Miles Industries Madrona MF28EN Manual

©2006, Miles Industries Ltd.
Madrona Free Standing Direct-Vent
Top or Rear Vent Stove
MF28EN (NG) / MF28EP (LPG)
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: If the information in these
instructions is not followed exactly, a re
or explosion may result causing property
damage, personal injury or loss of life.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor’s phone. Follow the gas
supplier’s instructions.
• If you cannot reach your gas supplier, call
the re department.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certied kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and nal
gas connection must be performed by a
licensed plumber or gas tter in the State of
Massachusetts. Also, see Carbon Monoxide
Detector requirements under “Safety and
Warning Information” on page 5.
Manufactured by
MILES INDUSTRIES LTD.
British Columbia, Canada
www.milesreplaces.com
Engine to be installed ONLY with the cast stove body
MFCS01 or MFCS02
Installation & Operating
Instructions
Do not store or use gasoline or other
ammable vapors and liquids in the vicinity
of this or any other appliance.
Installation and service must be performed
by a qualied installer, service agency or the
gas supplier.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
PLEASE READ THIS MANUAL BEFORE
INSTALLING AND OPERATING THIS
APPLIANCE.
4000973/07

2
Thank You ...
For purchasing the Madrona by Miles Industries. Your new radiant gas heater is a
technical appliance that must be installed by a qualied dealer. Each Madrona is fully
tested during the production process for your safety and comfort.
Your unit has been professionally installed by:
Dealer Name _______________________________________
Phone Number ______________________________________
Should you encounter an operational problem, call your dealer immediately.
Do not try to repair the unit as you may cause an injury or damage the replace.

3
CONTENTS
Table of Contents
Safety & Warning Information......................................................4
Specications................................................................................7
Approval & Codes — Ratings — High Altitude
Installations— Supply Gas — Electrical
Dimensions & Clearances............................................................8
Dimensions — Hearth Requirements — Clearances
Venting..........................................................................................10
Top / Rear Outlet — Vent Material — Wall Thickness —
Framing Vent in Combustible Walls & Ceilings — Typical
Venting Components — How to Read the Venting Chart
— Venting Chart — Restrictors — Vent Termination
Installation...................................................................................15
Fan (Blower) — Venting Conguration — Gas Line Routing
Packs Contents—Appliance & Castings.................................. 15
Appliance Preparation................................................................16
Window & Log Pack — Cast Base — Engine —Cast Side
Panels — Fixing Casting Side Panels & Engine — Lighting
Instructions Plate — Remote Control Receiver — Gas Pipe
& Connector — Receiver Position — Optional Fan (Blower)
— Venting Outlet — Top Spar — Front Hooks — Rear Log
Support
Supply Gas..................................................................................21
Ceramic Logs.............................................................................. 22
Window Retting.........................................................................23
Operation Check & Aeration Settings Adjustment..................
23
Aeration Settings — Air Shutter
Front & Top Installation.............................................................. 24
Remote Control Handset Wall Holder........................................25
Owner’s Information...................................................................
26
Operating Your Stove — Cleaning — Checks —
Batteries — Touch-up Paint — Servicing — Remote
Control Operation — Manual ON/OFF Switch
Lighting Instructions..................................................................31
Wiring Diagram...........................................................................32
Options........................................................................................33
Venting accessories...................................................................34
Warranty......................................................................................
37
Replacement Parts.....................................................................
38

4
Safety & Warning Information
Children and adults should be ALERTED to the
hazards of high surface temperature and should
STAY AWAY to avoid burns or clothing ignition. Young
children should be CAREFULLY SUPERVISED when
they are in the same room as the appliance.
DO NOT place furniture or any other combustible
household objects within 36” of the replace front.
READ and UNDERSTAND all instructions carefully
before starting the installation. FAILURE TO FOLLOW
these installation instructions may result in possible re
hazard and will void the warranty.
Prior to the rst ring of the replace, READ the
Owner’s Information section of this manual.
DO NOT USE this appliance if any part has been under
water. Immediately, CALL a qualied service technician
to inspect the unit and to replace any part of the control
system and any gas control that has been under water.
THIS UNIT IS NOT FOR USE WITH SOLID FUEL.
Installation and repair should be PERFORMED by a
qualied service person. The appliance and venting
system should be INSPECTED before initial use and at
least annually by a professional service person. More
frequent cleaning may be required due to excessive
lint from carpeting, bedding, etc. It is IMPERATIVE that
the unit’s control compartment, burner, and circulating
air passageways BE KEPT CLEAN to provide for
adequate combustion and ventilation air.
Always KEEP the appliance clear and free from
combustible materials, gasoline, and other ammable
vapors and liquids.
NEVER OBSTRUCT the ow of combustion and
ventilation air. Keep the front of the appliance CLEAR
of all obstacles and materials for servicing and proper
operation.
Due to the high temperature, the appliance should
be LOCATED out of trafc areas and away from
furniture and draperies. Clothing or ammable material
SHOULD NOT BE PLACED on or near the appliance.
This unit MUST be used with a vent system as
described in this installation manual. NO OTHER vent
system or components MAY BE USED.
This gas replace and vent assembly MUST be vented
directly to the outside and MUST NEVER be attached
to a chimney serving a separate solid fuel burning
appliance. Each gas appliance MUST USE a separate
vent system. Common vent systems are PROHIBITED.
INSPECT the external vent cap on a regular basis to
make sure that no debris, plants, trees, shrubs are
interfering with the air ow.
The glass door assembly MUST be in place and sealed
before the unit can be placed into safe operation.
DO NOT OPERATE this appliance with the glass door
removed, cracked, or broken. Replacement of the glass
door should be performed by a licensed or qualied
service person. DO NOT strike or slam the glass door.
The glass door assembly SHALL ONLY be replaced
as a complete unit, as supplied by the replace
manufacturer. NO SUBSTITUTE material may be used.
DO NOT USE abrasive cleaners on the glass door
assembly. DO NOT ATTEMPT to clean the glass door
when it is hot.
TURN OFF the gas before servicing this appliance.
It is recommended that a qualied service technician
perform an appliance check-up at the beginning of
each heating season.
Any safety screen or guard removed for servicing
MUST BE REPLACED before operating this appliance.
SAFETY INFORMATION
BE CAREFUL not to put any decorating objects
sensitive to heat on the stove or too close to the stove
as it gets very hot when operating.
DO NOT use this heater as a temporary source of heat
during construction.
NOTE: When operating your new replace for the rst time, some vapors may be released due to the burning
of curing compounds used in the manufacture of the appliance. They may cause a slight odor and could cause
the ames to be the full height of the rebox, or even slightly higher, for the rst few hours of operation. It is also
possible that these vapors could set off any smoke detection alarms in the immediate vicinity. These vapors are
quite normal on new appliances. We recommend opening a window to vent the room. After a few hours’ use, the
vapors will have disappeared and the ames will be at their normal height.

5
State of California. Proposition 65 Warning. Fuels used in gas, wood-burning or oil red
appliances, and the products of combustion of such fuels, contain chemicals known to the
State of California to cause cancer, birth defects and other reproductive harm. California
Health & Safety Code Sec. 25249.6.
Safety & Warning Information
State of Massachusetts Carbon Monoxide Detector/Vent Terminal Signage
Requirements
For all side wall horizontally vented gas fueled equipment installed in every dwelling,
building or structure used in whole or in part for residential purposes, including those owned
or operated by the Commonwealth and where the side wall exhaust vent termination is less
than seven (7) feet above nished grade in the area of the venting, including but not limited
to decks and porches, the following requirements shall be satised:
1. INSTALLATION OF CARBON MONOXIDE DETECTORS. At the time of installation of
the side wall horizontal vented gas fueled equipment, the installing plumber or gastter
shall observe that a hard wired carbon monoxide detector with an alarm and battery back-
up is installed on the oor level where the gas equipment is to be installed. In addition, the
installing plumber or gastter shall observe that a battery operated or hard wired carbon
monoxide detector with an alarm is installed on each additional level of the dwelling,
building or structure served by the side wall horizontal vented gas fueled equipment. It
shall be the responsibility of the property owner to secure the services of qualied licensed
professionals for the installation of hard wired carbon monoxide detectors.
a. In the event that the side wall horizontally vented gas fueled equipment is installed in a
crawl space or an attic, the hard wired carbon monoxide detector with alarm and battery
back-up may be installed on the next adjacent oor level.
b. In the event that the requirements of this subdivision can not be met at the time of
completion of installation, the owner shall have a period of thirty (30) days to comply with
the above requirements; provided, however, that during said thirty (30) day period, a battery
operated carbon monoxide detector with an alarm shall be installed.
2. APPROVED CARBON MONOXIDE DETECTORS. Each carbon monoxide detector as
required in accordance with the above provisions shall comply with NFPA 720 and be ANSI/
UL 2034 listed and IAS certied.
3. SIGNAGE. A metal or plastic identication plate shall be permanently mounted to the
exterior of the building at a minimum height of eight (8) feet above grade directly in line
with the exhaust vent terminal for the horizontally vented gas fueled heating appliance or
equipment. The sign shall read, in print size no less than one-half (1/2) inch in size, “GAS
VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OBSTRUCTIONS”.
4. INSPECTION. The state or local gas inspector of the side wall horizontally vented gas
fueled equipment shall not approve the installation unless, upon inspection, the inspector
observes carbon monoxide detectors and signage installed in accordance with the
provisions of 248 CMR 5.08(2)(a)1 through 4.
SAFETY INFORMATION
Massachusetts
California

6
Safety & Warning Information
(b) EXEMPTIONS: The following equipment is exempt from 248 CMR 5.08(2)(a)1
through 4:
1. The equipment listed in Chapter 10 entitled “Equipment Not Required To Be Vented”
in the most current edition of NFPA 54 as adopted by the Board; and
2. Product Approved side wall horizontally vented gas fueled equipment installed in a
room or structure separate from the dwelling, building or structure used in whole or in
part for residential purposes.
(c) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM
PROVIDED. When the manufacturer of Product Approved side wall horizontally vented
gas equipment provides a venting system design or venting system components with
the equipment, the instructions provided by the manufacturer for installation of the
equipment and the venting system shall include:
1. Detailed instructions for the installation of the venting system design or the venting
system components; and
2. A complete parts list for the venting system design or venting system.
(d) MANUFACTURER REQUIREMENTS - GAS EQUIPMENT VENTING SYSTEM
NOT PROVIDED. When the manufacturer of a Product Approved side wall horizontally
vented gas fueled equipment does not provide the parts for venting the ue gases, but
identies “special venting systems”, the following requirements shall be satised by the
manufacturer:
1. The referenced “special venting system” instructions shall be included with the
appliance or equipment installation instructions; and
2. The “special venting systems” shall be Product Approved by the Board, and the
instructions for that system shall include a parts list and detailed installation instructions.
(e) A copy of all installation instructions for all Product Approved side wall horizontally
vented gas fueled equipment, all venting instructions, all parts lists for venting
instructions, and/or all venting design instructions shall remain with the appliance or
equipment at the completion of the installation.
State of Massachusetts Carbon Monoxide Detector/Vent Terminal Signage
Requirements - Cont.
SAFETY INFORMATION
Massachusetts

7
Specications
This appliance is certied to ANSI Z21.88b-2003/CSA 2.33b-2003 Vented Gas Fireplace
Heater standard for use in Canada and USA, and to CGA 2.17-91 High Altitude Standard in
Canada. This appliance is for direct vent installations.
Conversion between fuels may only be done using the approved conversion kits listed on
page 33. This appliance complies with CGA P.4.1 Testing method for measuring annual
replace efciencies.
The installation must conform to local codes or, in the absence of local codes, with the
National Fuel Gas Code, ANSI Z223.1 or the Natural Gas and Propane Installation Code
CAN/CGA-B149. Only qualied licensed or trained personnel should install this appliance.
This appliance, when installed with the optional circulating fan kit (blower), must be
electrically grounded in accordance with local codes, or, in the absence of local codes, with
the National Electrical Code, ANSI/NFPA 70 or the Canadian Electrical Code, CSA C22.1.
Ratings
Model (Field convertible Top or Rear Vent Outlet) MF28EN MF28EP
Gas Natural Propane
Altitude (Ft)* 0-4,500 feet*
Input Maximum (Btu/h) 28,000 28,000
Input Minimum (Btu/h) 12,000 14,500
Manifold Pressure (in w.c.) 3.75 10.2
Minimum Supply Pressure (in w.c.) 5.0 11.0
Maximum Supply Pressure (in w.c.) 11.0 14.0
Main Burner Injector Marking 82-750 92-300
Pilot Injector Marking 51 30
Input ratings are shown in BTU per hour and are certied without deration for elevations up
to 4,500 feet (1,370 m) above sea level.
For elevations above 4,500 feet (1,370 m) in USA, installations must be in accordance with
the current ANSI Z223.1 and/or local codes having jurisdiction. Heating value of gas in some
areas is reduced to compensate for elevation—consult your local gas utility to conrm.
For installations at elevations above 4,500 feet (1,370 m) in Canada, please consult
provincial and/or local authorities having jurisdiction.
Heater engine MF28EN is used with natural gas.
Heater engine MF28EP is used with propane gas.
The supply pressure must be between the limits shown in the Ratings section above.
The supply connection is 3/8” NPT female.
The Madrona stove does not require an electrical power source unless it is tted with an
optional circulating fan—see page 19.
SPECIFICATIONS
*High
Altitude
Installations
Supply Gas
Electrical
Approval &
Codes
3/8” N.P.T.
Female
3/8” N.P.T.
5/16” O.D.
tubing
5/16”
are

Gas
inlet
position
3/8”
fem.
NPT
x
Gas
inlet
position
3/8”
fem.
NPT
x
Supplied
with top
vent; eld
convertible
to rear vent
8
Dimensions & Clearances
DIMENSIONS
Inlet collar
Ø 6-5/8” Exhaust
collar Ø 4”
17-7/8”
28-1/2”
23”
8-1/2”
27-1/2” 14”
31-1/2”
26-1/8”
Center
line
Hearth
Requirements
This unit is approved for mounting directly on combustible wood ooring. If installed directly
on carpeting, vinyl or soft combustible oor other than wood, it must be installed on a metal
or wood panel covering a minimum surface of 15” deep by 28” width.
4”
Dimensions

9
Dimensions & Clearances
Corner clearances Wall clearances
Mantel / shelf clearances
Maximum 26” from wall for
projection of combustible
shelf or mantel
Minimum 12” between
stove and combustible
shelf or mantel
Keep a minimum of
36” space in front
of stove free of
furniture or objects
Min. 36”
31-1/2”
17-7/8”
5” between
combustible wall
and back of stove
Min. 5”
between
combustible
wall and
stove
Min. 5” between
combustible wall
and stove
Min. 6” between
combustible wall
and side of stove
Min. 5”
between
combustible
wall and rear
of stove
17-7/8”
28-1/2”
CLEARANCES
Clearances
5”
40-1/2” minimum
43-1/2” minimum
26” maximum
Alcove clearances

10
Venting
Top / Rear
Outlet
Vent Material
This unit is shipped with a top outlet collar which is eld-convertible to rear outlet—see page 20
for details.
This unit is approved for installation using 4” x 6-5/8” co-axial direct vent pipe and accessories
manufactured by Simpson Dura-Vent, Security and Selkirk—see list of approved venting pipes
and accessories on pages 33–36.
This unit may also be converted to co-linear (2–3”) venting for use in solid-fuel burning replaces
and chimneys using adapters and accessories—see list of approved venting pipes and
accessories on pages 33–36. Instructions for co-linear conversion are packaged with the co-linear
adapter.
Do not mix components from different vent manufacturers, with the exception of Valor’s 551DVK
Horizontal Termination Kit which can be used in combination with approved manufacturers’
venting pipes listed on pages 35–36. Follow the installation instructions supplied with the
individual venting components.
Framing Vent
in
Combustible
Walls &
Ceilings
When penetrating through combustible walls and ceilings, frame a minimum of 10” x 10” opening
to ensure that the insulation is kept clear of the vent pipe. Also, seal all joints between the wall
plates, the wall and the vent pipe. Follow the installation instructions supplied with the individual
venting components.
10” (254mm)
10” (254mm)
The appliance vent is suitable for penetrating a combustible wall assembly up to 14” (36 cm) in
thickness. A non-combustible wall can be of any thickness up to the maximum horizontal run of
vent pipe allowed for the particular installation.
Wall
Thickness
Align the vent
center to the
center of the
frame
VENTING

11
VENTING
Snorkel required (min.
14” high) with horizontal
run through the wall
(no rise)
Venting
Through wall (without vertical rise)
Typical
Venting
Components
See list of approved venting pipes and accessories on pages 33–36.
Through wall (with vertical rise) Through roof
Maximum pipe length:
24” (straight out with snorkel)
14” (45° elbow out with snorkel)
No more than one 45°
elbow allowed

5 x 90º ELBOWS
MAXIMUM
Restrictor 75
NO
RESTRICTORS
Example 1
NO INSTALLATION
NO
INSTALLATION
V3
Restrictor 50
2 4 6 8 10 12 14 16 18 20
12
Venting
Allowable Vent
Congurations
Example 1
V Value = V1 (6’) + V2 (6’) + V3 (2’)= 14’
H Value = H1 (3’) + H2 (3’) = 6’
75% restrictor required
VERTICAL RISE
HORIZONTAL RUN
Not to scale
Roof termination
Wall termination
How to Read
the Venting
Chart
The total length of the vent pipe cannot exceed 40’ (12.2m).
The minimum vertical height with roof termination is 8’ (2.45 m).
Any combination of rise and run can be used as long as they are within the allowable
limits shown on the chart below.
A maximum of 5 x 90° elbows—or equivalent (2 x 45° = 90°)—can be used.
Each 90° elbow installed on the horizontal plane is equivalent to a 3’ horizontal pipe;
therefore, 3’ must be subtracted from allowable horizontal run. (45° elbow is equivalent
to 18” horizontal pipe.)
All horizontal pipe runs must be graded 1/4” per foot upwards in the direction of the
exhaust ow.
Co-linear venting in existing chimney systems is limited to 40’ vertical rise.
Restrictors are not required for co-linear installations.
1.
2.
3.
4.
5.
6.
7.
8.
5” min.
between
pipe and
combustible
walls
40
38
36
34
32
30
28
26
24
22
20
18
16
14
12
10
8
6
4
2
The chart below applies to top or rear outlet, roof or wall termination with a vertical rise.
All rear outlet venting without a vertical rise must be terminated by a snorkel.
VENTING

13
Venting
Restrictors SOME INSTALLATIONS REQUIRE RESTRICTORS. For improved ame picture and
performance, this unit is supplied with two different sets of vent restrictors. The level of
restriction required depends on the vertical rise in the venting system and, to a lesser
degree, the horizontal run and number of elbows.
The amount of restriction is based on laboratory tests. The ideal restrictor position may
vary slightly, especially when the vent pipe length is near the limits of the acceptable
congurations for each type of restrictors.
The chart on the previous page shows the vent restrictor required relative to the length
of the vent pipe. Restrictors are not required for co-linear applications.
To install restrictors:
Remove every second screw from the exhaust ports in the top of the rebox.
Install the restrictors with the removed screws.
1.
2.
VENTING
50 75
Restrictor 50 Restrictor 75
OR

14
Venting
KEY VENT TERMINAL LOCATIONS - MINIMUM DISTANCES MINIMUM
CLEARANCE
Inches Cm
AClearance above grade, verandah, porch, deck or balcony 12 30
BClearance to window or door that may be opened 12 30
CClearance to permanently closed window (recommended to prevent
condensation on window)
12 30
DVertical clearance to ventilated soft located above the terminal within a
horizontal distance of 2 feet (60 cm) from the center-line of the terminal
18 46
EClearance to unventilated soft 12 30
F Clearance to outside corner 12 30
GClearance to inside corner 6 30
H Horizontal clearance to center-line of meter/regulator assembly located within 15
feet (4.6 m)below the terminal
36 90
IClearance to service regulator vent outlet 36 90
JClearance to non-mechanical air supply inlet to the building or the combustion air
inlet to any other appliance
12 30
KClearance to a mechanical air supply inlet 72 180
LClearance above paved sidewalk or a paved driveway located on public property
Note: A vent must not terminate directly above a sidewalk or paved driveway,
which is located between two single-family dwellings and serves both dwellings
84 210
MClearance under a verandah, porch, deck or balcony
Only permitted if veranda, porch, deck or balcony is fully open on a minimum of 2
sides beneath the oor
12 30
Note: Local codes and regulations may require different clearances.
Horizontal
Vent
Termination
The vent terminal must be located on an outside wall or through the roof.
This direct vent appliance is designed to operate when an undisturbed airow hits the
outside vent terminal from any direction.
The minimum clearances from this terminal that must be maintained when located on
an outside wall are shown in the gure below. Any reduction in these clearances could
result in a disruption of the airow or a safety hazard. Local codes or regulations may
require greater clearances.
The vent terminal must not be recessed into a wall or siding.
The vent terminal should be positioned where it will not be covered by snowdrifts.
Sidewall vent terminations within 7’ of grade require a terminal guard.
•
•
•
•
•
•
VENTING

15
Installation
INSTALLATION
Fan (Blower)
Venting
Conguration
Gas Line
Routing
Consider visibility of shut-off valve or step-down regulators, etc. when planning gas
line routing.
This unit is supplied with a top outlet and is eld convertible to a rear outlet. Plan
routing of vent taking into consideration stove and vent clearances, allowable vent
terminal locations BEFORE cutting a hole in the roof or wall. Avoid penetrating the
wall/roof at structural members.
Allow for and install electrical wiring if there will be a blower to install. Ask the
homeowner if you are not sure.
Vertical
Vent
Termination
Roof
Pitch
Minimum
"H" (feet)
Flat to 7/12 1'
Over 7/12 to
8/12 1.5'
Over 8/12 to
9/12 2’
Over 9/12 to
10/12 2.5’
Over 10/12 to
11/12 3.25’
Over 11/12 to
12/12 4’
Over 12/12 to
14/12 5’
Venting
Packs Contents—Appliance & Castings
The Madrona Stove is supplied in three (3)
cartons.
In one carton is the engine.
In a second carton are the casting sides, the
top and the legs.
In a third carton are the casting front and base.
Unpack the cartons carefully. We strongly
recommend that you leave the engine sitting
on the packaging base in which it came to
avoid damaging the control valve, wires and
pipes already attached to the engine.
Some parts are packed in the cardboard sleeve around the engine;
make sure you take them all out of the packaging. The engine carton
contains a list of all components included in the three cartons. Make
sure you have all the components before you start the installation.
•
•
•
WARNING!
LEAVE ENGINE ON
PACKAGING BASE to
avoid damage to the
control valve, wires
and pipes.

16
Appliance Preparation
Rough-in the gas line and electrical wiring for a fan (if any).
Decide where the stove should be positioned to avoid moving it once all the casting pieces
are attached together.
Place the casting base upside down. Unscrew the bolts to insert the legs.
Slide each leg under the head of its bolt.
Tighten the bolts securely with a wrench.
1.
2.
3.
4.
5.



Appliance’s foot print
Casting Base
Release the spring bolts at top and bottom
of the window by pushing and turning 1/4
turn.
Lift the window and set it aside in a safe
place to avoid damage.
Remove the log pack from inside the rebox
and set it aside with the window. Please
handle the logs carefully as they are made of
fragile material and can easily be damaged.
1.
2.
3.
Window &
Log Pack
x 4
Detail
Fix the casting base to the oor or
hearth using bolts (not supplied)
through the casting feet—see the
bolting pattern below. (Required for
mobile homes only).
6.
PREPARATION

17
PREPARATION
Appliance Preparation
Engine
Detail
Flip the base upside-down. Place the engine on the base at its approximate
nal position—see detail below. Center the engine using the holes at front of
the base as guidelines.
Casting Side
Panels
On the casting side panels, release the top and bottom screws.
Drop a hinge pin on the back corner of base and drop the side panel on the pin.
Rotate the panel towards the engine.
Repeat with the other casting side panel.
1.
2.
3.

18
Appliance Preparation
Fit the pipe and connector supplied with the engine to the valve. Connect the gas line to
the inlet pipe.
3/8” gas line
connection
5/16” are
Gas Pipe &
Connector
Fixing
Casting Side
Panels &
Engine
Adjust the position of the engine to locate the top and bottom screws of the side panels
into the slots of the engine’s side bracket. Tighten the top and bottom screws.
Adjust the engine as required and x it to the casting base at bottom of its side
brackets with the nuts and bolts provided.
1.
2.
Receiver hooked to burner pipes
Lighting
Instructions
Plate
The lighting instructions plate is attached to the back of the engine and may have slid out
of its slot. Reposition the plate if this is the case.
Remote
Control
Receiver
Under the engine, the receiver box is clipped to the burner pipes to facilitate transportation.
Unclip the box and let it hang while you t the gas pipe.
PREPARATION

19
Appliance Preparation
Optional Fan
(Blower)
If the Circulating Fan Kit (blower) is to be installed,
we suggest that you do it now.
Take the fan out of its package.
Remove the mounting plate from the fan and
discard it.
Position the fan in such a way that its exhaust
is directed upwards, towards the space
between the inner and the outer walls of the
rebox.
Using 3 screws, x the fan to the rebox bracket.
Fix the fan control box bracket provided to the
control box with 2 screws.
Fix the bracket, with the control box attached, to
the casting base of the stove from underneath.
With 2 screws from the burner plate, x the fan’s
thermoswitch to the underside of the burner
plate, behind the pilot area.
See instructions with the 555CFK kit for
complete details.
1.
2.
3.
4.
5.
6.
7.
8.
Fan control
box position Fan control
box bracket
Once the gas pipe is tted, clip the receiver on top of the casting crossbar on the base,
to the left hand side of the valve. Make sure the receiver box is oriented with its wires
towards the back and its sensor at the front.
Receiver
Position
Receiver & clip Receiver clipped to crossbar in nal position
PREPARATION

20
Rear Log
Support
Appliance Preparation
Fix the rear support log to the back of the rebox with the metal
screws taken from the back of the rebox (2) and from behind the
burner (2).
Front Hooks Fix the 4 hooks to the inside
of the cast front with eight 8
mm screws provided.
Top Spar Position the top spar on the side brackets located
between the engine and the cast sides.
Fix the spar with four 3/8” pre-assembled screws
provided.
1.
2.
Venting
Outlet
If the appliance is to be vented from the top, it is ready for vent installation once the
engine is on the casting base.
If the appliance is to be vented from the rear, it must be converted. Follow these
simple steps:
1. Remove the following parts in this order:
Dura-Vent collar, gasket and intake plate from the top of the appliance
(22 screws of the intake plate and 2 rear screws of the collar);
Exhaust collar (8 screws).
NOTE: The gaskets are glued to the engine or the intake plate; it is not
necessary to separate them from the parts they are attached to. However,
if they need to be manipulated, BE CAREFUL not to damage them
because their material is fragile.
2. Re-install through the vent opening at the rear of the rebox in the
reverse order in which you took the parts out.
a.
b.
!
PREPARATION
Co-linear
Applications
For conversion of top or rear outlet collars to co-linear (2 x 3”) venting, refer to instructions
packaged with the 556CLA Co-linear Adapter.
NOTE: Co-linear venting may only be installed into solid-fuel burning replaces and chimneys.
