Safety Information
Important Safety Information
This injector should be connected to PoE networks only, without routing to outside plant.
The PD-9001GC Ethernet and Terminal ports are shielded RJ45 data sockets. They can’t be used as Plain
Old Telephone Service (POTS) sockets. Only RJ45 data connectors can be connected to these sockets.
The PD-9001GC Ethernet and Terminal interfaces are qualified as Safety Extra-LowVoltage (SELV)
circuits according to IEC 60950-1. These interfaces can only be connected to SELV interfaces on other
equipment.
The power cord must be a three-conductor type (two current carrying conductors; one ground conductor)
terminated on one end by an IEC 60320 appliance coupler (for connection to the PoE Media Converter),
and on the other end by a plug containing a ground (earth) contact.
The power cord must be rated for a minimum of 250Vac RMS operation, with aminimum rated current
capacity of 5 amps (or a minimum wire gauge of 18 AWG (0.823mm2).
WARNINGS!
This Midspan should only be connectedto an IP device with which it was bought. Using PD-9001GC with
other IP devices can cause damage to IP device.
Follow basic electricity safety measures whenever connecting PD-9001GC to its power source.
A voltage mismatch can cause equipment damage and may pose a fire hazard. If voltage indicated on the
label is different from the power outlet voltage, do not connect PD-9001GC to this power outlet.
Do not use cross-over cable between the PD-9001GC output port and the load device.
Preliminary Steps
Read installation instructions before connecting the PD-9001GC to its power source.
There is no “on/off” switch; simply plug the PD-9001GC into an AC power source.
Verify that a PoE Ready Ethernet-compatible device is connected.
Do not cover PD-9001GC or block airflow to the unit with any foreign objects. Keep PD-9001GC away from
excessive heat and humidity and free from vibration and dust.
Ensure cable length from Ethernet network source to terminal does not exceed 100 meters (330 feet). This
Midspan is not a repeater and does not amplify Ethernet data signal.
Use a splitter if desired; ensure splitter is connected close to the terminal and not on the PD-9001GC!
PD-9001GC EMC Compliance:
FCC Part 15 class B and EN55032 class B
EN55024
VCCI
PD-9001GC Safety Compliance:
UL/cUL per 60950-1
GS Mark
