Miele PG 8056 U User manual

Operating instructions
Commercial dishwasher
PG 8056
To avoid the risk of accidents or damage
to the appliance, it is essential to read
these instructions before it is installed
and used for the first time.
en - GB
M.-Nr. 12 304 470

Contents
2
Notes about these instructions...................................................................................... 5
Guide to the machine...................................................................................................... 6
Appliance overview ........................................................................................................... 6
Control panel..................................................................................................................... 7
Correct application ......................................................................................................... 8
Warning and Safety instructions.................................................................................... 10
Symbols used.................................................................................................................... 14
Disposal of your old dishwasher ...................................................................................... 14
Caring for the environment ............................................................................................ 15
User profiles..................................................................................................................... 16
User groups....................................................................................................................... 16
Daily operators .............................................................................................................. 16
Experienced operators .................................................................................................. 16
Operation tips .................................................................................................................. 17
Display............................................................................................................................... 17
Menus................................................................................................................................ 18
Symbols in the display ..................................................................................................... 20
Initial commissioning ...................................................................................................... 21
Opening and closing the door........................................................................................ 25
Comfort door locking mechanism..................................................................................... 25
Opening the door........................................................................................................ 25
Closing the door................................................................................................................ 25
Opening the door using the emergency release ............................................................... 26
Filling the salt reservoir .................................................................................................. 27
Reactivation....................................................................................................................... 27
Setting the water hardness level ....................................................................................... 28
Add salt reminder .............................................................................................................. 30
Machine lock-out in case of lack of salt............................................................................ 30
Adding rinsing agent ....................................................................................................... 33
Rinsing agent..................................................................................................................... 33
Add rinsing agent reminder ............................................................................................... 33
Areas of application ........................................................................................................ 35
Preparing the load ............................................................................................................. 35
Upper basket..................................................................................................................... 37
Adjusting the upper basket ............................................................................................... 38
Lower basket..................................................................................................................... 40
Loading plastic trays ......................................................................................................... 42
Operation.......................................................................................................................... 44
Adding cleaning agent....................................................................................................... 44
Dispensing module............................................................................................................ 46
LEDs in the buttons........................................................................................................... 49
Switching on...................................................................................................................... 50
Selecting a programme ..................................................................................................... 50
Starting a programme ....................................................................................................... 52

Contents
3
End of programme............................................................................................................. 53
Switching off...................................................................................................................... 53
Unloading the dishwasher................................................................................................. 53
Interrupting a programme.................................................................................................. 54
Cancelling a programme ................................................................................................... 55
Additional functions ........................................................................................................ 56
Delay start ......................................................................................................................... 56
Drying assistance .............................................................................................................. 57
Settings ......................................................................................................................... 58
Menu structure .................................................................................................................. 59
Delay start ......................................................................................................................... 60
Drying ................................................................................................................................ 60
Setting the language...................................................................................................... 61
Venting DOS modules ....................................................................................................... 62
Setting the date................................................................................................................. 63
Date format.................................................................................................................... 63
Set ................................................................................................................................. 63
Setting the time of day ...................................................................................................... 64
Setting the time ............................................................................................................. 64
Display........................................................................................................................... 65
Clock display................................................................................................................. 65
Regulating the volume....................................................................................................... 66
Keypad tone .................................................................................................................. 66
Buzzer tones.................................................................................................................. 66
Settingthe volume ......................................................................................................... 67
Further settings .............................................................................................................. 68
Opening the “Further settings” menu................................................................................ 68
Menu structure .................................................................................................................. 70
PIN code............................................................................................................................ 72
Approval ........................................................................................................................ 72
Changing the PIN code ................................................................................................. 72
Log book ........................................................................................................................... 74
Temperature unit................................................................................................................ 75
Move programme .............................................................................................................. 76
Additional functions........................................................................................................... 77
Resetting ....................................................................................................................... 77
Increased water level..................................................................................................... 78
Interim rinse................................................................................................................... 78
DOS dispensing system................................................................................................ 79
Temperature / Time ....................................................................................................... 82
Releasing programmes ..................................................................................................... 85
Water hardness ................................................................................................................. 86
Display view ...................................................................................................................... 86
Display............................................................................................................................... 87
Contrast......................................................................................................................... 87
Brightness ..................................................................................................................... 87
Switch off after .................................................................................................................. 88
Factory default setting....................................................................................................... 89
Software version................................................................................................................ 90

Contents
4
Cleaning and care ........................................................................................................... 91
Periodic checks ................................................................................................................. 91
Cleaning the control panel ................................................................................................ 92
Cleaning the door front ..................................................................................................... 92
Cleaning the wash cabinet ................................................................................................ 92
Cleaning the door and the door seal................................................................................. 93
Cleaning the filters in the wash cabinet ............................................................................ 93
Cleaning the spray arms.................................................................................................... 95
Problem solving guide .................................................................................................... 97
Faults with water inlet or drainage..................................................................................... 97
General problems with the commercial dishwasher ......................................................... 101
Noises................................................................................................................................ 102
Unsatisfactory washing result ........................................................................................... 103
Problem solving guide .................................................................................................... 105
Cleaning the water inlet filter............................................................................................. 105
Cleaning the drain pump and non-return valve................................................................. 106
Programme chart ............................................................................................................ 108
After sales service........................................................................................................... 110
Installation........................................................................................................................ 111
Installation ......................................................................................................................... 111
Building under ............................................................................................................... 111
Levelling and securing the dishwasher ......................................................................... 112
Floor anchoring ............................................................................................................. 113
Moving the dishwasher ..................................................................................................... 113
Electrical connection ...................................................................................................... 114
Peak-load negotiation ....................................................................................................... 115
Plumbing .......................................................................................................................... 116
Connecting the water inlet ................................................................................................ 116
Connecting the drain hose ................................................................................................ 118
Technical data.................................................................................................................. 119

Notes about these instructions
5
Warnings
Information which is important for safety is highlighted in a thick
framed box with a warning symbol. This alerts you to the potential
danger of injury to people or damage to property.
Read these warning notes carefully and observe the procedural
instructions and codes of practice they describe.
Notes
Information of particular importance that must be observed is
highlighted in a thick framed box.
Additional information and comments
Additional information and comments are highlighted in a box
framed with a single black line.
Operating steps
Instructions on how to operate the commercial dishwasher are
identified by specially marked operating steps. They explain the
procedure step by step.
Operating steps are indicated by a black square bullet point.
Example:
 Open the door of the commercial dishwasher.
Display
Information that is shown in the commercial dishwasher display
appears in a special font similar to the display text.
Example:
Select Delay start and confirm your choice with the OKbutton.

Guide to the machine
6
Appliance overview
aDoor lock
bUpper spray arm (not visible)
cUpper basket runner
dConnection for upper basket spray arm
eLower spray arm
fLower basket runner
gData plate
hRinsing agent container
iDoor lock latch
jDishwasher salt container
kDispenser for powder cleaning agent
lFilter combination
mBack:
Connection for dispensing modules
External dispenser pump for liquid
cleaning agent (DOS1)
External dispenser pump for rinsing agent
(DOS4)

Guide to the machine
7
Control panel
aOn/Offbutton
Turns the commercial dishwasher on and
off
bButtons 1–3 (programme selection
buttons)
Direct-access pushbuttons for storing
favourite programmes
cbutton (further programmes)
For selecting additional programmes
dDisplay
User interface
e and button (arrow buttons)
For navigating in the user interface
fbutton (cancel or back)
For cancelling a process in the user
interface
(not for cancelling programmes)
gStart/Stopbutton
For starting or cancelling a programme
hbutton (door release)
For opening the door
iOKbutton (confirmation)
For selecting options or confirming entries
in the user interface
jService interface
Testing and transmission point for the
Miele Customer Service Department

Correct application
8
This commercial dishwasher complies with all current local and
national safety requirements. Inappropriate use can, however, lead
to personal injury and material damage.
Read the operating instructions carefully before using the
commercial dishwasher for the first time. They contain important
information on the safety, use and maintenance of the appliance.
This way you will prevent the risk of accidents and damage to the
commercial dishwasher. Keep these operating instructions in a safe
place and pass them on to any future owner.
 This Miele commercial dishwasher with its short programme
durations and powerful cleaning performance is intended for
commercial use. It can also be used on ships with a hull longer than
24 metres as well as on oil rigs.
 This commercial dishwasher is subsequently referred to as a
dishwasher in these operating instructions.
Glasses, cutlery and crockery are referred to generally as crockery
when not more specifically defined.
 This appliance is designed exclusively for use as a “dishwasher”
for cleaning loads as described in these instructions. Conversions,
modifications and any other use are not permitted.
 This dishwasher is intended for stationary, indoor use only.
 The special inserts in the baskets should only be used for their
specific application.
 This dishwasher may not be used to clean medical products or
devices.
 This dishwasher can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience or
knowledge, if they are supervised whilst using it or have been shown
how to use it in a safe way and understand and recognise the
consequences of incorrect operation.

Correct application
9
 This commercial dishwasher can only be used on a ship if:
- The ship’s hull is longer than 24metres.
- The list of the vessel is not more than 2°.
- Any external vibration is no more than 150Hz at an amplitude of
0.35mm.
The safe operation and correct functioning of the commercial
dishwasher can only be guaranteed if the above conditions are met.
 The door of the commercial dishwasher must not be opened
during operation.
 Inappropriate use can lead to water leakage.
 The commercial dishwasher may not be operated on an open
deck.

Warning and Safety instructions
10
Correct installation
 This commercial dishwasher may only be installed and assembled
on ships with a hull longer than 24metres by qualified persons who
will ensure that the requirements for the safe installation of this
commercial dishwasher are met.
 When installing the commercial dishwasher, it must be securely
fixed to the floor.
Failure to do this could result in personal injury, damage to the
commercial dishwasher and damage to other objects and
installations.
 This commercial dishwasher must be securely bolted to the floor
using the supplied floor anchoring kit.
 Do not install this dishwasher in an area where there is a risk of
explosion or freezing conditions.
 In order to reduce the risk of damage from condensation, the
furniture in the area around the dishwasher should ideally be
designed for commercial use.
Furniture can be protected using the vapour protection set, which is
available as an optional accessory.
The vapour barrier film should be stuck under the worktop in the area
around the dishwasher door.
Technical safety
 This dishwasher must only be commissioned, repaired and
maintained by the Miele Customer Service Department, a dealer or a
suitably qualified service technician. Unauthorised installation,
maintenance and repairs can cause considerable danger for the user.
 This dishwasher must only be operated by appropriately trained
personnel. They must be instructed and trained regularly.
 Before using the dishwasher, check it for any externally visible
damage. Do not use a damaged dishwasher. This could be
dangerous.
 In the event of a damaged or leaking dishwasher, switch off at the
power supply immediately and call the Miele Customer Service
Department, a Miele dealer or a suitably qualified service technician.
 Faulty components must only be replaced by genuine Miele
original spare parts. Only when these parts are fitted can Miele
guarantee the correct functioning and safety of the appliance.
 The electrical safety of this dishwasher can only be guaranteed
when correctly earthed. If in any doubt, please have the electrical
installation tested by a qualified electrician.
 Please follow the advice on installation in these instructions and
the separate Installation diagram.

Warning and Safety instructions
11
 Before connecting the appliance, ensure that the connection data
on the data plate (voltage, frequency and fuse rating) match the
mains electrical supply.
 There must be no electrical sockets behind the dishwasher. Danger
of overheating and fire risk if the dishwasher were to be pushed up
against a plug. See “Electrical connection”.
 Do not connect the dishwasher to the mains electricity supply via a
multi-socket unit or an extension lead. These do not guarantee the
required safety of the appliance (e.g. danger of overheating).
 Never open the casing of the dishwasher. Any contact with live
connections or tampering with the electrical or mechanical
components of the dishwasher will endanger your safety and may
lead to appliance malfunctions.
 The dishwasher must not be used if the electrical connection cable
is damaged. A damaged connection cable may only be replaced by a
suitable connection cable of the same type. For safety reasons, such
replacement may only be carried out by the Miele Customer Service
Department or a qualified service technician.
 The dishwasher must be disconnected from the mains electricity
supply before any maintenance or repair work is carried out.
 The plastic housing of the water connection contains electrical
components. It must not be dipped in water.
 There are electrical wires in the water inlet hose. Do not shorten
the water inlet hose, even if it is too long.
 The integrated Waterproof system offers protection from water
damage, provided that the following conditions are met:
- Installation has been carried out correctly.
- The dishwasher is properly maintained and parts are replaced
where it can be seen that this is necessary.
- The stopcocks have been turned off during longer periods of
inactivity (e.g. whilst on holiday).
The Waterproof system will work even when the dishwasher is
switched off. However, the dishwasher must remain connected to the
electricity supply.
Correct use
 This dishwasher is designed for operation with water and
detergents suitable for use in commercial dishwashers only. Organic
solvents and flammable liquid agents must not be used in it.
This could cause an explosion, damage rubber or plastic components
in the dishwasher and cause liquids to leak out of it.

Warning and Safety instructions
12
 Only use detergents formulated for use in commercial
dishwashers. Unsuitable detergents could adversely affect
components of the dishwasher or the load items.
 Do not sit, stand or lean on the opened door. This would tip or
damage the dishwasher.
 After any plumbing work the water pipework to the dishwasher will
need to be vented. If this is not done, components can be damaged.
 Please be aware that the dishwasher may be operating at high
temperatures. When the door is opened there is a danger of burning
or scalding. Items, baskets and inserts must be allowed to cool down
before they are unloaded. Any water remaining in containers could
still be very hot. Empty them into the wash chamber before taking
them out.
 The water in the cabinet must not be used as drinking water.
 Pre-treating items (for example with washing-up liquid and other
cleaning agents) as well as some types of soiling and some cleaning
agents can cause a build-up of foam in the wash cabinet. Foam can
have an adverse effect on the cleaning result.
 Foam escaping from the wash cabinet can cause damage to the
dishwasher. If foam escapes the programme must be cancelled
immediately and the appliance must be disconnected from the mains
electrical supply.
 When using cleaning agents and specialised products, it is
essential that the manufacturer's instructions are followed. Cleaning
agents must only be used for the purpose they are designed for by
the manufacturer to avoid any material damage or the occurrence of
strong chemical reactions (e.g. oxyhydrogen explosion).
 Do not inhale or ingest powder detergent. Dishwasher detergent
contains irritant or corrosive ingredients which can cause burning in
the nose, mouth and throat if swallowed, or inhibit breathing. Seek
medical attention immediately if detergent has been swallowed or
inhaled.
 Miele cannot be held liable for any effect chemical cleaning agents
may have on the material of the items being cleaned. Observe the
cleaning agent manufacturer's instructions with regard to storage
conditions, use and dosage.
 To avoid material damage and corrosion, do not allow any acids or
solutions containing chloride to get into the wash cabinet or onto the
casing. Similarly avoid any ferrous materials with a corrosive effect.
 Do not wash items soiled with ash, sand, wax, lubricating grease
or paint in the dishwasher. These materials will cause damage to the
dishwasher.

Warning and Safety instructions
13
 Do not clean the dishwasher or near vicinity with a hose or a
pressure washer.
 Ensure that the outer casing of the machine does not come into
contact with solutions or steam containing acid to avoid any
corrosion damage.
 Be careful when sorting items with sharp pointed ends and
positioning them in the dishwasher that you do not hurt yourself or
create a danger for others. Sharp knives, forks, etc. should be placed
in baskets with the pointed ends facing downwards.
 Remove any coarse food deposits and empty out any containers
or utensils before loading them in the dishwasher.
Safety with children
 Children should be supervised in the vicinity of the dishwasher.
Never allow children to play with the appliance. There is a danger that
children might shut themselves in the dishwasher.
 Children must not use the dishwasher.
 Keep children away from chemical agents. These contain irritant
and corrosive ingredients which can cause burning in the mouth, or
inhibit breathing. Keep children away from the dishwasher when the
door is open. There could still be residual chemical agent in the wash
cabinet. Seek medical advice immediately if a child has swallowed or
inhaled chemical agent.
Accessories
 Only use genuine Miele original spare parts and accessories with
this dishwasher. Using spare parts or accessories from other
manufacturers will invalidate the guarantee and Miele cannot accept
liability.
 Only use Miele baskets and inserts with this dishwasher. Using
baskets and inserts made by other manufacturers, or making
modifications to Miele accessories can cause unsatisfactory cleaning
results, for which Miele cannot be held liable. Any resultant damage
would not be covered by the guarantee.

Warning and Safety instructions
14
Symbols used
Warning:
Observe the operating instructions!
Warning:
Danger of electric shock!
Warning: Hot surfaces:
It can be very hot inside the wash cabinet
when the door is opened!
Risk of being cut:
Wear cut-resistant protective gloves when
transporting and setting up the machine!
Disposal of your old dishwasher
 For safety and environmental reasons, dispose of all chemical
agents according to the manufacturer's instructions and to safety
regulations. Safety goggles and protective gloves should be worn.
 Remove or disable the door lock prior to disposal of the
dishwasher, so that children cannot become trapped inside (see
“Caring for the environment”).
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.

Caring for the environment
15
Disposing of the packaging material
The packaging material is used for handling and protects the
appliance from transport damage. The packaging material used is
selected from materials which are environmentally friendly for
disposal and can generally be recycled.
Recycling the packaging material reduces the use of raw materials.
Use material-specific collection points for valuable materials and take
advantage of return options. Your Miele dealer will take the packaging
material away.
Disposing of your old appliance
Electrical and electronic appliances contain many valuable materials.
They also contain certain materials, compounds and components
which were essential for their correct functioning and safety. These
could be hazardous to human health and to the environment if
disposed of with household waste or if handled incorrectly. Please do
not, therefore, dispose of your old appliance with household waste.
Instead, please make use of officially designated collection and
disposal points to dispose of and recycle electrical and electronic
appliances in your local community, with your dealer or with Miele,
free of charge. By law, you are solely responsible for deleting any
personal data from the old appliance prior to disposal. You are legally
obliged to remove any old batteries which are not securely enclosed
by the appliance and to remove any lamps without destroying them,
where this is possible. These must be taken to a suitable collection
point where they can be handed in free of charge. Please ensure that
your old appliance poses no risk to children while being stored for
disposal.

User profiles
16
User groups
Users can be divided into two groups:
- Daily operators
- Experienced operators
Access to “Additional settings” can be blocked to general, daily
operators by using a code (see “Additional settings, Code”).
Daily operators Operators must be instructed in operating and loading the
commercial dishwasher and trained regularly to guarantee safe daily
use.
Experienced
operators
Experienced operators can additionally block access to programmes,
modify temperature and holding times within programme cycles, and
alter water levels.

Operation tips
17
Display
The display is not a touch screen.
The display is used to select or set the following:
- the programme
- the Delay start time
- the settings
During a programme, the display shows the following:
- the programme name
- the programme stage / target temperature / actual temperature
- the estimated time left for the programme to run
- any relevant fault messages and information
Menu operation This dishwasher is operated exclusively via buttons on the control
panel. The buttons are arranged to the side of the display on the
stainless steel control panel and are operated by pressing gently.
Menu operation is via the keypad to the right of the display.
- button
For navigating upwards by row within a menu, or increasing the
value highlighted.
- button (Cancel or back)
For ending a menu early. Any changes to settings are not saved
and the display reverts to the previous menu.
- button
For navigating downwards by row within a menu, or decreasing the
value highlighted.
-OK button
For confirming a selection or for saving input. The display moves to
the next menu or, when entering values, to the next input position.
The procedure for entering values is described in the relevant
section.

Operation tips
18
Menus
The commercial dishwasher's user interface is divided into different
menus. These menus are displayed in a 3-line display on the control
panel.
Example:
Language 
,
;
(
english (GB)
deutsch
The name of the menu and a maximum of two menu options are
shown. The currently selected option is highlighted.
Single selection
Delay start
Yes
No (
Use the  and arrow buttons to navigate through the menu. The
highlighted option is selected by pressing the OKbutton. The option
which is selected will have a tick next to it. The other options are
automatically deselected.
Press the OKbutton to progress to the next menu, or to the next
input position when entering values. The procedure for entering
values is described in the respective chapter. Press the button to
revert to the previous menu without saving the entry.
Multiple selection
Release programme
Short
Universal ,
;
9
9
Use the  and arrow buttons to navigate through the menu.
Several options can be selected in succession within the menu using
the OKbutton. Once selected, an option will have a tick beside it.
To save your selection, select Accept and confirm with the OKbutton.

Operation tips
19
System messages The symbol denotes system messages. These give information
about current processes and the status of the commercial
dishwasher. System messages are displayed individually at the end of
the programme. If there are a number of system messages,
subsequent messages can be displayed by pressing the OKbutton.
System messages can also be displayed during the programme
sequence by pressing the OKbutton.
Example:

OK
Refill salt
Automatic switch-off
The commercial dishwasher has an automatic switch-off function.
The commercial dishwasher switches itself off automatically after the
time set. The display and all other LEDs are switched off. To switch
the commercial dishwasher back on, press the On/Off button.
The automatic switch-off function can be deactivated (see “Additional
settings, Switch off after”). The display will then remain switched on
in idle mode.

Operation tips
20
Symbols in the display
Navigation arrows

If a menu contains more than two options, two navigation arrows are
shown beside the options. The arrow buttons  and  can be used
to scroll through the options.
Dotted line ------- If a menu contains more than two options, the end of the option list is
marked by a dotted line. The last entry appears above the line, the
first entry below it.
Tick If there are several options available, the current setting is marked
with a tick .
Example
Delay start
Yes
No (
System
messages
The symbol denotes system messages and is displayed alternately
with the symbol. If OK appears in the bottom right of the display,
the system message must be confirmed using the OKbutton. If OK
does not appear in the display, after a few seconds the display skips
to the next level up.
Fault
messages
In the event of a fault, a warning triangle is shown in place of the
symbol. See “Problem solving guide” for more information.
