Midas M32 LIVE User manual

(Visit midasconsoles.com for Full Manual)
Quick Start Guide
M32 DIGITAL CONSOLE
Digital Console for Live and Studio with 40 Input Channels,
32 MIDAS Microphone Preampliers and 25 Mix Buses

2M32 DIGITAL CONSOLE Quick Start Guide 3
Terminals marked withthis symbol
carryelectrical currentof sucient
magnitude to constitute risk of electric
shock. Useonly high-quality commercially-available
speaker cables with plugs pre-installed. Allother
installation or modication should be performed only by
qualiedpersonnel.
This symbol, wherever it appears,
alertsyou to the presence of uninsulated
dangerous voltage inside the
enclosure-voltage that may be sucient to constitute a
risk ofshock.
This symbol, wherever it appears,
alertsyou to important operating and
maintenance instructions in the
accompanying literature. Please read the manual.
Caution
To reduce the risk of electric shock, donot
remove the top cover (or the rear section).
No user serviceable parts inside. Refer servicing to
qualied personnel.
Caution
To reduce the risk of re or electric shock,
do not expose this appliance to rain and
moisture.The apparatus shall not be exposed to dripping
or splashing liquids and no objects lled with liquids,
suchas vases, shall be placed on the apparatus.
Caution
These service instructions are for use
by qualied service personnel only.
Toreduce the risk of electric shock do not perform any
servicing other than that contained in the operation
instructions. Repairs have to be performed by qualied
servicepersonnel.
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
8. Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized
or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong.The wide
blade or the third prong are provided for your safety. Ifthe
provided plug does not t into your outlet, consult an
electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or
pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11. Use only attachments/accessories specied by
themanufacturer.
12. Use only with the
cart, stand, tripod, bracket,
or table specied by the
manufacturer, orsold with
the apparatus. When a cart
is used, use caution when
moving the cart/apparatus
combination to avoid
injury from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Refer all servicing to qualied service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug
is damaged, liquid has been spilled or objects have fallen
into the apparatus, the apparatus has been exposed
to rain or moisture, does not operate normally, or has
beendropped.
15. The apparatus shall be connected to a MAINS socket
outlet with a protective earthing connection.
16. Where the MAINS plug or an appliance coupler is
used as the disconnect device, the disconnect device shall
remain readily operable.
17. Correct disposal of this
product:This symbol indicates that
this product must not be disposed
of with household waste,
according to the WEEE Directive
(2012/19/EU) and your national
law.This product should be taken
to a collection center licensed for the recycling of waste
electrical and electronic equipment (EEE).The
mishandling of this type of waste could have a possible
negative impact on the environment and human health
due to potentially hazardous substances that are generally
associated with EEE. At the same time, your cooperation
in the correct disposal of this product will contribute to
the ecient use of natural resources. For more
information about where you can take your waste
equipment for recycling, please contact your local city
oce, or your household waste collection service.
MUSIC Group accepts no liability for any loss which
may be suered by any person who relies either
wholly or in part upon any description, photograph,
or statement contained herein.Technical specications,
appearances and other information are subject to
change without notice. All trademarks are the property
of their respective owners. MIDAS, KLARKTEKNIK,
TURBOSOUND, BEHRINGER, BUGERA and DDA are
trademarks or registered trademarks of MUSIC Group IP
Ltd. © MUSIC Group IP Ltd. 2014 All rights reserved.
For the applicable warranty terms and conditions
and additional information regarding MUSIC Group’s
LimitedWarranty, please see complete details online at
music-group.com/warranty.
Las terminales marcadas con este símbolo
transportan corriente eléctrica de
magnitud suciente como para constituir
un riesgo de descarga eléctrica. Utilice solo cables de
altavozde alta calidad con clavijasTSde6,3mm
pre-instaladas (puedeadquirirlos en comercios
especializados en audio). Cualquierotra instalación o
modicación debe ser realizada únicamente por un
técnico cualicado.
Este símbolo, siempre que aparece,
leadvierte de la presencia de voltaje
peligroso sin aislar dentro de la caja;
estevoltaje puede ser suciente para constituir un riesgo
dedescarga.
Este símbolo, siempre que aparece,
leadvierte sobre instrucciones operativas
y de mantenimiento que aparecen en la
documentación adjunta. Por favor, lea el manual.
Atención
Para reducir el riesgo de descarga
eléctrica, no quite la tapa (o la parte
posterior). No hay piezas en el interior del equipo que
puedan ser reparadas por el usuario. Si es necesario,
póngase en contacto con personal cualicado.
Atención
Para reducir el riesgo de incendio o
descarga eléctrica, no exponga este
aparato a la lluvia, humedad o alguna otra fuente que
pueda salpicar o derramar algún líquido sobre el aparato.
Nocoloque ningún tipo de recipiente para líquidos sobre
el aparato.
Atención
Las instrucciones de servicio deben
llevarlas a cabo exclusivamente personal
cualicado. Para evitar el riesgo de una descarga eléctrica,
no realice reparaciones que no se encuentren descritas
en el manual de operaciones. Lasreparaciones deben ser
realizadas exclusivamente por personalcualicado.
1. Lea las instrucciones.
2. Conserve estas instrucciones.
3. Preste atención a todas las advertencias.
4. Siga todas las instrucciones.
5. No use este aparato cerca del agua.
6. Limpie este aparato con un paño seco.
7. No bloquee las aberturas de ventilación. Instale el
equipo de acuerdo con las instrucciones del fabricante.
8. No instale este equipo cerca de fuentes de calor
tales como radiadores, acumuladores de calor, estufas u
otros aparatos (incluyendo amplicadores) que puedan
producir calor.
9. No elimine o deshabilite nunca la conexión a tierra
del aparato o del cable de alimentación de corriente.
Unenchufe polarizado tiene dos polos, uno de los cuales
tiene un contacto más ancho que el otro. Una clavija con
puesta a tierra dispone de tres contactos: dos polos y la
puesta a tierra. El contacto ancho y el tercer contacto,
respectivamente, son los que garantizan una mayor
seguridad. Si el enchufe suministrado con el equipo no
concuerda con la toma de corriente, consulte con un
electricista para cambiar la toma de corriente obsoleta.
10. Coloque el cable de suministro de energía de manera
que no pueda ser pisado y que esté protegido de objetos
alados. Asegúrese de que el cable de suministro de
energía esté protegido, especialmente en la zona de la
clavija y en el punto donde sale del aparato.
11. Use únicamente los dispositivos o accesorios
especicados por el fabricante.
12. Use únicamente la
carretilla, plataforma,
trípode, soporte o mesa
especicados por el
fabricante o suministrados
junto con el equipo.
Altransportar el equipo,
tenga cuidado para evitar
daños y caídas al tropezar con algún obstáculo.
13. Desenchufe el equipo durante tormentas o si no va a
utilizarlo durante un periodo largo.
14. Confíe las reparaciones únicamente a servicios
técnicos cualicados. La unidad requiere mantenimiento
siempre que haya sufrido algún daño, si el cable de
suministro de energía o el enchufe presentaran daños,
sehubiera derramado un líquido o hubieran caído objetos
dentro del equipo, si el aparato hubiera estado expuesto
a la humedad o la lluvia, si ha dejado de funcionar de
manera normal o si ha sufrido algún golpe o caída.
15. Al conectar la unidad a la toma de corriente eléctrica
asegúrese de que la conexión disponga de una unión
atierra.
16. Si el enchufe o conector de red sirve como único
medio de desconexión, éste debe ser accesiblefácilmente.
17. Cómo debe deshacerse de
este aparato: Este símbolo indica
que este aparato no debe ser
tratado como basura orgánica,
según lo indicado en la Directiva
WEEE (2012/19/EU) y a las
normativas aplicables en su país.
En lugar de ello deberá llevarlo al punto limpio más
cercano para el reciclaje de sus elementos eléctricos/
electrónicos (EEE). Al hacer esto estará ayudando a
prevenir las posibles consecuencias negativas para el
medio ambiente y la salud que podrían ser provocadas por
una gestión inadecuada de este tipo de aparatos. Además,
el reciclaje de materiales ayudará a conservar los recursos
naturales. Para más información acerca del reciclaje de
este aparato, póngase en contacto con el Ayuntamiento
de su ciudad o con el punto limpio local.
MUSIC Group no admite ningún tipo de responsabilidad
por cualquier daño o pérdida que pudiera sufrir
cualquier persona por conar total o parcialmente en
la descripciones, fotografías o armaciones contenidas
en este documento. Las especicaciones técnicas,
imágenes y otras informaciones contenidas en este
documento están sujetas a modicaciones sin previo
aviso. Todas las marcas comerciales que aparecen
aquí son propiedad de sus respectivos dueños.
MIDAS, KLARKTEKNIK,TURBOSOUND, BEHRINGER,
BUGERA y DDA son marcas comerciales o marcas
registradasde MUSICGroupIPLtd. ©MUSICGroupIPLtd.
2014 Reservados todos los derechos.
Si quiere conocer los detalles y condiciones aplicables
de la garantía así como información adicional sobre la
Garantía limitada de MUSIC group, consulte online toda la
información en la web music-group.com/warranty.
Important Safety
Instructions
LEGAL DISCLAIMER Instrucciones de
seguridad
NEGACIÓN LEGAL
GARANTÍA LIMITADA
LIMITED WARRANTY

4M32 DIGITAL CONSOLE Quick Start Guide 5
Les points repérés par ce symbole portent
une tension électrique susante pour
constituer un risque d’électrocution.
Utilisez uniquement des câbles d’enceintes de haute
qualité disponibles dans les points de vente avec les
connecteurs Jack mono 6,35 mm déjà installés.
Touteautre installation ou modication doit être
eectuée uniquement par un personnel qualié.
Ce symbole avertit de la présence d’une
tension dangereuse et non isolée à
l’intérieur de l’appareil - elle peut
provoquer des chocs électriques.
Attention
Ce symbol signale les consignes
d’utilisation et d’entre !Tien importantes
dans la documentation fournie. Lisez les consignes de
sécurité du manuel d’utilisation de l’appareil.
Attention
Pour éviter tout risque de choc électrique,
ne pas ouvrir le capot de l’appareil ni
démonter le panneau arrière. L’intérieur de l’appareil
ne possède aucun élément réparable par l’utilisateur.
Laissertoute réparation à un professionnel qualié.
Attention
Pour réduire les risques de feu et de choc
électrique, n’exposez pas cet appareil à la
pluie, à la moisissure, aux gouttes ou aux éclaboussures.
Ne posez pas de récipient contenant un liquide sur
l’appareil (un vase par exemple).
Attention
Ces consignes de sécurité et d’entretien
sont destinées à un personnel qualié.
Pouréviter tout risque de choc électrique, n’eectuez
aucune réparation sur l’appareil qui ne soit décrite par le
manuel d’utilisation. Les éventuelles réparations doivent
être eectuées uniquement par un technicien spécialisé.
1. Lisez ces consignes.
2. Conservez ces consignes.
3. Respectez tous les avertissements.
4. Respectez toutes les consignes d’utilisation.
5. N’utilisez jamais l’appareil à proximité d’un liquide.
6. Nettoyez l’appareil avec un chion sec.
7. Veillez à ne pas empêcher la bonne ventilation de
l’appareil via ses ouïes de ventilation. Respectezles
consignes du fabricant concernant l’installation
del’appareil.
8. Ne placez pas l’appareil à proximité d’une source
de chaleur telle qu’un chauage, une cuisinière ou tout
appareil dégageant de la chaleur (y compris un ampli
depuissance).
9. Ne supprimez jamais la sécurité des prises bipolaires
ou des prises terre. Les prises bipolaires possèdent deux
contacts de largeur diérente. Leplus large est le contact
de sécurité. Les prises terre possèdent deux contacts plus
une mise à la terre servant de sécurité. Si la prise du bloc
d’alimentation ou du cordon d’ali-mentation fourni ne
correspond pas à celles de votre installation électrique,
faites appel à un électricien pour eectuer le changement
de prise.
10. Installez le cordon d’alimentation de telle façon
que personne ne puisse marcher dessus et qu’il soit
protégé d’arêtes coupantes. Assurez-vous que le cordon
d’alimentation est sufsamment protégé, notamment au
niveau de sa prise électrique et de l’endroit où il est relié à
l’appareil; cela est également valable pour une éventuelle
rallonge électrique.
11. Utilisez exclusivement des accessoires et des
appareils supplémentaires recommandés par lefabricant.
12. Utilisez
exclusivement des
chariots, des diables,
desprésentoirs, despieds
et des surfaces de
travail recommandés
par le fabricant ou
livrés avec le produit.
Déplacezprécautionneusement tout chariot ou diable
chargé pour éviter d’éventuelles blessures en cas dechute.
13. Débranchez l’appareil de la tension secteur en cas
d’orage ou si l’appareil reste inutilisé pendant une longue
période de temps.
14. Les travaux d’entretien de l’appareil doivent
être eectués uniquement par du personnel qualié.
Aucunentretien n’est nécessaire sauf si l’appareil est
endommagé de quelque façon que ce soit (dommagessur
le cordon d’alimentation ou la prise par exemple), siun
liquide ou un objet a pénétré à l’intérieur du châssis,
si l’appareil a été exposé à la pluie ou à l’humidité, s’il ne
fonctionne pas correctement ou à la suite d’une chute.
15. L’appareil doit être connecté à une prise secteur
dotée d’une protection par mise à la terre.
16. La prise électrique ou la prise IEC de tout appareil
dénué de bouton marche/arrêt doit rester accessible
enpermanence.
17. Mise au rebut appropriée de
ce produit: Ce symbole indique
qu’en accord avec la directive DEEE
(2012/19/EU) et les lois en vigueur
dans votre pays, ce produit ne doit
pas être jeté avec les déchets
ménagers. Ce produit doit être
déposé dans un point de collecte agréé pour le recyclage
des déchets d’équipements électriques et électroniques
(EEE). Une mauvaise manipulation de ce type de déchets
pourrait avoir un impact négatif sur l’environnement et la
santé à cause des substances potentiellement
dangereuses généralement associées à ces équipements.
En même temps, votre coopération dans la mise au rebut
de ce produit contribuera à l’utilisation ecace des
ressources naturelles. Pour plus d’informations sur
l’endroit où vous pouvez déposer vos déchets
d’équipements pour le recyclage, veuillez contacter votre
mairie ou votre centre local de collecte des déchets.
MUSIC Group ne peut être tenu pour responsable pour
toute perte pouvant être subie par toute personne
se ant en partie ou en totalité à toute description,
photographie ou armation contenue dans ce
document. Les caractéristiques, l’apparence et d’autres
informations peuvent faire l’objet de modications
sans notication.Toutes les marques appartiennent à
leurs propriétaires respectifs. MIDAS, KLARK TEKNIK,
TURBOSOUND, BEHRINGER, BUGERA et DDA sont des
marques ou marques déposées de MUSIC Group IP Ltd.
© MUSIC Group IP Ltd. 2014Tous droits réservés.
Pour connaître les termes et conditions de garantie
applicables, ainsi que les informations supplémentaires
et détaillées sur la Garantie Limitée de MUSIC Group,
consultez le site Internet music-group.com/warranty.
Vorsicht
Die mit dem Symbol markierten
Anschlüsse führen so viel Spannung,
dass die Gefahr eines Stromschlags besteht.
Verwenden Sie nur hochwertige, im Handel
erhältliche Lautsprecherkabel mit vorinstallierten
6,3 mmTSSteckern. Alle anderen Installationen
oder Modikationen sollten nur von qualiziertem
Fachpersonal ausgeführt werden.
Achtung
Um eine Gefährdung durch Stromschlag
auszuschließen, darf die Geräteabdeckung
bzw. Geräterückwand nicht abgenommen werden.
ImInnern des Geräts benden sich keine vom Benutzer
reparierbarenTeile. Reparaturarbeiten dürfen nur von
qualiziertem Personal ausgeführt werden.
Achtung
Um eine Gefährdung durch Feuer bzw.
Stromschlag auszuschließen, darf dieses
Gerät weder Regen oder Feuchtigkeit ausgesetzt werden
noch sollten Spritzwasser oder tropfende Flüssigkeiten
in das Gerät gelangen können. Stellen Sie keine mit
Flüssigkeit gefüllten Gegenstände, wie z. B.Vasen,
aufdasGerät.
Achtung
Die Service-Hinweise sind nur durch
qualiziertes Personal zu befolgen.
Umeine Gefährdung durch Stromschlag zu vermeiden,
führen Sie bitte keinerlei Reparaturen an dem Gerät
durch, die nicht in der Bedienungsanleitung beschrieben
sind. Reparaturen sind nur von qualiziertem
Fachpersonaldurchzuführen.
1. Lesen Sie diese Hinweise.
2. Bewahren Sie diese Hinweise auf.
3. Beachten Sie alleWarnhinweise.
4. Befolgen Sie alle Bedienungshinweise.
5. Betreiben Sie das Gerät nicht in der Nähe vonWasser.
6. Reinigen Sie das Gerät mit einem trockenen Tuch.
7. Blockieren Sie nicht die Belüftungsschlitze. Beachten
Sie beim Einbau des Gerätes die Herstellerhinweise.
8. Stellen Sie das Gerät nicht in der Nähe von
Wärmequellen auf. SolcheWärmequellen sind z. B.
Heizkörper, Herde oder andereWärme erzeugende Geräte
(auchVerstärker).
9. Entfernen Sie in keinem Fall die
Sicherheitsvorrichtung von Zweipol- oder geerdeten
Steckern. Ein Zweipolstecker hat zwei unterschiedlich
breite Steckkontakte. Ein geerdeter Stecker hat zwei
Steckkontakte und einen dritten Erdungskontakt.
Derbreitere Steckkontakt oder der zusätzliche
Erdungskontakt dient Ihrer Sicherheit. Falls das
mitgelieferte Steckerformat nicht zu Ihrer Steckdose
passt, wenden Sie sich bitte an einen Elektriker, damit die
Steckdose entsprechend ausgetauscht wird.
10. Verlegen Sie das Netzkabel so, dass es vor
Tritten und scharfen Kanten geschützt ist und nicht
beschädigt werden kann. Achten Sie bitte insbesondere
im Bereich der Stecker, Verlängerungskabel und an
der Stelle, an der das Netzkabel das Gerät verlässt,
aufausreichendenSchutz.
11. Das Gerät muss jederzeit mit intaktem Schutzleiter
an das Stromnetz angeschlossen sein.
12. Sollte der Hauptnetzstecker oder eine
Gerätesteckdose die Funktionseinheit zum Abschalten
sein, muss diese immer zugänglich sein.
13. Verwenden Sie nur Zusatzgeräte/Zubehörteile,
dielaut Hersteller geeignet sind.
14. Verwenden
Sie nurWagen,
Standvorrichtungen,
Stative, Halter oder Tische,
die vom Hersteller benannt
oder im Lieferumfang
des Geräts enthalten
sind. Falls Sie einen
Wagen benutzen, seien Sie vorsichtig beim Bewegen
derWagen-Gerätkombination, umVerletzungen durch
Stolpern zuvermeiden.
15. Ziehen Sie den Netzstecker bei Gewitter oder wenn
Sie das Gerät längere Zeit nicht benutzen.
16. Lassen Sie alleWartungsarbeiten nur von
qualiziertem Service-Personal ausführen. EineWartung
ist notwendig, wenn das Gerät in irgendeinerWeise
beschädigt wurde (z. B. Beschädigung des Netzkabels oder
Steckers), Gegenstände oder Flüssigkeit in das Geräteinnere
gelangt sind, das Gerät Regen oder Feuchtigkeit ausgesetzt
wurde, das Gerät nicht ordnungsgemäß funktioniert oder
auf den Boden gefallen ist.
17. Korrekte Entsorgung dieses
Produkts: Dieses Symbol weist
darauf hin, das Produkt
entsprechend derWEEE Direktive
(2012/19/EU) und der jeweiligen
nationalen Gesetze nicht
zusammen mit Ihren
Haushaltsabfällen zu entsorgen. DiesesProdukt sollte bei
einer autorisierten Sammelstelle für Recycling elektrischer
und elektronischer Geräte (EEE) abgegeben werden.
Wegen bedenklicher Substanzen, diegenerell mit
elektrischen und elektronischen Geräten in Verbindung
stehen, könnte eine unsachgemäße Behandlung dieser
Abfallart eine negative Auswirkung auf Umwelt und
Gesundheit haben. Gleichzeitig gewährleistet Ihr Beitrag
zur richtigen Entsorgung dieses Produkts die eektive
Nutzung natürlicher Ressourcen. Fürweitere
Informationen zur Entsorgung Ihrer Geräte bei einer
Recycling-Stelle nehmen Sie bitte Kontakt zum
zuständigen städtischen Büro, Entsorgungsamt oder zu
Ihrem Haushaltsabfallentsorgerauf.
MUSIC Group übernimmt keine Haftung für Verluste,
die Personen entstanden sind, die sich ganz oder
teilweise auf hier enthaltene Beschreibungen,
Fotos oder Aussagen verlassen haben.Technische Daten,
Erscheinungsbild und andere Informationen können
ohne vorherige Ankündigung geändert werden.
AlleWarenzeichen sind Eigentum der jeweiligen
Inhaber. MIDAS, KLARKTEKNIK,TURBOSOUND,
BEHRINGER, BUGERA und DDA sindWarenzeichen oder
eingetrageneWarenzeichen der MUSIC Group IP Ltd.
© MUSIC Group IP Ltd. 2014 Alle Rechte vorbehalten.
Die geltenden Garantiebedingungen und zusätzliche
Informationen bezüglich der von MUSIC Group
gewährten beschränkten Garantie nden Sie online unter
music-group.com/warranty.
Consignes de sécurité
DÉNI LÉGAL
GARANTIE LIMITÉE
Wichtige
Sicherheitshinweise
HAFTUNGSAUSSCHLUSS
BESCHRÄNKTE GARANTIE

6M32 DIGITAL CONSOLE Quick Start Guide 7
Aviso!
Terminais marcados com o símbolo
carregam corrente elétrica de magnitude
suciente para constituir um risco de choque elétrico.
Use apenas cabos de alto-falantes comercialmente
disponíveis de alta qualidade com pluguesTS de ¼"
pré-instalados.Todas as outras instalações e modicações
devem ser efetuadas por pessoas qualicadas.
Este símbolo, onde quer que o encontre,
alerta-o para a leitura das instruções de
manuseamento que acompanham o
equipamento. Por favor leia o manual de instruções.
Atenção
De forma a diminuir o risco de choque
eléctrico, não remover a cobertura
(ouasecção de trás). Não existem peças substituíveis por
parte do utilizador no seu interior. Para esse efeito recorrer
a um técnico qualicado.
Atenção
Para reduzir o risco de incêndios ou
choques eléctricos o aparelho não deve ser
exposto à chuva nem à humidade. Além disso, não deve
ser sujeito a salpicos, nem devem ser colocados em cima
do aparelho objectos contendo líquidos, tais como jarras.
Atenção
Estas instruções de operação devem ser
utilizadas, em exclusivo, por técnicos de
assistência qualicados. Para evitar choques eléctricos
não proceda a reparações ou intervenções, que não as
indicadas nas instruções de operação, salvo se possuir as
quali-cações necessárias. Para evitar choques eléctricos
não proceda a reparações ou intervenções, que não as
indicadas nas instruções de operação. Só o deverá fazer se
possuir as qualicações necessárias.
1. Leia estas instruções.
2. Guarde estas instruções.
3. Preste atenção a todos os avisos.
4. Siga todas as instruções.
5. Não utilize este dispositivo perto de água.
6. Limpe apenas com um pano seco.
7. Não obstrua as entradas de ventilação. Instale de
acordo com as instruções do fabricante.
8. Não instale perto de quaisquer fontes de calor
tais como radiadores, bocas de ar quente, fogões de
sala ou outros aparelhos (incluindo amplicadores)
que produzam calor.
9. Não anule o objectivo de segurança das chas
polarizadas ou do tipo de ligação à terra. Uma cha
polarizada dispõe de duas palhetas sendo uma mais larga
do que a outra. Uma cha do tipo ligação à terra dispõe
de duas palhetas e um terceiro dente de ligação à terra.
A palheta larga ou o terceiro dente são fornecidos para
sua segurança. Se a cha fornecida não encaixar na sua
tomada, consulte um electricista para a substituição da
tomada obsoleta.
10. Proteja o cabo de alimentação de pisadelas ou
apertos, especialmente nas chas, extensões, e no local
de saída da unidade. Certique-se de que o cabo eléctrico
está protegido.Verique particularmente nas chas, nos
receptáculos e no ponto em que o cabo sai doaparelho.
11. O aparelho tem de estar sempre conectado à rede
eléctrica com o condutor de protecção intacto.
12. Se utilizar uma cha de rede principal ou uma
tomada de aparelhos para desligar a unidade de
funcionamento, esta deve estar sempre acessível.
13. Utilize apenas ligações/acessórios especicados
pelofabricante.
14. Utilize apenas com
o carrinho, estrutura,
tripé, suporte, ou mesa
especicados pelo
fabricante ou vendidos
com o dispositivo.
Quandoutilizar um
carrinho, tenha cuidado ao
mover o conjunto carrinho/dispositivo para evitar danos
provocados pela terpidação.
15. Desligue este dispositivo durante as trovoadas
ou quando não for utilizado durante longos períodos
detempo.
16. Qualquer tipo de reparação deve ser sempre
efectuado por pessoal qualicado. É necessária uma
reparação sempre que a unidade tiver sido de alguma
forma danicada, como por exemplo: no caso do cabo
de alimentação ou cha se encontrarem danicados;
naeventualidade de líquido ter sido derramado ou
objectos terem caído para dentro do dispositivo; no caso
da unidade ter estado exposta à chuva ou à humidade;
seesta não funcionar normalmente, ou se tiver caído.
17. Correcta eliminação deste
produto: este símbolo indica que
o produto não deve ser eliminado
juntamente com os resíduos
domésticos, segundo a Directiva
REEE (2012/19/EU) e a legislação
nacional. Este produto deverá
ser levado para um centro de recolha licenciado para a
reciclagem de resíduos de equipamentos eléctricos e
electrónicos (EEE). O tratamento incorrecto deste tipo
de resíduos pode ter um eventual impacto negativo
no ambiente e na saúde humana devido a substâncias
potencialmente perigosas que estão geralmente
associadas aos EEE. Ao mesmo tempo, a sua colaboração
para a eliminação correcta deste produto irá contribuir
para a utilização eciente dos recursos naturais. Paramais
informação acerca dos locais onde poderá deixar o seu
equipamento usado para reciclagem, é favor contactar
os serviços municipais locais, a entidade de gestão de
resíduos ou os serviços de recolha de resíduosdomésticos.
O MUSIC Group não se responsabiliza por perda alguma
que possa ser sofrida por qualquer pessoa que dependa,
seja de maneira completa ou parcial, de qualquer
descrição, fotograa, ou declaração aqui contidas.
Dados técnicos, aparências e outras informações estão
sujeitas a modicações sem aviso prévio.Todas as
marcas são propriedade de seus respectivos donos.
MIDAS, KLARKTEKNIK,TURBOSOUND, BEHRINGER,
BUGERA e DDA são marcas ou marcas registradas
do MUSIC Group IP Ltd. © MUSIC Group IP Ltd.
2014Todos direitos reservados.
Para obter os termos de garantia aplicáveis e condições e
informações adicionais a respeito da garantia limitada do
MUSIC group, favor vericar detalhes na íntegra através
do website music-group.com/warranty.
Instruções de Segurança
Importantes
LEGAL RENUNCIANTE
GARANTIA LIMITADA
注意
感電の.恐れがありますので、カ
バーやその他の部品を取り外
したり、開けたりしないでください。高品
質なプロ用スピーカーケーブル（¼" TS標準
ケーブルおよびツイストロッキングプラ
グケーブル）を使用してください。
注意
火事および感電の危険を防ぐ
ため、本装置を水分や湿気の
あるところには設置しないで下さい。装置
には決して水分がかからないように注意
し、花瓶など水分を含んだものは、装置の
上には置かないようにしてください。
注意
このマークが表示されている
箇所には、内部に高圧電流が
生じています。手を触れると感電の恐れが
あります。
注意
取り扱いとお手入れの方法に
ついての重要な説明が付属の
取扱説明書に記載されています。ご使用の
前に良くお読みください。
注意
1. 取扱説明書を通してご覧ください。
2. 取扱説明書を大切に保管してくだ
さい。
3. 警告に従ってください。
4. 指示に従ってください。
5. 本機を水の近くで使用しないでくだ
さい。
6. お手入れの際は常に乾燥した布巾を使
ってください 。
7. 本機は、取扱説明書の指示に従い、
適切な換気を妨げない場所に設置してく
ださい。取扱説明書に従って設置してくだ
さい。
8. 本機は、電気ヒーターや温風機器、
ストーブ、調理台やアンプといった熱源か
ら 離して 設 置してください 。
9. ニ極式プラグおよびアースタイプ
(三芯)プラグの安全ピンは取り外さないで
ください。ニ極式プラグにはピンが二本つ
いており、そのうち一本はもう一方よりも幅
が広くなっています。アースタイプの三芯プ
ラグにはニ本のピンに加えてアース用のピ
ンが一本ついています。これらの幅の広い
ピン、およびアースピンは、安全のためのも
のです。備え付けのプラグが、お使いのコン
セントの形状と異なる場合は、電器技師に
相談してコンセントの交換をして下さい。
10. 電源コードを踏みつけたり、挟んだり
しないようご注意ください。電源コードや
プラグ、コンセント及び製品との接続には
十分にご注意ください。
11. すべての装置の接地(アース)が確保
されていることを確認して下さい。
12. 電源タップや
電源プラグは電
源遮断機として利
用されている場合
には、これが直ぐ
に操作できるよう
手元に設置して下
さい。
13. 付属品は本機製造元が指定したもの
のみをお使いください。
14. カートスタンド、三脚、ブラケット、
テーブルなどは、本機製造元が指定したも
の、もしくは本 機 の 付属 品となるもののみ
をお使いください。カートを使用しての運
搬の際は、器具の落下による怪我に十分ご
注意ください。
15. 雷雨の場合、もしくは長 期 間ご 使 用に
ならない場合は、電源プラグをコンセント
から抜いてください。
16. 故障の際は当社指定のサービス技術
者にお問い合わせください。電源コードも
しくはプラグの損 傷 、液体の装置内への浸
入、装置の上に物が落下した場合、雨や湿
気に装置が晒されてしまった場合、正常に
作動しない場合、もしくは装置を地 面に落
下させてしまった場合など、いかなる形で
あれ装置に損傷が加わった場合は、装置
の修理・点検を受けてください。
17. 本製品に電源コード
が付属されている場合、
付属の電源コードは本製
品以外ではご使用いただ
けません。電源コードは
必ず本製品に付属された
電源コードのみご使用く
ださい。
ここに含まれる記 述、写真、意見の
全体または一部に依拠して、いかな
る人が損害を生じさせた場合にも、
MUSIC Groupは一切の賠償責任を負いま
せん。技術仕様、外観およびその他の
情報は予告なく変更になる場合があり
ます。商標はすべて、それぞれの所有
者に帰属します。MIDAS、KLARK TEKNIK、
TURBOSOUND、BEHRINGER、BUGERAおよ
びDDAはMUSIC Group IP Ltd.の商標ま
たは登録商標です。© MUSIC Group IP Ltd.
2014無断転用禁止。
適用される保証条件とMUSIC Groupの限定
保証に関する概要については、オンライン
上music-group.com/warrantyにて詳細をご確
認ください。
安全にお使いいただくために
限定保
法的放

8M32 DIGITAL CONSOLE Quick Start Guide 9
ࣝధ൦ಗ঄ᄋጽቬ᝻ܭЧధ
ܹᄋႄุߜڛᝐႄԁᬘǎᬎ
Ώၺࣝధ ¼''TSᩛତ݁
ᄋᰵַ᠐˅ˋܧ٩ጴǎధᄋ߸ᜊួ
஠ڪᮍႁՍಬᄋ˅ˋցᤊᛢǎ
൦ಗ঄ଣᧉ১ַаߜڛఴ
ፑᎇᄋԁᬘႄԎధᝐႄԁᬘǎ
൦ಗ঄ଣᧉ১ಋ󰪀ᬅᄋ᧙᜷
ᄋΏၺԤ፦οឮ௛ǎឱ󰪀឵ధ
Угǎ
࠶
˟ᥙГᝐႄԁᬘឱӉ఼
ᮈᄧᑁ᭨૖ౝǎ᝻ܭа෦
ధԼΚၺ፦οΏၺᄋᦋǎឱ࠳፦ο
ᮋႁՍಬᄋ˅ˋցᤊᛢǎ
࠶
˟ᥙГᅍ༣ᝐႄԁᬘឱӉ
࠳൦᝻ܭᎷᭂ๹໾ິ˘ǎ
൦᝻ܭ˸ˁԼԫ๰͵໠ຶᄪధ๰͵ᄋࠕ
٩˸ˁԼᎷЦʾݡᔊၬ኏ǎ
࠶
፦οឮ௛௨ፍՍಬᄋ˅ˋ፦
οցΏၺᄋǎ˟ᥙГᝐႄԁ
ᬘᬕΏၺឮ௛˻ଣ҃ᄋܲឱӉᤊᛢ
ͶЦ߳፦οǎధ፦οڪᮍႁՍಬᄋ˅
ˋցᤊᛢǎ
1. ឱ󰪀឵ᤉឮ௛ǎ
2. ឱݱؔεߜᤉឮ௛ǎ
3. ឱญధᄋ᝞ᇩǎ
4. ឱᥗ߷ధᄋឮ௛ǎ
5. ឱӉڛ᭦ᤄබᄋڢஶΏၺశַǎ
6. ឱၺࣱ࣌ຎพశַǎ
7. ឱӉ܅܌ᤱ᮴Աǎ߸ᜊశַ௒ឱᥗ
ཱིԉࠓᄋឮ௛ǎ
8. ឱӉ࠳శַ߸ᜊڛམ຺ᬅᤄ
ݡ఍ජྠ༰ߖЦ߳ၸམ᧛ᄋ᝻ܭ
Ӌ઻ҫ஋٩ǎ
9. ឱӉሩᬕ౞মତ݁଍ڢତ݁ᄋ߸М
ᜊᎷǎ଍ڢତ݁௨ႁˑ˕ତ܌଍གྷԤʸ˕
଍ڢ݁౟ǎᔫᬥ᠏ଣΚᄋତ݁ˁᤡՍ১
ᄋତឱႄࢻట૲ʸ˕Սᤡᄋତǎ
10. ݱؔεઑႄ຺ጴΏЦˁᜃ᡼ᢇ҉
ᆢࡀЦญႄ຺ତ݁Ǎܴၺ᤮ତԤ᝻ܭ
ᤍ଍ܬǎ
11. ឱԷΏၺԉࠓ૊ࠁᄋᬅ࡜᝻ܭ֘
ᦢǎ
12. ឱԷΏၺԉࠓ
૊ࠁᄋᬥ᠏ᩚ
׭ᄋଏᢽ౷ߖ
ʽᝉ౷஄౷֘ಹ
ߖǎᔫΏၺଏᢽ
౐ୄᤃ᝻ܭឱญ
߸М஋Ꮇ᝻ܭ
ᥙГଏᢽ֘᝻
ܭϛωᏬԫǎ
13. ᥆󰩧ႄᭈᲟ󰩤ఱˁΏၺశ᝻ܭ௒
ឱફѤႄ຺ତ݁ǎ
14. ధ፦οڪᮍႁՍಬᄋ፦οցᤊ
ᛢǎ᝻ܭԫ૰௒ᭋᤊᛢ፦οΔݡႄ຺ጴ
ႄ຺ତ݁ԫ૰๰͵ุЛྮᗁЛ᝻ܭ
а᝻ܭᥔᭂ๹ԫ໾᝻ܭˁᑠ൥ࣣᤃͼ
ᜃ୒گǎ
15. శ᝻ܭᤍ଍ႄ຺௒ʸࠁ᜷ధ଍ڢ
εઑǎ
16. ᔫႄ຺ତ݁٩Ч
ᏺՍ٩ၺͼளႄᜊᎷ
ε᝾߳ܬᬥ௒Լ
ஶΨ୳ͼ࿅ঘǎ
17. శַᤡၺ๓
ફ2000ዜʿڢӞశ
ַᤡၺ᭥མࣝජό౏
ʿǎ
ࠬͶڃڛ൦ឮ௛˻ଣ҃ᄋМᦋ
ᦋଢᤙǍڐྠܧ௛Ꮼᤶᄋ૰
݀MUSIC Groupˁ᠈Ͷ᠋ǎ઀స
ԡஞ֘ܲ᜻ᔫధటஉিˁԴᛢᤱ
ᅽǎధᄋ׹ಗڪ˟ЦՋᒮధᏩᄋ
᠊ǎMIDASKLARK TEKNIKTURBOSOUND
BEHRINGERBUGERA֘DDA௨MUSIC Group IP
Ltd.ОՄᄋ׹ಗญг׹ಗǎ© MUSIC Group
IP Ltd. 2014ྡీధǎ
ధУᮄˮᬸڅεοᄋᤡၺ౏൝ԤЦ߳ᄲУ
θ্ឱᄇᬇmusic-group.com/warrantyᎫቤಋ
ᄻߺ஠ᄋឡጻθ্ǎ
其他的重要信息
保修条款
法律声明

10 11M32 DIGITAL CONSOLE Quick Start Guide
(3) (4) (5) (7) (6) (8) (9)(3) (4) (5) (7)
(6)
(8) (9)
(10)
(11)
(12)
(13) (14) (15)
(1)
(2)
1. Control Surface
(1) CONFIG/PREAMP - Adjust the preamp gain
for the selected channel with the GAIN
rotary control. Press the 48 V button to apply
phantom power for use with condenser
microphones and press the Øbutton to
reverse the channel’s phase. The LED meter
displays the selected channel’s level. Press the
LOW CUT button and select the desired
high-pass frequency to remove unwanted
lows. Press the VIEW button to access more
detailed parameters on the Main Display.
(2) GATE/DYNAMICS - Press the GATE button
to engage the noise gate and adjust the
threshold accordingly. Press the COMP button
to engage the compressor and adjust the
threshold accordingly. When the signal level
in the LCD meter drops below the selected
gate threshold , the noise gate will silence
the channel. When the signal level reaches
the selected dynamics threshold, the peaks
will be compressed. Press the VIEW button
to access more detailed parameters on the
MainDisplay.
(3) EQUALISER - Press the EQ button to
engage this section. Select one of the four
frequency bands with the LOW, LO MID,
HI MID and HIGH buttons. Press the MODE
button to cycle through the types of EQ
available. Boost or cut the selected frequency
with the GAIN rotary control. Select the
specic frequency to be adjusted with the
FREQUENCY rotary control and adjust the
bandwidth of the selected frequency with the
WIDTH rotary control. Press the VIEW button
to access more detailed parameters on the
Main Display.
(4) BUS SENDS - Quickly adjust the bus sends by
selecting one of the four banks, followed by
one of the four rotary controls. Press the VIEW
button to access more detailed parameters on
the Main Display.
(5) RECORDER - Connect an external memory
stick to install rmware updates, load and
save show data, and to record performances.
Press the VIEW button to access more detailed
Recorder parameters on the Main Display.
(6) MAIN BUS - Press the MONO CENTRE or
MAIN STEREO buttons to assign the channel
to the main mono or stereo bus. When MAIN
STEREO (stereo bus) is selected, the PAN/
BAL adjusts to the left-to-right positioning.
Adjust the overall send level to the mono
bus with the M/C LEVEL rotary control.
Press the VIEW button to access more detailed
parameters on the Main Display.
(7) MAIN DISPLAY - The majority of the M32’s
controls can be edited and monitored via
the Main Display. When the VIEW button is
pressed on any of the control panel functions,
it is here that they can be viewed. The main
display is also used for accessing the 60+
virtual eects. See section 3. Main Display.
(8) MONITOR - Adjust the level of the monitor
outputs with the MONITOR LEVEL rotary
control. Adjust the level of the headphones
output with the PHONES LEVEL rotary control.
Press the MONO button to monitor the audio
in mono. Press the DIM button to reduce the
monitor volume. Press the VIEW button to
adjust the amount of attenuation along with all
other monitor-related functions.
(9) TALKBACK - Connect a talkback microphone
via a standard XLR cable via the EXT MIC
socket. Adjust the level of the talkback mic
with the TALK LEVEL rotary control. Select the
destination of the talkback signal with the TALK
A/TALKB buttons. Press the VIEW button to
edit the talkback routing for A and B.
(10) SCENES - This section is used to save and
recall automation scenes in the console,
allowing dierent congurations to be
recalled at a later time. Please refer to the User
Manual for more details on this topic.
(11) ASSIGN - Assign the four rotary controls
to various parameters for instant access to
commonly-used functions. The LCD displays
provide quick reference to the assignments of
the active layer of custom controls. Assign each
of the eight custom ASSIGN buttons (numbered
5-12) to various parameters for instant access
to commonly-used functions. Press one of the
SET buttons to activate one of the three layers of
custom-assignable controls. Please refer to the
User Manual for more details on this topic.
(12) MUTE GROUPS - Press one of the buttons in
the MUTE GROUPS section to activate one of
the mute groups. For more details, see MUTE
GRP in section 3. Main Display.
(13) INPUT CHANNELS - The Input Channels
section of the console oers 16 separate
input channel strips. The strips represent four
separate layers of input for the console, which
can each be accessed by pressing one of the
following buttons:
•• INPUTS 1-16 - the rst and second blocks
eight channels assigned on the ROUTING/
HOME page
•• INPUTS 17-32 - the third and fourth
blocks of eight channels assigned on the
ROUTING / HOME page
•• AUX IN / USB - the fth block of six
channels & USB Recorder, and eight
channel FX returns (1L ...4R)
•• BUS MAST - this allows you to adjust the
levels of the 16 Mix Bus Masters, which is
useful when including Bus Masters into
DCA Group assignments, or when mixing
buses to matrices 1-6.
Press any of the above buttons (located to the
left of the Channel Strip) to switch the input
channel bank to any of the four layers listed
above. The button will illuminate to show
which layer is active.
You will nd a SEL (select) button on top
of every channel which is used to direct the
control focus of the user’s interface, including
all channel-related parameters to that channel.
There is always exactly one channel selected.
The LED display shows the current audio signal
level through that channel.
The SOLO button isolates the audio signal for
monitoring that channel.
The LCD Scribble Strip (which can be edited
via the Main Display) shows the current
channel assignment.
The MUTE button mutes the audio for that
channel.
(14) GROUP/BUS CHANNELS - This section oers
eight channel strips, assigned to one of the
following layers:
•• GROUP DCA 1-8 - Eight DCA (Digitally
Controlled Amplier) groups
•• BUS 1-8 - Mix Bus masters 1-8
•• BUS 9-16 - Mix Bus Masters 9-16
•• MTX 1-6 / MAIN C - Matrix Outputs 1-6
and the Main Centre (Mono) bus.
The SEL, SOLO & MUTE buttons, the LED
display, and the LCD scribble strip all behave in
the same way as for the INPUT CHANNELS.
(15) MAIN CHANNEL - This controls the Master
Output stereo mix bus.
The SEL, SOLO & MUTE buttons, and the LCD
scribble strip all behave in the same way as for
the INPUT CHANNELS.
The CLR SOLO button removes any solo
functions from any of the other channels.
Please refer to the User Manual for more information
on each of these topics.
(1)
(4) (6) (7) (8) (9) (10) (11)(5)
(2) (3)
2. Rear Panel
(1) MONITOR/CONTROL ROOM OUTPUTS-
connect a pair of studio monitors using
XLR or ¼" cables. Also includes a 12 V / 5 W
lamp connection.
(2) OUTPUTS 1 - 16 - Send analogue audio
to external equipment using XLR cables.
Outputs15 and 16 by default carry the main
stereo bus signals.
(3) INPUTS 1 - 32 - Connect audio sources
(suchas microphones or line level sources)
viaXLR cables.
(4) POWER - The IEC mains socket and
ON/OFF switch.
(5) USB INTERFACE CARD - Transmit up to
32channels of audio to and from a computer
via USB 2.0.
(6) REMOTE CONTROL INPUTS - Connect to a PC
for remote control via Ethernet cable.
(7) MIDI IN/OUT - Send and receive MIDI
commands via 5-pin DIN cables.
(8) AES/EBU OUT - Send digital audio via 3-pin
AES/EBU XLR cable.
(9) ULTRANET - Connect to a personal
monitoring system, such as the BEHRINGER
P16, via Ethernet cable.
(10) AES50 A/B - Transmit up to 96 channels in
and out via Ethernet cables.
(11) AUX IN/OUT - Connect to and from external
equipment via ¼" or RCA cables.
Please refer to the User Manual for more information
on each of these topics.

12 13M32 DIGITAL CONSOLE Quick Start Guide
3. Main Display
(3)
(4) (5)
(1) (2)
(1) DISPLAY SCREEN - The controls in this section
are used in conjunction with the colour screen
in order to navigate and control the graphical
elements it contains.
By including dedicated rotary controls that
correspond to the adjacent controls on the
screen, as well as including cursor buttons,
theuser can quickly navigate and control all of
the colour screen’s elements.
The colour screen contains various displays
that give visual feedback for the operation of
the console, and also allow the user to make
various adjustments not provided for by the
dedicated hardware controls.
(2) MAIN/SOLO METERS - This triple 24-segment
meter displays the audio signal level output
from the main bus, as well as the main centre
or solo bus of the console.
(3) SCREEN SELECTION BUTTONS - These
eight illuminated buttons allow the user to
immediately navigate to any of the eight
master screens that address dierent sections
of the console. The sections that can be
navigated are:
•• HOME - The HOME screen contains an
overview of the selected input or output
channel, and oers various adjustments
not available through the dedicated top-
panel controls.
The HOME screen contains the following
separate tabs:
home: General signal path for the
selected input or output channel.
cong: Allows selection of the signal
source/destination for the channel,
conguration of insert point, and
other settings.
gate: Controls and displays the channel
gate eect beyond those oered by the
dedicated top-panel controls.
dyn: Dynamics - controls and displays the
channel dynamics eect (compressor)
beyond those oered by the dedicated
top-panel controls.
eq: Controls and displays the channel
EQ eect beyond those oered by the
dedicated top-panel controls.
sends: Controls and displays for channel
sends, such as sends metering and
send muting.
main: Controls and displays for the
selected channel’s output.
•• METERS - The meters screen displays
dierent groups of level meters for
various signal paths, and is useful for
quickly ascertaining if any channels need
level adjustment. Since there are no
parameters to adjust for the metering
displays, none of the metering screens
contain any ‘bottom of the screen’
controls that would normally be adjusted
by the six rotary controls.
The METER screen contains the following
separate screen tabs, each containing
level meters for the relevant signal paths:
channel, mix bus, aux/fx, in/out and rta.
•• ROUTING - The ROUTING screen is where
all signal patching is done, allowing
the user to route internal signal paths
to and from the physical input/output
connectors located on the console’s
rear panel.
The ROUTING screen contains the
following separate tabs:
home: Allows patching of physical inputs
to the 32 input channels and aux inputs of
the console.
out 1-16: Allows patching of internal
signal paths to the console’s 16 rear panel
XLR outputs.
aux out: Allows patching of internal signal
paths to the console’s six rear panel ¼" /
RCA auxiliary outputs.
p16 out: Allows patching of internal signal
paths to the 16 outputs of the console’s
16-channel P16 Ultranet output.
card out: Allows patching of internal
signal paths to the 32 outputs of the
expansion card.
aes50-a: Allows patching of internal
signal paths to the 48 outputs of the rear
panel AES50-A output.
aes50-b: Allows patching of internal
signal paths to the 48 outputs of the rear
panel AES50-B output.
xlr out: Allows the user to congure the
XLR outs on the rear of the console in
blocks of four, from either local inputs,
the AES streams, or expansion card.
•• SETUP - The SETUP screen oers controls
for global, high-level functions of the
console, such as display adjustments,
sample rates & synchronisation, user
settings, and network conguration.
The SETUP screen contains the following
separate tabs:
global: This screen oers adjustments
for various global preferences of how the
console operates.
cong: This screen oers adjustments for
sample rates and synchronisation, aswell
as conguring high-level settings for
signal path buses.
remote: This screen oers dierent
controls for setting up the console as a
control surface for various DAW recording
software on a connected computer. It also
congures the MIDI Rx/Tx preferences.
network: This screen oers dierent
controls for attaching the console to a
standard Ethernet network. (IP address,
Subnet Mask, Gateway.)
scribble strip: This screen oers controls
for various customisation of the console’s
LCD scribble strips.
preamps: Shows the analogue gain for
local mic inputs (XLR at the rear) and
phantom power, including setup from
remote stage boxes (e.g. DL16) connected
via AES50.
card: This screen selects the input/
output conguration of the installed
interface card.
•• LIBRARY - The LIBRARY screen allows
loading and saving of commonly-used
setups for the channel inputs, eects
processors, and routing scenarios.
The LIBRARY screen contains the
following tabs:
channel: This tab allows the user to load
and save commonly used combinations
of the channel processing, including
dynamics andequalisation.
eects: This tab allows the user to
load and save commonly used eects
processor presets.
routing: This tab allows the user to load
and save commonly used signal routings.
•• EFFECTS - The EFFECTS screen controls
various aspects of the eight eects
processors. On this screen the user
can select specic types of eects for
the eight internal eects processors,
congure their input and output paths,
monitor their levels, and adjust the
various eects parameters.
The EFFECTS screen contains the
following separate tabs:
home: The home screen provides a
general overview of the virtual eects
rack, displaying what eect has been
inserted in each of the eight slots, as well
as displaying input/output paths for each
slot and the I/O signal levels.
fx1-8: These eight duplicate screens
display all of the relevant data for
the eight separate eects processors,
allowing the user to adjust all parameters
for the selected eect.
•• MUTE GRP - The MUTE GRP screen allows
for quick assignment and control of the
console’s six mute groups, and oers two
separate functions:
1. Mutes the active screen during the
process of assigning channels to
mute groups. This ensures that no
channels are accidentally muted
during the assignment process
during a live performance.
2. It oers an additional interface
for muting/unmuting the groups
in addition to the dedicated mute
group buttons at the bottom of
the console.
•• UTILITY - The UTILITY screen is a
supplemental screen designed to work in
conjunction with the other screens that
may be in view at any particular moment.
The UTILITY screen is never seen by itself,
it always exists in the context of another
screen, and typically brings up copy, paste
and library or customisation functions.
(4) ROTARY CONTROLS - These six rotary controls
are used to adjust the various elements
located directly above them. Each of the six
controls can be pushed inward to activate a
button-press function. This function is useful
when controlling elements that have a dual
on/o status that is best controlled by a
button, as opposed to a variable state that is
best adjusted by a rotary control.
(5) UP/DOWN/LEFT/RIGHT NAVIGATION
CONTROLS - The LEFT and RIGHT controls
allow for left-right navigation among the
dierent pages contained within a screen
set. A graphical tab display shows which
page you are currently on. On some screens
there are more parameters present than
can be adjusted by the six rotary controls
underneath. In these cases, use the UP
and DOWN buttons to navigate through
any additional layers contained on the
screen page. The LEFT and RIGHT buttons
are sometimes used to conrm or cancel
conrmation pop-ups.
Please refer to the User Manual for more information
on each of these topics.

14 15M32 DIGITAL CONSOLE Quick Start Guide
4. Quick Reference Section
Editing Channel Strip LCDs
1. Hold down the select button for the channel you
wish to change and press UTILITY.
2. Use the rotary controls below the screen to
adjust parameters.
3. There is also a dedicated Scribble Strip tab on
the SETUP menu.
4. Select the channel while viewing this screen
to edit.
Using Buses
Bus Setup:
The M32 oers ultra exible busing as each channel’s
bus sends can be independently Pre- or Post-Fader,
(selectable in pairs of buses). Select a channel
and press VIEW in the BUS SENDS section on the
channel strip.
Reveal options for Pre/Post/Subgroup by pressing
the Down Navigation button by the screen.
To congure a bus globally, press its SEL button and
then press VIEW on the CONFIG/PREAMP section
on the channel strip. Use the third rotary control to
change congurations. This will aect all channel
sends to this bus.
Note: Mix buses can be linked in odd-even adjacent
pairs to form stereo mix buses. To link buses
together, select one and press the VIEW button near
the CONFIG/PREAMP section of the channel strip.
Press the rst rotary control to link. When sending
to these buses, the odd BUS SEND rotary control will
adjust send level and even BUS SEND rotary control
will adjust pan/balance.
Matrix Mixes
Matrix mixes can be fed from any mix bus as well as
the MAIN LR and Centre/Mono bus.
To send to a Matrix, rst press the SEL button
above the bus you want to send. Use the four rotary
controls in the BUS SENDS section of the channel
strip. Rotary controls 1-4 will send to Matrix 1-4.
Press the 5-8 button to use the rst two rotary
controls to send to Matrix 5-6. If you press the VIEW
button, you will get a detailed view of the six Matrix
sends for the selected bus.
Access the Matrix mixes using layer four on the
output faders. Select a Matrix mix in order to access
its channel strip, including dynamics with 6-band
parametric EQ and crossover.
For a stereo Matrix, select a Matrix and press the
VIEW button on the CONFIG/PREAMP section of
the channel strip. Press the rst rotary control near
the screen to link, forming a stereo pair.
Note, stereo panning is handled by even BUS SEND
rotary controls as described in Using Buses above.
Using DCA Groups
Use DCA Groups to control the volume of multiple
channels with a single fader.
1. To assign a channel to a DCA, rst be sure you
have the GROUP DCA 1-8 layer selected.
2. Press and hold the select button of the DCA
group you wish to edit.
3. Simultaneously press the select buttons of a
channel you wish to add or remove.
4. When a channel is assigned, its select button
will light up when you press the SEL button of
its DCA.
Sends on Fader
To use Sends on Faders, press the Sends on Faders
button located near the middle of the console.
You can now use Sends On Faders in one of two
dierent ways.
1. Using 16 input faders: Select a bus on the
output fader section on right and the input
faders on the left will reect the mix being sent
to the selected bus.
2. Using eight bus faders: Press the select button
of an input channel on the input section on the
left. Raise the bus fader on the right side of the
console to send the channel to that bus.
Mute Groups
1. To assign/remove a channel from a Mute Group,
press the MUTE GRP screen selection button.
You will know you are in edit mode when the
MUTE GRP button lights and the six Mute
Groups appear on the six rotary controls.
2. Now press and hold one of the six Mute Group
buttons you wish to use and simultaneously
press the SEL button of the channel you wish to
add to or remove from that Mute Group.
3. When complete, press the MUTE GRP button
again to reactivate the dedicated Mute Group
buttons on the M32.
4. Your Mute Groups are ready to use.
Assignable Controls
1. The M32 features user-assignable rotary
controls and buttons in three layers. Toassign
them, press the VIEW button on the
ASSIGNsection.
2. Use the Left and Right Navigation button to
select a Set or layer of controls. These will
correspond to the SET A, Band Cbuttons on
the console.
3. Use the rotary controls to select the control and
choose its function.
Note: The LCD Scribble Strips will change to indicate
the controls for which they are set.
Eects Rack
1. Press the EFFECTS button near the screen to
see an overview of the eight stereo eects
processors. Keep in mind that eects slots 1-4
are for Send type eects, and slots 5-8 are for
Insert type eects.
2. To edit the eect, use the sixth rotary control to
select an eects slot.
3. While a eects slot is selected, use the fth
rotary control to change which eect is in
that slot, and conrm by pressing the control.
Press the sixth rotary control to edit the
parameters for that eect.
4. Over 60 eects include Reverbs, Delay, Chorus,
Flanger, Limiter, 31-Band GEQ, and more.
Please refer to the User Manual for a full list
and functionality.
5. Firmware Updates & USB Stick Recording
To Update Firmware:
Download the new console rmware from the
M32 product page onto the root level of a USB
memory stick.
Press and hold the RECORDER section’s VIEW
button while switching the console on to enter the
update mode.
Plug the USB memory stick into the top panel
USB connector.
The M32 will wait for the USB drive to become ready
and then run a fully-automated rmware update.
When a USB drive fails to get ready, updating will
not be possible and we recommend switching
the console o / on again for booting the
previous rmware.
The update process will take two to three minutes
longer than the regular boot sequence.
To Record to the USB Stick:
Insert the USB Stick into the port on the RECORDER
section and press the VIEW button.
Use the second page for conguring the recorder.
Press the fth rotary control under the screen to
begin recording.
Use the rst rotary control to stop. Wait for the
ACCESS light to turn o before removing the stick.
Notes: Stick must be formatted for FAT le system.
Maximum record time is approximately three hours
for each le, with a le size limit of 2 GB. Recording
is at 16-bit, 44.1 kHz or 48 kHz depending on console
sample rate.

16 17M32 DIGITAL CONSOLE Quick Start Guide
6. Block Diagram
MAIN
L R C L R
SOLOMATRIX
1 2 5 6
MIX BUS
1 2 15 16
FADER
MIX 1–16
INSERT
6-BAND
EQ
INSERT
COMP/ EXPAN
KEY-IN
Pre EQ Post EQ
EQ
Pre Fader Post Fader
Matrix 1,3,5
MUTE
MUTE
SOLO
Post Fader Post Fader
Post Fader
Post Fader
Matrix 2,4,6
MIX 1-16
OUT
EFFECTS 1-8
EFFECT
31 BAND GEQ 31 BAND GEQ
FX OUT L FX OUT R
FX IN L
FX IN R
USB
PLAY
USB
REC
USB RECORDER
REC LEVEL
USB
MEMORY
USB MEMORY
RECORDER
L+C/R+C MIX
L+C OUT
R+C OUT
+
+
DSP
PATCH
USB
PLAY
USB
REC
FX 1-8 OUT (L / R)
FX 1-8 IN (L / R)
6
16
8 x 2 8 x 2
MIX 1-16 INSERT RETURN
16
MIX 1-16 INSERT SEND
16
MIX 1-16 OUT
MAIN LRC INSERT RETURN
MATRIX 1-6 INSERT RETURN
6
MATRIX 1-6 INSERT SEND
6
MATRIX 1-6 OUT
3 3
MAIN LRC INSERT SEND
3
MAIN LRC OUT
3
MAIN LRC PRE EQ OUT
PATCH CUE
MONITOR LR OUT
2
MONITOR L+C/R+C OUT
2 2
MONITOR SOURCE IN
8
AUX Returns 1–8 AUX Returns 7–8 by default on USB Play
Pre EQ
Pre EQ/Pre Fader/Post Fader/Post Pan L
Pre EQ/Pre Fader/Post Fader/Post Pan R
Pre Fader
Mix 1,3...15 Mix 2,4...16
SOLO
4BAND
EQ
ATT
Pre EQ/Pre Fader/Post Fader/Post Pan L
Pre EQ/Pre Fader/Post Fader/Post Pan R
MUTE
MUTE
FADER LCR
PAN (LR)
PAN (LCR)
GAIN
Post Fader Post Pan
GAIN
32 32 32 32 32
ATT
CH 1–32
LOW
CUT GATE/
DUCK
INSERT
4-BAND
EQ
INSERT
COMP/ EXPAN
DELAY
KEY-IN
Pre EQ Post EQ
EQ
Pre Fader
Mix 1,3...15 Mix 2,4...16
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan L
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan R
KEY-IN
EQ
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan L
Pre HP/Pre Gate/Post Gate/Pre EQ/Post EQ/Pre Fader/Post Fader/Post Pan R
SOLO
INSERT RETURN INSERT SEND PRE LOW CUT OUT POST FADER OUT
MUTE
MUTE
FADER LCR
PAN (LR)
PAN (LCR)
GAIN
Post Fader Post Pan
GAIN
COMP/ EXPAN
8 x 2
STEREO FX RETURNS 1 L/R – 8 L/R
Pre Fader/Post Fader/Post Pan L
Pre Fader/Post Fader/Post Pan R
Pre Fader
Mix 1,3...15 Mix 2,4...16
SOLO
Pre Fader/Post Fader/Post Pan L
Pre Fader/Post Fader/Post Pan R
MUTE
MUTE
FADER LCR
PAN (LR)
PAN (LCR)
GAIN
Post Fader Post Pan
GAIN
WHITE NOISE
PINK NOISE
OSCILLATOR
SINE WAVE
GENERATE
GAIN
COMP/ EXPAN
LCR PAN (LR)
PAN (LCR)
GAIN
GAIN
FADER
MATRIX
1-6
INSERT INSERT
KEY-IN
Pre EQ Post EQ
EQ
Pre Fader Post Fader
MUTE
SOLO
MATRIX 1-6
OUT
Post Fader
COMP/ EXPAN EQ
6BAND COMP/
EXPAN
FADER
MAIN LRC
INSERT
6BAND
EQ
INSERT
COMP/ EXPAN
KEY-IN
Pre EQ Post EQ
EQ
GAIN
Pre Fader Post Fader
Matrix 1,3,5
MUTE
MUTE
SOLO
Post Fader Post Fader
Post Fader
Matrix 2,4,6
MAIN LRC
OUT
COMP/ EXPAN
mute mute mute mute mute
mute mute mute mute
stereo
mono
stereo
mute
stereo
mono
stereo
stereo
mono
stereo stereo
mono
stereo
TALKBACK
COMP
ON
GAIN
+48V
A/D
GAIN
+
MONO
MONITOR LR OUT
DELAY
DELAY
MONITOR
D/A
PHONES OUT
MONITOR L OUT
D/A MONITOR R
OUT
SOLO / SOURCE
MONITOR SOURCE IN
MI
D
2
GAIN GAIN GAIN
PHONES OUT
Revision 1, 2014-06-27, JD
Midas M32 Block Diagram
P16 BUS
(16ch)
D/A
OUT 1-16
D/A
AUX OUT 1-6
DELAY
GAIN
GAIN GAIN
AES/EBU OUT
GAIN
16 6 16
6
MONITOR LR OUT
2
16 16
8
I/O
PATCH
A/D
INPUT
(1-32)
AES-50 A
(48ch IN)
AES-50 B
(48ch IN)
SLOT
(32ch IN)
AES-50 A
(48ch OUT)
AES-50 B
(48ch OUT)
SLOT
(32ch OUT)
40
AUX RETURN (1-6)
+48V
PHANTOM
A/D
7. Technical Specications
Processing
Input Processing Channels 32 Input Channels, 8 Aux Channels, 8 FX Return Channels
Output Processing Channels 16
16 aux buses, 6 matrices, main LRC 100
Internal Eects Engines (True Stereo / Mono) 16
Internal Show Automation (structured Cues / Snippets) 500 / 100
Internal Total Recall Scenes (incl. Preampliers and Faders) 100
Signal Processing 40-Bit Floating Point
A/D Conversion (8-channel, 96 kHz ready) 114 dB Dynamic Range (A-weighted*)
D/A Conversion (stereo, 96 kHz ready) 120 dB Dynamic Range (A-weighted*)
I/O Latency (Console Input to Output) 0.8 ms
Network Latency (Stage Box In > Console > Stage Box Out) 1.1 ms
Connectors
MIDAS PRO Series Microphone Preamplier (XLR) 32
Talkback Microphone Input (XLR) 1
RCA Inputs / Outputs 2
XLR Outputs 16
Monitoring Outputs (XLR / ¼" TRS Balanced) 2
Aux Inputs/Outputs (¼" TRS Balanced) 6
Phones Output (¼" TRS) 2 (Stereo)
Digital AES/EBU Output (XLR) 1
AES50 Ports (KLARK TEKNIK SuperMAC) 2
Expansion Card Interface 32 Channel Audio Input / Output
ULTRANET P-16 Connector (No Power Supplied) 1
MIDI Inputs / Outputs 1
USB Type A (Audio and Data Import / Export) 1
USB Type B, rear panel, for remote control 1
Ethernet, RJ45, rear panel, for remote control 1
Mic Input Characteristics
Design MIDAS PRO Series
THD+N (0 dB gain, 0 dBu output) < 0.01% (unweighted)
THD+N (+40 dB gain, 0 dBu to +20 dBu output) < 0.03% (unweighted)
Input Impedance (Unbalanced / Balanced) 10 kΩ / 10 kΩ
Non-Clip Maximum Input Level +23 dBu
Phantom Power (Switchable per Input) +48 V
Equivalent Input Noise @ +45 dB gain (150 Ω source) -125 dBu (22 Hz-22 kHz, unweighted)
CMRR @ Unity Gain (Typical) > 70 dB
CMRR @ 40 dB Gain (Typical) > 90 dB

18 M32 DIGITAL CONSOLE Quick Start Guide 19
Input/Output Characteristics
Frequency Response @ 48 kHz Sample Rate 0 dB to -1 dB (20 Hz-20 kHz)
Dynamic Range, Analogue In to Analogue Out 106 dB (22 Hz-22 kHz, unweighted)
A/D Dynamic Range, Preamplier and Converter (Typical) 109 dB (22 Hz-22 kHz, unweighted)
D/A Dynamic Range, Converter and Output (Typical) 109 dB (22 Hz-22 kHz, unweighted)
Crosstalk Rejection @ 1 kHz, Adjacent Channels 100 dB
Output level, XLR Connectors (Nominal / Maximum) +4 dBu / +21 dBu
Output Impedance, XLR Connectors (Unbalanced / Balanced) 50 Ω / 50 Ω
Input impedance, TRS Connectors (Unbalanced / Balanced) 20 kΩ / 40 kΩ
Non-Clip Maximum Input Level, TRS Connectors +21 dBu
Output Level, TRS (Nominal / Maximum) +4 dBu / +21 dBu
Output Impedance, TRS (Unbalanced / Balanced) 50 Ω / 50 Ω
Phones Output Impedance / Maximum output Level 40 Ω / +21 dBu (Stereo)
Residual Noise Level, Out 1-16 XLR Connectors, Unity Gain -85 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, Out 1-16 XLR Connectors, Muted -88 dBu 22 Hz-22 kHz unweighted
Residual Noise Level, TRS and Monitor out XLR Connectors -83 dBu 22 Hz-22 kHz unweighted
Display
Main Screen 7" TFT LCD, 800 x 480 Resolution, 262k Colours
Channel LCD Screen 128 x 64 LCD with RGB Colour Backlight
Main Meter 24 Segment (-57 dB to Clip)
Power
Switch-Mode Power Supply Auto-Ranging 100-240 VAC (50/60 Hz) ± 10%
Power Consumption 120 W
Physical
Standard Operating Temperature Range 5°C – 40°C (41°F – 104°F)
Dimensions 891 x 612 x 256 mm (35.1 x 24.1 x 10.1")
Weight 25 kg (55 lbs)
* A-weighted figures are typically ~3 dB better
Other important information
1. Register online. Please register your new
MUSIC Group equipment right after you purchase it by
visiting midasconsoles.com. Registering your purchase
using our simple online form helps us to process your repair
claims more quickly and eciently. Also, read the terms and
conditions of our warranty, ifapplicable.
2. Malfunction.Should your MUSICGroup
Authorized Reseller not be located in your vicinity, you
may contact the MUSIC Group Authorized Fulller for your
country listed under “Support” at midasconsoles.com.
Shouldyour country not be listed, please check if your
problem can be dealt with by our “OnlineSupport” which
may also be found under “Support” at midasconsoles.com.
Alternatively, please submit an online warranty claim at
midasconsoles.com BEFORE returning theproduct.
3. Power Connections. Before plugging the unit
into a power socket, please make sure you are using the
correct mains voltage for your particular model. Faultyfuses
must be replaced with fuses of the same typeand rating
without exception.
1. Registro online. Le recomendamos que registre
su nuevo aparato MUSIC Group justo después de su compra
accediendo a la página web midasconsoles.com. Elregistro
de su compra a través de nuestro sencillo sistema online nos
ayudará a resolver cualquier incidencia que se presente a la
mayor brevedad posible. Además,aproveche para leer los
términos y condiciones de nuestra garantía, si es aplicable
en sucaso.
2. Averías. En el caso de que no exista un distribuidor
MUSIC Group en las inmediaciones, puede ponerse en
contacto con el distribuidor MUSIC Group de su país,
queencontrará dentro del apartado “Support” de nuestra
página web midasconsoles.com . En caso de que su país no
aparezca en ese listado, acceda a la sección “Online Support”
(quetambiénencontrará dentro del apartado “Support” de
nuestra páginaweb) y compruebe si su problema aparece
descrito y solucionado allí. De forma alternativa, envíenos a
través de la página web una solicitud online de soporte en
periodo de garantía ANTES de devolvernos el aparato.
3. Conexiones de corriente. Antes de enchufar
este aparato a una salida de corriente, asegúrese de que
dicha salida sea del voltaje adecuado para su modelo
concreto. En caso de que deba sustituir un fusible quemado,
deberá hacerlo por otro de idénticas especicaciones,
sinexcepción.
1. Enregistrez-vous en ligne.Prenez le temps
d’enregistrer votre produit MUSIC Group aussi vite que
possible sur le site Internet midasconsoles.com. Le fait
d’enregistrer le produit en ligne nous permet de gérer
les réparations plus rapidement et plus ecacement.
Prenezégalement le temps de lire les termes et conditions
de notre garantie.
2. Dysfonctionnement. Si vous n’avez pas de
revendeur MUSIC Group près de chez vous, contactez le
distributeur MUSIC Group de votre pays: consultez la liste
des distributeurs de votre pays dans la page “Support” de
notre site Internet midasconsoles.com. Si votre pays n’est
pas dans la liste, essayez de résoudre votre problème avec
notre “aideen ligne” que vous trouverez également dans la
section “Support” du site midasconsoles.com. Vous pouvez
également nous faire parvenir directement votre demande
de réparation sous garantie par Internet sur le site
midasconsoles.com AVANT de nous renvoyer le produit.
3. Raccordement au secteur. Avant de relier
cet équipement au secteur, assurez-vous que la tension
secteur de votre région soit compatible avec l’appareil.
Veillez à remplacer les fusibles uniquement par des modèles
exactement de même taille et de même valeur électrique
— sans aucune exception.
1. Online registrieren. Bitte registrieren Sie
Ihr neues MUSIC Group-Gerät direkt nach dem Kauf auf
der Website midasconsoles.com. Wenn Sie Ihren Kauf
mit unserem einfachen online Formular registrieren,
können wir Ihre Reparaturansprüche schneller und
ezienter bearbeiten. Lesen Sie bitte auch unsere
Garantiebedingungen, fallszutreend.
2. Funktionsfehler. Sollte sich kein MUSICGroup
Händler in Ihrer Nähe benden, können Sie den
MUSICGroup Vertrieb Ihres Landes kontaktieren, derauf
midasconsoles.com unter „Support“ aufgeführt ist.
Sollte Ihr Land nicht aufgelistet sein, prüfen Sie bitte,
ob Ihr Problem von unserem „Online Support“ gelöst
werden kann, den Sie ebenfalls auf midasconsoles.com
unter „Support“ nden. Alternativ reichen Sie bitte Ihren
Garantieanspruch online auf midasconsoles.com ein,
BEVOR Sie das Produktzurücksenden.
3. Stromanschluss. Bevor Sie das Gerät an
eine Netzsteckdose anschließen, prüfen Sie bitte, obSie
die korrekte Netzspannung für Ihr spezielles Modell
verwenden. Fehlerhafte Sicherungen müssen ausnahmslos
durch Sicherungen des gleichen Typs und Nennwerts
ersetztwerden.
1. Registre-se online. Por favor, registre seu novo
equipamento MUSIC Group logo após a compra visitando
o site midasconsoles.com Registrar sua compra usando
nosso simples formulário online nos ajuda a processar
seus pedidos de reparos com maior rapidez e eciência.
Além disso, leia nossos termos e condições de garantia,
caso seja necessário.
2. Funcionamento Defeituoso.
Casoseufornecedor MUSIC Group não esteja localizado
nas proximidades, você pode contatar um distribuidor
MUSIC Group para o seu país listado abaixo de “Suporte”
emmidasconsoles.com. Se seu país não estiver na
lista, favorchecar se seu problema pode ser resolvido
com o nosso “Suporte Online” que também pode ser
achado abaixo de “Suporte”em midasconsoles.com.
Alternativamente, favor enviar uma solicitação de garantia
online em midasconsoles.com ANTES da devolução
do produto.
3. Ligações. Antes de ligar a unidade à tomada,
assegure-se de que está a utilizar a voltagem correcta para
o modelo em questão. Os fusíveis com defeito terão de
ser substituídos, sem qualquer excepção, por fusíveis do
mesmo tipo e corrente nominal.
1. ヒューズの格納部/電圧の選択:
ユ ニット を パ ワーソケ ットに 接 続 する 前 に 、
各モデルに対応した正しい主電源を使用し
ていることを確認してください。ユニットに
よっては 、230 Vと120 Vの2つの違うポジ
ションを切り替えて使う、ヒューズの格 納部
を備えているものがあります。正しくない値
のヒューズは、絶対に適切な値のヒューズに
交換されている必要があります。
2. 故障:MUSIC Groupディーラーがお客様
のお近くにないときは、midasconsoles.comの
“Support”内に列記されている、お客様の国
のMUSICGroupディストリビューターにコン
タクトすることができます。お客様の国が
リストに ない 場 合 は 、同じmidasconsoles.com
の“Support”内にある“OnlineSupport”でお客
様の問題が処理できないか、チェックして
みてください。あるいは、商品を返送する前
に、midasconsoles.comで、オンラインの保証
請求を要請してください。
3. 電源接続:電源ソケットに電源コードを
接続する前に、本製品に適切な電圧を使用
してい ることをご 確 認ください 。不具合が
発生したヒューズは必ず電圧および電流、
種類が同じヒューズに交換する必要があり
ます。
Important information
Aspectos importantes
Informations importantes
Weitere wichtige
Informationen
Outras Informações
Importantes
その他の重要な情報

20 M32 DIGITAL CONSOLE Quick Start Guide 21
FEDERAL COMMUNICATIONS
COMMISSION COMPLIANCE
INFORMATION
Responsible Party Name: MUSIC Group Research
UK Limited
Address: Klark Industrial Park,
Walter Nash Road,
Kidderminster. Worcestershire.
DY11 7HJ. England.
Phone Number: [phone]
M32 DIGITAL CONSOLE
complies with the FCC rules as mentioned in the following paragraph:
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his
own expense.
Important information:
Changes or modications to the equipment not expressly approved by MUSIC Group
can void the user’s authority to use the equipment.
M32 DIGITAL CONSOLE
1. 在线注册。 请购买 MUSIC Group 产品后立
即在 midasconsoles.com 网站注册。 网页上有简
单的在线注册表格。 这有助于我们更快更有
效率地处理您维修等事宜。 请阅读保修的相
关条款及条件。
2. 无法正常工作。 若您的 MUSIC Group 产品
无法正常工作, 我们会为您尽快修复。 请联
系您购买产品的销售商。 若你所在地区没有
MUSIC Group 销售商, 请联系 midasconsoles.com
网站的 “WHERETOBUY” 一栏下的所列出的子
公司或经销商。
3. 电源连接。 将本设备连接电源前, 请确
保使用的电压正确。 保险丝需要更换时,
必须使用相同型号及定额的保险丝。
其他的重要信息
Other important information

midasconsoles.com
