel off, power reference off, duty cycle off, offset off, frequency 50 MHz, AUTO average, free run, AUTO range
(for E-Series sensors and N8480 Series)
Display Color display with selectable single and split screen formats are available. A quasi-analog display is available for peaking
measurements. The dual channel power meter can simultaneously display any two configurations of A, B, A/B, B/A, A-B,
B-A and relative. With the optional USB ports, additional dual channel (C & D), adds up to total 4-channels measurement
display.
Power meter general specifications
Dimensions The following dimensions exclude front and rear protrusions:
212.6 mm W x 88.5 mm H x 348.3 mm D (8.5 in x 3.5 in x 13.7 in)
Weight Model Net Shipping
N1913A 3.6 kg (8.0 lb) 8.2 kg (18.1 lb)
N1914A 3.7 kg (8.2 lb) 8.2 kg (18.3 lb)
Rear panel connectors
Recorder outputs Analog 0 to 1 volt, 1 kΩ output impedance, BNC connector. N1914A recorder outputs are dedicated to channel A and
channel B.
GPIB, USB 2.0 and
10/100BaseT LAN
Interfaces to allow communication with an external controller
Trigger Input (optional) 1Input has TTL compatible logic levels and uses a BNC connector
High: > 2.4 V Low: < 0.7 V
Trigger Output (optional) 1Output provides TTL compatible logic levels and uses a BNC connector
High: > 2.4 V Low: < 0.7 V
Ground Binding post, accepts 4 mm plug or bare wire connection
USB Host (options) USB ports which connects to U2000 series USB power sensors
VGA Out (options) Standard 15-pin VGA connector, allows connection of external VGA monitor
1� For automated power or frequency sweep function�

Page 11
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Performance Characteristics (Continued)
Line power
Input voltage range 90 to 264 VAC, automatic selection
Input frequency range 47 to 63 Hz and 400 Hz at 110 Vac
Power requirement 75 VA (50 Watts)
Environmental characteristics
Electromagnetic compatibility Complies with the essential requirements of EMC Directive (2004/108/EC) as follows:
IEC61326- 1:2005 / EN61326- 1:2006
CISPR11:2003 / EN55011:2007 (Group 1, Class A)
The product also meets the following EMC standards:
Canada: ICES/NMB- 001:2004
Australia/New Zealand: AS/NZS CISPR 11:2004
Product safety This product conforms to the requirements of the following safety standards:
IEC 61010- 1:2001 / EN 61010- 1:2001
CAN/CSA- C22.2 No.61010- 1- 04
ANSI/UL61010- 1:2004
Low Voltage Directive This product conforms to the requirements of European Council Directive “2006/95/EC”
Operating environment
Temperature 0 to 55 °C
Maximum humidity 95% at 40 °C (non-condensing)
Maximum altitude 4,600 meters (15,000 feet)
Storage conditions
Non-operating storage temperature –40 to +70 °C
Non-operating maximum humidity 90% at 65 °C (non-condensing)
Non-operating maximum altitude 4,600 meters (15,000 feet)
Remote programming
Interface GPIB, USB and LAN interfaces operates to IEEE 488.2 standard
Command language SCPI standard interface commands. Code-compatible with legacy E4418B/9B EPM Series, 436A, 437B
and 438A power meters (43X compatibility only with option N191xA-200).
GPIB compatibility SH1, AH1, T6, TE0, L4, LE0, SR1, RL1, PP1, DC1, DT1, C0
1� Characteristics describe product performance that is useful in the application of the product, but is not covered by the product warranty�

Page 12
Find us at www.keysight.com
N1913A/14A EPM Series Power Meters Ordering Information
Options
Power meter configurations
N1913/4A-004 Delete power sensor cable(s)
N1913/4A-101 1Single/dual-channel average power meter
N1913/4A-201 Single/dual-channel average power meter with VGA, trigger in/out,
1 front and 1 rear USB port
N1913/4A-B01 Without battery (mandatory for Option 201)
N1913/4A-C01 Front calibrator, front sensor
N1913/4A-C02 Front calibrator, parallel front and rear sensor
N1913/4A-C03 Rear calibrator, parallel front and rear sensor
N1913A-200 436A and 437B code compatibility for new N1913A purchase
N1914A-200 438A code compatibility for new N1914A purchase
N6901A-1FP 436A and 437B code compatibility for N1913A. Post purchase upgrade
only.
N6902 A-1FP 438A code compatibility for N1914A. Post purchase upgrade only.
Power sensor cables
11730A Power sensor cable: 1.5 m/5 ft
11730B Power sensor cable: 3.0 m/10 ft
11730C Power sensor cable: 6.1 m/20 ft
11730D Power sensor cable: 15.2 m/50 ft
11730E Power sensor cable: 30.5 m/100 ft
11730F Power sensor cable: 61 m/200 ft
Other accessories
34131A Transit case
34141A Soft carrying case
34161A Accessory pouch
N191xA-908 Rackmount kit for one instrument
N191xA-909 Rackmount kit for two instruments
Software Description
BV0007B BenchVue Power Meter/Sensor Control and Analysis app license
Calibration
N191xA-1A7 Calibration + Uncertainties + Guardbanding
N191xA-A6J ANSI Z540-1-1994 Calibration
R-50C-011-3 Calibration Assurance Plan - Return to Keysight - 3 years
R-50C-011-5 Calibration Assurance Plan - Return to Keysight - 3 years
R-50C-021-3 ANSI Z540-1-1994 Calibration - 3 years
R-50C-021-5 ANSI Z540-1-1994 Calibration - 5 years
GPIB connectivity products
82357B USB/GPIB converter
10833x GPIB cables: 10833D (0.5 m), 10833A (1 m), 10833B (2 m), 10833C (4 m),
10833F (6 m), 10833G (8 m)
1� Option 101 provides the calibrator and the sensor(s) on the front panel� It can’t be ordered with any of
the B0x/C0x options�
Standard-shipped accessories
– Power cord
– Power sensor cable, 1�5 m (5 ft) (One
per N1913A, two per N1914A)
– USB cable Type A to Mini-B, 6 ft
Power meters
Model Description
N1913A Single-channel average power
meter
N1914A Dual-channel average power meter

Page 13
Find us at www.keysight.com
E-Series Power Sensor Specifications
The E-Series of power sensors have their calibration factors stored in EEPROM and operate over a wide dynamic range� They are
designed for use with the EPM Series of power meters and two classes of sensors are available:
– CW power sensors (E4412A and E4413A)
– Average power sensors (E9300 sensors)
E-Series CW Power Sensor Specifications
Widest dynamic range: 100 pW to 100 mW (–70 to +20 dBm)
Table 4. E4410 Series max SWR specification.
Model Maximum SWR Maximum SWR Maximum power Connector type
E4412A 10 MHz to 18 GHz 10 to < 30 MHz: 1.22 1200 mW (+23 dBm) Type-N (m)
30 MHz to < 2 GHz: 1.15
2 to < 6 GHz: 1.17 2
6 to < 11 GHz: 1.2
11 to 18 GHz: 1.27 3
E4413A 50 MHz to 26.5 GHz 50 to < 100 MHz: 1.21 200 mW (+23 dBm) APC-3.5 mm (m)
100 MHz to < 8 GHz: 1.19
8 to < 18 GHz: 1.21 4
18 to 26.5 GHz: 1.26 5
1� Applies to sensors with serial prefix US 3848 or greater�
2� Max SWR is 1�2 for high power from +17 to +20 dBm�
3� Max SWR is 1�34 for high power from +17 to +20 dBm�
4� Max SWR is 1�28 for high power from +17 to +20 dBm�
5� Max SWR is 1�49 for high power from +17 to +20 dBm�
N1913A/14A EPM Series Power Meters Ordering Information (Continued)
Options (Continued)
Documentation
N191xA-0B1 Hard copy English language User’s Guide and Installation Guide
N191xA-0BF Hard copy English language Programming Guide
N191xA-0BW Hard copy English language Service Guide
N191xA-ABA Hard copy English language User’s Guide and Programming Guide
N191xA-ABJ Hard copy Japanese localization User’s Guide and Programming Guide
N1913A-CD1 Documentation Optical Disk (consists of documentation CD-ROM and Keysight Instruments Control DVD)

Page 14
Find us at www.keysight.com
For power levels greater than 0 dBm, add 0�5%/dB to the calibration factor uncertainty specification
E-Series CW Power Sensor Specifications (Continued)
Calibration factor (CF) and
reflection coefficient (Rho)
Calibration factor and reflection
coefficient data are provided at 1 GHz
increments on a data sheet included with
the power sensor� This data is unique
to each sensor� If you have more than
one sensor, match the serial number on
the data sheet with the serial number
on the power sensor you are using� The
CF corrects for the frequency response
of the sensor� The EPM power meter
automatically reads the CF data stored
in the sensor and uses it to make the
corrections�
Reflection coefficient (Rho) relates to the
SWR according to the following formula:
SWR = 1 + Rho/1 – Rho�
Maximum uncertainties of the CF data are
listed in Table 5a, for the E4412A power
sensor, and Table 5b for the E4413A power
sensor� The uncertainty analysis for the
calibration of the sensors was done in
accordance with the ISO/TAG4 Guide�
The uncertainty data reported on the
calibration certificate is the expanded
uncertainty with a 95% confidence level
and a coverage factor of 2�
Table 5a. E4412A calibration factor uncertainty at calibrated powers.
Frequency Uncertainty1(%)
50 MHz Reference
10 to < 30 MHz 1.8
30 MHz to < 2 GHz 1.8
2 to < 16 GHz 2.4
16 to 18 GHz 2.6
Table 5b. E4413A calibration factor uncertainty at calibrated powers.
Frequency Uncertainty1(%)
50 MHz Reference
100 MHz to < 2 GHz 1.8
2 to < 10 GHz 2.4
10 to < 12 GHz 2.6
12 to < 20 GHz 2.8
20 to 26.5 GHz 3.0
1� For power levels greater than 0 dBm, add 0�5%/dB to the calibration factor uncertainty specification

Page 15
Find us at www.keysight.com
E-Series CW Power Sensor Specifications (Continued)
Power linearity
Table 6. E4410 Series power linearity specification.
Power Temperature (25 ± 5 °C) Temperature (0 to 55 °C)
100 pW to 10 mW (–70 to +10 dBm) ± 3% ± 7%
10 mW to 100 mW (+10 to +20 dBm) ± 4.5% ± 10%
+20
+10
+6
–20
–35
–70
± 4%
+3%
A
B
–70 –35 –20 –10 +10 +20
Power level used as reference (dBm)
Power level being measured (dBm)
Figure 1� Relative mode power measurement linearity with EPM Series power
meter/E-Series CW power sensor at 25 °C ± 5 °C (typical)�
The chart in Figure 1 shows the typical
uncertainty in making a relative power
measurement, using the same power
meter channel and the same power sensor
to obtain the reference and the measured
values� Example A illustrates a relative
gain (amplifier measurement)� Example
B illustrates a relative loss (insertion
loss measurement)� This chart assumes
negligible change in frequency and
mismatch occur when transitioning from
the power level used as the reference to
the power level being measured�
Example A
– P = 10(P)/10 x 1 mW
– P = 10 6/10 x 1 mW
– P = 3�98 mW
– 3%x3.98mW=119.4μW
Example B
– P = 10 (P)/10 x1 mW
– P = 10 –35/10 x 1 mW
– P = 316 nW
– 3% x 316 nW = 9�48 nW
where
– P = power in Watts
and
– (P) = power in dBm
Mechanical characteristic
Mechanical characteristics such as center
conductor protrusion and pin depth are
not performance specifications� They
are, however, important supplemental
characteristics related to electrical
performance� At no time should the pin
depth of the connector be protruding�

Page 16
Find us at www.keysight.com
E-Series E9300 Average Power Sensor Specifications
The E-Series E9300 wide dynamic range, average power sensors are designed for use with the EPM family of power meters� These
specifications are valid ONLY after proper calibration of the power meter and apply for CW signals unless otherwise stated�
Specifications apply over the temperature range 0 to 55 °C unless otherwise stated, and specifications quoted over the temperature
range 25 °C ± 10 °C, conform to the standard environmental test conditions as defined in TIA/EIA/IS-97-A and TIA/EIA/IS-98-A�
The E-Series E9300 power sensors have two independent measurement paths (high and low power paths) as shown in Table 7�
Table 7. E9300 Series two-path specification.
“A” suffix sensors “B” suffix sensors “H” suffix sensors
High power path –10 to +20 dBm +20 to +44 dBm 0 to +30 dBm
Low power path –60 to –10 dBm –30 to +20 dBm –50 to 0 dBm
Table 8. E9300 Series sensors specification.
Model Frequency
range
Maximum SWR
(25 °C ± 10 °C)
Maximum SWR
(0 to 55 °C)
Maximum power Connector type
–60 to +20 dBm wide dynamic range sensors
E9300A 10 MHz to 18 GHz 10 to < 30 MHz : 1.15 10 to < 30 MHz : 1.21 +25 dBm (320 mW) average Type-N (m)
30 MHz to < 2 GHz : 1.13 30 MHz to < 2 GHz : 1.15 +33 dBm peak (2 W)
2 to < 14 GHz : 1.19 2 to < 14 GHz : 1.20 (< 10 μsec)
14 to < 16 GHz : 1.22 14 to < 16 GHz : 1.23
16 to 18 GHz : 1.26 16 to 18 GHz : 1.27
E9301A 10 MHz to 6 GHz 10 to < 30 MHz : 1.15 10 to < 30 MHz : 1.21 +25 dBm (320 mW) average Type-N (m)
30 MHz to < 2 GHz : 1.13 30 MHz to < 2 GHz : 1.15 +33 dBm peak (2 W)
2 to 6 GHz : 1.19 2 to 6 GHz : 1.20 (< 10 μsec)
E9304A 9 kHz to 6 GHz 9 KHz to < 2 GHz : 1.13 9 KHz to < 2 GHz : 1.15 +25 dBm (320 mW) average Type-N (m)
2 to 6 GHz : 1.19 2 to 6 GHz : 1.20 +33 dBm peak (2 W)
(< 10 μsec)
–30 to +44 dBm wide dynamic range sensors
E9300B 10 MHz to 18 GHz 10 MHz to < 8 GHz : 1.12 10 MHz to < 8 GHz : 1.14 0 to 35 °C: 30 W avg Type-N (m)
8 to < 12.4 GHz : 1.17 8 to < 12.4 GHz : 1.18 35 to 55 °C: 25 W avg
12.4 to 18 GHz : 1.24 12.4 to 18 GHz : 1.25 < 6 GHz: 500 W pk
> 6 GHz: 125 W pk
500 W.μS per pulse
E9301B 10 MHz to 6 GHz 10 MHz to 6 GHz : 1.12 10 MHz to 6 GHz : 1.14 0 to 35 °C: 30 W avg Type-N (m)
35 to 55 °C: 25 W avg
< 6 GHz: 500 W pk
> 6 GHz: 125 W pk
500 W.μS per pulse
–50 to +30 dBm wide dynamic range sensors
E9300H 10 MHz to 18 GHz 10 MHz to < 8 GHz : 1.15 10 MHz to < 8 GHz : 1.17 3.16 W avg Type-N (m)
8 to < 12.4 GHz : 1.25 8 to < 12.4 GHz : 1.26 100 W pk
12.4 to 18GHz : 1.28 12.4 to 18GHz : 1.29 100 W.μS per pulse
E9301H 10 MHz to 6 GHz 10 MHz to < 6 GHz : 1.15 10 MHz to < 6 GHz : 1.17 3.16 W avg Type-N (m)
100 W pk
100 W.μS per pulse

Page 17
Find us at www.keysight.com
E-Series E9300 Average Power Sensor Specifications (Continued)
1.2
1.18
1.16
1.14
1.12
1.1
1.08
1.06
1.04
1.02
1
SWR
Frequency GHz
0.01 2.00 4.00 6.00 8.00 10.00 12.00 14.00 16.00 18.00
1.2
1.18
1.16
1.14
1.12
1.1
1.08
1.06
1.04
1.02
1
SWR
Frequency GHz
0.01 2.00 4.00 6.00 8.00 10.00 12.00 14.00 16.00 18.00
1.20
1.15
1.10
1.05
1.00
SWR
0 2 4 6 8 10 12 14 16 18
Frequency GHz
1.2
1.15
1.1
1.05
1
SWR
0 2 4 6 8 10 12 14 16 18
Frequency GHz
Typical SWR, 10 MHz to 18 GHz (25 °C ± 10 °C) for E9300A and
E9301A sensor�
Typical SWR, 9 kHz to 6 GHz (25 °C ± 10 °C) for E9304A sensors�
Typical SWR, 10 MHz to 18 GHz (25 °C ± 10 °C) for E9300B and
E9301B sensors�
Typical SWR, 10 MHz to 18 GHz (25 °C ± 10 °C) for E9300H and
E9301H sensors�

Page 18
Find us at www.keysight.com
E-Series E9300 Average Power Sensor Specifications (Continued)
Power linearity 1
Table 9. E9300 Series power linearity (after zero and cal at ambient environmental conditions) sensor.
Sensor Power Linearity (25 ± 10 °C) Linearity (0 to 55 °C)
E9300A, E9301A, E9304A –60 to –10 dBm ± 3.0% ± 3.5%
–10 to 0 dBm ± 2.5% ± 3.0%
0 to +20 dBm ± 2.0% ± 2.5%
E9300B, E9301B –30 to +20 dBm ± 3.5% ± 4.0%
+20 to +30 dBm ± 3.0% ± 3.5%
+30 to +44 dBm ± 2.5% ± 3.0%
E9300H, E9301H –50 to 0 dBm ± 4.0% ± 5.0%
0 to +10 dBm ± 3.5% ± 4.0%
+10 to +30 dBm ± 3.0% ± 3.5%
1� After zero and calibration at ambient environmental conditions�
Typical E9300A/01A/04A power linearity at 25 °C, after zero and
calibration, with associated measurement uncertainty�
Power range Measurement uncertainty
–30 to –20 dBm ± 0.9%
–20 to –10 dBm ± 0.8%
–10 to 0 dBm ± 0.65%
0 to +10 dBm ± 0.55%
+10 to +20 dBm ± 0.45%
0.5
0.4
0.3
0.2
0.1
0
–0.1
–0.2
–0.3
–0.4
–0.5
% Error
18141062–2–8–10–14–18–22–26–30 20
Power (dBm)
1
0.8
0.6
0.4
0.2
0
–0.2
–0.4
–0.6
–0.8
–1
% Error
–10 –5 0 5 10 15 20 25 30
Power (dBm)
Typical E9300B/01B power linearity at 25 °C, after zero and
calibration, with associated measurement uncertainty�
Power range Measurement uncertainty
–6 to 0 dBm ± 0.65%
0 to +10 dBm ± 0.55%
+10 to +20 dBm ± 0.45%
+20 to +26 dBm ± 0.31%
Typical E9300H/01H power linearity at 25 °C, after zero and
calibration, with associated measurement uncertainty�
Power range Measurement uncertainty
–26 to –20 dBm ± 0.9%
–20 to –10 dBm ± 0.8%
–10 to 0 dBm ± 0.65%
0 to +10 dBm ± 0.55%
+10 to +20 dBm ± 0.45%
+20 to +26 dBm ± 0.31%
1
0.8
0.6
0.4
0.2
0
–0.2
–0.4
–0.6
–0.8
–1
% Error
–10 –5 0 5 10 15 20 25 30
Power (dBm)

Page 19
Find us at www.keysight.com
E-Series E9300 Average Power Sensor Specifications (Continued)
Effects of change in temperature on linearity
Note: If the temperature changes after calibration and you choose not to re-calibrate the sensor, the following additional power
linearity error should be added to the linearity specs in Table 9�
For small changes in temperature: The typical maximum additional power linearity error due to small temperature change after
calibration is ± 0�15%/°C (valid after zeroing the sensor)�
For large changes in temperature: refer to Table 10�
Table 10. Typical maximum additional power linearity error due to temperature change (valid after zeroing the
sensor).
Sensor Power Additional power linearity error
(25 °C ± 10 °C)
Additional power linearity error
(0 to 55 °C)
E9300A, E9301A, E9304A –60 to –10 dBm ± 1.5% ± 2.0%
–10 to 0 dBm ± 1.5% ± 2.5%
0 to +20 dBm ± 1.5% ± 2.0%
E9300B, E9301B –30 to +20 dBm ± 1.5% ± 2.0%
+20 to +30 dBm ± 1.5% ± 2.5%
+30 to +44 dBm ± 1.5% ± 2.0%
E9300H, E9301H –50 to 0 dBm ± 1.5% ± 2.0%
0 to +10 dBm ± 1.5% ± 2.5%
+10 to +30 dBm ± 1.5% ± 2.0%
Measured power
A+20 dBm
–10 dBm
60 dBm
B+44 dBm
H+30 dBm
+20 dBm, 0 dBm
–30 dBm, –50 dBm
± 2%
± 1%
± 1%
± 2%
A–60 dBm
B–30 dBm
H–50 dBm
–10 dBm
+20 dBm
0 dBm
+20 dBm
+44 dBm
+30 dBm
Figure 2� Relative mode power measurement linearity with an EPM Series power meter, at 25 °C
± 10 °C (typical)�
Figure 2 shows the typical uncertainty in
making a relative power measurement,
using the same power meter channel and
same power sensor to obtain the reference
and the measured values, and assumes
that negligible change in frequency and
mismatch error occur when transitioning
from the power level used as the reference
to the power level being measured�

Page 20
Find us at www.keysight.com
E-Series E9300 Average Power Sensor Specifications (Continued)
Switch point data
The E9300 power sensors have two paths as shown in Table 7� The power meter automatically selects the proper power level path� To
avoid unnecessary switching when the power level is near the switch point, switching point hysteresis has been added�
E9300 “A” suffix sensors example:
– Hysteresis causes the low power path to remain selected until approximately –9�5 dBm as the power level is increased, above this
power the high power path will be selected� The high power path will remain selected until approximately –10�5 dBm is reached as
the signal level decreases, below this power the low power path will be selected�
Switching point linearity:
– Typically = ± 0�5% (= ± 0�02 dB)
Switching point hysteresis:
– 0�5 dB typical
Table 11. E9300 Series sensor switch point specification.
E9300 sensor suffix Conditions 1Zero set Zero drift 2Measurement noise 3
A Lower power path (15 to 75% RH) 500 pW 150 pW 700 pW
Lower power path (75 to 95% RH) 500 pW 4,000 pW 700 pW
High power path (15 to 75% RH) 500 nW 150 nW 500 nW
High power path (75 to 95% RH) 500 nW 3000 nW 500 nW
B Lower power path (15 to 75% RH) 500 nW 150 nW 700 nW
Lower power path (75 to 95% RH) 500 nW 4 μW 700 nW
High power path (15 to 75% RH) 500 μW 150 μW 500 μW
High power path (75 to 95% RH) 500 μW 3000 mW 500 μW
H Lower power path (15 to 75% RH) 5 nW 1.5 nW 7 nW
Lower power path (75 to 95% RH) 5 nW 40 μW 7 nW
High power path (15 to 75% RH) 5 μW 1.5 μW 5 μW
High power path (75 to 95% RH) 5 μW 30 mW 5 μW
1� RH is the abbreviation for relative humidity�
2� Within 1 hour after zero set, at a constant temperature, after a 24-hour warm-up of the power meter with power sensor connected�
3� The number of averages at 16 for normal mode and 32 for x2 mode, at a constant temperature, measured over a one minute interval and two standard
deviations�
