Microh LEDP64(K) User manual

1 of 2
MICROH - LEDP64(K)
Manual
This device is a lighting product which can create decorative effects. It is designed for club, stage
and other entertainment halls.
Specification:
1. Weight: 2.5kg
2. Size: 31X23X23 cm
3. Power Input: AC 120V 60Hz
4. Wattage: 30W
5. LEDS: ultra bright 10mm, 181PCS RGB (36 RED, 85 GREEN, 60 BLUE)
6. XLR: 3PIN female XLR socket and 3PIN male XLR socket
7. Built-in microphone
8. Led display
Operation:
1. Use the MODE button to choose required working mode, then use UP and DOWN to adjust the
relative reference date
A Color: LED display shows “C.L.X”, “X”= 0-7. Press UP or DOWN button to adjust “X”.
0---BLACK 1---RED 2---green 3---blue 4---purple 5---yellow 6---cyan
7---white
B Color Change: LED display shows “J. X X”, “X X”= 01-99 means the speed of color change.
Press UP or DOWN button to adjust the speed of color change.
C Color Fade: LED display shows “F.X.X”, “X X”= 01-99 means the speed of color fade,
press UP or DOWN button to adjust the speed of color fade.
D Auto Mode: LED display show “A - -“, it will auto run the color change and color fade.
E Sound mode: LED display shows “S.XX”, “XX”=00-31 means levels for sound sensitivity.
Press UP or DOWN button to adjust the levels of sound sensitivity.
F Slave mode: LED display shows “S.L.A.” the master fixture decides the running state of
current fixture the above A-E all have master function.

2 of 2
G DMX mode: LED display show “X X X”, X X X= 001-512, the current fixture covers 4 DMX
channels. The DMX value and function is as follows:
CHANNEL VALUE FUNCTION
000-189 DIMMER
190-250 FLASH
CH1 251-255 NO FUNCTION
CH2 000-255 RED
CH3 000-255 GREEN
CH4 000-255 BLUE
2. LED display ON/OFF: When the device is turned on, the LED display remains on by
pressing “MODE” button plus “UP” or press “MODE” button plus “OFF” the led display to turn
off after 20 seconds (in which no buttons are pressed).
