Miller DELTAWELD 302 User manual

OWNER’S
MANUAL
July 1996 Form: OM-223H
Effective With Serial No. KG141349
cover_om 4/95 −ST-800 453 PRINTED IN USA
©1996 MILLER Electric Mfg. Co.
Deltaweld®302, 452, 652 (60 Hz)
Deltaweld®402, 602, 852 (50/60 Hz)
CV/DC Welding Power Sources For GMAW, FCAW, SAW Welding, And CAC-A Cutting And Gouging
Model Rated
Welding Voltage Range Max OCV IP
Rating
Amperes Input at Rated Load Output, 50 or 60 Hz,
Three-Phase
Model
Welding
Output
Range
DC
OCV
DC
R
a
ti
ng 200 V 230 V 380 V 400 V 440 V 460 V 575 V KVA KW
300
Amp
300 A @ 32
(29) Volts
DC, 100%
Duty Cycle
10 −32 38
(43) 21M -- 42 3.2* 27 1.8* 25 1.7* 23 1.6* 21 1.6* 17 1.3* 16.9 1.26* 12.9 0.21*
450
Amp
450 A @ 38
(36.5) Volts
DC, 100%
Duty Cycle
10 −38 48 21M 72
3.2* 63 2.7* 39 2.6* 37 2.2* 33 2.1* 32 1.4* 25 1.1* 25.1 1.09* 21.1 0.26*
650
Amp
650 A @ 44
Volts DC,
100% Duty
Cycle
10 −44 54 21M -- 96
3.2* 58 3.3* 54 3.0* 50 2.8* 48 1.6* 38 1.3* 38.2 1.26* 34.2 0.35*
*While idling
( ) Indicates specification differences for CE models

dec_con1 10/95
Declaration of Conformity For
European Community (CE) Products
This information is provided for units with CE certification (see rating label on unit.)
NOTE
Manufacturer’s Name: Miller Electric Mfg. Co.
Manufacturer’s Address: 1635 W. Spencer Street
Appleton, WI 54914 USA
Declares that the product: Deltaweld®402, 602, And 852
conforms to the following Directives and Standards:
Directives
Electromagnetic compatibility Directives: 89/336/EEC, 92/31/EEC
Low Voltage Directive: 73/23/EEC
Machinery Directives: 89/392/EEC, 91/368/EEC, 93/C 133/04, 93/68/EEC
Standards
Safety Requirements for Arc Welding Equipment part 1: EN 60974-1: 1990
Arc Welding Equipment Part 1: Welding Power Sources: IEC 974-1
(April 1995 −Draft revision)
Degrees of Protection provided by Enclosures (IP code): IEC 529: 1989
Insulation coordination for equipment within low-voltage systems:
Part 1: Principles, requirements and tests: IEC 664-1: 1992
Electromagnetic compatibility (EMC) Product standard for arc welding equipment:
EN50199: August 1995
European Contact: Mr. Luigi Vacchini, Managing Director
MILLER Europe S.P.A.
Via Privata Iseo
20098 San Giuliano
Milanese, Italy
Telephone: [phone]
Fax: [phone]

OM-223 Page 9
SECTION 1 −DEFINITIONS
1-1. Warning Label Definitions
S-176 254-A
1 1.1 1.2 1.3
3 3.1 3.2 3.3
4 4.1
+
22.1 2.2
+
+
5 6
+
2.3
Warning! Watch Out! There are
possible hazards as shown by the
symbols.
1 Electric shock from welding
electrode or wiring can kill.
1.1 Wear dry insulating gloves.
Do not touch electrode with
bare hand. Do not wear wet or
damaged gloves.
1.2 Protect yourself from electric
shock by insulating yourself
from work and ground.
1.3 Disconnect input plug or
power before working on
machine.
2 Breathing welding fumes can
be hazardous to your health.
2.1 Keep your head out of the
fumes.
2.2 Use forced ventilation or local
exhaust to remove the fumes.
2.3 Use ventilating fan to remove
fumes.
3 Welding sparks can cause
explosion or fire.
3.1 Keep flammables away from
welding. Do not weld near
flammables.
3.2 Welding sparks can cause
fires. Have a fire extinguisher
nearby, and have a
watchperson ready to use it.
3.3 Do not weld on drums or any
closed containers.
4 Arc rays can burn eyes and
injure skin.
4.1 Wear hat and safety glasses.
Use ear protection and button
shirt collar. Use welding
helmet with correct shade of
filter. Wear complete body
protection.
5 Become trained and read the
instructions before working on
the machine or welding.
6 Do not remove or paint over
(cover) the label.
1/96

OM-223 Page 10
Warning! Watch Out! There are
possible hazards as shown by the
symbols.
Electric shock from wiring can kill.
Disconnect input plug or power
before working on machine.
Read the Owner’s Manual before
working on this machine.
1 Consult rating label for input
power requirements, and
check power available at the
job site −they must match.
2 Read Owner’s Manual and
inside labels for connection
points and procedures.
3 Move jumper links as shown
on inside label to match
voltage at job site.
4 Having a loop of extra length,
connect grounding conductor
first.
5 Connect line input conductors
as shown on inside label −
double-check all connections,
jumper link positions, and
input voltage before applying
power.
S-179 290
1
4
5
ÍÍÍ
ÍÍÍ
ÍÍÍ
3
ÍÍÍ
ÍÍÍ
2
?V
?A
?V
3
1/96
S-179 563
1 Warning! Watch Out! There
are possible hazards as
shown by the symbols.
2 Electric shock from wiring and
exposed weld terminals can
kill.
3 Close door before turning on
unit.
12 3
1/96
1 Warning! Watch Out! There
are possible hazards as
shown by the symbols.
2 Electric shock from welding
electrode or wiring can kill.
3 Sparks from arcing electrode
can cause explosion or fire −
disconnect cable for process
not in use.
4 Read Owner’s Manual for
connection procedures.
5 Electric shock from wiring can
kill.
6 Disconnect input power
before working on unit or
making terminal strip
connections.
Nameplate D-179 389
1
234 56
1

OM-223 Page 11
1-2. Manufacturer’s Rating Labels For CE Products
S-174 346 / S-174 347 / S-174 348
Match label to one on
unit. See Section 2-1.

OM-223 Page 12
1-3. Symbols And Definitions
Some symbols are found only on CE products.
NOTE
AAmperes Voltage Control/
Panel Gas Metal Arc Welding (GMAW) Temperature
Output Circuit Breaker Remote On
Positive High
Inductance Weld
Output Terminal
Positive Low
Inductance Weld
Output Terminal
Negative Weld
Output Terminal Input
VVolts Off Wire Feed Protective Earth
(Ground)
U0Rated No Load
Voltage (Average) U1Primary Voltage U2Conventional Load Voltage Line Connection
I1Primary Current I2Rated Welding
Current XDuty Cycle Three-Phase
Transformer
Rectifier
IP Degree Of
Protection Alternating Current S1KVA Direct Current
Percent

OM-223 Page 13
SECTION 2 −INSTALLATION
2-1. Selecting A Location
1 Lifting Eye
2 Lifting Forks
Use lifting eye or lifting forks to
move unit.
If using lifting forks, extend forks
beyond opposite side of unit.
3 Rating Label (Non CE Models
Only)
Use rating label to determine input
power needs. Label located under
front access door.
4 Plate Label (CE Models Only)
Label located under front access
door.
5 Rating Label (CE Models
Only)
Use rating label to determine input
power needs. Label located on rear
access door (see Section 1-2).
6 Line Disconnect Device
Locate unit near correct input pow-
er supply.
YSpecial installation may be
required where gasoline or
volatile liquids are present −
see NEC Article 511 or CEC
Section 20.
3
6
18 in
(460 mm)
18 in
(460 mm)
OR
1
2
Movement
Location And Airflow
4
5
2-2. Dimensions And Weights
Dimensions
Di
mens
i
ons
Height 27-1/4 in (692 mm)
C
D
Width 22-1/4 in (565 mm)
DEDepth* 35-3/4 in (908 mm)
4 Holes A** 35 in (889 mm)
B*** 1-1/4 in (32 mm)
C21 in (533 mm)
D1-3/16 in (30 mm)
E7/16 in (11 mm) Dia
A*300 Amp Model = 28-1/4 in (718 mm)
**300 Amp Model = 25-7/8 in (657 mm)
***300 Amp Model = 3/4 in (19 mm)
Weight
300 Amp Net: 323 lb (147 kg)
Ship: 340 lb (154 kg)
B
450 Amp Net: 384 lb (174 kg)
Ship: 401 lb (182 kg)
B
Ref. ST-153 556-A 650 Amp Net: 472 lb (214 kg)
Ship: 489 lb (222 kg)

OM-223 Page 14
2-3. Tipping
YBe careful when placing or
moving unit over uneven
surfaces.
2-4. 115 VAC Receptacle And Circuit Breakers
Ref. ST-800 452-A
YTurn Off power before con-
necting to receptacle.
1 115 V 15 A AC Receptacle
RC9
Power is shared between RC9 and
Remote 14 receptacle RC8 or
terminal strip 1T (see Section 2-8).
2 Circuit Breaker CB1
3 Circuit Breaker CB2
CB1 protects 115 volts ac portion of
RC8, 1T, and RC9 from overload.
CB2 protects 24 volts ac portion of
RC8 and 1T from overload.
Press button to reset breaker.
1
3
2
