NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010707
Product and Cut-out Dimensions
K1911Vi / K1901Vi
36"
25" min.
35 3/4"
83 1/2" - 85 3/8"
9 1/2"
24"
2" - 8 3/8"
4 1/8"
84"
1 1/4"
E
UNIT ACCEPTS
A CUSTOM
FRONT PANEL
6 5/8" - 8 1/2"
Notes
5 foot - 120 Volt - 15 Amp 3-wire molded plug power
supply connects lower left rear.
Standard NEMA 5-15 Outlet - locate less than 9" above
finished floor
E -
O -
• All Installations must be done in accordance with local codes
Location Codes
O

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010707
Front Panel Information
Fully Integrated Model
Width: 35 3/4" in all cases
Thickness: Minumum 3/4" outside frame
Height: Determined using the following calculation:
Panel Height = HOC - TKH
HOC = Total height of cabinet or side panel
TKH = Toe-kick height
Note: Panel may extend above unit.
This is not considered in height calculation
Maximum panel weight: 200 Pounds
Miele
Fully Integrated
Refrigerator
TKH
HOC
Panel Height
Custom Panel Installations
These units do not come equipped with a front panel. They are designed to accept a custom door panel supplied by
the cabinet maker. Miele has a unique panel integration system which allows the panels to align with the surrounding
cabinets.
Panel size is determined in the following manner:
Panel Notes
If the adjoining cabinets are taller than the height of machine (HOM) - the front panel may be extended accordingly.
Simply maintain the toekick height and extend the panel the needed distance.
Adjoining cabinet
Machine
Extended Panel

NOTE: Drawing is not to scale.
SPECIFICATION SHEETS 010707
Front Panel Information
Hinging Details
0-1/8"
Front Panel
1" 1-1/4" 1-1/2"
0-3/4"
0-3/4" 1-1/4" 1-1/2" 1-3/4"
2"
1"
Cabinet Front
0-3/4"
1"
1-1/4"
1-1/2"
0-1/8"
FrontPanel
0-3/4" 1-1/4" 1-1/2" 1-3/4"
1"
Cabinet Front
90° Door 115° Door
Thickness options Thickness options
Door Swing
NOTE: Additional space needed depending on
thickness of front panels and handle used
38 11/16"
7/16"
Door Swing
16 7/8"
MAX
NOTE: Additional space needed depending on
thickness of front panels and handle used
