Microh FIREFOX-RG User manual

www.microhdj.com
MODEL: FIREFOX-RG
User Manual

Thanks for your purchasing, please read this manual carefully before operating the
system. It gives you general information for your safe and better operation.
Inspection
Check for the contents in the package refer to the following list:
1. Laser lighting: 1
2. Power cable: 1
3. User manual: 1
Technical parameters
1. Laser diode: Red 650nm, green 532nm
2. Power supply：AC120V, 50/60Hz, 55W
3. Laser power：Green 50mw, Red 150mW
4. Motor: N1.8 high precision step motor
5. Control mode：Sound control/Auto/master-slave/DMX
6. Dimensions：293mm×172mm×103mm
7. Net weight：3.0KG
8. Gross weight：3.5KG
DANGER
LASER RADIATIONAVOID EXPOSURE
TO BEAM CLASS 3B LASER PRODUCT
----------------- 1 -------------------

Function Setting
（
digital board
）
THE ‘MODE’ FUNCTION
‘Audi’: SOUND CONTROL
‘Auto’:AUTO-PLAY CONTROL
‘dxxx’: DMX512 CONTROL, xxx is DMX address
UP: DMX address up
DOWN: DMX address down
ENTER: PLEASE PRESS ENTER AFTER YOU CHANGE STATE,
Installation
1、Firstly, be sure that the using voltage is match with the voltage marked on the base
of the laser lighting ;
2、Installation should be made by professional technician. fix the laser lighting and
adjust the angle of the laser lighting to you need;
3、Please check whether the fan and the exhaust is blocked;
4、There is a hole for connection. when hang the laser lighting, be sure the cable can
undertake 10 times of the lighting weight;
5、The laser lighting should be fixed;
6、It is essential to be earthed well for the sake of safety.
-----------------2-------------------

DMX512
This laser light is controlled by the standard DMX. Please connect controlling panel
with the lighting as following
Before using the DMX512 controller, you should set the channel address in the
digital display.
One unit has 8 channels, so each unit must be assigns 8 channels at least. We may
assign 8 channels for one unit, then DMX address = 8*N+1, N=0, 1, 2, 3 ……
Example: One loop address=1, two loop address=9, three loop address=17, four loop
address=25 Loop Digital address
1 1
2 9
3 17
4 25
If we assign 9 channels for one unit, then DMX address=9*N+1, N=0, 1, 2, 3……
-----------------3-------------------

DMX Control Parameter Chart
Channel No DMX512 fig. Content
Channel 1
Control
mode
0~69 Laser off
70~139 Sound control
140-209 Auto play
210~255 DMX control
Channel 2 Pattern
Selection 0~129 Static patterns for manual
130--255 Dynamic Geometric patterns
Channel 3
Horizontal
move
0 No move
1~39 From left to right move
40-159 From right to left move
180-255 Right and left in-phase move
Channel 4
Vertical
move
0 No move
1-39 From up to down
40~159 From down to up
160~255 Up and down in-phase move
Channel 5 Rotation
direction 0--127 Counterclockwise rotation
128--255 Clockwise rotation
Channel 6 Rotation
speed
0--255 From slow to fast
Channel 7 Strobe 0--10 No strobe
11-255 Strobe from slow to fast
Channel 8 Color
selection 0-99 Red
100-199 Green
200-255 Red+ green
When the channel 2 is select to static pattern for
manual (0--129), the follow channel is valid.
-----------------4-------------------

Maintenance
•Please clean the lens regularly. Do not do it using the wet cloth or other chemical.
the clean times is depend on the using frequency and surrounding condition; it is
recommended that should be cleaned every 20 days;
•Please clean the lighting surface and engine outlet regularly.
•Be sure that there is no flammable or explosive subject nearby. The least distance
is 0.5 meters. at the same time, keep more than 15cm between the wall and laser
lighting;
Warning
•Power off before installation or maintenance;
•The danger class of this laser lighting is CLASS III B. it’s dangerous for
observing laser
•Keep at least 0.5 meters distance between the lighting and flammable
material;
-----------------5-------------------
