Miele professional PW 6088 User manual

Operating and installation instructions
for washer-extractor
PW 6088
To avoid the risk of accidents or
damage to the machine it is
essential to read these instructions
before it is installed and used for the
first time. M.-Nr. 09 592 250
en - AU, NZ

Disposal of the packing
material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Recycling packaging materials saves
raw materials and reduces the amount
of waste produced. Rather than just
throwing these materials away, please
ensure they are recycled.
Ensure that any plastic wrappings,
bags, etc are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposing of your old machine
Electrical and electronic machines
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your machine.
Please do not therefore dispose of it
with your general waste.
Please dispose of it at your local
community waste collection/recycling
centre or contact your dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
Energy saving tips
Energy and water consumption
–Water consumption and energy
usage are determined by the size of
the load.
To make the most out of your
machine, load the maximum dry load
for the programme you are using.
Detergent
–Do not exceed the amounts of
detergent recommended by the
manufacturer on the packaging.
– Reduce the amount of detergent for
smaller loads.
When drying with a tumble dryer
Selecting the highest possible spin
speed for the wash programme will
save energy when drying in a tumble
dryer afterwards.
Caring for the environment
2

Caring for the environment..........................................2
Warning and Safety instructions .....................................6
Operating the machine ............................................14
Control panel .....................................................14
Before using for the first time.........................................14
Display ..........................................................15
Operating a wash-salon machine .....................................17
Tips ............................................................18
1. Sort the laundry .................................................18
2. Load the drum ..................................................19
3. Select a programme .............................................19
Garment care label symbols ........................................20
Short instructions ................................................21
Select a programme...............................................25
Selecting/changing a programme .....................................25
Saving a favourite programme .......................................27
Extras ..........................................................28
Pre-wash ........................................................28
Starch stop.......................................................28
Rinse hold .......................................................29
Intensive* ........................................................29
Water plus* ......................................................29
Timer ...........................................................30
Spinning ........................................................31
Maximum final spin speed...........................................31
Rinse and interim spin ...........................................31
To omit the final spin (Rinse hold) ..................................31
To omit the spin between rinses and the final spin .....................31
Changing the programme sequence .................................32
Payment system...................................................32
Interrupting a programme ...........................................32
To cancel a programme ............................................32
Changing a programme ............................................32
Contents
3

Detergent .......................................................33
Water softeners ...................................................33
Washing with several components ....................................33
Colour run and dye removers/dyes ....................................33
Fabric conditioners, liquid starch and starch formulations ..................34
Automatic dispensing of fabric conditioner or liquid
starch to laundry at the end of a programme ..........................34
Adding fabric conditioner or liquid starch separately ...................34
Adding starch separately .........................................34
Adding starch separately using Starch stop ..........................34
External dispensing system..........................................35
Empty sensor ..................................................35
Cleaning and care ................................................37
Cleaning the machine ..............................................37
Cleaning the water inlet filters ........................................40
Problem solving guide ............................................41
Problem solving guide ..............................................41
The programme does not start .......................................41
A fault message appears in the display ................................42
General problems .................................................43
An unsatisfactory wash result ........................................44
The door will not open ..............................................45
To continue a programme after a power cut .............................45
Peak load cut-out..................................................46
Service interval ...................................................46
Opening the drum door in the event of a
blocked drain outlet and/or power failure ...............................47
Drain the machine. ..............................................47
Cleaning the drainage system .....................................48
Opening the drum door ..........................................49
After sales service ................................................50
Repairs..........................................................50
PC / Optical interface...............................................50
Optional accessories ...............................................50
Contents
4

Installation ......................................................51
Front view........................................................51
Rear view ........................................................52
Side view ........................................................53
Bird's eye view....................................................53
Installing the machine ..............................................53
Installation on a raised plinth .........................................54
Payment system...................................................54
Installation surface.................................................55
Removing the transit bars ...........................................55
Re-fitting the transit bars ............................................56
Levelling the machine ..............................................57
Plumbing ........................................................58
IMPORTANT Australia and New Zealand. ............................58
Connection to the cold water supply ................................58
Hot water connection ............................................59
Recycled water connection .......................................59
Hot water supply................................................59
Water drainage ...................................................60
Drain valve version ..............................................60
Machines with a drain pump ......................................60
Electrical connection ...............................................61
Technical data ...................................................62
Contents
5

~It is essential to read these instructions.
This machine conforms to current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the machine,
please read these instructions carefully before using it for the first
time. They contain important information on its safety, use and
maintenance.
Keep these instructions in a safe place and ensure that they are
made available to new users. They must be made aware of these
warning and safety instructions.
Correct application
~This machine is designed for domestic use and for use in similar
environments by guests in hotel or motel rooms, bed & breakfasts
and other typical living quarters. This does not include
common/shared facilities or commercial facilities within hotels,
motels or bed & breakfasts. It must only be used to wash garments
which have been declared suitable for washing by the manufacturer
indicated on the garment care label.
Any other use may be dangerous. The manufacturer can not be held
liable for damage resulting from incorrect or improper use
oroperation.
Warning and Safety instructions
6

~This machine must be used as described in these operating
instructions and must be checked on a regular basis to make sure it
is functioning correctly. Maintenance must be carried out when
necessary.
~This machine is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they have been shown how
to use it correctly by a person responsible for their safety.
~The machine is not suitable for outdoor use.
~This machine must not be installed and operated in mobile
installations (e.g. on a ship).
Warning and Safety instructions
7

Safety with children
~Keep children away from the machine at all times. It is not a toy!
To avoid the risk of injury, do not allow children to play on or near it
or to play with its controls. Supervise children whilst you are using it.
~Older children may only use the machine if its operation has
been clearly explained to them and they are able to use it safely,
recognising the dangers of misuse.
~For machines with a 'porthole' door, remember that the porthole
glass will be hot when washing at very high temperature.
Do not let children touch it.
Warning and Safety instructions
8

Technical safety
~Before setting up the machine, check it for any externally visible
damage.
Do not install or use a damaged machine.
~Before connecting the machine, ensure that the connection data
on the data plate (voltage and rated load) match the mains
electricity supply. If in any doubt, consult a qualified electrician.
~The electrical safety of this machine can only be guaranteed
when continuity is complete between it and an effective earthing
system which complies with local and national safety regulations. It
is most important that this basic safety requirement is present and
regularly tested and, where there is any doubt, the on-site wiring
system should be inspected by a qualified electrician. The
manufacturer cannot be held liable for the consequences of an
inadequate earthing system (e.g. electric shock).
~Do not connect the machine to the mains electricity supply by an
extension lead. Extension leads do not guarantee the required
safety of the appliance (e.g. danger of overheating).
~Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs should only be
undertaken by a Miele approved service technician. If this is not
done, any resultant damage will not be covered by the warranty.
Ensure current is not supplied to the machine until after
maintenance or repair work has been carried out.
~Do not make any alterations to the machine, unless authorised to
do so by Miele.
~If the connection cable is faulty, it must only be replaced by a
Miele approved service technician to protect the user from danger.
Warning and Safety instructions
9

~In the event of a fault or for cleaning purposes, the machine is
only completely isolated from the electricity supply when:
–it is switched off at the wall socket and the plug is withdrawn, or
–it is switched off at the mains, or
–the screw-out fuse is removed (in countries where this is
applicable).
~This machine must only be connected to the on-site water supply
using a hose that is in good condition. Old hoses must not be
re-used. Check the hose regularly for signs of wear. Change in good
time to avoid the risk of leaks and subsequent damage.
~Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can the safety
standards of the machine be guaranteed.
~Do not use force to open the drum door. The door handle is fitted
with a safety device to ensure that the door lock functions correctly.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the machine and its
surroundings in a clean condition at all times. Any damage which
may be caused by cockroaches or other vermin will not be covered
by the manufacturer's warranty.
Warning and Safety instructions
10

Correct use
~Do not install your machine in rooms where temperatures below
freezing may occur. Frozen hoses may burst or split. The reliability
of the electronic control unit may be impaired at temperatures below
freezing point.
~Before using the machine for the first time, check that the transit
bars at the rear of the machine have been removed (see section on
"Installation"). During spinning, a transit bar which is still in place
may result in damage to both the machine and adjacent furniture or
appliances.
~Turn off the tap if the machine is to be left for any length of time
(e.g. holiday), especially if there is no floor drain (gully) in the imme-
diate vicinity.
~Flooding danger.
If hooking the drain hose into a wash basin, check that the water can
drain off quickly enough to prevent the sink from overflowing. Make
sure the drain hose is secure, so that the force of the water flowing
out of the hose does not dislodge it.
~Take care to ensure that foreign objects (e.g. nails, pins, coins,
paper clips) do not find their way into the machine with the laundry.
Shake out wash cloths before placing them in the machine to ensure
that any coarse or harmful residues are removed. These may
damage components of the machine (e.g. suds container, drum),
which in turn can result in damage to the laundry.
~If the correct amount of detergent is dispensed, the machine
should not need to be descaled. If, however, you do wish to descale
the machine, only use Miele Descaler for washing machines and
strictly observe the instructions on the packaging. If in doubt,
contact Miele.
Warning and Safety instructions
11

~Fabrics which have been pre-treated in solvent-based cleaning
agents must be thoroughly rinsed in clean water before being
washed in this machine.
~Never use solvent-based cleaning agents in this machine, as this
may result in damage to component parts and create toxic fumes.
Such agents also pose a fire and explosion hazard.
~Benzine, petrol, paraffin or any easily flammable liquid must not
be stored or used near this machine. Fire and explosion risk!
~Only use dyes specified by the manufacturer as being suitable for
use in a washing machine. Always observe the manufacturer's
instructions carefully.
~Colour run and dye removers contain sulphur compounds which
can cause damage such as corrosion. Do not use these products in
this machine.
~Avoid contact of stainless steel surfaces (front, lid, casing) with
liquid cleaning and disinfecting agents which contain chlorine or
sodium hypochlorite. These agents can have a corrosive effect on
stainless steel.
Aggressive vapours containing chlorine bleach can also be
corrosive. Do not store open containers of these agents near the
machine.
~If detergent comes into contact with eyes, rinse out immediately
with lukewarm water. If swallowed, see a doctor immediately.
Persons with skin wounds or sensitive skin should avoid contact with
washing detergent.
Warning and Safety instructions
12

~Do not use a pressure washer or hose to clean the machine.
~It is particularly important to observe manafucturer's instructions
when using a combination of cleaning agents and special
application products. Only use the product for the application
described by the manufacturer, to avoid any material damage or the
occurrence of strong chemical reactions.
Accessories
~Only use genuine Miele spare parts and accessories with this
appliance.
If non-Miele parts are used, warranty, performance and product
liability claims may be invalidated.
Disposing of your old machine
~Before disposing of an old machine it is important to disable the
door lock. This way you will prevent the risk of children accidentally
locking themselves in and endangering their lives.
Miele cannot be held liable for damage caused by
non-compliance with these Warning and Safety instructions.
Warning and Safety instructions
13

Control panel
aDisplay
See the following pages for more information.
bShort cut buttons
For selecting an individual programme quickly. These buttons can be
re-programmed to select your favourite wash programmes instead of the
pre-set ones.
cStart button
dPC / Optical interface
This is used by service technicians for testing purposes and for uploading new
software to the machine.
eMulti-function selector
This is used to select menu options (by turning it) and to confirm your selection
(by pressing it).
fOn-Off button s
To save energy, the machine will switch off automatically 15 minutes after the
end of the programm/anti-crease phase or after being switched on, if no other
selection is made.
Before using for the first time
Before using the machine for the first time ensure that it is correctly installed
and connected. See "Installation". Also check that the drain filter is securely
tightened to prevent the risk of water leaks during use.
Operating the machine
14

Display
Entry menu
1 Cottons Uni. 40°C Programme selection...
2 Cottons Hygiene 95°C Settings F...
3 Cottons rapid 60°C
4 Minimum iron 40°C 10:00
When the machine is switched on, the entry menu (with four
favourite programmes listed) appears and Programme
selection is highlighted.
Multi-function selector
Turning the multi-function selector moves the highlighting to
the next option.
Pressing the multi-function selector selects the highlighted
option.
Short cut buttons
Pressing a short cut button selects one of the four favourite
programmes shown on the left of the display.
If you wish to change the programmes shown in this list you
can do so (see "Saving a favourite programme" for more
information).
The short cut buttons have different functions in the other
menus. Where this is the case, an arrow Hwill appear in the
display above the short cut button, together with a
description of its function .
Programme selection
There are two ways of selecting a programme:
–Option 1: Select Programme selection from the display and
press the multi-function selector.
–Option 2: Press short cut button D,E,For G.
This will automatically take you into the main menu for that
programme.
Operating the machine
15

Programme selection menu
Programme
selection
Cottons Uni V
Cottons Hygiene
Cottons rapid
Minimum iron H
You can use the multi-function selector to select any
programme. The highlighting will move up or down
depending on the direction the multi-function selector is
turned in.
The HVarrows on the right of the display, indicate further
options.
Pressing the multi-function selector takes you to the main
menu of the programme selected.
Wash programme main menu
Cottons Uni. 40°C 1200 rpm
Duration: 0:53 h
Extras
H
Timer Y
H
Back A
H
Turn the multi-function selector to highlight programme,
temperature or spin speed. Pressing the multi-function
selector selects the highlighted option and opens the relevant
sub-menu.
The sub-menus Extras and Timer can be accessed by
pressing the short cut button directly below them.
To go back to the entry menu press short cut button G
below the word Back.
Alternatively, you can also highlight and confirm all options by
just using the multi-function selector.
Settings menu J
The Settings menu is used for altering standard settings. See
the separate booklet supplied with the machine for further
information on how to alter settings.
Operating the machine
16

Operating a wash-salon machine
The entry menu will vary depending on the Control setting
selected.
The machine is operated either with the short cut buttons
D,E,F,Gor the multi-function selector.
WS shortcut keys, basic
1 Cottons Uni. 40°C
2 Cottons Hygiene 95°C
3 Cottons rapid 60°C
4 Minimum iron 40°C
4 programmes are available to choose from. To specify which
programmes are available go to the Settings/supervisor level
menu.
WS shortcut keys + Logo
M
PROFESSIONAL
30°C
H
60°C
H
95°C
H
More
H
12 programmes are available to choose from. To specify
which programmes are available go to the
Settings/supervisor level menu.
Operating the machine
17

1. Sort the laundry
^Empty all pockets.
,Foreign objects (e.g. nails,
coins, paper clips, etc.) can cause
damage to textiles and to
components in the machine.
Removing marks
^Badly soiled areas, stains etc. should
be cleaned as soon as possible,
preferably whilst still fresh. Spillages
should be carefully dabbed off using
a soft, colourfast cloth. Do not rub!
Badly soiled areas can be pre-treated
with liquid detergent, stain removers
etc. first, following the manufacturer's
instructions. With particularly stubborn
stains ask your dry cleaner for advice.
,Do not use solvent-based
cleaning agents in this machine.
Sorting laundry
^Sort the laundry by colour and by
care label. Most garments have a
textile care label in the collar or side
seam.
Dark textiles often contain excess dye
and should be washed separately
several times before being included in
a mixed load. Always wash whites and
coloureds separately.
–Curtains: Remove lead weights first
or place in a laundry bag.
–Underwiring and collar stiffeners:
Any loose wiring in bras, shirt collar
stiffeners, etc. should be removed or
sewn in.
– Knitted garments, trousers and
jeans, T-shirts and sweat shirts: Turn
inside out, if recommended by the
manufacturer.
– Close any zips, fasten hooks and
eyes etc before washing.
–Fasten duvet covers etc. to prevent
small items from being rolled up
inside them.
–See the separate booklet supplied
with the machine for further tips.
Do not wash any items in this machine
which are specified by the
manufacturer as not washable on the
care label. (hsymbol)
Tips
18

2. Load the drum
^Switch the machine off with the K
On/Off button.
^To open the drum door pull on the
handle.
Do not use force as it is fitted with a
safety device to prevent it being
opened by mistake. Forcing the door
handle can cause damage to the
locking mechanism (see "Problem
solving guide, The door will not
open").
^Unfold the laundry and load loosely
into the drum. Mixing both large and
small items gives better wash results
and also helps distribute the load
evenly during spinning.
The most efficient use of energy and
water is achieved when a full load is
washed. However, do not overload as
this causes creases and reduces
cleaning efficiency.
^Close the drum door. Press the door
firmly to shut it and then lock the
handle in position. Do not slam the
drum door.
,Make sure that no items are
caught between the door and the
drum.
3. Select a programme
^Select the most appropriate
programme for the load being
washed.
See the separate booklet supplied with
the machine for an overview of which
programmes are available.
Tips
19

Washing
The figure quoted in the bucket is the
maximum temperature the garment
can be washed at. The number of
bars under the symbol indicate the
level of agitation permitted.
9No bar under the symbol:
= normal agitation
4One bar under the symbol:
= reduced agitation
cTwo bars under the symbol:
= much reduced agitation
/Hand wash (if no temperature
is specified use the lowest
temperature or cold)
hDo not wash
Drying
The number of dots indicates the
drying temperature
qNormal temperature
rLow temperature
sDo not tumble dry
Ironing
The number of dots indicates the
ironing temperature
IHot iron (max sole plate temp.
approx. 200°C)
HMedium hot iron (max sole
plate temp. approx. 150°C)
GCool iron (max sole plate
temp. approx. 110°C). Do not
steam iron garments carrying
this symbol.
JDo not iron
Professional cleaning
fDry clean only. The letters
indicate the type of cleaning
agent required.
p
wProfessional Wet Clean only
DDo not dry clean
Bleaching
xAny oxidising bleaching
agent can be used
{Only use an oxygen based
bleach or a non-chlorine
bleach
zDo not bleach
Garment care label symbols
20
