MicroTouch OF-100P-A1 User manual

OF-100P-A1
Open Frame Touch Monitor
User Manual

1
About This Document
No part of this publication may be reproduced, transmitted, transcribed, stored in a
retrieval system, or translated into any language or computer language, in any form or
by any means, including, but not limited to, electronic, magnetic, optical, chemical,
manual, or otherwise without prior written permission of MicroTouchTM a TES Company.
The information in this document is subject to change without notice. MicroTouchTM a
TES Company makes no representations or warranties with respect to the contents
herein, and specifically disclaims any implied warranties of merchantability or fitness for
a particular purpose. MicroTouchTM a TES Company reserves the right to revise this
publication and to make changes from time to time in the content hereof without
obligation of MicroTouchTM a TES Company to notify any person of such revisions or
changes. Windows is a registered trademark of Microsoft, Inc. Other brand or product
names are trademarks of their respective holders.

2
FCC/ IC Statement
This device complies with Part 15 of the FCC Rules and Canadian ICES-003/NMB-003
regulation. Operation is subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) This device must accept any interference received,
including interference that may cause undesired operation.
Warning:
This device generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the manufacturer’s instruction manual, may cause harmful
interference with radio communications. Operation of this equipment in a residential area
is likely to cause harmful interference, in which case you will be required to correct the
interference at your own expense.

3
Usage Notice
Precautions
Please follow all warnings, precautions and maintenance as recommended in this user’s
manual to maximize the life of your unit.
Do ：
▪Turn off the product before cleaning.
▪Use a soft cloth moistened with mild detergent to clean the product housing.
▪Use only the qualified power adapter that comes with your device.
▪Disconnect the power plug from AC outlet if the product is not going to be used for an
extended period of time.
Don’t ：
▪Do not use abrasive cleaners, waxes or solvents for your cleaning.
▪Do not operate the product under the following conditions:
- Extremely hot, cold or humid environment.
- Areas susceptible to excessive dust and dirt.
- Near any appliance generating a strong magnetic field.
! Warning - To prevent the risk of fire or shock hazards, and do not
expose the product to moisture.
! Warning - Please do not open or disassemble the product as this may
cause electric shock.
! Warning - Power cord shall be connected to a socket-outlet with
earthing connection.
! Warning - The cable cover cannot be removed under normal use
conditions.
! Warning - Stability Hazard. The touch monitor may fall, causing
serious personal injury or death. To prevent injury, this
touch monitor must be securely attached to the wall in
accordance with the installation instructions.

4
Avis d’utilisation
Précautions
Veuillez suivre toutes les mises en garde, précautions et entretiens recommandés dans
ce manuel d’utilisation pour maximiser la durée de vie de votre unité.
À faire :
▪Éteindre l’appareil avant de le nettoyer.
▪Utiliser un chiffon humidifié par une solution savonneuse pour nettoyer le boîtier du
produit.
▪Utiliser uniquement l’adaptateur d’alimentation prescrit pour votre appareil.
▪Débrancher l’appareil lorsqu’il n’est pas utilisé pendant une période prolongée.
À éviter :
▪Ne pas utiliser de nettoyants abrasifs, de cires ou de solvants pour le nettoyage
▪Ne jamais utiliser l’appareil dans les conditions suivantes :
–des conditions environnementales extrêmes (chaud, froid ou humidité)
–des endroits remplis de poussières et de saletés.
–à proximité d’appareils produisant un fort champ magnétique.
! Mise en garde —Pour prévenir les risques d’incendie ou
d’électrocution, ne pas exposer le produit à l’humidité.
! Mise en garde —Prière de ne pas ouvrir ou démonter le produit, car
cela pourrait entraîner l’électrocution.
! Mise en garde –Le cordon d’alimentation doit être branché à une
prise pourvue d’une mise à la terre.
! Mise en garde –La gaine du câble ne doit pas être retirée en
conditions normales d’utilisation.
! Mise en garde —Risque de renversement. Le moniteur tactile peut se
renverser et causer de graves blessures corporelles, voire la mort.
Pour prévenir les blessures, ce moniteur tactile doit être solidement
fixé au mur selon les instructions d’installation.

5
TableofContents
Chapter 1........................................................................................................................6
1.1 Overview....................................................................................................................7
1.2 Feature ......................................................................................................................7
1.3 Specifications.............................................................................................................7
1.4 Block Diagram............................................................................................................8
1.5 Interface Connectors..................................................................................................9
1.5.1 Power Connector ...............................................................................................9
1.5.2 Video Signal Connector .....................................................................................9
1.6 Package Overview...................................................................................................11
Chapter 2......................................................................................................................14
2.1 About VESA Mount................................................................................................155
2.2 About Wall Mount...................................................................................................166
2.2.1 Landscape .....................................................................................................166
2.2.2 Portrait ...........................................................................................................177
2.2.3 Face Up .........................................................................................................188
2.3 On-Screen Display.................................................................................................199
2.3.1 OSD Function Description................................................................................21
2.3.2 Timing Table Chart...........................................................................................22
2.3.3 EDID Data........................................................................................................22
2.4 Dimension..............................................................................................................233
2.4.1 Front View......................................................................................................233
2.4.2 Side View.......................................................................................................233
2.4.3 Rear View ......................................................................................................244
Appendix ....................................................................................................................255

6
Chapter 1
Product Introduction

7
1.1 Overview
The OF-100P-A1 series is a 10” touchscreen monitor that builds to withstand commercial
grade open frame monitor, with stylish thin cable management bracket and versatile
design OF-100P-A1 is an exceptional choice for applications for all business sectors and
well suited for point-of-sales, point-of-information, point-of-service and interactive signage.
1.2 Feature
▪Cable management bracket design for easy organize cable.
1.3 Specifications
LCD Touch Panel
Size
10” TFT LCD
Brightness
500 cd/m2(Non-touch screen)
425 cd/m2 (P-CAP)
Number of Pixels
1280(H) x 800(V)
Touch Type
P-CAP/ 10 points
USB Standard
USB-IF specification version 1.1 Full Speed Compliable
Environment
Compliance
IPX0
Operating Temperature
0C ~ 50C
Storage Temperature
-20C ~ 60C
Operating Humidity
20% ~ 80% RH, non-condensing
Mounting
VESA 100 mm x 100 mm
Dimension (W x H x D)
260.67mm x 183.37mm x 39.4 mm
Net Weight
1.4 kg
Gross Weight
2.4 kg

8
1.4 Block Diagram
12V
Standard 1.1
Refer to 1.5.2

9
1.5 Interface Connectors
1.5.1 Power Connector
The AC/DC converter shall have an IEC320 type male power receptacle for
connection to AC mains power. The power cord, exact type to be supplied in the
appropriate Option Kit, shall be length of 1.8 0.05 meters, and PC99 compliant.
1.5.2 Video Signal Connector
The video signal input via D-type 15-pin female connector.
Connector Pin Assignment:
Pin
Signal
1
Red video signal input
2
Green video signal input
3
Blue video signal input
4
NC
5
DDC ground for the VESA DDC2B function
6
Analog signal ground for the red video
7
Analog signal ground for the Green video
8
Analog signal ground for the blue video
9
+ 5V: Input from host system for the VESA DDC2B function
10
Signal ground
11
NC
12
SDA signal input for the VESA DDC2B function
13
Horizontal signal input from host system
14
Vertical signal input from host system
15
SCL signal input for the VESA DDC2B function

10
Pin
Signal
Pin
Signal
1
ML_Lane 0(p) Data0 +
11
Signal ground
2
Signal ground
12
ML_Lane 3(n) Data3 -
3
ML_Lane 0(n) Data0 -
13
Signal ground
4
ML_Lane 1(p) Data1 +
14
Signal ground
5
Signal ground
15
AUX_CH(p) AUX + Signal for
Auxiliary Channel
6
ML_Lane 1(n) Data1 -
16
Signal ground
7
ML_Lane 2(p) Data2 +
17
AUX_CH(n) AUX - Signal for
Auxiliary Channel
8
Signal ground
18
Hot Plug
9
ML_Lane 2(n) Data 2 -
19
DP_PWR Return
10
ML_Lane 3(p) Data3 +
20
DP_PWR
Pin
Signal
Pin
Signal
1
TMDS Data2+
11
TMDS Clock Shield
2
TMDS Data2 Shield
12
TMDS Clock–
3
TMDS Data2–
13
CEC
4
TMDS Data1+
14
Reserved (N.C. on device)
5
TMDS Data1 Shield
15
SCL
6
TMDS Data1–
16
SDA
7
TMDS Data0+
17
DDC/CEC Ground
8
TMDS Data0 Shield
18
+5V Power
9
TMDS Data0–
19
Hot Plug Detect
10
TMDS Clock+

11
1.5.3 Signal Connector
USB Connector (Plug)
Pin
Description
1
VCC
Supply Voltage
2
D-
Ground Connection
3
D+
USB Signal
4
GND
USB Signal

12
1.6 Package Overview
LCD Display
Power Cord
DC Power Supply
OSD Key pad
DP cable
VGA cable
USB cable (A to B)
Brackets
Screw

13
! Warming!
This product is intended to be supplied by a Listed Power Adapter or DC power
source, rated 12Vdc, 1.0A minimum, Tma = 50 degree C minimum, and the
altitude of operation = 3048m minimum. If it needs further assistance with
purchasing the power source, please contact to MicroTouch for further
information.
! Mise en garde!
Cet appareil est conçu avec une alimentation de courant CA, d’une tension nominale de
12Vdc, 1.0A minimum, Tma = 50 degrés C minimum et l’altitude de l’utilisation = 3048 m
minimum. Pour d’autres conseils pour l’installation de la source d’alimentation,
communiquer avec MicroTouch pour de plus amples renseignements.

14
Chapter 2
Product Installation

15
2.1 About VESA Mount
The OF-100P-A1 series conform to the “VESA Flat Display Mounting Interface
Standard”which defines a physical mounting interface for touch monitor and
corresponding with the standards of touch monitor mounting devices. The VESA
mount is located on the back of this unit.
VESA Mount
! Warming!
Please select the MicroTouch original screws!
The distance between the back cover surface and the bottom of the screw hole
is 8 mm. Please use four M4 screws diameter with 8-10mm proper length to
mount your monitor.
Note: The mounting stand must be able to support at least 7.67 lbs (3.48 Kg).
! Mise en garde!
Sélectionner les vis d’origine de MicroTouch!
La distance entre la surface du couvercle arrière et le bas de l’orifice de la vis est
de 8 mm. Utiliser les vis M4 de diamètre pour le montage de votre moniteur.
Remarque : Le support de montage doit pouvoir supporter un poids d’au moins
7.67 lb (3,48kg).

16
2.2 About Wall Mount
The OF-100P-A1 series support wall mount and this monitor can be mounted to the
wooden or concrete wall with 8xM4 screws diameter with 6mm length and two
bracket set on the opposites.
2.2.1 Landscape
Depending on your mounting scheme, alternately, you may use the side brackets to
mount your displays onto your wall or device.
Find a suitable location for attaching side brackets.
A. The left and right sides
B. The Top and bottom sides
! Warming!
This apparatus is intended to be supported by a Listed Wall Mount Bracket” or
the equivalent.
! Mise en garde!
Cet appareil est conçu pour être supporté par un support de fixation mural
répertorié ”ou l’équivalent.

17
2.2.2 Portrait
A. The left and right sides
B. The Top and bottom sides

18
2.2.3 Face Up
Step1: Attach Bracket 1 to Assembly OF-100P-A1 with included screws.
Step2: Attach Bracket 2 on customer’s cabinet with included screws
Step3: Attach Step1 to Step2 with included screws.

19
2.3 On-Screen Display
The OF-100P-A1 series provide RJ45 port for connecting with OSD remote key. And
the following is OSD key function table:
OSD Key
Menu off status
Menu on status
Menu appear
Menu disappear/ return to main item
▲
Brightness
Main item select up/ Adjust up
▼
Contrast
Main item select down/ Adjust down

Enter/Select sub-item function
Power On/Off
1. Press the “MENU” button to pop up the “on-screen menu” and press “Up” or “Down” button to
select among the five functions in the main menu.
2. Choose the adjustment items by pressing the “Enter” button.
3. Adjust the value of the adjustment items by pressing the “Up” or “Down” button.
4. With the OSD menu on screen, press “Menu” button to return main menu or exit OSD.
5. The OSD menu will automatically close, if you have left it idle for a pre-set time.
6. To Lock the OSD / Power menu buttons, please follow the instructions below.
(Please note: the monitor has to be turned ON with a valid signal pre-set)
a. Press “Menu” key, the OSD menu will pops upon display.
b. Press and hold the “Menu” key again with the OSD menu on the screen, the OSD menu
will disappear. Then press the "Power" key 1 time while the menu key is still being
pressed. The “Lock/Unlock” menu will appear for 3 seconds.
