SAFETY WARNINGS
ROTAC WASTE CART TIPPER
Part Numbers: A010240
Model: LONG ARM
Installation, Service, and Use Manual

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 2of 10
26-18-1006 rev.- Model: LONG ARM

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 3of 10
26-18-1006 rev.- Model: LONG ARM
SAFETY
CAUTION:
➢Do not operate waste truck packing blade while the tipper is in the dump orraised position.
The packing blade may damage the waste cart tipper.
➢Do not cover the brake/safety/indicator lights on the vehicle with the mounting plate, the
tipper unit itself, or any other related hardware.
➢Safe working procedures must be followed at all times. Always wear correct safety gear.
➢Follow OSHA Lockout/Tagout procedures during all installation, repair, or maintenance.
➢Inspect operation of waste cart tipper daily before starting route.
➢Ensure all persons are clear of waste cart tipper before and during operation.
➢Never operate a damaged waste cart tipper.
➢Never reach into a waste container or place hands or arms in harm’s way during operation.
➢Never lift damaged carts with missing or broken parts.
➢Never lift an overloaded cart.
➢Never use waste cart tipper to lift items other than properly designated carts.
➢Never loosen any hydraulic fittings or hoses unless the system is off and depressurized.
➢Never weld on truck unless a ground is in place, the battery is disconnected, and no
flammable objects are present.
➢Do not remove the stop fasteners. They serve a functional purpose to limit the rotation of
the actuator and extend service life.
INSTALLATION PREPARATION
1.) Please read this manual completely and familiarize yourself with all of the necessary
procedures. Contact Micromatic LLC at [phone], ext. 3211, if there is a question.
2.) To install the waste cart tipper onto the truck to the installation dimensions stated in this
service manual requires an empty truck parked on a smooth and level surface.
3.) Waste cart tippers can weigh over 300 pounds. During installation, always use a hoist to
lift and secure the lifters into place and to prevent accidents.
4.) During installation, secure the waste cart tipper with a chain or suitable lifting strap to
prevent accidents.
5.) Reference 26-18-1001 for the waste tipper hydraulic tap-in kit user manual.
TWO YEAR LIMITED WARRANTY
➢Seller warrants that Buyer will receive good title to the products and that the
products received by initial purchaser will be free from defects in materials and
workmanship consistent with trade practice quality control for a period of two (2)
years from date of shipment, provided:
oThe product has been installed and used within defined specifications.
oNo repair or alteration has occurred other than by Seller’s personnel.
oNo misapplication or negligent use has transpired in the judgement of
Seller’s personnel.

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 4of 10
26-18-1006 rev.- Model: LONG ARM
➢THERE ARE NO OTHER WARRANTIES THAT EXTEND BEYOND THE
WARRANTY HEREIN CONTAINED and no statement, oral or written, inconsistent
with this warranty is binding on the Seller. No agent, employee, or representative
of the Seller has any authority to bind the Seller to any confirmation,
representation, or warranty concerning the equipment that is the subject of this
document beyond that specifically included in the written quotation. Extension of,
or amendment to, this warranty can be made only in writing by a duly authorized
officer of the Seller.
➢This warranty is made IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR
IMPLIED, including any warranty of MERCHANTABILITY or FITNESS FOR A
PARTICULAR PURPOSE.
➢Seller’s remedy for breach of any warranty shall be limited as defined below.
oSeller agrees to repair or replace, without cost, any part of the product
manufactured by the Seller that, for the warranty period as specified above,
may prove, upon Seller’s inspection, to be defective in material or
workmanship and not commercially acceptable.
oSeller shall have the option to inspect any parts claimed to be defective
either at Seller’s place of business or Buyer’s place of manufacture. No
return shall be accepted unless Seller has had an opportunity to inspect the
product or has expressly authorized the return.
oUnder no circumstances shall Seller be liable for consequential or incidental
damages resulting from any breach of warranty even though Seller may
have been advised of the possibility of such damages, nor will Seller’s
liability for breach of any warranty exceed the purchase price of the product
less the value of the equipment at time of acceptance.
oAny claim for breach of Seller’s warranty herein contained must be made in
writing, addressed to the Seller, and set forth in sufficient detail to permit
identification of the defect. Any claim for breach of warranty must be made
within twenty-four (24) months after breach of warranty. If not made within
said twenty-four (24) month period, it shall be conclusively deemed to have
been waived.
oThe remedies for breach of warranty herein contained shall be exclusive.

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 5of 10
26-18-1006 rev.- Model: LONG ARM
TIPPER SPECIFICATIONS Note: Product specifications subject to change without notice.
Tipper Part Numbers
A010240 (with Weld Plate)
Model Name
LONG ARM
Mounting Weld Plate Part Number
(Included with A010240)
A010233
Cart Compatibility
ANSI Z245.60 Type B-US Two-Bar Carts
Lift to bar dimension 14 1/2–15 1/4"
Tipper Bar Compatibility
YES
Cycle Time
6-8 second cycle (up and down)
Finish
Durable paint, High Visibility Color
Hydraulic Port Threads
9/16-18 UNF-2B SAE Straight Threads
Hydraulic Actuator Type
Rotary Vane
Hydraulic Flow Rate Required
3.7 –4.9 GPM
Recommended Pressure Setting
1,300 psi Minimum
Rated Maximum System Pressure
Recommended Pressure Setting
3,000 psi
2,200 psi
Hydraulic Displacement
38.40 in3
Rated Lifting Weight Capacity
400 lb Continuous use,
Dump Angle
50-56° (depending on arm position)
Mounting Height Recommended:
Capability:
Mount and adjust arms so tipper saddle
is 33”- 35” from ground
49”-61" from top of mounting plate to
ground
Ground Clearance
Mounting height dependent
(see diagrams)
Dry Weight
A010240 = 300 lbs
Design and Manufacture Location
USA, Berne Indiana
Warranty
2-year limited warranty
Note: Product specifications subject to change without notice.

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 6of 10
26-18-1006 rev.- Model: LONG ARM
TIPPER DIMENSIONS –SHOWN IN THREE (3) POSITIONS
➢Each waste cart manufacturer has slightly different dimensions for contact points.
➢When carrying out tipper installation onto truck, account for height changing when
the truck is in loaded and unloaded conditions. Expect approximately 1” of sag.
➢During installation, verify operation throughout full range of motion and ensure
waste cart is securely retained during the dump cycle and released when dropped
to the ground. If necessary, adjust the lifting saddle, arm position, and/or position
of tipper on the truck.
Recommend temporary mounting and performing a test
fit and can pick up before fully welding mounting plate
into place.
Note: Be sure and account for chassis sag when loaded.

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 7of 10
26-18-1006 rev.- Model: LONG ARM
INSTALLATION:
WELDING PLATE FOR MOUNTING
A010240 includes welding plate
NOTES:
➢It is recommended to temporarilytack the mounting weld plate into position enough
to support the weight of the tipper and then perform a trial pick up and dump cycle
to confirm operation is proper.
➢Welding plate mounting should be backed up by a rigid structure strong enough to
support the tipper and loading. It is okay for the plate to extend above truck sill.
oIf necessary, weld supplemental structure for additional plate support.
➢Stud threads require ½-13 UNC grade 8 nuts to mount tipper to weld plate.
oRecommended installation torque: 60 ft-lb with thread lock applied.
➢Proper mounting distance from ground required to ensure proper function.
➢WARNING: Never weld on truck unless a ground is in place, the battery is
disconnected, and no flammable objects are present.
➢WARNING: A flow control device MUST be used to control the flow of hydraulic
fluid which affects the speed of the actuator. Running without a flow control device
can be dangerous and lead to damage to the tipper and waste can.
oRecommended speed is a cycle of 6-8 seconds.
oMicromatic sells a flow control –see Service Parts section.
➢WARNING: The hydraulic plumbing MUST have a pressure relief valve installed
in the hydraulic circuit on the actuator pressure lines to protect the actuator from
damage from pressure spikes.

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 8of 10
26-18-1006 rev.- Model: LONG ARM
TIPPER MOUNTING OPTIONS
The standard tipper base mounting plate is equipped with one mounting pattern:
MAINTENANCE
Lubrication
➢Pivot joints are equipped with six (6) easy access grease zerk fittings.
➢Main pivot joints should be greased monthly to flush contaminates from pivot joint.
Inspection Prior to Each Use
➢Fasteners should be inspected to ensure all are in place and tight –See Torques below.
➢Stop bolts serve a functional purpose to limit the rotation of the actuator. Make sure they
are in place and do NOT remove them.
➢Inspect all welds for cracks and repair or replace as necessary.
➢Hydraulic oil and oil filter on the waste truck should be checked periodically and changed
according to the manufacturer-recommended intervals.

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 9of 10
26-18-1006 rev.- Model: LONG ARM
SERVICE PARTS KITS
(IF YOUR PARTS DIFFER FROM THOSE SHOWN, PLEASE CONTACT MICROMATIC LLC. CUSTOMER
SUPPORT AT [phone] EXT. 3211 FOR PROPER REVISION OF REPAIR MANUAL)
•SEAL KIT FOR ACTUATOR = 450687-K1
•HYDRAULIC FLOW CONTROL VALVE = 26-11-3562 (sold separately from tipper)
•ACTUATOR REPAIR MANUAL = REPAIR MANUAL –HS-1.5 THRU HS-015

Micromatic LLC RotacTippers.com
525 Berne St
Berne, IN 46711
1-260-589-2136 x3211
[e-mail]
Page 10 of 10
26-18-1006 rev.- Model: LONG ARM
➢Refer to repair procedure Repair Manual - HS-1.5 THRU HS-015 to carry out
maintenance on the 450687-S-B rotary actuator with seal kit 450687-K1. Please contact
Customer Service or go to http://www.rotactippers.com.
➢For the latest information and updates on this user manual and Rotac Tippers, please go
to http://www.rotactippers.com.
