Microtech e-tab style Instruction manual

rev. 2.0
QUICK USER GUIDE

INDEX
Keys Function in the user interface
Acknowledgements 4
Start/ power off 10
Lock screen 11
Language settings 12
Monitoring and battery charge
Computer connectivity and data transfer
13
Menu App Launcher 15
System settings 20
Package contents 5
Overview 6
Warnings 7
Keys description 8
Wireless & Networking
Lock screen with smile
14

23
Bluetooth settings
24
Account
25
Apps
26
Localization and Security
27
Internet
Language and input
Date and time
28
Technical datasheet
Account management
Backup and recovery
Device info
Multi Window
Display settings
Connecting to a network 21
Sound settings 22
3G settings

4
Thank you for purchasing e-tab.
Congratulations on the purchase of our e-tab-Style.
It is a modern and powerful tablet with quad-core SoC
and ARM Cortex A17 architecture, 2 GB 64-bit DDR3
RAM and a storage capacity of 16 GB.
The tablet comes with a screen protected by a high-
strength tempered glass, a particularly strong back
cover with anti-slip grip and an extremely compact
polycarbonate frame.
Microtech has developed this product with passion,
commitment and attention to detail. Microtech wishes you
to be able to make full use and be satised with it.
Thank you for choosing a product designed in Italy.
Microtech team
ACNOWLEDGMENTS
Trademark protection
e-tab Style and e-tab Style logo are registered trademarks
of Microtech.
All trademarks and copyrights belong to their rightful
owners.

Microtech S.r.l e-tab Style 5
PACKAGE CONTENT
e-tab Style
AC network adapter
USB-OTG adapter
User manual
Stereo earphones
USB cable for PC
connection

6
OVERVIEW
248 mm
173 mm
10 mm

Microtech S.r.l e-tab Style 7
WARNINGS
This user manual contains important safety instructions
and information for the proper use of the device.
Please follow the instructions found in this manual
carefully.
If you wish to purchase additional accessories you can
nd them on our website www.e-tab.it
To prevent hearing damage, do not listen to high volume
audio for a long time.
Never abruptly disconnect the tablet from the PC while it is
exchanging data. It could cause errors and malfunctions.
Avoid shocks and do not drop the device as it may be
damaged.
Do not use alcohol, thinner or gasoline to clean the
display. Only use a dry cloth.
Stand-by duration can vary according to different
environmental inuences.

8
KEYS DESCRIPTION
12 4
5
7
3
9
10
68
13
12
11
14

Microtech S.r.l e-tab Style 9
1. ESC Press to return to the previous screen
application.
Press and hold to start e-tab. Touch for short
periods to lock or unlock the screen.
2. Power and
lock
Used to charge the battery via the included power
supply.
3-Jack
charge
To connect the TV via HDMI cable (optional).
4-HDMI
Microphone
5-MIC
Used for data trafc to and from your computer (e.g.,
music, videos, photos).
6- USB-data
Used for USB OTG, mouse, keyboard, USB stick with
special converter.
7-USB HOST
Used to connect headphones.
8-Headphone
Jack
Insert here your Micro SD (maximum capacity 32 GB).
9-TF card slot
2 MPixels.
10- Front
camera
It improves the brightness of the screen depending on the
environmental conditions.
11- Light sensor
8Mpixels with LED ash and autofocus
12- Rear
camera
AAC Speaker
13- Left speaker
AAC Speaker
14- Right speaker

10
To start your e-Tab Style press and hold the power button.
Once the screen is active, move your nger on the lock
icon next to the circle that will appear on the
screen to unlock it.
START/POWER OFF
To turn off the tablet press and hold the start button until
you see a window that asks you if you want to turn it off.
To lock the tablet switch in stand-by mode, press and
immediately release the power button.

Microtech S.r.l e-tab Style 11
If the device is not used for the specied time period or
the power button is pressed briey, the screen turns off
and display lock is activated.
Pressing for a short time the power button will reactivate
the screen.
LOCK SCREEN
LOCK SCREEN WITH SMILE
You can unlock the device automatically using face
recognition.
To enable this feature you need to configure the system
to recognize your face and associate a sequence or a pin.

12
LANGUAGE SETTINGS
The device is delivered in Italian.
To change the language settings, follow the instructions
below:
Press on the menu symbol in the lower part
of the device.
Select Settings.
Scroll down the left side until the end of the
list.
Select Language input.
On the right side, select Language.
Choose your preferred language.
Press the Home button to go back.

Microtech S.r.l e-tab Style 13
The device has a 2.0 High-Speed USB.
After connecting the device to your computer, the
message Preparing SD card will appear in the upper left
corner.
At this point, it will be necessary locate the device
connected and explore the information with a touch of ES
File Explorer.
When using the device for data transfer, you cannot
access the MicroSD card from your PC!
CONNECTION TO THE COMPUTER AND DATA
TRANSFER
The recharge symbol in the lower right taskbar indicates
the charging status of the battery.
If the charge is low, the device automatically turns off.
If you see that the charge is low, use the power supply or
connect the device to a computer via USB.
It takes about 5 hours to charge the device completely.
MONITORING AND BATTERY CHARGE

14
KEYS FUNCTION IN USER INTERFACE
Back key
You return to the previous screen from any
program.
Home key
It takes you back to the home screen.
Windows key
It lets you visualize the windows of previous
panels.
Microphone key
Press to launch Voice Search.
A window showing the installed apps.
Press to launch Google Search.
A small panel showing the status of the
network, the system clock and the battery
It decreases the volume.
It increases the volume.

Microtech S.r.l e-tab Style 15
MENÚ APP LAUNCHER
Email management program.
Email management program with a Google
Account.
Internet Browser
Android program allowing the display of web
pages.
Program that allows you to install applications
not available in the Android Market.
Apk
Program allowing the installation of Android
applications. Most of them are free.
Play Store
A files and applications manager that can be
interfaced with the main cloud services, FTP
and Samba servers, Windows and Linux
operating systems and OS X.
ES File Explorer
Both front and rear cameras
Camera
E-mail
G-mail

16
Pocket calculator
Time display and alarm settings.
Changes in the basic settings.
Dictation function
Application that allows you to play videos in
4K / 2160P (Quad HD).
Management and display of images and
video.
It can also be synchronized with the albums
on Picasa Web.
Android program for the management of
appointments that can be automatically
synchronized with a Google account.
Calendar
Photos
4K Video
Sounds Recorder
Settings
Time

Microtech S.r.l e-tab Style 17
Google translator
It is an automatic translation service provided
by Google Inc. to translate a section of text
or an entire web page into another language.
Google docs
It is an application that allows you to create
documents with clever editing and style
tools that help you to easily format text and
paragraphs.
Google Presentations
You can make presentations, with a variety of
topics, thousands of fonts, embedded videos,
animations and more.
Google sheets
Word processing and worksheets application
Google ChromeCast
ChromeCast is a multimedia streaming
device.

18
Google Drive
It is a web service of online storage and
synchronization, which allows file hosting,
file sharing and collaborative editing of
documents.
Google Cloud Print
Google Cloud Print is a new technology that
connects compatible printers to the web.
Google Keep
It is a tool for taking notes, available on the
Play Store for Android devices and on the
Chrome Store for Google Chrome.
Google Play Newsstand
It is a virtual newsstand where you can
choose on payment and free magazine from
all sectors placed in special shelves and
divided by category.
Google Keyboard
Google keyboard makes text input easy and
intelligent. You can scroll your finger across
the letters to activate gestural typing or create
notes with voice typing.

Microtech S.r.l e-tab Style 19
Adobe Reader
Program to visualize PDF documents.
Hangout
Instant messaging and VoIP software
developed by Google.
Youtube
Platform that allows sharing and watching
videos.
Google Play Music
Virtual store where you can listen and buy
music.
Google Earth
It is an application showing three-dimensional
graphics and aerial photographs of the Earth.
Google Play Books
Service that allows you to read books and
access Google’s online store.

20
Touch the setup icon to open the system settings menu:
The device will automatically search for available WLAN.
SYSTEM SETTINGS
WIRELESS AND NETWORKS
Tap the Wi-Fi key to switch to the ON position.
WLAN Settings: Select your network here.
You may need to enter a WLAN password.
