Miele PDR 507 HP User manual

Operating and installation instructions
Heat-pump tumble dryer
It is essential to read these operating instructions before installing and
using the appliance. This prevents both personal injury and damage to
the appliance.
en-AU, NZ M.-Nr. 11 420 910

Contents
2
Caring for the environment ................................................................................. 6
Warning and Safety instructions ......................................................................... 7
Operating the tumble dryer ................................................................................ 19
Control panel......................................................................................................... 19
Symbols on the control panel ............................................................................... 20
Symbols in the display .......................................................................................... 21
Sensors and touch display with sensor controls .................................................. 22
Main menu............................................................................................................. 22
Examples on how to operate the appliance.......................................................... 23
Selection list ..................................................................................................... 23
Single selection ................................................................................................ 23
Setting numerical values .................................................................................. 23
Exiting a submenu............................................................................................ 23
Using for the first time ........................................................................................ 24
Switching on the tumble dryer .............................................................................. 24
Setting the display language ................................................................................. 24
Reference to external appliances.......................................................................... 25
Setting the display brightness............................................................................... 25
Confirming the time query..................................................................................... 25
Setting the time of day .......................................................................................... 25
Selecting programme packages ........................................................................... 26
Setting up a payment system................................................................................ 26
Completing the commissioning process............................................................... 27
1. Notes on correct laundry care ....................................................................... 28
Washing................................................................................................................. 28
Drying .................................................................................................................... 28
Care label symbols ................................................................................................ 28
2. Loading the tumble dryer ............................................................................... 29
3. Selecting a programme .................................................................................. 30
Switching on the tumble dryer .............................................................................. 30
Selecting a programme ......................................................................................... 30
Selecting standard programmes with the programme selector ....................... 30
Selecting special programmes via the programme selector position ......... 30
4. Selecting programme settings....................................................................... 31
Main menu for a programme................................................................................. 31
Selecting the drying level ................................................................................. 31
Selecting the duration (timed drying programmes) ......................................... 31

Contents
3
Selecting Extras..................................................................................................... 32
Gentle tumble................................................................................................... 32
Anti-crease ....................................................................................................... 32
Selecting Delay start ............................................................................................. 33
5. Starting a programme..................................................................................... 34
Starting a programme ........................................................................................... 34
6. End of programme - unloading the drum...................................................... 35
At the end of the programme ................................................................................ 35
Removing the laundry ........................................................................................... 35
Observing care instructions .................................................................................. 35
Programme chart ................................................................................................ 36
Standard programmes .......................................................................................... 36
 Special programmes ........................................................................................ 38
Programme packages ........................................................................................... 41
Changing the programme sequence................................................................. 44
Changing a programme after it has started .......................................................... 44
Cancelling a programme ....................................................................................... 44
Reselecting a cancelled programme................................................................ 44
Adding or removing laundry .................................................................................. 44
Fragrance flacon.................................................................................................. 45
Inserting a fragrance flacon................................................................................... 45
Opening the fragrance flacon................................................................................ 47
Closing the fragrance flacon ................................................................................. 47
Removing/replacing the fragrance flacon ............................................................. 48
Cleaning and care ............................................................................................... 49
Observing cleaning intervals ................................................................................. 49
1. When to clean the fluff filters........................................................................ 49
2. When to clean the filter in the plinth............................................................. 50
3. When to clean the grille on the bottom right/heat exchanger for heat
dissipation ........................................................................................................ 51
Cleaning the filters................................................................................................. 51
Removing the fragrance flacon ........................................................................ 51
Removing visible fluff ....................................................................................... 51
Cleaning the fluff filters and air flow openings thoroughly ............................... 52
Cleaning the filter in the plinth............................................................................... 54
Removing the plinth filter ................................................................................. 54
Cleaning the plinth filter with water .................................................................. 55
Replacing the plinth filter.................................................................................. 55

Contents
4
Cleaning the filter insert (in the plinth) ................................................................... 57
Removing the filter insert ................................................................................. 57
Checking the cooling fins on the heat exchanger ............................................ 58
Refitting the filter insert in the plinth................................................................. 59
Refitting the fluff filter in the plinth ........................................................................ 59
Cleaning and closing the fluff filter flap ................................................................. 60
Cleaning the bottom right grille/heat exchanger ................................................... 61
Removing the grille........................................................................................... 61
Cleaning the cooling fins .................................................................................. 62
Refitting the grille ............................................................................................. 62
Cleaning the dryer ................................................................................................. 63
Problem solving guide ........................................................................................ 64
The display shows the following messages or faults ............................................ 64
Unsatisfactory drying result................................................................................... 67
The drying process takes a long time. .................................................................. 68
General problems with the tumble dryer ............................................................... 69
Regenerating the plinth filter ................................................................................. 70
Service.................................................................................................................. 71
Contact in case of fault ......................................................................................... 71
Optional accessories............................................................................................. 71
Installation............................................................................................................ 72
Front view .............................................................................................................. 72
Rear view............................................................................................................... 73
Installation locations.............................................................................................. 74
Side view .......................................................................................................... 74
Steel plinth........................................................................................................ 74
View from above............................................................................................... 74
Washer-dryer stack .......................................................................................... 74
Transporting the dryer to its installation site ......................................................... 75
Installation ............................................................................................................. 76
Downtime after installation............................................................................... 76
Levelling the dryer ............................................................................................ 76
Room ventilation .............................................................................................. 77
External control equipment .............................................................................. 77
Drain hose for condensed water ........................................................................... 78
Electrical connection ............................................................................................. 80
Technical data...................................................................................................... 81

Contents
5
Supervisor level ................................................................................................... 82
Opening the Supervisor level ................................................................................ 82
Access via code ............................................................................................... 82
Change code.................................................................................................... 82
Opening the Supervisor level ........................................................................... 82
Exiting the Supervisor level ................................................................................... 82
Language............................................................................................................... 83
Brightness ............................................................................................................. 83
Clock display......................................................................................................... 83
Finish tone volume ................................................................................................ 83
Keypad tone .......................................................................................................... 83
Welcome tone volume........................................................................................... 83
Fault alarm............................................................................................................. 84
Memory ................................................................................................................. 84
Anti-crease ............................................................................................................ 84
Further cooling ...................................................................................................... 84
Cooling down temperature.................................................................................... 84
Delay start ............................................................................................................. 85
Programme name.................................................................................................. 85
Drying level Cottons .............................................................................................. 85
Drying level Minimum iron..................................................................................... 85
Drying level Automatic plus................................................................................... 85
Drying level Machine iron ...................................................................................... 85
Clean the airways .................................................................................................. 86
Programme packages ........................................................................................... 86
Peak load signal .................................................................................................... 87
Peak load prevention............................................................................................. 87
Payment system .................................................................................................... 87
Settings for the payment system ..................................................................... 87
Time / Impulse.................................................................................................. 88
Feedback signal to pay system........................................................................ 88
Payment system lock ....................................................................................... 88
Clear paid signal............................................................................................... 89
Debounce time ................................................................................................. 89
Payment system overriding time ...................................................................... 89
Duration Cool air .............................................................................................. 89
Duration Warm air............................................................................................. 89
FOC programmes............................................................................................. 89

Caring for the environment
6
Disposal of the packing
material
The transport and protective packaging
has been selected from materials which
are environmentally friendly for
disposal, and can normally be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites. Ensure that any plastic
wrappings, bags etc. are disposed of
safely and kept out of the reach of
babies and young children. Danger of
suffocation.
Disposing of your old
appliance
Electrical and electronic appliances
often contain valuable materials. They
also contain specific materials,
compounds and components, which
were essential for their correct function
and safety. These could be hazardous
to human health and to the environment
if disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre for electrical and electronic
appliances. You are also responsible for
deleting any personal data that may be
stored on the appliance prior to
disposal. Please ensure that your old
appliance poses no risk to children
while being stored prior to disposal.

Warning and Safety instructions
7
 It is essential to read these instructions.
This tumble dryer complies with all current local and national
safety requirements. However, inappropriate use can lead to
personal injury and damage to property.
Read the operating instructions carefully before using the tumble
dryer. They contain important information on safety, installation,
use and maintenance of the appliance. This prevents both
personal injury and damage to the tumble dryer.
In accordance with standard IEC60335-1, Miele expressly and
strongly advises that you read and follow the instructions in
“Installation”, as well as in the “Warning and Safety instructions”.
Miele cannot be held liable for injury or damage caused by non-
compliance with these instructions.
Keep these operating instructions in a safe place and pass them
on to any future owner.
When instructing other people how to use the tumble dryer, they
must be made aware of these Warning and Safety instructions.
Correct application
 The dryer is intended exclusively for drying textiles washed in
water which have been labelled as suitable for tumble drying by the
manufacturer on the care label. Any other applications may be
dangerous. Miele cannot be held liable for damage resulting from
incorrect or improper use or operation.

Warning and Safety instructions
8
 This tumble dryer is intended for commercial use in small
businesses, care homes, sports clubs, hospitals and other similar
commercial environments. This machine may also be operated by
lay persons in public areas such as laundrettes, communal laundry
rooms or similar.
 This tumble dryer is not suitable for outdoor use.
 This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience or knowledge, unless they are supervised whilst
using it or have been shown how to use it in a safe way and
understand and recognise the consequences of incorrect operation.
 Young children must not be allowed to use this appliance.
 Older children may only use the dryer if its operation has been
clearly explained to them and they are able to use it safely. They
must be able to understand and recognise the possible dangers
caused by incorrect operation.
 Children must not be allowed to clean or maintain the tumble
dryer unsupervised.
 Children should be supervised in the vicinity of the tumble dryer.
Do not allow them to play with the appliance.

Warning and Safety instructions
9
Technical safety
 Before installing the dryer, check it for visible signs of damage.
Do not install or use a damaged appliance.
 Do not make any alterations to the dryer, unless authorised to do
so by Miele.
 Do not connect the dryer to the mains electricity supply by an
extension lead. Extension leads do not guarantee the required safety
of the appliance (e.g. danger of overheating).
 If the electrical connection cable is faulty, it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 The electrical safety of this appliance can only be guaranteed
when continuity is complete between it and an effective earthing
system. It is essential that this standard safety requirement is
observed and regularly tested. If in any doubt, have the electrical
installation inspected by a qualified electrician. Miele cannot be held
liable for the consequences of an inadequate earthing system (e.g.
electric shock).
 Unauthorised repairs could result in unforeseen dangers for the
user, for which Miele cannot accept liability. Repairs must only be
carried out by a Miele authorised service technician, otherwise any
subsequent damage will not be covered by the warranty.
 Faulty components must only be replaced by genuine Miele
original spare parts. Miele can only guarantee the safety standards of
the machine when Miele replacement parts are used.
 To ensure the correct performance of the tumble dryer and to
prevent malfunctions and fire hazards, it is important to carry out
maintenance on a regular basis.

Warning and Safety instructions
10
 In the event of a fault and for cleaning purposes, the tumble dryer
must be disconnected from the electricity supply. It is only
completely disconnected when:
– it is switched off at the wall socket or the plug is withdrawn, or
– the mains fuse is disconnected, or
– it is switched off at the mains circuit breaker.
For further information see “Installation - Electrical connection”.
 This tumble dryer must not be installed and operated in mobile
locations (e.g. on a ship).
 Please observe the instructions in “Installation” and “Technical
data”.
 The electrical socket must be easily accessible so that the tumble
dryer can be disconnected from the electricity supply.
 If the appliance is hard wired, adequate provision must be made
on site to switch off all poles to disconnect the tumble dryer from the
electricity supply. The means of disconnection must be incorporated
in the fixed wiring in accordance with the wiring rules.
 The gap between the bottom of the tumble dryer and the floor
must not be blocked with plinth facings, deep pile carpet etc., which
would obstruct the openings. This would hinder a sufficient flow of
air to the tumble dryer.
 The appliance must not be installed behind a lockable door, a
sliding door or a door with a hinge on the opposite side to that of the
tumble dryer, in such a way that a full opening of the tumble dryer
door is restricted.
 This tumble dryer is supplied with a special lamp to cope with
particular conditions (e.g. relating to temperature, moisture, chemical
resistance, abrasion resistance, and vibration). This special lamp
must only be used for the purpose for which it is intended. It is not
suitable for room lighting. Replacement lamps may only be fitted by
a Miele authorised technician or by Miele Professional Service.

Warning and Safety instructions
11
 Information on the heat pump and refrigerant
– This tumble dryer uses refrigerant gas which is not flammable and
not explosive.
– The humming noises caused by the heat pump during the drying
process are normal. They do not impair the correct functioning of
the dryer.
Damage to the tumble dryer by switching it on too soon.
This can damage the heat pump.
After setting up the tumble dryer, wait for at least one hour before
switching it on.
– This tumble dryer contains fluorinated greenhouse gases. They
are hermetically sealed.
Designation of refrigerant: R134a
Amount of refrigerant: 0.61 kg
Global warming potential of refrigerant: 1430 kg CO2 e
Global warming potential of appliance: 872 kg CO2 e

Warning and Safety instructions
12
Correct use
Warning: Risk of fire / Flammable materials.
To avoid the possible danger of fire, please read these warnings
carefully.
A clogged filter is a fire hazard!
The fluff filter must be cleaned after every programme.
 The maximum load is 7kg (dry laundry). See the “Programme
chart” for the maximum recommended loads for individual
programmes.
 Do not lean on the door. Otherwise, the tumble dryer may tip over,
causing injury to yourself or others.
 Always close the door after use. This way you will avoid the
danger of
– children climbing into the tumble dryer or hiding things in it.
– pets or other small animals climbing into the tumble dryer.
 Do not use a pressure washer or high-pressure hose to clean the
tumble dryer.
 Keep the room where the tumble dryer is located free from dust
and fluff. Fluff must not be allowed to accumulate around the dryer.
If the air that is taken into the machine contains dirt particles, they
can cause blockages. This can lead to faults and create a fire
hazard.

Warning and Safety instructions
13
 The tumble dryer must not be used
– without the fluff filters and the filter in the plinth in place.
– without the bottom right grille fitted.
– if the fluff filters or the filter in the plinth are damaged in any way.
In case of damage, fluff filters and plinth filter must be replaced
immediately.
A damaged filter would cause an excessive build-up of fluff which in
turn would cause a fault.
 To ensure problem-free operation of the dryer:
– Remove the fluff from the filter surfaces and the fluff filters after
every drying cycle.
– In addition, the fluff filters, filter surfaces, the grille at the bottom
right and the air passages must be cleaned when prompted by
the display.
 Do not install the tumble dryer in a room where there is a risk of
frost. At temperatures around freezing point, the tumble dryer may
not be able to operate properly. There is a risk of damage if the
condensed water is allowed to freeze in the pump and drain hose.
The permitted room temperature is between 2°C and 35°C.
 If the water is drained externally, make sure the drain hose is
secured against slipping, e.g. if you hang it in a laundry tub or
laundry trough.
Otherwise the hose may slip off and the condensation water flowing
out may cause damage.
 Condensed water is not drinking water.
It can cause health problems in both people and animals if
consumed.

Warning and Safety instructions
14
 To prevent the risk of fire, the following textiles must not be dried
in the tumble dryer:
– Items which have not been washed.
– Items, such as workwear, which have not been thoroughly
cleaned and are still soiled with grease, oil or other deposits (such
as cooking oils, cosmetics, lotions, etc.). If items have not been
thoroughly cleaned, there is a danger that they might ignite when
heated, even after they have been removed from the tumble dryer
at the end of the programme.
– Items (e.g. mops and floor cloths) that have been treated with
inflammable cleaning agents or which contain residues of
acetone, alcohol, benzene, petrol, kerosene, stain remover,
turpentine, wax and wax remover or other chemicals.
– Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing such heavily soiled items ensure that you use a
larger quantity of detergent and select a high temperature. If in
doubt, wash the items several times.
 Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer.
The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat.
If the heat cannot escape, the items can become hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent
heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics contaminated with vegetable or
cooking oil, or hair care products, be placed in a tumble dryer, they
should first be washed in hot water with extra detergent - this will
reduce, but not eliminate, the hazard.
 Remove all items from pockets (e.g. lighters, matches).

Warning and Safety instructions
15
 WARNING: Never switch the tumble dryer off before the end of
the drying programme unless all items are removed immediately and
spread out to cool down.
 Fire hazard!
This tumble dryer must not be connected to a controllable socket
(e.g. a timer or a peak-load switch-off device).
The tumble dryer may only be operated with a peak-load device if
this is connected to the tumble dryer via the Miele XCI box and the
relevant settings have been configured on the tumble dryer.
There is a risk of the laundry self-igniting if the drying programme is
cancelled before the cooling phase has finished.
 To prevent the risk of fire, the following textiles must never be
dried in the tumble dryer:
– Items which have been cleaned using industrial chemicals (e.g.
professional dry-cleaning agents).
– Fabrics which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– Fabrics which contain padding or fillings which are damaged (e.g.
pillows, jackets). The filling could fall out and cause a fire.
 The programme finishes when the cooling phase has been
completed. Many programmes are followed by a cooling phase to
ensure that the items are not too hot to handle when you remove
them (this also reduces the risk of the laundry self-igniting).
Make sure that you do not remove the laundry until the programme
has finished.

Warning and Safety instructions
16
 Fabric softener and similar products must be used according to
the instructions on the manufacturer's packaging.
 Do not store or use petrol, kerosene, paraffin or other flammable
substances near the dryer. Risk of fire and explosion!
 Do not expose the dryer to air which contains chlorine, fluorine or
other solvent vapours. This contaminated air can cause a fire.
 For appliance parts made from stainless steel:
Avoid contact between stainless steel surfaces and liquid detergents
or disinfecting agents containing chlorine or sodium hypochlorite.
These agents can cause corrosion on stainless steel.
Aggressive chlorine bleach vapours can also be corrosive.
Do not store open containers of these agents near the appliance.

Warning and Safety instructions
17
Using a fragrance flacon (optional accessory)
 Only ever use original Miele fragrance flacons.
 The fragrance flacon must be stored in its packaging so please
make sure you retain this.
 Make sure that you always keep the fragrance flacon, or the fluff
filter with the flacon inserted in it, in a horizontal position when
carrying it, and do not tip or place it down on any surface. The
fragrance can leak.
 Use an absorbent cloth immediately to wipe up any fragrance
which has run out of the flacon onto the floor, the dryer or any dryer
components (e.g. the fluff filter).
 If fragrance which has run out of a flacon should come in contact
with the skin - wash the skin thoroughly with soap and water; come
in contact with the eyes - rinse the eyes with clean water for at least
15minutes; be swallowed - rinse out the mouth thoroughly with
clean water. Seek medical advice in the case of contact with the
eyes or if fragrance has been swallowed.
 If fragrance which has run out of a flacon comes in contact with
clothing, change the clothing immediately. Wash the clothing or any
cloths used for mopping up fragrance thoroughly with plenty of
water and detergent.
 There is the risk of fire or damage to the tumble dryer if the
following instructions are not observed:
– Never refill a flacon with fragrance.
– Never use a faulty fragrance flacon.
 Dispose of an empty fragrance flacon with the household waste
and never use it for any other purpose.
 Please also observe the information supplied with the fragrance
flacon.

Warning and Safety instructions
18
Accessories
 Only use genuine Miele spare parts and accessories with this
machine.
If spare parts or accessories from other manufacturers are used, any
warranty, performance and product liability claims will be invalidated.
 Miele tumble dryers and Miele washing machines can be installed
as a washer-dryer stack. This requires a Miele washer-dryer stacking
kit which can be purchased separately. Please ensure that the
washer-dryer stacking kit is suitable for your Miele tumble dryer and
your Miele washing machine.
 If you order a plinth for this tumble dryer (available from Miele as
an optional accessory), make sure it is the correct one.
Miele cannot be held liable for damage caused by non-
compliance with these Warning and Safety instructions.

Operating the tumble dryer
19
Control panel
a language sensor
For selecting the current user
language in the display.
After switching the appliance off and
back on, the supervisor language is
displayed again.
bTouch display with sensors
Displays the selected programme.
The programme settings are selected
using the sensors in the touch
display.
c sensor
Takes you back one level in the
menu.
dStart/Stop sensor
For starting the selected programme
and cancelling a programme that has
already started.
eOptical interface
For service technicians.
fProgramme selector
For selecting the drying programmes.
The programme selector can be
turned clockwise or anti-clockwise.
g button
For switching the tumble dryer on
and off.
The tumble dryer switches off
automatically to save energy. This
occurs 15 minutes after the end of
the programme/Anti-crease phase, or
after being switched on if no further
selection is made.

Operating the tumble dryer
20
Symbols on the control panel
Special programmes


Express
Normal




Minimum iron
Normal plus
Normal
Hand iron
Woollens


Timed drying programme
Warm air





Cottons
Normal plus
Normal
Hand iron
Machine iron
PRO

Cottons PRO
Normal


Cottons Eco
Normal
