MICROMATIC JoeTap JT-NIM Quick start guide

NITROGEN
INFUSION MODULE
INSTALLATION, USE & MAINTENANCE GUIDE
JT-NIM
SAFETY FIRST!
READ INSTRUCTIONS COMPLETELY
Before getting started please read this
user manual and at all times follow
the important safety instructions.
v1.5
Pending
Certied by the
National Sanitation Foundation

2| NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE MICROMATIC.COM /[phone]
PART LIST OVERVIEW.....................................................................................3
INSTALLATION OVERVIEW .......................................................................... 4-5
ROUTINE MAINTENANCE & CLEANING....................................................... 5-6
WARRANTY INFORMATION .............................................................................7
TABLE OF CONTENTS

MICROMATIC.COM /[phone] NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE |3
2
3
4
5
6
7
8
9
16
17
15
18
19
20
21
22
23
14
13
25
26
24
1
10
11
12
PART LIST OVERVIEW
ITEM PART NUMBER DESCRIPTION
1 JESF-4 Stout Faucet, Polished Stainless Steel (Included w/ Tower)
2 4332 Coupling Nut (Included w/ Tower)
3 D6P3C Chrome Outside Flange (Included w/ Tower)
4 D7P Inside Tower Flange ABS (Included w/ Tower)
5 D8 Tower Shank Nut (Included w/ Tower)
6 D5N-ARF SpinStop™Shank, 304 Stainless Steel (Included w/ Tower)
7 105SL Clamp-Stepless for 1/4" GEN-X™ Tubing (Included w/ Tower)
8 548GENX 1/4" GEN-X™ Tubing (Included w/ Tower)
9PI201612S John Guest Fitting 3/8" O.D. to 1/2" O.D. (Included with JT-NIM)
10 01752322C Accumulator (Included with JT-NIM)
11 JT-NIM Nitrogen Infusfusion Module
12 548GENX 1/4" GEN-X™Tubing (Included with JT-NIM)
13 ADMF0606-200 Inline Filter/Strainer (Included with JT-NIM)
ITEM PART NUMBER DESCRIPTION
14 548GENX 1/4" GEN-X™Tubing (Included with JT-NIM)
15 105SL Clamp-Stepless for 1/4" GEN-X™ Tubing
16 HBF100L Corney Keg Ball Lock Liquid Connection (Black) (For use with Corney Keg)
17 HBF100G Corney Keg Ball Lock Gas Connection (Grey) (For use with Corney Keg)
18 7485SS Keg Coupler, D System, 304 Stainless Steel Probe (For use with Beverage Tank™)
19 759 Neoprene Coupling Washer (For use with Beverage Tank™)
20 526BS-304 1/4" Stainless Steel Tail Piece (For use with Beverage Tank™)
21 874 Coupling Hex Nut Chrome Plated Brass (for use with Beverage Tank™)
22 170SL Clamp Stepless for 5/16" Vinyl
23 550WDC 3/8" Braided Vinyl Gas Tubing (Included with JT-NIM)
24 550WDC 3/8" Braided Vinyl Gas Tubing (Included with JT-NIM)
25 170SL Clamp Stepless for 5/16" Vinyl Gas Hose
26 842N Gas Regulator High Pressure Nitrogen Primary

4| NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE MICROMATIC.COM /[phone]
NITROGEN INLET
50 PSI
PRODUCT OUTLET
(TO FAUCET)
PRODUCT INLET
(FROM KEG)
NITROGEN OUTLET
(TO KEG)
TUBING FROM DISPENSE
TOWER PUSHES INTO
JOHN GUEST FITTING
TUBE CONNECTS KEG TO THE
NITRO INFUSION MODULE
PRESSURE FROM TANK IS
SET TO 50 PSI
COUPLER / BALL LOCK FITTING
PRESSURE TO THE KEG IS
PRE-SET @10 PSI
ACCUMULATOR
DISSOLVED SOLIDS FILTER
• Mount Nitro Infusion Module vertically in a refrigerated area. Hose connections must be
on bottom side of Nitro Infusion Module.
• The Nitro Infusion Module is not suitable for installations with ow control faucets.
A constant ow rate is required to generate stable high quality nitrogen infusion.
• Attach nitrogen regulator to nitrogen tank making sure outbound shutoff is in
OFF position.
• Attach gas tube from nitrogen inlet on Nitrogen Infusion Module to the nitrogen
regulator output barb and clamp in place. Gas output shutoff valve must be in OFF
position. Adjust pressure on regulator by turning adjustment screw in. Adjust pressure
to 50 PSI.
• Attach gas tube from nitrogen outlet on Nitrogen Infusion Module to the coupler on
coffee keg and clamp in place. Attach coffee supply line from product outlet on the keg
coupler to the coffee inlet line from Nitro Infusion Module and clamp in place.
• Attach John Guest tting after accumulator to line from dispense tower.
• Ensure dispense faucet is in closed position. A nitro dispense faucet (part number
JESF-4 or 12543) with restrictor disc must be used for correct dispense.
• Engage coupler on coffee supply keg.
• Turn ON gas supply.
• Open faucet and pour coffee to purge system.
INSTALLATION OVERVIEW

MICROMATIC.COM /[phone] NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE |5
ROUTINE MAINTENANCE & CLEANING
DAILY
• Wipe down and clean all surfaces with warm soapy water (no chlorinated cleaners).
– Refrigerated product storage area
• Exterior surfaces of the stout faucet nozzles remove and soak in approved sanitizer/
cleaner or carbonated water.
• Remove and rinse inlet lter/dissolved solids lter.
USE PROTECTIVE GLOVES
AND EYE PROTECTION
EVERY TWO WEEKS
IF USING BEVERAGE TANK™
MATERIALS
• Micro Matic Liquid Coffee Line Cleaner (MM-C128)
• Rubber gloves
• Eye protection
• Additional Beverage Tank™recommended
METHOD
1. Disconnect the keg coupler from product keg.
2. Fill cleaning vessel with warm (80° - 95° F) tap water (2 gal. min.). It is not
recommended that a canister used to dispense coffee be used for cleaning. It is
recommended to use a separate can designated for cleaning and rinsing.
3. Place an empty bucket under the faucet.
4. Engage the coupler on the water lled cleaning vessel. Open the faucet until the line
has been thoroughly cleared of product and clear water ows out of the faucet. Run
entire two gallons of water through dispensing system.
5. Close the faucet.
6. Vent pressure from cleaning vessel by pulling safety vent pull ring.
7. Open pressurized vessel, empty any water remaining in vessel, add applicable
amount of Micro Matic Coffee Line Cleaner, JOETAP®NIM requires 10 ozs.
DO NOT DILUTE!
8. Place an empty bucket under the faucet.
9. Re-connect keg coupler and pressurize container. Open the faucet until the line has
been lled with chemical. Chemical is light blue in color and will pour from the faucet.
10. Close the faucet and allow chemical to soak for 15 minutes.
11. Disconnect keg coupler, vent pressurized vessel. Open vessel and rinse out any
remaining chemicals. Rell with fresh water.
12. Re-connect keg coupler and pressurize container. Open faucet and ush until
chemical is completely ushed from line.
13. Rinse and attach coupler to product keg. Allow 12 ozs of coffee product to be ushed
through the line, discard.
14. Rinse all cleaning equipment and ttings thoroughly before storing

6| NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE MICROMATIC.COM /[phone]
USE PROTECTIVE GLOVES
AND EYE PROTECTION EVERY TWO WEEKS
IF USING CORNY KEGS WITH BALL LOCK FITTINGS
MATERIALS
• Micro Matic Liquid Coffee Line Cleaner (MM-C128)
• Rubber gloves
• Eye protection
• Additional Corny Keg (canister) recommended
METHOD
1. Disconnect the liquid and gas ball lock ttings from corny keg.
2. Fill cleaning vessel with warm (80° - 95° F) tap water (2 gal. min.). It is not recom-
mended that a canister used to dispense coffee be used for cleaning. It is recom-
mended to use a separate can designated for cleaning and rinsing.
3. Place an empty bucket under the faucet.
4. Connect each ball lock tting to its appropriate tting. Open the faucet until the line
has been thoroughly cleared of product and clear water ows out of the faucet. Run
entire two gallons through dispensing system.
5. Close the faucet.
6. Vent pressure from cleaning vessel by pulling safety vent pull ring.
7. Open pressurized vessel, empty any water remaining in vessel, add applicable
amount of Micro Matic Coffee Line Cleaner, JOETAP®NIM requires 10 ozs.
DO NOT DILUTE!
8. Place an empty bucket under the faucet.
9. Re-connect ball lock ttings and pressurize container. Open the faucet until the
line has been lled with chemical. Chemical is light blue in color and will pour from
the faucet.
10. Close the faucet and allow chemical to soak for 15 minutes.
11. Disconnect ball lock ttings, vent pressurized vessel. Open vessel and rinse out any
remaining chemicals. Rell with fresh water.
12. Re-connect ball lock ttings and pressurize container. Open faucet and ush until
chemical is completely ushed from line.
13. Rinse and attach ball lock ttings to product corny keg. Allow 12 ozs of coffee product
to be ushed through the line, discard.
14. Rinse all cleaning equipment and ttings thoroughly before storing.
ROUTINE MAINTENANCE & CLEANING

MICROMATIC.COM /[phone] NITROGEN INFUSION MODULE INSTALLATION, USE & MAINTENANCE GUIDE |7
STANDARD TERMS & CONDITIONS FOR USE OF PRODUCT; LIMITED WARRANTY; INDEMNIFICATION
By opening the packaging containing this product or by using such product in any manner, you are consenting and agreeing to be bound by the
following terms and conditions. You are also agreeing that the following terms and conditions constitute a legally valid and binding contract that is
enforceable against you. If you do not agree to all of the terms and conditions set forth below, you must promptly return the product for a full refund
prior to using the product in any manner.
ALL SALES ARE SUBJECT TO AND EXPRESSLY CONDITIONED UPON THE TERMS AND CONDITIONS CONTAINED HEREIN, AND UPON PURCHASER’S
ASSENT THERETO. NO VARIATION OF THESE TERMS AND CONDITIONS SHALL BE BINDING UPON MICRO MATIC USA, INC. UNLESS AGREED TO IN
WRITING AND SIGNED BY AN AUTHORIZED REPRESENTATIVE OF MICRO MATIC. Purchaser, by accepting the product shall be deemed to have
assented to the terms and conditions set forth herein, notwithstanding any terms contained in any prior or later communications from purchaser
and whether or not Micro Matic shall specically or expressly object to any such terms.
To the maximum extent permitted by law, with respect to Product proved to Micro Matic’s satisfaction to be defective or nonconforming,
Purchaser’s exclusive remedy and Micro Matic’s maximum liability hereunder in any case is expressly limited to, at Micro Matic’s election, (i)
the repair or replacement of the Product without charge or refund of the purchase price, upon return of the Product in accordance with Micro
Matic’s instructions above, or (ii) the repayment of, or crediting the Purchaser with, an amount equal to the purchase price of the Product. To
the maximum extent permitted by law, Micro Matic is not responsible for, and Purchaser releases Micro Matic from direct, special, punitive,
incidental or consequential damages of any kind arising from any use or failure of, or related in any way to the Product, or based upon any
contract, tort, strict liability or other legal or equitable theory, including without limitation loss of beverage, loss of gas, loss of sales, loss of
work, downtime, or for any other labor or any other expense, damage or loss including personal injury or property damage, unless such personal
injury or property damage is caused by Micro Matic’s gross negligence, even if Micro Matic has been advised of the possibility of such damage
or loss. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may
not apply to you.
USE OF PRODUCT
Purchaser agrees that no rights or licenses under Micro Matic’s patents shall be implied from the sale of the Product, and Purchaser does not
receive any right under Micro Matic’s patent rights hereunder.
PURCHASER HEREBY GRANTS TO MICRO MATIC A NONEXCLUSIVE, WORLDWIDE, UNRESTRICTED, ROYALTY-FREE, FULLY PAID-UP LICENSE, WITH THE
RIGHT TO GRANT AND AUTHORIZE SUB-LICENSES, UNDER ANY AND ALL PATENT RIGHTS IN INVENTIONS COMPRISING MODIFICATIONS, EXTENSIONS,
OR ENHANCEMENTS MADE BY PURCHASER TO THE PRODUCT OR TO THE MANUFACTURE OR USE OF THE PRODUCT (“IMPROVEMENT PATENTS”),
TO MAKE, HAVE MADE, USE, IMPORT, OFFER FOR SALE OR SELL ANY AND ALL PRODUCT; EXPLOIT ANY AND ALL METHODS OR PROCESSES; AND
OTHERWISE EXPLOIT IMPROVEMENT PATENTS FOR ALL PURPOSES.
Purchaser acknowledges that, unless otherwise indicated on the Product label, the Product has not received approval from any federal, state
or local regulatory agencies. Purchaser has the responsibility and hereby expressly assumes the risk to learn the hazards involved in using
the Product. Purchaser also has the duty to warn Purchaser’s customers, employees, agents, assigns, ofcers, successors and any auxiliary
or third party personnel of any and all risks involved in using or handling the Product. Purchaser agrees to comply with instructions furnished
by Micro Matic relating to the use of the Product and expressly represents and warrants to Micro Matic that Purchaser will use the Product in
accordance with the Product label and the instructions in this manual and in accordance with the practices of a reasonable person and all laws
and regulations now and hereinafter enacted; and Purchaser shall not misuse the Product in any manner. Purchaser shall not reverse engineer,
decompile, disassemble or modify the Product. Purchaser acknowledges that Micro Matic retains ownership or license rights of all patents,
trademarks, trade secrets and other proprietary rights relating to or residing in the Product and Purchaser receives no rights to such intellectual
property rights by virtue of its purchase of Product other than as expressly set forth herein. Purchaser shall have no right to use any trademarks
owned or licensed to Micro Matic without the express written permission of Micro Matic.
RELEASE AND INDEMNITY
By operating this Product, the Purchaser hereby takes full responsibility for any risks associated with its use. Purchaser agrees to fully release,
discharge, disclaim and renounce any and all claims, demands, actions, causes of action and/or suits in law or equity, now existing or hereafter
arising, whether known or unknown, against Micro Matic, and its ofcers, directors, employees, agents, successors and assigns (collectively
the “Released Parties”), with respect to the use of the Product. Purchaser agrees to fully protect, defend, and indemnify, hold harmless the
Released Parties from and against all liability, losses, damages, costs, or expenses of any nature, including without limitation, reasonable
attorney’s fees, which they may at any time suffer, incur, or be required to pay resulting from or arising out of (i) any ordinary hazards that may
be present in the normal operation of the Product; (ii) any claim of injury, illness, or death resulting from consuming beverages dispensed by
the Product, whether or not prepared as specied by the Product; (iii) any hazards from the use or misuse of the Product; (iv) any claim that
the Product is defective, negligently designed or manufactured in any manner, or otherwise determined to be the cause of injury or death to
persons, or damage to property, or both; (v) any claim that the Product or the manufacture, sale, or labeling of the Product fails to comply
with any governmental requirement, or the labeling on the Product, or on or within the packaging for the Product (including any instructions or
warnings), is inadequate in any manner; (vi) any claim that the Product should have been recalled pursuant to any governmental requirement;
(vii) Micro Matic’s negligence or willful misconduct in supplying the Product; or (viii) any injuries, losses, or damages (compensatory, direct,
incidental, consequential or otherwise) of any kind arising in connection with or as a result of possession or use of the Product. Purchaser shall
fully cooperate with the Released Parties in the investigation and determination of the cause of any accident involving the Product which results
in personal injury or property damage and shall make available to the Released Parties all statements, reports, recordings and tests made by
Purchaser or made available to Purchaser by others. If you do not consent to this indemnication, you must promptly return the Product for a
full refund prior to using the Product in any manner.
WARRANTY INFORMATION

01828-D0518 ©2018 Micro Matic USA, Inc. All Rights Reserved. Micro Matic reserves the right to change specifications without notice.
