Vestax PMC-05Pro User manual

(b) C.F. FINE CONTROL
PROFESSIONAL MIXING CONTROLLER
FUNCTIONS
The replacement crossfader unit for PMC-05ProD is
"CF-X".
"CF-05PRO","CF-PCV" cannot be substituted in this
mixer.
OWNER'S MANUAL
Vestax Corporation
1-18-6 Wakabayashi, Setagaya-ku, Tokyo 154-0023 Japan
Phone [phone] Fax [phone]
Web : www.vestax.jp
Vestax (Europe) Ltd.
Unit 5 Riverwey Industrial Park Alton Hampshire GU34 2QL England, U.K.
Phone [phone] Fax [phone]
Web : www.vestax.co.uk
Vestax Technical Center of America
8489 W. Third Street Ste. 1044 Los Angleles, CA 90048
Phone [phone] Fax [phone]
TOP PANEL
CURVE PATTERN SWITCH (a) selects the crossfader
curve pattern.
Setting the C.F. FINE CONTROL to minimum, the
crossfader curve is most sharp,moving the control
clockwise,towards max,gradually reduces the
sharpness of the curve (b).
Thank you for purchasing the VESTAX PMC-05ProD. Please read this owner's manual carefully before you start to
use in order to understand fully how it to operate your new mixer.
CONGRATULATIONS!
FEATURES
The new Vestax Digital Fader System consists of coils and a permanent magnet.There is no contact between
these parts.Therefore,neither the element or magnet gets degraded or damaged even after hard usage.
Unlike an optical type fader,the digital fader system does not get effected even by liquid spills or dusts.
Control of the fader curve by a complete digital signal system, enabling creation of sharp edges in the curve
pattern.
CAUTION!!
パーツ交換の際は 印のネジを
ゆるめないで下さい。
WHEN YOU CHANGE ANY PARTS,
DO NOT LOOSE THE SCREWS WITH
MARKING.
MAX
MIN
PGM 2PGM 1
REVERSE
NORMAL
PGM 1 PGM 2
MONITOR LEVEL
C.F. MONITOR
LINE1LINE2
PHONO1PHONO2
21
LEVEL LEVEL
0
1
2
3
4
5
6
7
8
9
10
0
1
2
3
4
5
6
7
8
9
10
+12dB-12dB
+12dB
-12dB
R
L
+12dB-12dB
+12dB
-12dB
RL L
+12dB-12dB
+12dB
-12dB
R
MAXMIN
LEVEL
EQ
HI
LO
PAN
MAIN MIC TRIM
EQ
HI
LO
BAL
PGM 1
C.F.REV
TRIM
LEVEL POWER
C.F. FINE
EQHI
LO
BAL
PGM 2 MASTER
PHONES
CURVE PATTERN
MAX
MIN
DIGITAL FADER CONTROL
1
2
34
MAXMIN MAXMIN MAXMIN
PROFESSIONAL MIXING CONTROLLER
(a) CURVE PATTERN SWITCH
All manuals and user guides at all-guides.com
all-guides.com

1
2
34
1
2
34
1
2
34
1
2
34
PRE-SET CURVE
SHAPE 1:
SHAPE 2:
SHAPE 3:
SHAPE 4:
C.F.POSITION
C.F.POSITION
C.F.POSITION
Using curve pattern switch,select the crossfader curve pattern from SHAPE1-4, to set the cross-
fader pattern.
As this curve shape is very sharp,it is
used for hard scratch play.
Setting C.F.FINE CONTROL to
minimum,the curve sharp is most
sharp.As the switch moves closer to
max,the curve sharpness reduces.
This curve shape is "A" type curve.
In this position,switching C.F. FINE
CONTROL from MIN to MAX, the
crossfader curve shape changes
from slow slope curve to sharp slope
by 8 steps.
This curve shape is rectangle wave type.Moving the crossfader from right to left or from
left to right,it performs like a "transformer scratch".Switching C.F. FINE CONTROL, the 8
patterns crossfader curve shape can be selected.It enables selection of the 8 patterns of
curve shape as fig 1- fig 8 below.
C.F. FINE CONTROL :MIN
C.F. FINE CONTROL :MIN
C.F. FINE CONTROL :MIN
C.F. FINE CONTROL :MAX
C.F. FINE CONTROL :MAX
C.F. FINE CONTROL :MAX
C.F.POSITION fig-3 fig-4fig-1
C.F. FINE CONTROL :MIN
fig-8
C.F. FINE CONTROL :MAX
fig-7fig-6fig-5
fig-2
