Microwave networks CM7 User manual

CM7/8
100Base-T
Digital Microwave Radio
System User’s Manual
Site____________________
Part Number 8821607-00
Rev. E
Issued: 5/05

CM7/8 100Base-T System User’s Manual 5/04/05 Page iii
CM7/8 100Base-T Manual Revision History
Section Changed Pages Changed
Revision A – Initial Release
Revision B - 8/03
Front Matter cover, history, contents
Chapter 1, General Information 1-2, 1-8, 1-10, 1-11, 1-12
Chapter 2, Principles of Operation 2-2, 2-4, 2-15, 2-16
Chapter 3, Module Descriptions 3-4-1 to 3-4-4, 3-7-3, 3-7-4, 3-8-1, 3-9-1 to 3-9-4
Chapter 6, Maintenance 6-4, 6-28, 6-31
Appendix B, QuikLink Screens B-27, B-30
Appendix D, Alarm Codes All
Appendix E, Frequency Settings E-1
Appendix F, SNMP Option F-3 to F-5, F-7 to F-9, F-12, F-18
Rev. C 11/21/03
Front Matter cover, revision history, TOC
Chapter 3, Module Descriptions 3-7-4, 3-7-5, 3-12-4, 3-12-5
Appendix C, Configuration Tables C-1 to C-8
Index I-1 to I-4
Rev. D 2/25/04
Front Matter all
Chapter 3, Module Descriptions 3-1, 3-2, 3-1-1 to 3-1-12 (all), 3-14-1 to 3-14-6 (all)
Chapter 4, Installation all
Appendix C, Configuration Tables all
Index all
Rev. E 5/04/05
Front Matter cover, revision history, LOF (xxv)
Chapter 2, Principles of Operation 2-2, 2-15, 2-16, 2-17
Appendix D, Alarm Codes D-5

Page iv 5/04/05 CM7/8 100Base-T System User’s Manual

CM7/8 100Base-T System User’s Manual Pagev
Introduction
Welcome to the CM7/8 100Base-T System User’s Manual. Use this section as a short
guide of the organization of information in this manual. Use the Table of Contents for
further detail.
Manual Organization
Apart from this, manual chapters and sections include the following:
Glossary—describes common terms and acronyms used in this manual.
Table of Contents—indexes subject headings and page numbers.
Chapter 1, General Information—information about the radio system including
equipment description and system specifications.
Chapter 2, Principles of Operation—including a description of signal flow through the
radio, equipment descriptions and configurations, switching and loopback information,
and detailed instructions on how to use the radio features.
Chapter 3, Module Descriptions—divided into sections with module block diagrams and
other module-specific information, such as operation, features, and jumper and switch
settings.
Chapter 4, Equipment Installation—gives step-by-step instructions on how to unpack,
configure, and install the radio.
Chapter 5, System Verification—describes radio alignment and tests.
Chapter 6, Maintenance—procedures, and provides sections on troubleshooting and
module replacement procedures.
Appendix A, T/I Curves—for the CM7/8 100Base-T radio.
Appendix B, QuikLink Screens—description used on the local maintenance terminal.
Appendix C, Configuration Tables—necessary to prepare the radio for operation.
Appendix D, Alarm Codes—alarm condition codes that the system logs.
Appendix E, Frequency Settings—LO FREQ ADJ dip switch settings.
Appendix F, SNMP Option—discusses the SNMP option installation and operation.
Index—index of key words.
Using This Manual

Chapter 2 Alignment
Page vi CM7/8 100Base-T System User’s Manual
Quick Reference
The following quick reference table identifies tasks and the manual sections with the
appropriate information or procedure.
Quick Reference Table
Description Chapter
How to install the radio 4
How to verify radio operation 5
How to maintain the radio 6
How to troubleshoot the radio 6
How to repair the radio 6
How to spare the radio TXU/RXU 6
How to switch TX 2
How to switch RX 2
How to initiate loopbacks 2
How to enable or disable APC 2
How to check or change frequency 2
How to change protection configuration 2
How to add service channel 2
How to add orderwire 2
How to add a WTU 2
How to check for alarms 2
How to check the alarm log 2
How to check performance values 2
How to establish RF loopback 6
How to check receive threshold 5
How to check Tx fade margin 5
How to add NMU 2
How to add SNMP management App. F

Commercial Warranty
Microwave Networks, Inc. (MNI) manufactured products are warranted to be free from defect in
material and workmanship for a period of two (2) years from date of shipment. In the event of a
defect during the warranty period, Buyer will return item to the MNI depot repair facility for
repair or replacement. Repair at MNI's option may include the replacement of parts or equipment,
and all replaced parts or equipment shall be the property of MNI. Parts or equipment replaced dur-
ing the warranty period are warranted for the remainder of the original applicable warranty period
or ninety (90) days, whichever is greater. This express warranty is extended by MNI to the origi-
nal Buyer for commercial, industrial or governmental use. Such action on the part of MNI shall be
the full extent of MNI's liability and Buyer's exclusive remedy.
This warranty extends only to products manufactured by MNI, and it is expressly conditioned
upon the equipment having been installed in accordance with the installation practices accepted
by the telecommunications industry, the standard installation and configuration practices recom-
mended by MNI, and the equipment having been maintained in accordance with MNI recom-
mended standard maintenance practices. Frequency sensitive components, towers, vidicon tubes,
test equipment, batteries, and other manufacturers' products are excluded, but carry their own sep-
arate limited warranties as authorized by the individual manufacturers.
This warranty shall automatically terminate if the product is used in other than its normal and cus-
tomary manner, has been subject to misuse, accident, neglect or damage, has improper alterations
or repairs made to it, or if nonconforming parts are used in the product, unless done by a service
facility authorized by MNI to perform warranty service. An authorization to return products to
MNI under this warranty must be obtained from the MNI Customer Care Center prior to making
shipment to MNI's repair center. All returns shall be shipped freight prepaid and collect shipments
will not be accepted. MNI will prepay return freight charges on repaired and replaced products
found to be defective. There will be a minimum charge for each warranty module replacement
requested as an emergency exchange.
Because each radio system is unique, MNI disclaims liability for range, coverage, or operation of
a system as a whole under this warranty except by a separate written agreement signed by an
officer of MNI. MNI's total liability is limited to the total price of the products sold. Buyer's sole
remedy is to request MNI, at MNI's option, to either refund the purchase price, repair or replace
product(s) that are not as warranted. No action shall be brought for any breach of this contract
more than one (1) year after the accrual of such cause of action except for money due upon open
account.
This MNI warranty is given in lieu of all other warranties, either expressed or implied, which are
specifically excluded, including warranties of merchantability or fitness for a particular purpose.
In no event shall MNI be liable for any incidental or consequential damages arising from this war-
ranty.

Where you can find us
Company Headquarters:
Microwave Networks
4000 Greenbriar
Stafford, TX 77477
USA
Tel [phone]
Fax [phone]
Toll free in US 1.888.225.6429
Internet: www.microwavenetworks.com
24-Hour Customer Service Hotline
Tel [phone]
Toll free in US 1.888.225.4762
International London
Tel [phone]
Fax [phone]

CM System Users Manual Pageix
