HL 91
ICAT024-007 002 31
HL 91 LEVEL INDICATORS
lAnodized aluminum external protection
lHigh resistance against impacts
lApplicability to pressurized tanks up to 14.5 psi (1 bar)
MATERIALS
External protection Anodized aluminum
Terminals Reinforced nylon
Central body See-thru polyamide
Reading tag Polyamide
Fixing screws Zinc-plated steel
Nuts Zinc-plated steel
Seals Buna - Viton
FLUIDS COMPATIBILITY
In accordance with ISO 2943 (Norm ISO 6743/4)
Mineral oils HH - HL - HM - HR - HV - HG
Wateremulsions HFAE-HFAS
Synthetic fluids HS - HFDR - HFDU - HFDS
PRESSURE
Maximum working pressure 14.5 psi (1 bar)
WORKING TEMPERATURE
-22 ¸195 °F (-30 ¸90 °C)
THERMOMETER RANGE
HL 91-10 32 ¸176 °F (0 ¸80 °C)
HL 91-20 32 ¸212 °F (0 ¸100 °C)
HL 91-30 32 ¸212 °F (0 ¸100 °C)
01/09.2011
HL 91 level indicators are directly connected to the reservoir to check the level and temperature of the hydraulic fluid.
There are 3 different dimensions available with difference between centers of 3 in (76 mm), 5 in (127 mm) and 10 in
(254 mm) and are equipped with M10 or M12 fixing screws.
Versions with a thermometer are also available.
The external protection is made of anodized aluminum to provide strong impact resistance, while the central body is
made of see-thru polyamide.
TECHNICAL DATA

HL 91
32 002 ICAT024-007
01/09.2011
DIMENSIONS
Indicator type Weight A B C D E F G
Kg(lbs) mm(in) mm(in) mm(in) mm(in) Metric mm(in) mm(in)
HL 91-10 0,15
(0.33)
106
(4.1732)
17,5
(0.6890)
41
(1.6142)
76
(3.0000)
M10 76
(3.0000)
11 (0.4330)
M12 13 (0.5118)
HL 91-20 0,19
(0.42)
157
(6.1811)
20,5
(0.8071)
86
(3.3858)
127
(5.0000)
M10 124
(5.0000)
11 (0.4330)
M12 13 (0.5118)
HL 91-30 0,23
(0.51)
284
(11.1811)
20,5
(0.8071)
213
(8.3858)
254
(10.0000)
M10 254
(10.0000)
11 (0.4330)
M12 13 (0.5118)
ASSEMBLY INSTRUCTIONS
The connection of the HL 91 level indicators is done through the built-in-screws. After they pass the tank's drilled wall
they have to be mounted using the supplied nuts to a torque of 88.5 lbf in (10 Nm).
Before connecting make sure there are no burrs in the screws mounting seats.
RESERVOIR HOLES
NOTE
To avoid accidental impacts that
might break the level indicator and
cause oil leaks, we suggest to
arrange additional protection of the
tank.
SCREWNUT
TANK'S WALL

HL 91
ICAT024-007 002 33
01/09.2011
HOW TO ORDER AN HL 91 LEVEL INDICATOR
1234
HL 91 - 10 - T1 - T - B
1Indicator type CODE
3 in (76 mm) wheelbase HL 91-10
5 in (127 mm) wheelbase HL 91-20
10 in (254 mm) wheelbase HL 91-30
2Fixing screws CODE
M10 T1
M12 T2
3Thermometer CODE
Without N
With thermometer T
4Seals CODE
Buna B
Viton V
Standard
On request

HB 02
34 002 ICAT024-008
HB 02 LEVEL INDICATOR
lAluminum body
lMaximum working pressure 145 psi (10 bar)
lHigh resistance to weather conditions
MATERIALS
Body Aluminum
Tag Polyamide
Contrast screen Painted aluminum
FLUIDS COMPATIBILITY
According to ISO 2943 (Norm ISO 6743/4)
Mineral oils HH - HL - HM - HR - HV - HG
Wateremulsions HFAE-HFAS
Synthetic fluids HS - HFDR - HFDU - HFDS
PRESSURE
Maximum working pressure 145 psi (10 bar)
WORKING TEMPERATURE
-22 ¸195 °F (-30 ¸90 °C)
HB 02 level indicators are directly connected to the reservoir to check the level of the hydraulic fluid.
The body is made of aluminum and provides a see-thru tag made of polyamide resin.
They are available with GAS threads from G1/4" to G1"1/4 and are supplied with the necessary bonded seal washer.
TECHNICAL DATA
01/09.2011

HB 02
ICAT024-008 002 35
DIMENSIONS
Indicator type Weight A B C D E Tightening
torque
Kg(lbs) GAS-BSPP mm(in) mm(in) mm(in) mm(in) Nm(lbf in)
HB 02-GB 0,006
(0.013) G1/4 6
(0.2362)
11
(0.4331)
18
(0.7087)
11
(0.4331)
15
(133)
HB 02-GC 0,010
(0.022) G3/8 7,5
(0.2953)
11,5
(0.4528)
22
(0.8661)
13
(0.5118)
15
(133)
HB 02-GD 0,013
(0.029) G1/2 7,5
(0.2953)
11,5
(0.4528)
27
(1.0630)
16
(0.6299)
20
(177)
HB 02-GE 0,020
(0.044) G3/4 10,5
(0.4134)
10,5
(0.4134)
32
(1.2598)
20
(0.7874)
30
(265)
HB 02-GF 0,032
(0.070) G1 9,5
(0.3740)
12,5
(0.4921)
40
(1.5748)
26
(1.0236)
50
(442)
HB 02-GG 0,054
(0.119) G11/4 10,5
(0.4134)
15,5
(0.6102)
50
(1.9685)
34
(1.3386)
60
(531)
ASSEMBLY INSTRUCTIONS
HB 02 level indicators get connected to the tank by screwing them to a seat with an orthogonal surface.
Before connecting make sure there are no burrs in the mounting threaded seats.
Use the tightening torques suggested by the table above.
01/09.2011
NOTE
To avoid accidental impacts that
might break the level indicator
and cause oil leaks, we suggest
to arrange additional
protection of the tank.

HB 02
36 002 ICAT024-008
HOW TO ORDER AN HB 02 LEVEL INDICATOR
1Level indicator type CODE
See table on page 5 HB 02
2Connection thread CODE
G 1/4 GB
G 3/8 GC
G 1/2 GD
G 3/4 GE
G1 GF
G 1 1/4 GG
Standard
On request
01/09.2011
12
HB 02 - GF
