1 OVERVIEW
1.1 INTRODUCTION
This user’s guide describes the hardware and software setup for the BM20 Bluetooth®Evaluation Board.
This board contains the hardware needed to evaluate the BM20 Bluetooth module. The BM20 module is
mounted to an evaluation board that demonstrates the module’s key features. The evaluation board contains:
Stereo audio output
Easy access to IO pins
6 push buttons to control audio playback
Status LEDs
The BM20 supports the following Bluetooth profiles: A2DP, AVRCP, and HFP/HSP
A2DP stereo audio (Sink mode wi support for Sub-Band Coding (SBC),
AVRCP media player remote control
HFP/HSP for accepting a phone call support.
For data sheet and other details related to BM20 module, refer to the Microchip web
site at http://www.microchip.com.
This chapter discusses the following topics:
BM20 Evaluation Board Features
BM20 Evaluation Board Contents and Part Details
1.2 BM20 EVALUATION BOARD FEATURES
The BM20 Evaluation Board has the following features:
Fully qualified Bluetooth version 4.1 module, fully compatible with Bluetooth version 3.0, 2.0, 1.2
system.
Embedded BM20 module with postage-stamp size form factor of 15 x 29 x 2.5 mm (include shielding
case)
Embedded Bluetooth stack profiles: A2DP, AVRCP, and HFP/HSP
Stereo audio output for highest quality audio
Castellated SMT pads for easy and reliable PCB mounting
Environmentally friendly, RoHS compliant
Bluetooth SIG certified
On board external CDA for speaker demonstration.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 7
1.3 BM20 EVALUATION BOARD CONTENTS
BM20 Evaluation Board contains the following components as shown in Figure 1-1 which describes the
evaluation board’s interfaces and connectors. Table 1-1 describes the various components of the evaluation
board.
FIGURE 1-1: BM20 EVALUATION BOARD
Audio Output (JP23) MIC (JP22) NFC tag connector (JP3)
Pin
Description
Pin
Description
Pin
Description
1
AOHPL
1
MIC_P1
1
NFC_P
2
AOHPM
2
AGND
2
NFC_N
3
AOHPR
3
MIC_N1
1 2 3
1 2 3
1 2

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 8
IO Connector (J1) On Board External CDA Interface (J2)
Pin
Description
Pin
Description
Pin
Description
1
P0_0
7
P2_4
1
External AMP enable
control(P1_5)
2
P3_0
8
P0_2
2
3
P2_0
9
P0_3
3
R channel signal to external
AMP.
4
P1_5
10
P0_5
4
5
P0_4
11
P2_7
5
L channel signal to external
AMP.
6
P0_1
12
P2_4
6
7
5V power for external AMP
from USB.
8
External AMP Connector (JP26) Battery connector (JP20) and Jack (JP19)
(Alternative for BAT_IN)
Pin
Description
Pin
Description
1
EXT_AMP_EN
1
BAT_IN
2
SPKR
2
GND
3
AGND
4
SPKL
5
AMP_POWER
1 2 3 4 5
2 1
+
1
3
5
7
9
11
2
4
6
8
10
12

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 9
TABLE 1-1:BM20 EVALUATION BOARD HARDWARE
Hardware Component
Description
BM20
Bluetooth®4.1 Module
USB Connector
DC 5V input, USB to UART for EEPROM R/W
BAT connector & Jack
JP20 and JP19 , alternative for BAT_IN
Audio Out
Audio 3.5 mm jack for audio playback(P6).
External AMP daughter board connector (JP26).
On Board external CDA output connector (J3/4).
Audio In
Audio 3.5 mm jack for Mono microphone input(P5) and AUX input(P7)
Status LEDs
Red and Blue LEDs show the pairing/connection status
MFB Button
Switch to turn on/off BM20 module (SW7; Button 0 in UI)
Play/Pause Button
Button to play or pause the audio playback (SW8; Button1 in UI)
Previous Track Button
Button to skip track backwards (SW4; Button 5 in UI)
Next Track Button
Button to skip track forwards(SW5; Button 4 in UI)
Volume Up Button
Button to increase volume (SW9; Button 2 in UI)
Volume Down Button
Button to decrease volume (SW10; Button 3 in UI)
Reset Button
Reset system (SW11)
NFC Tag Connector
NFC Tag connector.(For NFC tag without Rectifier Circuit)(JP3)
MP Tool Interface
Interfaces connect to VICTORIA board when use MP Tool

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 10
2. Getting Started
2.1 INTRODUCTION
This chapter describes how the BM20 Evaluation Board works. Certain hardware and utilities are essential to
support the evaluation/development of demo applications. This chapter discusses the following topics:
Hardware Requirements
Software/Utility Requirements
Module Configuration
2.2 HARDWARE REQUIREMENTS
2.2.1 HARDWARE SETUP
To setup the evaluation hardware, perform the following steps:
1. Make sure pin 1 / 2 / 3 of “SW12”in “Off / Off / On”state make .system in application mode.
2. Connect the portable mini-speaker 3.5 mm to the stereo audio out connector (P6).
2.2.2 USING THE EVALUATION BOARD
1. Connect Li-Ion batteries to JP20 or JP19.
2. Click MFB button to turn-on and enter pairing mode. The status LEDs will blink. Now the BM20 Evaluation
board should be discoverable.
3. Turn on Bluetooth device manager on a host device (PC or smartphone), the host device will display a list
of discoverable Bluetooth devices. The board display as “EDDY SHS”.
4. If the pairing with the device is successful, BM20 evaluation board can connect to the host device. Once
connected, BM20 evaluation board enables Advanced Audio Distribution Profile (A2DP) for audio
playback and Audio Video Remote Control Profile (AVRCP) for player control.
2.3 APPLICATION DEMONSTRATION
2.3.1 AUDIO DEMONSTRATION
In this demonstration, user can play an audio stream on both BM20 evaluation boards using a computer or
smartphone. The following are the steps to perform the demonstration.
1. Connect BM20 evaluation board to a host device (PC or smartphone) that has an audio source.
2. Connect headphones (or mini-speakers) to BM20 evaluation board P6.
3. Open the audio source on the host device. Microchip recommends using media player.(e.g. Microsoft
Media Player, iTunes, and Android).
4. Start the audio stream on the media player.
When BM20 evaluation board is connected to an audio source compatible with Bluetooth AVRCP, the audio
control buttons are use to:
Control the volume of audio output.
Go to the previous track.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 11
Go to the next track.
Start / stop playing the current track.
FIGURE 1-2: BM20 EVALUATION BOARD AUDIO CONTROL BUTTONS
FIGURE 1-3: BM20 EVALUATION BOARD WITH EXTERNAL CLASS-D AMPLIFIER
(It need modify the setting in UI to support external amplifier)

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 12
2.3.2 HSP/HFP DEMONSTRATION
In this demonstration, user can explore the hands-free profile setting to receive an incoming voice call from a
paired smartphone. This demonstration requires a microphone. It would be good to use a PC
headset/microphone (with two-plugs). The following are the steps to perform the demonstration.
1. Connect the headset/microphone to BM20 evaluation board’s audio out connector (P6) and MIC input
(P5) respectively.
2. Connect BM20 evaluation board to a smartphone that supports the A2DP and HFP/HSP Bluetooth
profiles.
3. From another one phone, initiate a call to the smartphone that is paired with BM20 evaluation board. The
A2DP stream pauses and the ringtone plays on the headset.
4. Click button “MFB” on BM20 evaluation board to accept the incoming call.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 13
2.4 SOFTWARE/UTILITY REQUIREMENTS
2.4.1 UI SETTING
Step1. Open UI tool
Step2. Firstly, you can load default UI setting or previous setting file.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 14
Step3. Click “Edit” to modify the settings meet your needs.
Step4. In the main settings, it can enable or disable supported profile or function which system need.
Click “Next” for other setting.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 15
Step5. You can do system and functional setting in these pages.
Click “Help” you can get more detail information.
Step6. After finish parameter set up, click “Finish” button and a message will remind you check EEPROM
size on your system.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 16
Step7. Click “Save” button to save these UI parameter as a “.txt” file
Step8. We will use MPET tool to merge it with EEPROM table and use EEPROM tool load these parameter
to system.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 17
2.4.2 DSP TOOL SETTING
Step1. Open DSP tool
Step2. Select IC version ““IS2020_XXX_SHS” (XXX is the version of chip, e.g. IS2020S-203)
Step3. You can setup all voice and audio function in these pages.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 18
Step4. Click “Save”button to save these DSP parameter as a “.txt”file after finish all DSP setting.
Then use MPET tool to merge it with EEPROM table and use EEPROM tool load these
parameter to system.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 19
2.4.3 MERGE TOOL SETTING
Step1. Open MPET tool, click “Next” to set up.
Step2. Select “UI Patch Only” to use full EEPROM table to merge UI and DSP parameter.

BM20 BLUETOOTH
EVALUTATION BOARD USER’S GUIDE
Preliminary Edition
2015 Microchip Technology Inc.
page 20
Step3. Select the bin file (full EEPROM table) and click “Next”
Step4. If the bin file had included UI, DSP or patch code parameter, you can see them in block 1 as the
figure below. If you want keep the in your new system, you can select the item which you want to keep and
use “pull down”button to add them to merge list. If you want to add new parameter (e.g. UI and DSP
parameter), click “+” button to add these files into tool for merge with EEPROM table.
