Microh LED BLADE P64 MKIII User manual

Introduction
Thank you for purchasing the LED BLADE P64 MKIII par xture. For your own safety
and knowledge, please read this manual before installing or operating the device.
This manual covers the important information on installation and applications.
Please install and operate the xture according to instructions. Meanwhile, please
keep this manual for future reference.
The LED BLADE P64 MKIII par xture is manufactured following CSA standards,
complying with international standard DMX512 protocol. This xture is applicable
but not limited to large scale live performances, theater, studio, nightclubs and
discos.
The LED BLADE P64 MKIII par xture features 36 LEDs (9 Red) (9 Green) (9 Blue)
(9 White). Please carefully unpack it when you receive the xture and check if it was
damaged during the transportation.
Please check whether the following items are included inside the box:
Item Quantity
LED BLADE P64 MKIII xture 1
Power cord 1
User Manual 1
Blade Bracket 2

Safety Instructions
CAUTION!
ELECTRIC SHOCK WARNING!
USE EXTREME CAUTION WHEN HANDLING WIRES.
This device has been delivered in safe working condition. In order to maintain this
condition and to ensure safe operation, it is absolutely necessary for the user to
follow the safety instructions and warning notes written in this user manual.
Important:
Damage caused by the disregard of this user manual are not subject to warranty.
The dealer will not accept liability for any resulting defects or problems.
If the device has been exposed to temperature changes, do not switch it on
immediately. The arising condensation could damage the device. Leave the device
switched off until it has reached room temperature, and is dry.
This device falls under protection-class I, therefore it is essential that the device be
grounded. The electrical connection must be carried out by a qualied technician.
The device should only be used with rated voltage and frequency. Make sure that
the available voltage is not higher than 120V as stated at the end of this manual.
Make sure the power cord is never crimped or damaged in any way, as this could
cause shock and damage. If your power cord is damaged in any way, please
purchase a new cable from your local MICROH dealer. Always disconnect power,
when the device is not in use or before cleaning it. Never pull out the plug by
tugging the power cord.
During initial start-up, some smoke or smell may arise. This is a normal process,
and does not necessarily mean that the device is defective. It should decrease
gradually. Please do not project the beam onto combustible substances.
Fixtures cannot be installed on or near combustible substances. Keep more than
50cm distance from wall for proper ventilation and air ow. If your xture is or has
become damaged in any way, it shall be exclusively replaced or repaired by the
manufacturer to avoid any hazard.
CAUTION!
Never touch the device during operation!
The housing may heat up!
CAUTION!
Never look directly into light source,
as sensitive persons may suffer from an epileptic shock.
CAUTION!
The electric connection must only be carried out by a qualied electrician

Mounting and Installation
Caution: For added protection, mount the xtures in areas outside walking paths,
seating areas, or in areas were the xture might be reached by unauthorized
personnel. Before mounting the xture to any surface, make sure that the
installation area can hold a minimum point load of 10 times the device’s weight.
Fixture installation must always be secured with a secondary safety attachment,
such as an appropriate safety cable. Never stand directly below the device when
mounting, removing, or servicing the xture.
Whether installing inverted on a truss / ceiling or set on a at level surface (see
illustration below). Be sure this xture is kept at least 0.5m (1.5 ft.) away from any
ammable materials (decoration etc.). Always use and install the supplied safety
cable as a safety measure to prevent accidental damage and/or injury in the event
the clamp fails.
Mounting Points: Overhead mounting requires extensive experience, including
calculating working load limits. A knowledge of the installation material being
used and periodic safety inspection of all installation material and the xture are
all imperative and should only be performed by a qualied technician. Improper
installation can result in bodily injury and damage.
Be sure to complete all rigging and installation procedures before connecting the
main power cord to the appropriate wall outlet.
Clamp Mounting: The MICROH DJ LED BLADE P64 MKIII provides a unique
mounting bracket assembly that integrates 2 brackets to be used to mount on
a truss or the oor. When mounting this xture to truss, be sure to secure an
appropriately rated clamp to the included bracket tted through the center hole.
As an added safety measure, be sure to attach at least one properly rated safety
cable to the xture.

Regardless of the rigging option you choose for your LED BLADE P64 MKIII,
always be sure to secure your xture with a safety cable. The xture provides a
built-in rigging point for a safety cable on the hanging bracket as illustrated above.
Be sure to only use the designated rigging point for the safety cable and never
secure a safety cable to a carrying handle.
Proper Usage: This product is for overhead mounting only. For safety purposes,
MICROH DJ recommends mounting lighting effect products on steady elevated
platforms or sturdy overhead supports using suitable hanging clamps. In all cases,
use safety cables. Obtain appropriate mounting hardware from your lighting vendor.
Operation Stipulation
• This xture can only be used indoors and it must be the consistent power condition
• Please pay attention to the installation and do not swing or mishandle the
xture in any way while using it.
• Please be sure the lamp is located in an area that isn’t too hot or damp. Before
installation make sure that you have 0.5m clearance between the xture and
the subject that is being illuminated.
• Please use appropriate and safe power line to connect the xture
• Please be sure to familiarize yourself with the lamp functions before operating,
since damage is mainly due to improper operation. Thus professional operation
is needed for this xture.
• Please use original packaging while transporting this unit.
• Please do not modify the lamp. Any unauthorized or nonprofessional operation
is not guaranteed by the factory, any breakdown and damage, the factory has
no obligation for maintenance.

DMX512 Control Data Connection:
This xture complies with international USITT DMX standards and can be used
with a 3 pin DMX connector. Plug in the 3 pin XLR cable to the female 3-pin XLR
output of your controller and the other side to the male 3-pin XLR input of the LED
battery par light. To connect the units to DMX, you must daisy chain the xtures
together as referred in the diagram below. Always end your DMX-512 connection
with a DMX terminator
For installations where the DMX cable has to
run a long distance, or is in an electrically noisy
environment, it is recommended to use a DMX
terminator. This helps in preventing corruption of
the digital control signal by electrical noise. The
DMX terminator is simply an XLR a 120 120 Ω
resistor connected between pins 2 and 3, which is
then plugged into the output XLR socket of the last
xture in the chain. Please see illustrations below:
Key Description
MENU: Access the menu
DOWN: “reduction key” or “key under the
selected”; decrease the value
function down menu.
UP: “add key” or “selection on the
key”; increase Lou = value
function, shift on the menu
ENTER: “OK button”; to determine the
function into the user selected
(that is to stop the ongoing
functions, run the function the
user selected items

Menu Display
Number Display Show Function
1 d001-d512 DMX mode
2 CHnd 4 or 8 channel selection
3 Auxx/Soxx Au01-Au08: RGBW Colour mixing
Au09: Colour jumping
Au10: Colour fade
So01-So02: Sound mode
4St00 St00: Master to strobe
St00:-St16: Strobe slow to fast
5 SP00-SP16 Colour jumping and colour gradient speed
(slow to fast)
6R000-R255 Red dimmer
7G000-G255 Green dimmer
8B000-B255 Blue dimmer
9 U000-U255 White dimmer
10 Iron-IroF Infrared remote control
IR Remote Controller Instruction
1. Press the “MENU” button, select “Iron ” then can use the IR remote
controller
2. Key Description:
FLASH = Auto run
STROBE = Strobe
FADE = Color gradient
SMOOTH = Sound control

DMX512 Controller Channel Function
4 Channel Mode
Channel Value Function
1 000-255 Red dimmer
2 000-255 Green dimmer
3 000-255 Blue dimmer
4000-255 White dimmer
8 Channel Mode
Channel Value Function
1 000-255 Dimmer
2 000-255 Red dimmer
3 000-255 Green dimmer
4000-255 Blue dimmer
5 000-255 White dimmer
6004-255 Strobe (slow to fast)
7000-019 Red
020-035 Green
036-051 Blue
052-067 White
068-083 Yellow/Amber
084-099 Purple
101-109 Dark Cyan
110-127 Cyan
128-169 Colour snap
170-210 Colour fade
211-255 Sound mode (slow to fast)
8000-255 Colour snap/ Fade speed control (slow to fast)

Specications
Voltage: AC120V, 60Hz 5A
Power Consumption: 60W
LED Quantity: 36x1 Watt (9 Red) (9 Green) (9 Blue) (9 White)
Function: DMX512, Sound Control, Auto, Master/Slave, IR Remote
Beam Angle: 25°
DMX Channel: 4 CH/ 8 CH
Display: LCD function show
Net Weight: 1.5Kg
Product Size (mm): 268 x 67 x 245

Maintenance And Cleaning
The following points have to be considered during the inspection:
1. All screws for installing the device or parts of the device must be tightly
connected, and must not be corroded.
2. There must not be any deformations on the housing, colour lenses, xations
or installation spots (ceiling, suspension, trussing).
3. Mechanically moved parts must not show any traces of wearing and must not
rotate with unbalances
4. The electric power supply cables must not show any damage, material
fatigue or sediments.
Further instructions depending on the
CAUTION
Disconnect from mains before starting maintenance operation.
In order to keep the xture in good condition and extend the life, we suggest
regular cleaning to the xture.
1. Clean the inside and outside lens each week to avoid the light output from
darkening due to accumulation of dust, dirt, etc.
2. Clean the fan each week.
3. A detailed electrical check by approved technician every three months is
advised. Ensure the circuit contacts are in good condition.
We recommend a frequent cleaning of the device. Please use a moist, lint- free
cloth. Never use alcohol or solvents.
PLEASE NOTE:
All information for this product is subject to change without notice!
