Million Dollar Baby Emily II Installation and operating instructions

Emily II Hutch (M4749) Assembly and Operation Manual
Congratulations on purchasing this product. This product will provide many years of service if you adhere to the following guidelines for
assembly, maintenance, and operation. This product is for residential use only. Any institutional use is strictly prohibited.
Please be sure to follow the instructions for proper assembly. Use a Phillips head screwdriver for assembling the product in addition to
the Allen wrench included in the hardware box. Do not use power screwdrivers. All of our products are made from natural woods.
Please understand that natural woods have color variations which are the result of nature and not defects in workmanship.
DO NOT SUBSTITUTE PARTS. ALL MODELS HAVE THE SAME QUANTITY OF PARTS AND HARDWARE. YOUR MODEL MAY
LOOK DIFFERENT FROM THE ONE ILLUSTRATED DUE TO STYLISTIC VARIATIONS.







Tools needed:
(not included)
H. Wood screws X 40
J. Wood dowel X 30
1
K. Cam lock X 11
I. Cam bolt X 1
PARTS
A. Top panel
B. Left side panel
C. Center panel
E. Long shelf X 2
F. Short shelf X 2
G-2. Middle back board
G-4. Right side board
D. Right side panel
G-3. Back bottom board
G-1. Back top board
HARDWARE

STEP 1.
Insert wood dowels (J) to the both ends of long
shelves (E) and short shelves (F) as shown in the
illustration.
STEP 2.
STEP 2A.
2A. Attach cam bolts (I) to the both sides of
Center panel (C).
2B. Attach cam bolts (I) to the left side panel (B),
and then assemble the long shelves (E) using
cam locks (K) as shown in the illustration.
STEP 2B.

STEP 3.
Assemble the short shelves (F) using cam locks
(K) as shown in the illustration.
STEP 4.
Attach Cam Bolts (I) to the right side panel (D)
Assemble the right side panel (D) using cam
locks (K) as shown in the illustration.
STEP 5.
Attach Cam Bolts (I) to the top panel (A).
Insert wood dowels (J) to the end of left side
panel (B), center panel (C) and right side panel
(D).
Assemble the top panel (A) use cam locks (K) as
shown in the illustration.

Step 6. Back panel assembly
Use wood screws (H) to assemble the back panel as shown in the illustration and set it up to the combo.
KEEP THIS MANUAL IN
ASAFE PLACE FOR
FUTURE REFERENCE.

Please refer to the label (sample below). Record the
model/ item number and serial number of your product,
the name of the store where you made the purchase,
the date of purchase and the wood finish in the box to
the lower right.
WE WILL ASK YOU FOR YOUR SERIAL NUMBER
FOR ALL WARRANTY AND REPLACEMENT PART
REQUESTS. KEEP THIS MANUAL INSIDE THE PLASTIC
HOLDER FOR FUTURE REFERENCE.
Please read the Caution and Warning Statements insert
before usin
g
y
our
p
roduct.
