Midian MOT-TVS-2-PRO-M User manual

1
MOT-TVS-2-PRO-M
Frequency Hopping, Rolling Code Voice Scrambler for Motorola Professional Series Mobile
Radios
MOT-VPU-15-PRO-M
Voice Inversion Scrambler for Motorola Professional Series Mobile Radios
Manual Revision: 2014-05-19
Covers Software Revisions:
MOT-PRO: 2.95 and Higher
Covers Hardware Revisions:
MOT-PRO: 7313F and Higher
This manual supports the following Midian TVS-2 and VPU-15 scramblers:
MOT-TVS-2-PRO-M & MOT-VPU-15-PRO-M
MOT-TVS-2-PRO-M MOD-1306 & MOT-VPU-15-PRO-M MOD-1306
MOT-TVS-2-PRO-M MOD-1331 & MOT-VPU-15-PRO-M MOD-1331
This manual supports the following radios:
North America: CDM-750, CDM-1250, CDM-1550-LS+
EMEA Region: GM-140, GM-160, GM-340, GM-360, GM-380, GM-640, GM-660, GM-1280
Asia: GM-328, GM-338, GM-338-LS, GM-339, GM-398, GM-399, MCX-720, MCX-760, MCX-780
Latin America: PRO-3100, PRO-5100, PRO-7100, PRO-7200

2
SPECIFICATIONS
Operating Voltage 3.3 VDC
Operating Current 8 mA
Operating Temperature -30 - +60 C
Frequency Response 300-2100 Hz
Input Impedance 200 k
Carrier Suppression 60 dB < Peak Voice
Audio Output Impedance 75 
Tone Distortion <1%
Encryption Specifications
TVS-2: Encryption Sequences +40 Trillion
TVS-2: Random Number Generator 64 bits
TVS-2: Sequence Length (est.) 84 billion years
VPU-15: Inversion Codes Available 37
GENERAL INFORMATION
The MOT-TVS-2-PRO series is a high-level hopping code scrambler that plugs into the Motorola Professional
series radios. Midian’s TVS-2 uses the hopping type rolling code encryption for higher security rather than
sweeping code type and offers 4 user-programmable hop rates and is down gradable to voice inversion. The
scrambler is capable of features such as ANI, ENI, OTAR, Deadbeat Disable, Spy, and more when using Midian’s
Kryptic Signaling format with Midian’s CAD-300 and DDU-300.
The MOT-VPU-15-PRO series is an entry level voice inversion scrambler that plugs into the Motorola
Professional series radios. The scrambler is capable of features such as ANI, ENI, OTAR, Deadbeat Disable,
Spy, and more when using Midian’s Kryptic Signaling format with Midian’s CAD-300 and DDU-300.
For more detailed information on the scramblers’ features, troubleshooting and system information please
reference the TVS-2 Technical Reference Manual.
INSTALLATION OVERVIEW
1. Test the radio for functionality.
2. Program the radio per the Radio Programming Section of this manual.
3. Install the scrambler into the radio per the Hardware Installation Section of this manual.
4. Program the scrambler per the Product Programming Section of this manual.
Note: Midian is not responsible for any damage/loss resulting from the use of Midian’s products.

3
RADIO PROGRAMMING
MOT-TVS-2-PRO-M & MOT-VPU-15-PRO-M for Motorola MDC-1200 capable mobile radios
CDM-750, CDM-1250, GM-140, GM-160, GM-328, GM-338, GM-398, PRO-3100, PRO-5100, PRO-7100
Programming Instructions
It is necessary to program the radio before installing the scrambler. This is because the Option Board Feature
of the radio must be enabled in order to program the scrambler using a RIB box and to hear confirmation beeps
from the radio after programming the scrambler.
1. In the Radio Configuration Window under the Option Board Tab, select Advanced Option Interface as the
Option Board Type. Do not check the Option Board Configuration Download box.
2. When programming the “Conventional Personality”, Pre-Emphasis may be enabled, but De-Emphasis must
be disabled. This is because De-Emphasis will prevent the scrambler from decoding synchronization data.
Compression should not be used with the scrambler. No, or Low Level expansion may be used. Check the
Option Board Feature box for all channels if using a button to control the mode of the scrambler. If doing
scrambling on a per channel basis, then check Option Board Feature only for scrambled channels. It will be
necessary to set the power up state of the scrambler to Scramble for per channel scrambling.

4
The following two steps apply to the accessory connector and may be skipped by most users.
3. An accessory pin may be used to control the transmit mode of the scrambler between scramble and clear.
This is useful in remote control applications. To enable this feature, one of the radio accessory pins must be
assigned to Option Board 1 (Input) via the CPS programmer.
4. An accessory pin may be used to initiate an emergency ANI. This allows for an external emergency foot
switch or button, and frees-up one of the radio front buttons. To enable this feature, one of the radio
accessory pins must be assigned to Option Board 2 (Input) via the CPS programmer. The switch must be
held in the active state for about 2 seconds before an emergency ANI will be sent.
Note: Accessory pin features do not require any special scrambler programming.

5
MOT-TVS-2-PRO-M & MOT-VPU-15-PRO-M
GM-339, GM-340, GM-360, GM-380, GM-399, PRO-7200 Programming Instructions
It is necessary to program the radio before installing the scrambler. This is because the Option Board Feature
of the radio must be enabled in order to program the scrambler using a RIB box and to hear confirmation beeps
from the radio after programming the scrambler.
1. In the Per Radio Miscellaneous Window under the Global Tab, select “Advanced” as the “Option Board Type”
and set the RX Audio (Accessory Connector) to “Filtered Squelched”. Note: The Accessory Connector is the
rear accessory connector, but this setting also affects the audio going to the options connector.
2. For each personality, under the Miscellaneous tab, the “Option Board” must be enabled. Check the Option
Board box for all channels if using a button to control the mode of the scrambler. If doing scrambling on a per
channel basis, then check Option Board Feature only for scrambled channels. It will be necessary to set the
power up state of the scrambler to Scramble for per channel scrambling.
3. For each personality, under the “Audio” tab, the “Voice Pre-emphasis/De-emphasis” must be disabled.

6
MOT-TVS-2-PRO-M MOD-1306 & MOT-VPU-15-PRO-M MOD-1306
CDM-1550-LS+, GM-338-LS Programming Instructions
It is necessary to program the radio before installing the scrambler. This is because the Option Board Feature
of the radio must be enabled in order to program the scrambler using a RIB box and to hear confirmation beeps
from the radio after programming the scrambler.
Conventional Programming:
1. In the Radio Configuration Window under the Option Board Tab, select Advanced Option Interface as the
Option Board Type. Do not check the Option Board Configuration Download box.
2. When programming the “Conventional Personality”, Pre-Emphasis may be enabled, but De-Emphasis must
be disabled. This is because De-Emphasis will prevent the scrambler from decoding synchronization data.
Compression should not be used with the scrambler. No, or Low Level expansion may be used. Check the
Option Board Feature box for all channels if using a button to control the mode of the scrambler. If doing
scrambling on a per channel basis, then check Option Board Feature only for scrambled channels. It will be
necessary to set the power up state of the scrambler to Scramble for per channel scrambling.

7
LTR Programming:
1. In the LS Trunking Personality window, check the Option Board Feature box for each personality. Check the
Option Board Feature box for all channels if using a button to control the mode of the scrambler. If doing
scrambling on a per channel basis, then check Option Board Feature only for scrambled channels. It will be
necessary to set the power up state of the scrambler to Scramble for per channel scrambling.
2. In the LS Trunking Site window Pre-Emphasis should be enabled, but De-Emphasis must not be enabled.
This is because De-Emphasis will prevent the scrambler from decoding synchronization data. The scrambler
by its very nature performs De-Emphasis function. Compression should not be used with the scrambler.
Expansion should also be disabled.

8
The following two steps apply to the accessory connector and may be skipped by most users.
5. An accessory pin may be used to control the transmit mode of the scrambler between scramble and clear.
This is useful in remote control applications. To enable this feature, one of the radio accessory pins must be
assigned to Option Board 1 (Input) via the CPS programmer.
6. An accessory pin may be used to initiate an emergency ANI. This allows for an external emergency foot
switch or button, and frees-up one of the radio front buttons. To enable this feature, one of the radio
accessory pins must be assigned to Option Board 2 (Input) via the CPS programmer. The switch must be
held in the active state for about 2 seconds before an emergency ANI will be sent.
Note: Accessory pin features do not require any special scrambler programming.

9
MOT-TVS-2-PRO-M MOD-1331 & MOT-VPU-15-PRO-M MOD-1331 for MPT-1327 Trunking Radios
GM-640, GM-660, GM-1280, MCX-720, MCX-760, MCX-780 Programming Instructions
It is necessary to program the radio before installing the scrambler. This is because the Option Board Feature
of the radio must be enabled in order to program the scrambler using a RIB box and to hear confirmation beeps
from the radio after programming the scrambler.
1. In the Per Radio Parameters Window set the “Option Board Fitted Mode” as “Advanced”.
2. Edit the ‘MPT Personality’. In the “Options” window, check the “Option Board Enable” box. Check Option
Board Enable for all channels if using a button to control the mode of the scrambler. If doing scrambling on a
per channel basis, then check Option Board Enable only for scrambled channels. It will be necessary to set
the power up state of the scrambler to Scramble for per channel scrambling.

10
3. If using conventional channels, edit the ‘Conventional Personality Data’. In the “Conventional Personality”
window, check the “Option Board Enable” box. Check Option Board Enable for all channels if using a button
to control the mode of the scrambler. If doing scrambling on a per channel basis, then check Option Board
Enable only for scrambled channels. It will be necessary to set the power up state of the scrambler to
Scramble for per channel scrambling.

11
HARDWARE INSTALLATION
Be certain to follow standard anti-static procedures when handling any of Midian’s products.
Radio Firmware: For the mobile radios listed, it is necessary to have radio firmware version R05.00.00 or higher.
If the radio has an older firmware version, it is necessary to upgrade to the newest firmware.
Verifying the firmware version can be done several ways. On most radios, this information is on a label on the
bottom of the radio. For display radios, selecting the SoftwareVer# option from the utility menu will report the
version. Consult Motorola if you cannot determine the firmware version.
Disassembling the Radio:
Additional disassembly instructions are also available in Motorola’s Basic Service Manual.
1. Disconnect power.
2. Remove plastic cover from the radio chassis by prying the sides away and lifting up.
3. Remove the 6 retaining bolts from the metal lid using a Torx™ size 20 screwdriver. Carefully begin removing
the lid. If there is already an option board installed such as a voice storage board, disconnect it by gently
lifting the latch holding the 40-pin flex cable in place.
4. Remove the lid completely. Unscrew the three bolts holding the option board frame to the lid if one is present.
Note: It is not recommended to use the radio for transmitting while disassembled, as some model radios require
the lid to be installed for RF power.
Installing the Scrambler:
1. Insert the 40-pin flex cable into the 40-pin flex connector on the scrambler, making certain it is seated
properly, then close the latch. The silver foil side of the flex should face the edge of the board.

12
2. The scrambler is then mounted into the metal lid of the radio using the option board mounting kit. See pictures
below. The mounting kit is ordered from Midian as PRO Option B or from Motorola as RLN4823B. The
mounting kit includes the 40-pin flex cable, the mounting frame and 3 mounting screws.
Reassembling the Radio:
Additional assembly instructions are also available in Motorola’s Basic Service Manual.
1. Once scrambler is installed in the lid, insert the other side of the 40-pin flex cable into the 40-pin flex
connector on the radio’s main board. The shiny side of the flex should face down.
2. Reinstall the metal lid making sure the flex bends toward the back of the radio, otherwise it will be pinched by
the lid. Tighten the screws down in number sequence shown on the lid to 17 in lbs (1.9 NM) torque. Repeat to
verify torque is correct after completing the sequence.
3. Snap on plastic cover.
HARDWARE ALIGNMENT
The MOT-TVS-2-PRO-M series does not require any hardware adjustments, however, when ordering the
scrambler, the radio it will be used in must be specified. The scrambler will come modified by Midian for the
proper model of radio. If for some reason you decide to modify the board because the radio changes, the table
below indicates the parts to change. For example if changing a PRO-M module into a PRO-M MOD-1306; R-3
and R-21 would need to change values.
Scrambler R-1 R-3 R-8 R-12 R-17 R-21 R-23 R-25 R-36 C-33
PRO-M 750 K 300 K N/A 62 K 27 K 100 K 150 K 100 K 0 Ohm N/A
PRO MOD-1306 750 K 750 K N/A 62 K 27 K 91 K 150 K 100 K 0 Ohm N/A
PRO MOD-1331 910 K 910 K 27 K 27 K N/A 47 K 62 K 62 K N/A .01 uf

13
PRODUCT PROGRAMMING
Install the MPS programming software if you have not done so already. The MOT-TVS-2-PRO series version 2.8
and higher can be programmed via the Motorola RIB box.
Start the MPS software. From the product selection screen on the MPS software, locate and select MOT-TVS-2-
PRO or MOT-VPU-15-PRO and the desired model and click OK. The following table shows the proper MPS
selection based upon the model scrambler ordered.
PRO-M (MDC Mobile) MOT-TVS-2-PRO-M or MOT-VPU-15-PRO-M
PRO-M (LTR Mobile) MOT-TVS-2-PRO-M MOD-1306 or MOT-VPU-15-PRO-M MOD-1306
PRO-ME (5-Tone or MPT
Mobile) MOT-TVS-2-PRO-M, MOT-VPU-15-PRO-M, MOT-TVS-2-PRO-M MOD-1331 or MOT-VPU-15-PRO-M MOD-1331
Configure the programming software by selecting File->Preferences. Select the appropriate COM port. If using the
RIB box, make certain there is a check mark next to ‘Rib Box Enable’ by clicking on it.
Set the parameters of the MOT-TVS-2-PRO software to fit the application. If any clarifications on a feature are
required, move the mouse cursor over the feature name until the question mark appears and right click, an on-line
help for that feature will be shown. On the radio tab it is necessary to select the proper Radio Model. If the correct
product was selected in the step above then it will be preset in the default file. The following table indicates the
proper Radio Model Selection for the scrambler ordered:
(A) MDC/LTR Mobile MOT-TVS-2-PRO-M, MOT-VPU-15-PRO-M, MOT-TVS-2-PRO-M
MOD-1306 or MOT-VPU-15-PRO-M MOD-1306
(6) 5-Tone or MPT Mobile MOT-TVS-2-PRO-M, MOT-VPU-15-PRO-M, MOT-TVS-2-PRO-M
MOD-1331 or MOT-VPU-15-PRO-M MOD-1331
After entering the parameters, save the file by going to File - Save As. Enter the file name in the File Name block
and click Save. Saving the file will allow for quick and easy reprogramming of units. Turn power on to the radio
and then the RIB. Click ProgramUnit! in the MPS software. You will hear 1-3 beeps from the radio if programmed
successfully.
To read the parameters from the scrambler, Click on ReadUnit!.

14
The radio and RIB should be powered down for 3 seconds after reading or programming.
Important Note: Do not attempt to ‘clone’ the scrambler by reading one and then programming another. When
the scrambler is read, the security codes will be read out as zeroes. If another scrambler is then cloned with this
information, the scramblers will be incompatible because they have different security codes. To ensure
scramblers communicate with each other, program them from a saved file.

15
OPERATION
Mode Selection: Mode selection means a method of turning the scrambler on and off. In the MOT-TVS-2-PRO
and MOT-VPU-15-PRO series there are two ways of doing this:
Per-Channel Scramble On/Off: To use this feature each channel that is designated as a Scrambled channel
should have the Option Board Feature box enabled in the radio programming software. Channels that are
designated as Clear should NOT have the Option Board feature box enabled. Additionally the Power-Up State in
the MPS software should be set to Scramble. When using Per-Channel Scrambling, a button should NOT be
programmed for Mode Select in the MPS software.
Scramble On/Off Button: To use this feature each channel should have the Option Board Feature box enabled
in the radio programming software. The desired button should be programmed to no function in the radio
programming software. In the MPS software on the Radio tab in the Button Assignment area set the desired
button to “Mode Select”. Pressing and releasing this button will toggle the mode of the scrambler between
scramble and clear. A medium tone followed by a high tone indicates the scrambler is in Scramble mode and a
medium tone followed by a low tone indicates the scrambler is in Clear mode. Also on the Radio tab under the
Miscellaneous section
Code Selection: The TVS-2 or VPU-15 can have up to 4 different codes programmed.
Code Selection Button: To use this feature multiple security codes must be programmed into the TVS-2 or VPU-
15 scrambler. The desired button should be programmed to no function in the radio programming software. In the
MPS software on the Radio tab in the Button Assignment area set the desired button to “Code Select”. Pressing
and releasing this button will step the scrambler to the next security code. The scrambler will emit a number of
beeps corresponding to the code number the scrambler stepped to (i.e. 2 beeps equals security code 2). The
maximum number of codes is 4.
Password: If the password function is enabled the correct password (4 digits using 0-9) must be entered on a
compatible numeric keypad on power up. If the correct password is not entered within 5 attempts the unit will be
disabled. If the radio does not have a compatible numeric keypad do not enable this feature.
Midian’s Kryptic Signaling:
Midian’s TVS-2 and VPU-15 offer the following signaling functions:
ANI: When the PTT button is pressed the scrambler will generate an ANI to be decoded by Midian’s CAD-300 or
DDU-300.
Emergency ANI (ENI): When the Emergency button on the radio is pressed and held for 1 second the scrambler
will key the radio and transmit the ENI to be decoded by Midian’s CAD-300 or DDU-300.
Selective Call: The scrambler can be selectively called from Midian’s CAD-300 or DDU-300. When the scrambler
is called it will generate ringing beeps out the radio’s speaker.
Radio Kill: The scrambler can be disabled and re-enabled from Midian’s CAD-300 or DDU-300. When the
scrambler receives a disable command it will not allow any receive or transmit audio to pass through the
scrambler or for a PTT command to be given to the radio if the PTT path is controlled by the scrambler. When the
scrambler receives an enable command it will resume normal operation.
Spy: The scrambler can be sent a command from Midian’s CAD-300 or DDU-300 to key the radio and transmit
ambient noise from the microphone for 00-90 seconds in 10 second increments. This time is preprogrammed into
the scrambler.
Query: This command sent from Midian’s CAD-300 or DDU-300 will report to the CAD or DDU if the
scrambler/radio is currently on or off.

16
TECHNICAL NOTES
Radio Compatibility: Midian has taken the utmost care to ensure the option board integrates into the radio with
minimal impact to the features of the radio. However, some features may not be available in the radio when an
option board is used. If a feature is not available, please contact Midian to see if the feature can be added.
Radio Firmware: Midian recommends having the latest firmware in the radio when installing the scrambler.
However, it should be noted that occasionally firmware updates may cause a conflict with proper option
board/radio communications. This may appear that the scrambler is not working properly, but it is a conflict in the
serial communication between the option board and radio. If this happens it will be necessary to go back to the
original firmware revision.
Please note that firmware versions between the EMEA region and the Asia and America regions might be
different.
Scan: Midian strongly recommends not using the radio’s Scan function when using voice scramblers. First of all
synchronization packets will most likely not be decoded by the receiving radios, as the receiving radio may be
looking at a different channel when sync is transmitted. Additionally if using a combination of scrambling on a per-
channel basis and a mode select button to control the state of the scrambler, when the scan function is used the
radio will ignore the button. This is best resolved by using per-channel scrambling OR a mode select button, but
not both. If using scan and a mode-select button the Option Board Feature box in the radio programming section
must be enabled on all channels.
Known Issues: The "Enable Wired PTT" function on the "Radio" screen of the MPS UP is obsolete. This box
should never be checked. The "Combo (press & hold)" and "Emerg (press & hold)" are not supported on the P1,
P2, and P3 buttons when using Enhanced Integration. Use of the System Scan feature of the radio has been
known to cause a problem whereby the transmitter stays on the air 3 seconds after PTT is released. Checking the
"Reserved Function" box on the "Advanced" screen of the MPS UP works around this radio problem.
Accessory Pin Features: Upon power-up, the radio does not always report the state of the accessory pins to
the option board. It may be necessary to toggle the state of these inputs once after power-up to ensure correct
operation.
Option Board Feature: Enabling the option board feature tells the radio to report events such as button press,
PTT press, carrier detect, etc. to the option board. This feature enables communication between the option board
and the radio.
When controlling the scrambler with a radio button, it is absolutely required to enable this feature on all channels.
For scrambling on a per channel basis only enable the option board on scrambled channels and the power up
mode of the scrambler should be Scramble. On display models, the following icon appears on the LCD when
option board mode is on:
Known Issues: The radio must be off for a full 3 seconds prior to being turned on or the scrambler cannot reset
properly resulting in malfunction. The "Enable LCD Message" option in the MPS UP should not be enabled due to
problems in the radio. If problems are experienced when reading the scrambler from the RIB box, use the MPS
cable.

17
MIDIAN CONTACT INFORMATION
MIDIAN ELECTRONICS, INC.
2302 East 22nd Street
Tucson, Arizona 85713 USA
Toll-Free: 1-800-MIDIANS
Main: 520-884-7981
E-mail: [e-mail]
Web: www.midians.com

- This page intentionally left blank-

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
OSC2 36
TCMP
33
VDD 38
VPP 43
SS
32
B3 11
D7
34
OSC1 37
B0 8
B1
9
A5
2
A6
1
A7
44
A4
3
A3
4
A2
5
A1
6
A0
7
C4
21
C5
20
C3
23
C0
26
C1 25
C2
24
C6
19
C7 18
B4 12
B7
15
B6
14
GND 17
RES
41
B2 10
TCAP
35
IRQ 42
B5 13
SCK
31
MOSI
30
MISO
29
RDI
27
TDO
28
NC1 16
NC2
22
NC3 39 NC4 40
68705FPHS
IC1
10K
R32
PAD1
PAD2
Vddd
*
C3
*
C33
.01u
C2
*
R39
D
C
B
10K
R35
Vddd
*
R40
0R
R33
3 2
1
*
IC8
*
R9
VdddVddd
100p
C32
0R
R6
300K
R3
39p
C6
1.8M
R4
4.7K
R5
.0068u
C7
-
+
2
3
1
LMV324
IC7:1
-
+
6
5
7
LMV324
IC7:2
-
+
9
10
8
LMV324
IC7:3
-
+
13
12
14
LMV324
IC7:4
A
X0
X1
X
4053
IC9:1
B
Y1
Y0
Y
4053
IC9:2
C
Z
Z0
Z1
E
VCC
VEE GND
4053
IC9:3
39p
C5
1.2M
R2
750K
R1
0R
R36
27K
R17
*
R8
.0068u
C10
.0068u
C11
8.2K
R18
56K
R19
36K
R20
.001u
C12
1.2M
R22
100K
R21
.1u
C19
Vddd
.1u
C9
18K
R10
BSS
Q1
100K
R11
62K
R12
36K
R13
-
+
2
3
1
TLV2375
IC6:1
-
+
6
5
7
TLV2375
IC6:2
-
+
11
12
10
TLV2375
IC6:3
-
+
15
14
16
TLV2375
IC6:4
3/4SHDN
9
1/2SHDN 8
TLV2375
IC6:6
OSC1 18
OSC2
17
A4 3
A0
19
A1 20
MCLR 4
VDD
15
VDD
16
VSS
5
VSS
6
B6 13
B7
14
B1 8 B2 9 B3 10 B4 11
B0
7
B5 12
A2 1
A3
2
16F716
IC2
Vddd
36K
R16
10K1%
R14
10K1%
R15
100p
C31
39p
C13
1
2
3
4
5
6 7
8
LTC1069
IC5
Vddd
.1u
C16 +
4.7u
C30
.1u
C14
.001u
C15
22p
C4
36K
R24
150K
R23
100K
R25
0R
R31
22p
C27
*
C8
10K
R26
0R
R30
22p
C23
82p
C22
39p
C21
150p
C20
470p
C24
VS 1
GND
2
OUT 3
TRG
4
THS
5
MIC555
IC4
4.7K
R28
1K Ohms
RC18
Vddd
3.58 MHz.
Y1
4.7M
R29 22p
C26
22p
C25
CS
1
SCLK
2
SI
3
SO
4
VCC 8
NC1 7
NC2 6
GND 5
9346
IC3
100K
R7
.1u
C17
Vddd
10K
R38
0R
R37
Vddd
RESET
*
R630
*
R625
*
R34
100p
C615
SJ2
SJ4
SHDN 7
V+ 4
CLK 8
IN
2OUT 5
COM
1
OS
6
V-
3
7427
IC10
Vddd
4.7K
R41
.01u
C34
CP
CJS
1999-11-01 DML
2014-05-09
H-2
1 of 2 7313
MIDIAN ELECTRONICS, INC.
DATE:
DESIGN:
DWN BY:
REV:
APPR
COPYRIGHT ©
REV
SHEET PROJECT NUMBER
DOCUMENT NAME
SCHEMATIC
2012
MOT-TVS-2/MOT-VPU-15
PRO-M
VDDD
GND
RDY
PTT
MISO
DATA2
DATA1
OPT-ENACLK2
CLK1
TX IN
RX IN
DISC IN
TX OUT
RX OUT
A2
A1
D2
D1
*
C613
PIC201
PIC202
COC2
PIC301
PIC302
COC3
PIC401 PIC402
COC4
PIC501 PIC502
COC5
PIC601 PIC602
COC6
PIC701
PIC702
COC7
PIC801 PIC802
COC8
PIC901 PIC902
COC9
PIC1001PIC1002
COC10
PIC1101PIC1102
COC11
PIC1201
PIC1202
COC12
PIC1301
PIC1302
COC13
PIC1401
PIC1402
COC14
PIC1501
PIC1502
COC15
PIC1601
PIC1602
COC16
PIC1701
PIC1702
COC17
PIC1901
PIC1902
COC19
PIC2001PIC2002
COC20
PIC2101 PIC2102
COC21
PIC2201 PIC2202
COC22
PIC2301 PIC2302
COC23
PIC2401
PIC2402
COC24
PIC2501
PIC2502
COC25
PIC2601
PIC2602
COC26
PIC2701
PIC2702
COC27
PIC3001
PIC3002
COC30
PIC3101
PIC3102
COC31
PIC3201
PIC3202
COC32
PIC3301
PIC3302
COC33
PIC3401
PIC3402
COC34
PIC61301
PIC61302
COC613
PIC61501
PIC61502
COC615
PIIC101
PIIC102
PIIC103 PIIC104 PIIC105 PIIC106 PIIC107
PIIC108
PIIC109
PIIC1010
PIIC1011
PIIC1012
PIIC1013
PIIC1014
PIIC1015
PIIC1016
PIIC1017
PIIC1018
PIIC1019
PIIC1020
PIIC1021
PIIC1022
PIIC1023
PIIC1024
PIIC1025
PIIC1026
PIIC1027
PIIC1028
PIIC1029
PIIC1030
PIIC1031
PIIC1032
PIIC1033
PIIC1034
PIIC1035
PIIC1036
PIIC1037
PIIC1038 PIIC1039PIIC1040
PIIC1041
PIIC1042PIIC1043
PIIC1044
COIC1
PIIC201
PIIC202
PIIC203
PIIC204
PIIC205 PIIC206 PIIC207
PIIC208 PIIC209 PIIC2010PIIC2011 PIIC2012PIIC2013
PIIC2014
PIIC2015
PIIC2016
PIIC2017
PIIC2018
PIIC2019
PIIC2020
COIC2
PIIC301
PIIC302
PIIC303
PIIC304
PIIC305
PIIC306
PIIC307
PIIC308
COIC3
PIIC401
PIIC402
PIIC403
PIIC404
PIIC405
COIC4
PIIC501
PIIC502
PIIC503
PIIC504
PIIC505
PIIC506 PIIC507
PIIC508
COIC5
PIIC601
PIIC602
PIIC603
COIC6:1
PIIC605
PIIC606
PIIC607
COIC6:2
PIIC6010
PIIC6011
PIIC6012
COIC6:3
PIIC6014
PIIC6015
PIIC6016
COIC6:4
PIIC608
PIIC609
COIC6:6
PIIC701
PIIC702
PIIC703
COIC7:1
PIIC705
PIIC706
PIIC707
COIC7:2
PIIC708
PIIC709
PIIC7010
COIC7:3
PIIC7012
PIIC7013
PIIC7014
COIC7:4
PIIC801
PIIC802PIIC803
COIC8
PIIC9011
PIIC9012
PIIC9013
PIIC9014
COIC9:1
PIIC901
PIIC902
PIIC9010
PIIC9015
COIC9:2
PIIC903
PIIC904
PIIC905
PIIC906 PIIC907 PIIC908
PIIC909 PIIC9016
COIC9:3
PIIC1001
PIIC1002
PIIC1003
PIIC1004
PIIC1005
PIIC1006
PIIC1007PIIC1008
COIC10
PIPAD101
COPAD1
PIPAD201
COPAD2
PIPAD301
COPAD3
PIPAD401
COPAD4
PIPAD501
COPAD5
PIQ10D
PIQ10G
PIQ10S
COQ1
PIR101PIR102
COR1
PIR201 PIR202
COR2
PIR301PIR302
COR3
PIR401 PIR402
COR4
PIR501PIR502
COR5
PIR601 PIR602
COR6
PIR701
PIR702
COR7
PIR801 PIR802
COR8
PIR901
PIR902
COR9
PIR1001
PIR1002
COR10
PIR1101
PIR1102
COR11
PIR1201PIR1202
COR12
PIR1301PIR1302
COR13
PIR1401
PIR1402
COR14
PIR1501
PIR1502
COR15
PIR1601
PIR1602
COR16
PIR1701 PIR1702
COR17
PIR1801
PIR1802
COR18
PIR1901PIR1902
COR19
PIR2001 PIR2002
COR20
PIR2101
PIR2102
COR21
PIR2201 PIR2202
COR22
PIR2301PIR2302
COR23
PIR2401 PIR2402
COR24
PIR2501PIR2502
COR25
PIR2601 PIR2602
COR26
PIR2801
PIR2802
COR28
PIR2901
PIR2902
COR29
PIR3001PIR3002
COR30
PIR3101PIR3102
COR31
PIR3201
PIR3202
COR32
PIR3301 PIR3302
COR33
PIR3401
PIR3402
COR34
PIR3501
PIR3502
COR35
PIR3601PIR3602
COR36
PIR3701 PIR3702
COR37
PIR3801
PIR3802
COR38
PIR3901PIR3902
COR39
PIR4001PIR4002
COR40
PIR4101 PIR4102
COR41
PIR62501 PIR62502
COR625
PIR63001 PIR63002
COR630
PIRC1801
PIRC1802
CORC18
PISJ201 PISJ202
COSJ2
PISJ401 PISJ402
COSJ4
COtb0sch1
PIY101
PIY102
COY1

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
CP
CJS
1999-11-01 DML
2014-05-09
H-2
2 of 2 7313
MIDIAN ELECTRONICS, INC.
DATE:
DESIGN:
DWN BY:
REV:
APPR
COPYRIGHT ©
REV
SHEET PROJECT NUMBER
DOCUMENT NAME
SCHEMATIC
2012
MOT-TVS-2/MOT-VPU-15
PRO-M
*
D601
*
D602
*
D603
*
D604
*
D605
*
D606
*
R618
*
R619
*
R620
*
R621
*
R622
*
R623
*
Q603
*
Q602
*
R633
*
R646
*
R632
*
R648
*
C616
*
R647
J602:18
J601:3
*
R649
Vddd SW_B+
SW_B+
SJ1
TP2
100p
C610
Vddd
*
R629
*
R638
*
R631
*
C611
*
C612
*
R601
*
R602
*
R603
*
R607
*
R604
*
R608
*
R605
*
R609
*
R606
*
R610
1K
R611
1K
R612
*
R613
*
C609
-
+
4
3
1*
25
IC602
Vddd Vddd
Vddd Vddd
ROW1
ROW2 ROW3 ROW4 ROW5
COL1
COL2 COL3 COL4 COL5
411
LMV324
IC7:5
413
TLV2375
IC6:5
Vddd Vddd
SJ6 SJ7
*
Q601
1
B4
1
B5
1
B6
1
B7
1
B8
1
B9
1
B10
1
B11
1
B12
1
B13
1
B14
1
B15
1
B16
1
B17
1
B18
1
B19
1
B20
1
B21
ROW3
ROW4 ROW5
COL5
COL1 COL2 COL3
ROW1
COL1
COL2
COL3
ROW2
COL1
COL2
COL3
ROW3
COL1
COL2
COL3
ROW4
COL1
COL2
COL3
ROW5
KEY_INTRP
LED ENA
RW1RW2
A02 A01
LCD SEL
VDDD
GND
LED PWR
100p
C617
EXT MIC
PIB401 PIB402 PIB403
COB4
PIB501 PIB502 PIB503
COB5
PIB601 PIB602 PIB603
COB6
PIB701 PIB702 PIB703
COB7
PIB801 PIB802 PIB803
COB8
PIB901 PIB902 PIB903
COB9
PIB1001 PIB1002 PIB1003
COB10
PIB1101 PIB1102 PIB1103
COB11
PIB1201 PIB1202 PIB1203
COB12
PIB1301 PIB1302 PIB1303
COB13
PIB1401 PIB1402 PIB1403
COB14
PIB1501 PIB1502 PIB1503
COB15
PIB1601 PIB1602 PIB1603
COB16
PIB1701 PIB1702 PIB1703
COB17
PIB1801 PIB1802 PIB1803
COB18
PIB1901 PIB1902 PIB1903
COB19
PIB2001 PIB2002 PIB2003
COB20
PIB2101 PIB2102 PIB2103
COB21
PIC60901PIC60902
COC609
PIC61001
PIC61002
COC610
PIC61101
PIC61102
COC611
PIC61201
PIC61202
COC612
PIC61601
PIC61602
COC616
PIC61701
PIC61702
COC617
PID60101
PID60102
COD601
PID60201
PID60202
COD602
PID60301
PID60302
COD603
PID60401
PID60402
COD604
PID60501
PID60502
COD605
PID60601
PID60602
COD606
PIIC604
PIIC6013
COIC6:5
PIIC704
PIIC7011
COIC7:5
PIIC60201
PIIC60202
PIIC60203
PIIC60204
PIIC60205
COIC602
PIJ60103
COJ601:3
PIJ602018
COJ602:18
PIQ6010B
PIQ6010C
PIQ6010E
COQ601
PIQ6020B
PIQ6020C
PIQ6020E
COQ602
PIQ6030B
PIQ6030C
PIQ6030E
COQ603
PIR60101
PIR60102
COR601
PIR60201
PIR60202
COR602
PIR60301 PIR60302
COR603
PIR60401PIR60402
COR604
PIR60501 PIR60502
COR605
PIR60601PIR60602
COR606
PIR60701 PIR60702
COR607
PIR60801PIR60802
COR608
PIR60901 PIR60902
COR609
PIR61001PIR61002
COR610
PIR61101
PIR61102
COR611
PIR61201
PIR61202
COR612
PIR61301PIR61302
COR613
PIR61801
PIR61802
COR618
PIR61901
PIR61902
COR619
PIR62001
PIR62002
COR620
PIR62101
PIR62102
COR621
PIR62201
PIR62202
COR622
PIR62301
PIR62302
COR623
PIR62901
PIR62902
COR629
PIR63101
PIR63102
COR631
PIR63201
PIR63202
COR632
PIR63301
PIR63302
COR633
PIR63801 PIR63802
COR638
PIR64601
PIR64602
COR646
PIR64701 PIR64702
COR647
PIR64801
PIR64802
COR648
PIR64901PIR64902
COR649
PISJ101 PISJ102
COSJ1
PISJ601 PISJ602
COSJ6
PISJ701PISJ702
COSJ7
COtb0sch2
PITP201
COTP2
